CHIEF RFWD-110 Installation Instructions Manual

Lcd tv wall mount dual swing arm

Advertisement

Quick Links

WARNING
The maximum weight to be installed on the RFWD wall mount is 40 lbs. (18.1 kg).
WARNING
The RFWD is designed to be installed using wall studs or supporting framework.
The structure to which the RFWD wall mount is anchored must be capable of
supporting five times the total weight of the mount and all attached equipment.
CAUTION
To prevent damage to the RFWD, which could affect or void the Factory warranty,
and to the equipment that will be attached to it, thoroughly study all instructions
and illustrations before you begin the installation.
CAUTION
If your monitor uses a longer screw size other than those included in the kit,
DO NOT use the screws provided with the mount. Use the screws provided with
your monitor or contact the manufacturer. Using the wrong screws could result in
damage to your monitor.
If you have any questions about this installation, contact Chief Manufacturing at:
1.800.572.1373 or 952.277.3901.
INSTALLATION
INSTRUCTIONS
WALL MOUNT
DUAL Swing Arm
WARNINGS
LCD TV
(RFWD-110)
1
