PRODUCT GUIDE
MODEL 466224611
Sears Item No. 90112
Sears Model No. 415.90112110
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
For support and to register your
grill, please visit us at
www.charbroil.com
If you have questions or need
assistance during assembly,
please call 1-888-430-7870.
Estimated assembly time: 30 minutes
®
TEC™ is a trademark of Tec Infrared Grills.
Printed in China
See rating label on grill for serial number.
®
Assembly instructions © 2010
11/17/10 • G519-001-160801
