Page 2: Table Of Contents
3. What‟s the difference between „Common User Account‟ and „Administrator Account‟?..............12 4. How do I know the P-660HW-Tx v3's WAN IP address assigned by the ISP? ....................12 5. What is the micro filter or splitter used for? ........13 6.
Page 3 3. What is the microfilter used for? ............17 4. How do I know the ADSL line is up? ..........17 5. How does the P-660HW-Tx v3 work on a noisy ADSL? ....17 6. Does the VC-based multiplexing perform better than the LLC-based multiplexing? ..................
Page 4 5. What is Frequency-hopping Spread Spectrum Technology – (FHSS)? ................32 Security FAQ ..................33 1. How do I secure the data across the P-660HW-Tx v3 Access Point's radio link? ..............33 2. What is WEP? ..............33 3. What is WPA-PSK? ............34 4.
Page 5 Application Notes ................36 General Application Notes ..............36 1. Internet Access Using P-660HW-Tx v3 under Bridge mode . 36 2. Internet Access Using P-660HW-Tx v3 under Routing mode ..................... 39 3. Setup the P-660HW-Tx v3 as a DHCP Relay...... 41 4.
Page 6: Faq
Note: It is protected by super password, ‘1234’ by factory default. 4. How do I update the firmware and configuration file? You can do this if you access the P-660HW-Tx v3 as Administrator. You can upload the firmware and configuration file to Prestige from Web Condigurator, or using FTP or TFTP client software.
Page 7: How Do I Upgrade/Backup The Zynos Firmware By Using Tftp Client Program Via Lan
In case you forget the system password, you can erase the current configuration and restore factory defaults this way: Use the RESET button on the rear panel of P-660HW-Tx v3 to reset the router. After the router is reset, the LAN IP address will be reset to '192.168.1.1', the common user password will be reset to 'user', the Administrator password will be reset to „1234’.
Page 8: What Is Sua? When Should I Use Sua
Many-to-One and Server. With SUA, 'visible' servers had to be mapped to different ports, since the servers share only one global IP. The P-660HW-Tx v3 now has Full Feature NAT which supports five types of IP/Port mapping: One to One, Many to One, Many to Many Overload, Many to Many No Overload and Server.
Page 9: Is It Possible To Access A Server Running Behind Sua From The Outside Internet? How Can I Do It
11. Is it possible to access a server running behind SUA from the outside Internet? How can I do it? Yes, it is possible because P-660HW-Tx v3 delivers the packet to the local server by looking up to a SUA server table. Therefore, to make a local server accessible to the outside users, the port number and the inside IP address of the server must be configured.
Page 10: How Many Network Users Can The Sua/Nat Support
The Prestige does not limit the number of the users but the number of the sessions. The P-660HW-Tx v3 supports 2048 sessions that you can use the 'ip nat session' command in CLI to see. You can also use „ip nat hashTable wanif0‟...
Page 11: How Can I Protect Against Ip Spoofing Attacks
Note: In ZyNOS, you can not mix different filter groups in the same filter set. 16. How can I protect against IP spoofing attacks? The P-660HW-Tx v3's filter sets provide a means to protect against IP spoofing attacks. The basic scheme is as follows: For the input data filter: ...
Page 12: Product Faq
Moreover, only with Administrator Password, you could manage the P-660HW-Tx v3 via FTP/TFTP or Telnet. 4. How do I know the P-660HW-Tx v3's WAN IP address assigned by the ISP? You can view "My WAN IP <from ISP> : x.x.x.x" shown in Web Configurator „Status->Device Information ->WAN Information‟...
Page 13: What Is The Micro Filter Or Splitter Used For
You can also check your ISP or the information sheet given by the ISP. Please choose PPPoE as the encapsulation type in the P-660HW-Tx v3 if the ISP uses PPPoE. 8. Why does my provider use PPPoE? PPPoE emulates a familiar Dial-Up connection.
Page 14: When Do I Need Ddns Service
IP address we can use the DDNS service. The DDNS server allows to alias a dynamic IP address to a static hostname. Whenever the ISP assigns you a new IP, the P-660HW-Tx v3 sends this IP to the DDNS server for its updates.
Page 15: Why Do We Perform Traffic Shaping In The P-660Hw-Tx V3
All applications have their own natural bit rate. Large data transactions have a fluctuating natural bit rate. The P-660HW-Tx v3 is able to support variable traffic among different virtual connections. Certain traffic may be discarded if the virtual connection experiences congestion.
Page 16: What Is Content Filter
(that you specify) in the URL. You can set a schedule for when the P-660HW-Tx v3 performs content filtering. You can also specify trusted IP Addresses on LAN for which the P-660HW-Tx v3 will not perform content filtering. You can configure the details about it in Web Configurator, Advanced setup, Security ->...
Page 17: Adsl Faq
4. How do I know the ADSL line is up? You can see the DSL LED Green on the P-660HW-Tx v3's front panel is on when the ADSL physical layer is up.
Page 18: Does The Vc-Based Multiplexing Perform Better Than The Llc-Based Multiplexing
Maintenance -> Diagnostic -> DSL Line -> DSL Status: 8. What are the signaling pins of the ADSL connector? The signaling pins on the P-660HW-Tx v3's ADSL connector are pin 3 and pin 4. The middle two pins for a RJ11 cable.
Page 19 The low priority is internet access such as ftp etc … Triple Play is a port-based policy to forward packets from different LAN port to different PVCs, thus you can configure each PVC separately to assign different QoS to different application. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 20: Firewall Faq
2. What makes P-660HW-Tx v3 secure? The P-660HW-Tx v3 is pre-configured to automatically detect and thwart Denial of Service (DoS) attacks such as Ping of Death, SYN Flood, LAND attack, IP Spoofing, etc. It also uses stateful packet inspection to determine if an inbound connection is allowed through the firewall to the private LAN.
Page 21: What Kind Of Firewall Is The P-660Hw-Tx V3
4. The P-660HW-Tx v3's firewall is fast. It uses a hashing function to search the matched session cache instead of going through every individual rule for a packet.
Page 22: What Is Ping Of Death Attack
IP address of the targeted system. This makes it appear as if the host computer sent the packets to itself, making the system unavailable while the target system tries to respond to itself. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 23: What Is Brute-Force Attack
Configuration 1. How do I configure the firewall? You can use the Web Configurator to configure the firewall for P-660HW-Tx v3. By factory default, if you connect your PC to the LAN Interface of P-660HW-Tx v3, you can access Web Configurator via „http://192.168.1.1‟.
Page 24: Why Can't I Configure My P-660Hw-Tx V3 Using Web Configurator/Telnet Over Wan
1. Change the default Administrator password since it is required when setting up the firewall. 2. Limit who can access to your P-660HW-Tx v3‟s Web Configurator or CLI. You can enter the IP address of the secured LAN host in Web Configurator, Advanced Setup, Advanced ->...
Page 25: Why Can't I Upload The Firmware And Configuration File Using Ftp Over Wan
FTP connection from WAN. The WAN-to-LAN ACL summary will look like as shown below. Source IP= FTP host Destination IP= P-660HW-Tx v3's WAN IP All contents copyright © 2008 ZyXEL Communications Corporation.
Page 26: Log And Alert
Log and Alert 1. When does the P-660HW-Tx v3 generate the firewall log? The P-660HW-Tx v3 generates the firewall log immediately when the packet matches a firewall rule. The log for Default Firewall Policy (LAN to WAN, WAN to LAN, WAN to WAN) is generated automatically with factory default setting, but you can change it in Web Configurator.
Page 27: When Does The P-660Hw-Tx V3 Generate The Firewall Alert
5. What is the difference between the log and alert? A log entry is just added to the log inside the P-660HW-Tx v3 and e-mailed together with all other log entries at the scheduled time as configured. An alert is e-mailed immediately after an attacked is detected.
Page 29: Where Can You Find 802.11 Wireless Networks
(interoperate) with any brand of Access Point that is also Wi-Fi certified. 8. What types of devices use the 2.4GHz Band? Various spread spectrum radio communication applications use the 2.4 GHz band. This includes WLAN systems (not necessarily of the type IEEE All contents copyright © 2008 ZyXEL Communications Corporation.
Page 30: Does The 802.11 Interfere With Bluetooth Device
(1) Minimizing the number of walls and ceilings (2) Antenna is positioned for best reception (3) Keep WLAN products away from electrical devices, eg: microwaves, monitors, electric motors,…, etc. (4) Add additional APs if necessary. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 31: What's The Difference Between A Wlan And A Wwan
Yes, it supports up to 32 MAC Address filtering. 17. Does P-660HW-Tx v3 support auto rate adaption? Yes, it means that the AP on P-660HW-Tx v3 will automatically decelerate when devices move beyond the optimal range, or other interference is present.
Page 32: Advanced Faq
This avoids problems with fixed channel narrowband noise and simple jamming. Both transmitter and receiver must have their hopping sequences synchronized to create the effect of a All contents copyright © 2008 ZyXEL Communications Corporation.
Page 33: Security Faq
AP. The ESSID is a 32-character maximum string and is case-sensitive. Security FAQ 1. How do I secure the data across the P-660HW-Tx v3 Access Point's radio link? To secure the date across the P-660HW-Tx v3 Access Point‟s radio link, we could select any one of the security mode: Static 64/128 bit WEP, WPA-PSK, WPA, WPA2-PSK, WPA2.
Page 34: What Is Wpa-Psk
24 bit Initialization Vector, but it uses a 104 bit as secret key. Users need to use the same encryption level in order to make a connection. 7. Can the SSID be encrypted? No, WEP only encrypts the data packets not the 802.11n management All contents copyright © 2008 ZyXEL Communications Corporation.
Page 35: By Turning Off The Broadcast Of Ssid, Can Someone Still Sniff The Ssid
An intruder can masquerade as that user by using this captured information. An intruder who monitors the wireless network can apply this same attack principle on the wireless. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 36: Application Notes
In this case, we use P-660HW-Tx v3 which works as an ADSL bridge modem to connect to the ISP. The ISP will generally give one Internet account and limit only one computer to access the Internet.
Page 37 P-660HW-Tx v3 Series Support Notes Setup your P-660HW-Tx v3 under bridge mode The following procedure shows you how to configure your P-660HW-Tx v3 as bridge mode. We will use Web Configurator to guide you through the related menu. 1. Retrieve Prestige Web Please enter the LAN IP address of the Prestige router in the URL location to retrieve the web screen from the Prestige.
Page 38 P-660HW-Tx v3 Series Support Notes 2. Login first The default password is the default SMT password, '1234'. (1) Configure P-660HW-Tx v3 as bridge mode and configure Internet setup parameters in Web Configurator, Advanced Setup, Network -> WAN -> Internet Connection.
Page 39: Internet Access Using P-660Hw-Tx V3 Under Routing Mode
IP address of the computer is assigned by the P-660HW-Tx v3. The P-660HW-Tx v3 can also provide the DNS to the clients via DHCP if it is available. For this setup in Windows, we check the option 'Obtain an IP address automatically' in its TCP/IP setup.
Page 40 Specify a VPI (Virtual Path Identifier) and a VCI (Virtual Channel number Identifier) given to you by your ISP. Set to Dynamic if the ISP provides the IP for the P-660HW-Tx v3 IP Address dynamically. Otherwise, set to Static and enter the IP in the IP Assignment Address field.
Page 41: Setup The P-660Hw-Tx V3 As A Dhcp Relay
P-660HW-Tx v3 Series Support Notes (2) Configure a LAN IP for the P-660HW-Tx v3 and the DHCP settings in Web Configurator, Advanced Setup, Network -> LAN. 3. Setup the P-660HW-Tx v3 as a DHCP Relay  What is DHCP Relay? DHCP stands for Dynamic Host Configuration Protocol.
Page 42 Cu-SeeMe, and ICQ will need to connect to the local user behind the P-660HW-Tx v3. In such case, a SUA server must be configured to forward the incoming packets to the true destination behind SUA. After the required server are configured in Web Configurator, Advanced Setup, Network ->...
Page 43 Voice Net2Phone None 6701/client IP Network Time Protocol (NTP) None 123 /server IP Win2k Terminal Server None 3389/server IP Remote Anything None 3996 - 4000/client IP Virtual Network Computing None 5500/client IP All contents copyright © 2008 ZyXEL Communications Corporation.
Page 44 Certain Quake servers do not allow multiple users to login using the same unique IP, so only one Quake user will be allowed in this case. Moreover, when a Quake server is configured behind SUA, P-660HW-Tx v3 will not be able to provide information of that server on the internet.
Page 45 Also, since you need to specify the IP address of a server behind the P-660HW-Tx v3, a server must have a fixed IP address and not be a DHCP client whose IP address potentially changes each time P-660HW-Tx v3 is powered on.
Page 46 Web Configurator, Advanced Setup, Network -> NAT -> Port Forwarding. The outside users can access the local server using the P-660HW-Tx v3's WAN IP address which can be obtained from Web Configurator, Status -> WAN Information.
Page 47 All data sent over this connection can be encrypted and compressed, and multiple network level protocols (TCP/IP, NetBEUI and IPX) can be run correctly. Windows NT Domain Login level security is preserved even across the Internet. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 48 Configuration This application note explains how to establish a PPTP connection with a remote private network in the P-660HW-Tx v3 SUA case. In ZyNOS, all PPTP packets can be forwarded to the internal PPTP Server (WinNT server) behind SUA. The port number of the PPTP has to be entered in the Web Configurator, Advanced Setup, Network ->...
Page 49 P-660HW-Tx v3 Series Support Notes Example The following example shows how to dial to an ISP via the P-660HW-Tx v3 and then establish a tunnel to a private network. There will be three items that you need to set up for PPTP application, these are PPTP server (WinNT), PPTP client (Win9x) and the P-660HW-Tx v3.
Page 50 Internet IP address that the ISP assigns to P-660HW-Tx v3 router in SUA mode and enter this IP address in the VPN dial-up dialog box. You can check this Internet IP address from PNC Monitor or S Web Configurator, Status ->...
Page 51: Using Full Feature Nat
P-660HW-Tx v3 Series Support Notes 5. Using Full Feature NAT When P-660HW-Tx v3 is in Routing mode, you can select NAT Option as Full Feature in Network -> NAT -> General: Key Settings: Field Options Description When you select this option you can select...
Page 52 Configuring NAT Address Mapping Sets and NAT Server Sets The P-660HW-Tx v3 has 8 remote nodes and so allows you to configure 8 NAT Address Mapping Sets, You must specify which NAT Address Mapping Set (1~8) to use in the remote node when you select Full Feature NAT.
Page 53 Click the „Edit’ Button on the rule #1, then you can enter the window in which you can edit an individual rule and configure the Mapping Type, Local and Global Start/End IPs: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 54 Start IP address.  Configure Address Mapping Sets in CLI Setp 1: Telnet to the P-660HW-Tx v3. (We suppose the LAN IP Address of P-660HW-Tx v3 is 192.168.1.1) Step 2: Select one Address Mapping Set (#1~#8) by command „ip nat addrmap map [map #] [set name]‟...
Page 55 Load the server sets of NAT into buffer “disp 1” means to display the NAT server set in buffer, ip nat server disp [1] if parameter “1” is omitted, then it will display all the All contents copyright © 2008 ZyXEL Communications Corporation.
Page 56 192.168.1.36 and a FTP server at 192.168.1.33, then you need to specify for port 80 (Web) the server at IP address 192.168.1.36 and for port 21 (FTP) another at IP address 192.168.1.33. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 57 Examples  Internet Access Only  Internet Access with an Internal Server  Using Multiple Global IP addresses for clients and servers  Support Non NAT Friendly Applications (1) Internet Access Only All contents copyright © 2008 ZyXEL Communications Corporation.
Page 58 In this case, we do exactly as the figure (use the convenient pre-configured SUA Only set) and also go to Web Configurator, Advanced Setup, Network -> NAT -> Port Forwarding to specify the Internet Server behind the NAT as All contents copyright © 2008 ZyXEL Communications Corporation.
Page 59 Rule 4 (Server type) to map a web server and mail server with ILA3 (192.168.1.20) to IGA3. Type Server allows us to specify multiple servers, of different types, to other machines behind NAT on the LAN. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 60 Step 1: In this case, we need to map ILA to more than one IGA, therefore we must choose the Full Feature option from the NAT field in currently active remote node, and assign IGA3 to P-660HW-Tx v3‟s WAN IP Address. Step 2: Go to Web Configurator, Advanced Setup, Network -> NAT ->...
Page 61 (200.0.0.3). Rule 4 Setup: Select Server type to map our web server and mail server with ILA3 (192.168.1.20) to IGA3. Menu Network -> NAT -> Address Mapping should look as follows now: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 62 IP address. In this case it is better to use Many-to-Many No Overload or One-to-One NAT mapping types, thus each user login to the server using a unique global IP address. The following figure illustrates this. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 63: Using The Dynamic Dns (Ddns)
Without DDNS, we always tell the users to use the WAN IP of the P-660HW-Tx v3 to access the internal server. It is inconvenient for the users if this IP is dynamic. With DDNS supported by the P-660HW-Tx v3, you apply a DNS name (e.g., www.zyxel.com.tw) for your server (e.g., Web server) from a DDNS server.
Page 64 P-660HW-Tx v3 Series Support Notes When the ISP assigns the P-660HW-Tx v3 a new IP, the P-660HW-Tx v3 must inform the DDNS server the change of this IP so that the server can update its IP-to-DNS entry. Once the IP-to-DNS table in the DDNS server is updated, the DNS name for your web server (i.e., www.zyxel.com.tw) is still usable.
Page 65: Network Management Using Snmp
 ZyXEL SNMP Implementation ZyXEL currently includes SNMP support in some P-660HW-Tx v3 routers. It is implemented based on the SNMPv1, so it will be able to comm unicate with SNMPv1 NMSs. Further, users can also add ZyXEL's private MIB in the NMS to monitor and control additional system variables.
Page 66 System has to reboot for some fatal errors. And traps with the message of the fatal code will be sent.  Downloading ZyXEL's private MIB  Configure the P-660HW-Tx v3 for SNMP All contents copyright © 2008 ZyXEL Communications Corporation.
Page 67 P-660HW-Tx v3 Series Support Notes The SNMP related settings in P-660HW-Tx v3 are configured in Web Configurator, Advanced Setup, Advanced -> Remote MGNT -> SNMP The following steps describe a simple setup procedure for configuring all SNMP settings. Key Settings:...
Page 68: Using Syslog
In a typical environment, a LAN router is required to connect two local networks. The P-660HW-Tx v3 can connect three local networks to the ISP or a remote node, we call this function as 'IP Alias'. In this case, an internal router is not required.
Page 69 'IP Alias 1' and 'IP Alias 2' can be configured in Network -> LAN -> IP Alias. There are three internal virtual LAN interfaces for the P-660HW-Tx v3 to route the packets from/to the three networks correctly. They are enif0 for the major network, enif0:0 for the IP alias 1 and enif0:1 for the IP alias 2.
Page 70: Using Ip Policy Routing
LAN -> IP/DHCP Setup by configuring the P-660HW-Tx v3's first LAN IP address. Key Settings: DHCP If the P-660HW-Tx v3's DHCP server is enabled, the IP pool for the clients Setup can be any of the three networks. TCP/IP Enter the first LAN IP address for the P-660HW-Tx v3. This will create the Setup first route in the enif0 interface.
Page 71 The inclusion of length criterion is to differentiate between interactive and bulk traffic. Interactive applications, e.g., Telnet, tend to have short packets, while bulk traffic, e.g., file transfer, tends to have large packets. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 72 To implement this, we need to invoke the following command one by one: ip policyrouting set name Test (Set the name as Test of IP routing policy rule ) ip policyrouting set active (Enable the rule) ip policyrouting set criteria protocol All contents copyright © 2008 ZyXEL Communications Corporation.
Page 73 WAN site you apply the policy set in WAN interface. Apply to WAN Interface (Suppose we apply it to remote node in the example): wan node index wan node ippolicy All contents copyright © 2008 ZyXEL Communications Corporation.
Page 74: Using Call Scheduling
 What is Call Scheduling? Call scheduling enables the mechanism for the P-660HW-Tx v3 to run the remote node connection according to the pre-defined schedule. This feature is just like the scheduler ina video recorder which records the program according to the specified time.
Page 75 For example, if we want to apply the call schedule set 1 to remote node 1, we could use the commands: wan node index wan node callsch wan node save All contents copyright © 2008 ZyXEL Communications Corporation.
Page 76: Using Ip Multicast
Time service is implemented by the Daytime protocol(RFC-867), Time protocol(RFC-868), and NTP protocol(RFC-1305). You have to assign an IP address of a time server and then, the P-660HW-Tx v3 will get the date, time, and time-zone information from this server. You can configure it in Web Configurator, Advanced Setup, Maintenance ->...
Page 77: Using Zero-Configuration
IGMP to report their multicast group membership to any immediate-neighbor multicast routers so the multicast routers can decide if a multicast packet needs to be forwarded. At start up, the P-660HW-Tx v3 queries all directly connected networks to gather group membership.
Page 78 2+32 = 34 (decimal) = 22 (hex), you must input 22 (2) If you want to enable all service for VC hunting, the service bits will be 1+2+4+8+16+32=63(decimal)= 3f (hex), you must input 3f All contents copyright © 2008 ZyXEL Communications Corporation.
Page 79: How To Configure Packet Filter On P-660Hw-Tx V3
14. How to configure packet filter on P-660HW-Tx v3? The P-660HW-Tx v3 allows you to configure up to twelve filter sets with six rules in each set, for a total of 72 filter rules in the system. You can apply up to four filter sets to a particular port to block multiple types of packets.
Page 80 Usage: You can apply at most four filter sets to one remote node. wan node save  Apply to LAN Interface: lan index [index#] Usage: index#=1 main LAN 2 IP Alias#1 3 IP Alias#2 All contents copyright © 2008 ZyXEL Communications Corporation.
Page 81 = none|equal|notequal|less|greater] equal)|3(less)|4(greater) ) sys filter set srcip [address] [subnet Set the source IP address and subnet mask mask] sys filter set srcport [port#] [compare Set the source port and compare type (compare All contents copyright © 2008 ZyXEL Communications Corporation.
Page 82: Change Wan Mtu Via Web-Gui
Discard Changes 15. Change WAN MTU via WEB-GUI. You can change WAN MTU by: Network > WAN > Internet Connection > Advanced Setup, the default value is 1500. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 83: Wireless Application Notes
Step 1: Double click on the utility icon in your windows task bar the utility will pop up on your windows screen. Step 2: Select configuration tab. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 84 Step 4: Since there is no DHCP server to give the host IP you must first designate a static IP for your station. From Windows Start select Control Panel >Network Connection>Wireless Network Connection. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 85 Step1: Double click on the utility icon in your windows task bar the utility will pop up on your windows screen. Step 2: Select configuration tab. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 86 Step 4: Since there is no DHCP server to give the host IP you must first designate a static IP for your station. From Windows Start select Control Panel >Network Connection>Wireless Network Connection. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 87: Mac Filter
This provides an additional layer of control layer in that only stations with registered MAC addresses can connect. This approach requires that the list of MAC addresses be configured. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 88 Allow or block association from MAC addresses contained in this list. If Allow Filter Action Association is selected in this field, hosts with MAC addresses configured in this list will be allowed to associate with AP. If Deny Association is selected in this field, All contents copyright © 2008 ZyXEL Communications Corporation.
Page 89: Setup Wep (Wired Equivalent Privacy)
You can set up the Access Point from Web configurator，Network -> Wireless LAN -> General. (You can also configure it via CLI): Step 1: Select „Static WEP’ from the pull down menu „Security Mode‟ in Web Configurator: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 90 256-bit WEP key (secret key) with 58 hexadecimal digits There are two ways you can configure the WEP Key. (1) You can put in a special WEP key in the „WEP Key‟ menu directly. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 91 P-660HW-Tx v3 Series Support Notes (2) You can also put in an arbitrary sequence of characters in the „Passphrase‟ and then press button „Generate‟ to let the P-660HW-Tx v3 generate WEP Key for you: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 92 Step 1: Double click on the utility icon in your windows task bar or right click the utility icon then select 'Show Config Utility'. The utility will pop up on your windows screen: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 93 Note: If the utility icon doesn't exist in your task bar, click Start -> Programs -> …… to start the utility. Step 2: Select the 'Configuration' tab. Select „Set Security‟ to configure encryption type and parameters correspond with access point. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 94: Site Survey
Walls, doors, elevator shafts, and other obstacles offer different degree of attenuation. This will cause the RF coverage pattern be irregular and hard to predict. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 95 Step 3: Use a notebook with wireless client installed and run it's utility. An utility will provide information such as connection speed, current used channel, associated rate, link quality, signal strength and etc information as shown in utility below. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 96 Record down the changes at point where transfer rate drop and the link quality and signal strength information on the diagram as you go alone. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 97 Step 8: Repeat step 1~6 of survey on site as necessary, upon completion you will have an diagram and information of site survey. As illustrated below. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 98: Configure 802.1X And Wpa
WAP applies IEEE 802.1x Extensible Authentication Protocol (EAP) to authenticate wireless clients using an external RADIUS database. You can not use the P-660HW-Tx v3's local user database for WPA authentication purpose since the local user database uses MD5 EAP which can not to generate keys.
Page 99 Authentication can be done using local user database internal to the P-660HW-Tx v3 (authenticate up to 32 users) or an external RADIUS server for an unlimited number of users. Step 1: To change your P-660HW-Tx v3's authentication settings, login Web Configurator, Advanced Setup, Network ->...
Page 100 Step 1: Double click on your wireless utility icon in your windows task bar, the utility will pop up on your windows screen. Step 2: Select the configuration tab, type in the SSID (Service Set Identifier), select the operating Mode as Infrastructure, and select proper channel. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 101 P-660HW-Tx v3 Series Support Notes Step 3: Click Set Security to configure the security parameters: Step 4: Click OK for finish, and begin to Site survey. Connect to the AP as you have configured. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 102: The Wps/Wlan Button
The WPS/WLAN LED should change from on to off or vice versa. 2. Activate WPS (1) Make sure the POWER LED is on (not blinking). (2) Press the WPS WLAN ON/OFF button for 5 to 10 seconds and release it. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 103: Wps
Click this button to remove all configured wireless and wireless security settings for WPS connections on the ZyXEL Device. Apply Click Apply to save your changes back to the ZyXEL Device. Refresh Click Refresh to reload the previous configuration for this screen All contents copyright © 2008 ZyXEL Communications Corporation.
Page 104: Wps Station
You can find the PIN either on the outside of the device, or by checking the device‟s settings. Note: You must also activate WPS on that device within two minutes to have it present its PIN to the ZyXEL Device. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 105: Lan/Wan Packet Trace
Online Trace--display the trace real time on screen Offline Trace--capture the trace first and display later The details for capturing the trace in CLI as follows: First of all, you need to telnet to the P-660HW-Tx v3 firstly. The password is Administrator passwords, „admin‟ by default. ...
Page 106 & sys trcl sw on  Display the brief trace online by entering: sys trcd brief  Display the detailed trace online by entering: sys trcd parse Example: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 107: Offline Trace
Disable the trace log by entering: sys trcp sw off & sys trcl sw off  Display the trace briefly by entering: sys trcp brief  Display specific packets by using: sys trcp parse <from_index> <to_index> All contents copyright © 2008 ZyXEL Communications Corporation.
Page 108: Capture The Detailed Logs By Hyper Terminal
Capture the detailed logs by Hyper Terminal Step 1: Initiate a hyper terminal connection from your PC(suppose you connected to the LAN port of P-660HW-Tx v3) Step 2: Click the „properties‟ to configure parameters to telnet to the P-660HW-Tx v3.
Page 109 P-660HW-Tx v3 Series Support Notes Step 3: So that after you invoke the relevant commands, you could save the logs you‟ve captured. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 110: Firmware/Configurations Uploading And Downloading Using Tftp
Step 5:To upload the firmware, please save the remote file as 'ras' to Prestige. After the transfer is complete, the Prestige will program the upgraded firmware into FLASH ROM and reboot itself. An example: All contents copyright © 2008 ZyXEL Communications Corporation.
Page 111 Step 2: Type the command 'sys stdio 0' to disable console idle timeout in Command Line Interface (CLI). Step 3: Run the TFTP client software Step 4: To download the P-660HW-Tx v3 configuration, please get the remote file 'rom-0' from the Prestige. Step 5: To upload the P-660HW-Tx v3 configuration, please save the remote file as 'rom-0' in the Prestige.
Page 112: Using Tftp Command On Windows Nt
Step 2: Type the CI command 'sys stdio 0' to disable console idle timeout in Command Line Interface (CLI). Step 3: Download ZyNOS via LAN : c:\tftp -i [PrestigeIP] get ras [localfile] Step 4: Upload P-660HW-Tx v3 configurations via LAN: c:\tftp -i [PrestigeIP] put [localfile] rom-0 Step 5: Download P-660HW-Tx v3 configurations via LAN:...
Page 113: Using Ftp To Upload The Firmware And Configuration Files
Step 5 Use 'put' command to transfer the file to the Prestige. Example: Step 1: Connect to the Prestige by entering the Prestige's IP and Administrator password in the FTP software. Set the transfer type to 'Auto-Detect' or All contents copyright © 2008 ZyXEL Communications Corporation.
Page 114 Step 3: To upload the firmware file, we transfer the local 'ras' file to overwrite the remote 'ras' file. To upload the configuration file, we transfer the local 'rom-0' to overwrite the remote 'rom-0' file. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 115 P-660HW-Tx v3 Series Support Notes Step 4: The Prestige reboots automatically after the uploading is finished. Please do not power off the router at this moment. All contents copyright © 2008 ZyXEL Communications Corporation.
Page 116: Ci Command Reference
The latest CI Command list is available in release note of every ZyXEL firmware release. Please goto ZyXEL public WEB site http://www.zyxel.com/support/download_index.php to download firmware package (*.zip), you should unzip the package to get the release note in PDF format. All contents copyright © 2008 ZyXEL Communications Corporation.
