Mount the baby monitor
Adjust the baby unit angle.
Check for reception strength
and camera angle before
drilling the holes.
Drill two holes in the wall
(7/32" drill bit). If you drill
the holes into a stud, insert
the screws into the holes.
Tighten the screws until
only 1/4 inch of the screws
are exposed.
Specifications are subject to change without notice.
Use a pencil to mark two
holes in parallel. Make sure
they are the same distance
apart as the wall mount at
the bottom of the baby unit.
Align the holes on the wall
mount with the screws on
the wall.
Slide the wall mount down
until it locks into place.
© 2014 VTECH TELECOMMUNICATIONS LTD.
All rights reserved. 02/14. VM311_IG_V2.0
Document order number: 96-009904-010-100
Go to www.vtechphones.com
to register your product for
enhanced warranty support
and latest VTech product news.
VM311
VM311-13
VM311-2
VM311-23
VM310
VM310-13
Installation guide
