PRODUCT GUIDE
Kenmore Model No. 415.16120801
Kmart Item No. 640-174093112
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
®
Assembly instructions © 2008
Printed in China
See rating label on grill for serial number.
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-800-241-7548.
Estimated assembly time: 35-40 minutes
®
463611809
TM REVISION 00
•
463612009
•
10/16/08 • 80018007
