CHIEF RGTU-210 Installation Instructions Manual

Plasma tv wall mount, tilt universal

Advertisement

Quick Links

INSTALLATION
PLASMA TV WALL MOUNT
WARNING
A WARNING alerts you to the possibility of serious injury or death if you do not follow
the instructions.
CAUTION
A CAUTION alerts you to the possibility of damage or destruction of equipment if you do
not follow the corresponding instructions.
WARNING
Improper installation can result in serious personal injury! Make sure that the structural
members can support a redundant weight factor five times the total weight of the
equipment: if not, reinforce the structure before installing the RGTU.
WARNING
Be aware also of the potential for personal injury or damage to the unit if it is not
adequately mounted.
WARNING
The installer is responsible for verifying that the wall to which the RGTU is anchored will
safely support the combined load of all attached components or other equipment.
WARNING
The weight of the display placed on the RGTU must not exceed 175 lbs. (79.38 kg), the
maximum load capacity of the RGTU.
WARNING
Watch for pinch points. Do not put your fingers between movable parts.
WARNING
Make sure the mount and brackets are correctly oriented.
CAUTION
CAUTION: Check the unit for shipping damage before you begin the installation.
CAUTION
Over-tightening adjustment bolt will cause excessive wear and may distort adjustment
components.
If you have any questions about this installation, contact Chief Manufacturing at:
1.800.582-1373 or 952.277.3901.
INSTRUCTIONS
TILT Universal
(RGTU-210)

WARNINGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RGTU-210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF RGTU-210

  • Page 1: Installation Instructions

    CAUTION: Check the unit for shipping damage before you begin the installation. CAUTION Over-tightening adjustment bolt will cause excessive wear and may distort adjustment components. If you have any questions about this installation, contact Chief Manufacturing at: 1.800.582-1373 or 952.277.3901.
  • Page 2: Tools Required For Installation

    A S S E M B L Y D I A G R A M LARGE SCREEN DISPLAY MOUNT (RGTU-210) TOOLS REQUIRED FOR INSTALLATION • Phillips screwdrivers, No. 1 and No. 2 TIP • Drill and bit set • Wrench set NOTE: Other tools may be required depending on the method of installation.
  • Page 3 A S S E M B L Y D I A G R A M LARGE SCREEN DISPLAY MOUNT (RGTU-210) PARTS Figure 1. Parts...
  • Page 4 I N S T A L L A T I O N I N S T R U C T I O N S INSPECT THE MOUNT BEFORE ASSEMBLY 1. Carefully inspect the mount for shipping damage (see Figure 1). If any damage is apparent, call your carrier claims agent and do not continue with the installation until the carrier has reviewed the damage.
  • Page 5 I N S T A L L A T I O N I N S T R U C T I O N S 3.Find the center line of the display (see Figure 6). 4. Using six bolts (230) and six Nylock nuts (240), attach the tilt brackets (40) with the center hole of the tilt assembly as close to the center line of the display as possible (see Figure 7), positioning the assembly with the knob side...
  • Page 6: Install Wall Plate

    I N S T A L L A T I O N I N S T R U C T I O N S INSTALL WALL PLATE Install the wall plate as follows: WARNING: It is the responsibility of the installer to verify that the structure to which the mount is anchored will safely support five times the combined load of all attached components and equipment.
  • Page 7: Install Display

    I N S T R U C T I O N S I N S T A L L A T I O N INSTALL DISPLAY Install the display as follows: 1. Place the display on the wall plate (10) by hooking the hooks of the brackets (20 and 30) in the top of the wall plate (see Figure 11 and Figure 12).
  • Page 8 PART NO. 8805-000069 (Rev.B) 07/04...
