Aztech DSL906 1DA Series Easy Start

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADSL Ethernet
Bridge/Router Series
Easy Start
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSL906 1DA Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aztech DSL906 1DA Series

Summary of Contents for Aztech DSL906 1DA Series

  • Page 1 ADSL Ethernet Bridge/Router Series Easy Start Version 1.0...

  • Page 2: Safety Guidelines

    Safety Guidelines 1. Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage. 2. This product is for use only in UL Listed computers. Adhere to the following safety guidelines when using your unit to reduce the risk of fire, electric shock and injury.

  • Page 3: Minimum System Requirements

    Easy Start Easy Start Easy Start Easy Start Easy Start Introduction Thank you on your purchase of the ADSL Ethernet Router ! The ADSL Ethernet Router can be connected to any computer with an Ethernet card or to an Ethernet Hub / Switch. It makes use of your existing phone line for Internet surfing and at the same time allows you to use your phone.

  • Page 4: Front Indicators

    Easy Start Easy Start Easy Start Easy Start Easy Start Router Package For any missing items, please contact your dealer immediately. Installation CD ADSL Ethernet Router ADSL Ethernet Router Series Easy Start (graphic shown is only CAT-5 UTP Ethernet an example) cable (RJ-45) Telephone cable (RJ-11) Micro-Filter (optional)

  • Page 5: Back Panel

    Easy Start Easy Start Easy Start Easy Start Easy Start Back Panel LINE Telephone jack (RJ-11) to connect to your Telephone Wall Socket (ADSL line). PHONE Telephone jack (RJ-11) to connect to your Telephone Set via a Micro-Filter. RESET To reset your ADSL Router to factory default settings. (All customised settings that you have saved will be lost!) Please refer to the below footer...

  • Page 6: Connecting Your Router

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 1: Connecting Your Router Power off your computer or/and any connected devices before connecting your Router ! Step 1.1 Connecting to the Ethernet Back view of computer Ethernet Jack Back view of Router Ethernet Card CAT-5 UTP Ethernet cable...

  • Page 7: Step 1.4 Connecting To The Mains

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 1.3 Connecting to a Telephone Set (Optional) The connection of the Telephone Set to your Router is optional. Back view of Router (optional) Micro-Filter Phone cable Telephone Set 2 If your package does not come with a Micro-Filter, it implies that the model of your Router does not require an external Micro-Filter as it is already in-built in your Router.
  • Page 8 Easy Start Easy Start Easy Start Easy Start Easy Start Step 3: Configuring Your Ethernet Adapter For Windows® 95 / Windows® 98 / Windows® Me From your Windows desktop, right-click on the Network Neighborhood icon. Select Properties. From the Configuration tab, select TCP/IP->xxx where xxx refer to your Ethernet card model that is connected to your Router.
  • Page 9 Easy Start Easy Start Easy Start Easy Start Easy Start iii. Select the IP Address tab. Click the option Obtain an IP address automatically. Click OK. When prompted to restart, click Yes. For Windows® XP (Instructions are based on default Start menu) From your Windows desktop, click Start >...
  • Page 10 Easy Start Easy Start Easy Start Easy Start Easy Start Select the option Obtain an IP address automatically and click OK. Click OK again to close.
  • Page 11 Easy Start Easy Start Easy Start Easy Start Easy Start For Windows® 2000 From your Windows desktop, right-click on the icon My Network Places. Select Properties. At the Network and Dial-up Connections window, right-click on the Local Area Connection icon and select Properties. iii.
  • Page 12 Easy Start Easy Start Easy Start Easy Start Easy Start (This example uses 3Com EtherLink III Ethernet Card as an example) Select the option Obtain an IP address automatically. Click Click again to close.

  • Page 13: Internet Connection

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 4: Setting up your Router Modem for Internet Connection Power on both your Router and computer. Place the Installation CD into your CD-ROM Drive. The DSL Router Commander software would run automatically.(If the software doesn't run automatically, please navigate to the Installation CD and double-click on DSLCOM.EXE) You will be prompted for your log in password.
  • Page 14 Easy Start Easy Start Easy Start Easy Start Easy Start Click Apply for changes to take effect. Upon configuration successful, you will see a dialog box, 'Configuration Successful' prompted. Click OK. Click on DHCP tab. Select or enter the following information : vii.
  • Page 15 Easy Start Easy Start Easy Start Easy Start Easy Start When logged in to the router, please enter the following commands : Assuming 203.125.64.162(Please change accordingly) is the WAN IP address assigned by the Service Provider. ip alias lan 203.125.64.162 ip subnet add lan.alias .
