INTRODUCTION/WELCOME WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC (“FCA US”) vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. Your new FCA US vehicle has characteristics to enhance the driver's control under some driving conditions.
Page 6 INTRODUCTION/WELCOME VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines). WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.
Page 7 If your symptoms persist, please see an authorized dealer. When it comes to service, remember that your authorized dealer knows your Jeep ® vehicle best, has factory-trained technicians and genuine MOPAR ®...
Page 8: Driver Cockpit
CONTROLS AT A GLANCE DRIVER COCKPIT 1. Driver Memory Seat pg. 33 2. Headlight Switch pg. 41 3. Turn Signal/Light Lever pg. 40 4. Tachometer pg. 8 5. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) pg. 142 6.
Page 9: Controls At A Glance
CONTROLS AT A GLANCE 10. Shift Lever 11. Engine Start/Stop pg. 15 12. Electronic Speed Control pg. 43 13. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) Controls pg. 142 14. Opening The Hood pg. 193 15. Power Mirror Switch 16.
Page 10: Instrument Cluster
CONTROLS AT A GLANCE INSTRUMENT CLUSTER 1. Tachometer 2. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) 3. Speedometer (See page 163 for Instrument Cluster Warning Lights information.)
Page 11 CONTROLS AT A GLANCE 4. Fuel Gauge 5. Fuel Filler Door Location 6. Temperature Gauge (See page 170 for Instrument Cluster Indicator Lights information.)
Page 12: Getting Started
GETTING STARTED KEY FOB • This feature allows the driver to oper- ate the ignition switch with the push of a button as long as the Remote Keyless Entry (RKE) transmitter is in the pas- senger compartment. • The Keyless Push Button Ignition has four operating positions, three of which are labeled and will illuminate when in position.
Page 13 GETTING STARTED Locking And Unlocking The Doors/Liftgate • Push LOCK button once to lock all the doors and the liftgate. Push UNLOCK button once to unlock the driver’s door only and twice within five seconds to unlock all the doors and the liftgate. •...
Page 14: Remote Start
GETTING STARTED REMOTE START • Push REMOTE START button on the Key Fob twice within five seconds. Pushing the REMOTE START button a third time shuts the engine off. • To drive the vehicle, push UNLOCK button, insert the key in the ignition and turn to the ON/RUN position.
Page 15: Keyless Enter-N-Go
GETTING STARTED NOTE: • The Vehicle Security Alarm will not arm if you lock the doors with the manual door lock plungers. • Once armed, the Vehicle Security Alarm disables the unlock switch on the driver door trim panel and passenger door trim panel. To Disarm The System: Push the Key Fob UNLOCK button or cycle the ignition to the ON/RUN position.
Page 16 GETTING STARTED To Lock The Vehicle: • Both front door handles have buttons located on the outside of the handle. With one of the vehicle’s Keyless Enter-N-Go Key Fobs located outside the vehicle and within 5 ft (1.5m) of the driver's or passenger front door handle, push the door handle button to lock all four doors and liftgate.
Page 17 GETTING STARTED Lock Or Unlock The Liftgate • To Lock The Liftgate — With a valid Passive Entry RKE transmitter within 5 ft (1.5 m) of the liftgate, push passive entry lock button located to the right of electronic liftgate handle. •...
Page 18: Seat Belt Systems
GETTING STARTED Accessory Positions With Engine Off NOTE: The following functions are with the driver’s foot OFF the Brake Pedal (Transmission in PARK or NEUTRAL Position). Starting With The Ignition Switch In The OFF Position: • Push the ENGINE START/STOP button once to change the ignition switch to the ACC position.
Page 19: Supplemental Restraint System (Srs) — Air Bags
GETTING STARTED Seat Belt Pretensioner • The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. • A deployed pretensioner or a deployed air bag must be replaced immediately. WARNING! •...
Page 20 GETTING STARTED Advanced Front Air Bags • This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The Advanced Front Air Bags will not deploy in every type of collision. •...
Page 21 GETTING STARTED The OCS will NOT prevent deployment of the Passenger Advanced Front Air Bag. The OCS may reduce the inflation rate of the Passenger Advanced Front Air Bag if the OCS estimates that: • The front passenger seat is unoccupied or has very light objects on it; or •...
Page 22 GETTING STARTED Lighter Weight Passengers (Including Small Adults) When a lighter weight passenger, including a small adult, occupies the front passenger seat, the OCS may reduce the inflation rate of the Passenger Advanced Front Air Bag. This does not mean that the OCS is working improperly. Do not decrease OR increase the front passenger’s seated weight on the front passenger seat The front passenger’s seated weight must be properly positioned on the front...
Page 23 GETTING STARTED The OCS determines the front passenger’s most probable classification. If an occupant in the front passenger seat is seated improperly, the occupant may provide an output signal to the OCS that is different from the occupant’s properly seated weight input, for example: The Air Bag Warning Light in the instru- ment panel...
Page 24 GETTING STARTED • Do not add a secondary seat cover or mat. • At no time should any Supplemental Restraint System (SRS) component or SRS related component or fastener be modified or replaced with any part except those which are approved by FCA US LLC. Supplemental Knee Air Bags This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the steering column and a Supplemental Passenger Knee Air...
Page 25 GETTING STARTED WARNING! • Side Air Bags need room to inflate. Do not lean against the door or window. Sit upright in the center of the seat. • Being too close to the Side Air Bags during deployment could cause you to be severely injured or killed.
Page 26 GETTING STARTED Air Bag Warning Light • The air bags must be ready to inflate for your protection in a collision. The Occupant Restraint Controller (ORC) monitors the internal circuits and intercon- necting wiring associated with air bag system electrical components. •...
Page 27: Child Restraints
GETTING STARTED NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs; no data are recorded by the EDR under normal driving conditions and no personal data (e.g., name, gender, age, and crash location) are recorded. However, other parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.
Page 28 GETTING STARTED Locating LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the gap between the seatback and seat cushion.
Page 29 GETTING STARTED Center Seat LATCH The center seating position in this vehicle has a single dedicated anchorage. Use anchorages 3 and 4 to install a child seat in the center position. Do not use anchorages 2 and 3 to install a child seat. If you are installing three child restraints, you must use the seatbelt to install the center child restraint and you must use the LATCH anchors for the outboard position on the left side.
Page 30 GETTING STARTED Installing The Child Restraint Using The Vehicle Seat Belts The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint. Any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary.
Page 31 GETTING STARTED 3. Attach the tether strap hook of the child restraint to the top tether anchorage and remove slack in the tether strap according to the child restraint manufacturer’s instructions. Tether Anchorage Locations WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle.
Page 32: Head Restraints
GETTING STARTED HEAD RESTRAINTS Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear. WARNING! The head restraints for all occupants must be properly adjusted prior to operating the vehicle or occupying a seat.
Page 33 GETTING STARTED WARNING! • A loose head restraint thrown forward in a collision or hard stop could cause serious injury or death to occupants of the vehicle. Always securely stow removed head restraints in a location outside the occupant compartment. •...
Page 34: Front Seats
GETTING STARTED FRONT SEATS Power Seats — If Equipped Some models may be equipped with a power driver's seat. The power seat switch is located on the outboard side of the seat near the floor. Use the switch to move the seat up, down, forward or rearward.
Page 35 GETTING STARTED Memory Seat The memory seat feature allows you to save two different driver seating positions, driver's outside mirror, and radio station preset settings. The memory seat buttons are located on the driver's door panel. To set a memory position: 1.
Page 36 GETTING STARTED Manual Seat Adjustments Manual Front Seat Forward/Rearward Adjustment On models equipped with manual seats, the adjusting bar is located at the front of the seats, near the floor. While sitting in the seat, lift up on the bar and move the seat forward or rearward.
Page 37: Rear Seats
GETTING STARTED Manual Seat Height Adjustment — If Equipped The driver’s seat height can be raised or lowered by using a lever, located on the outboard side of the seat. Pull upward on the lever to raise the seat height or push downward on the lever to lower the seat height.
Page 38 GETTING STARTED Rear Seat Forward/Rearward Adjustment — If Equipped Lift up on the adjusting bar located at the front of the seat near the floor and release it when the seat is at the desired position. Then, using body pressure, move forward and rearward on the seat to be sure that the seat adjusters have latched.
Page 39: Heated/Ventilated Seats
GETTING STARTED HEATED/VENTILATED SEATS Front Heated Seats If your vehicle is equipped with front heated seats, the control buttons are located within the Uconnect system. You can gain access to the control buttons through the climate screen or the controls screen. •...
Page 40: Heated Steering Wheel
GETTING STARTED Front Ventilated Seats If your vehicle is equipped with ventilated seats, the seat cushion and seat back will have fans that draw the air from the passenger compartment and move air through fine perforations in the seat cover to help keep the driver and front passenger cooler in higher ambient temperatures.
Page 41: Tilt/Telescoping Steering Column
GETTING STARTED Vehicles Equipped With Remote Start On models that are equipped with remote start, the heated steering wheel can be programmed to come on during a remote start through the Uconnect system. Refer to “Uconnect Settings” in “Understanding Your Instrument Panel” in the Owner’s Manual on the DVD for further information.
Page 42: Engine Break-In Recommendations
OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.
Page 43: Headlight Switch
OPERATING YOUR VEHICLE HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights The headlight switch is located on the instrument panel to the left of the steer- ing wheel. • Rotate the headlight switch to the first detent for parking lights and to the second detent for headlights.
Page 44: Wiper/Washer Lever
OPERATING YOUR VEHICLE Ambient Light Dimmer • Rotate the left dimmer control upward or downward to increase or decrease the brightness of the ambient light located in the overhead console, door handle lights, under I/P lights, door map pocket lights, and cubby bin lights. •...
Page 45: Electronic Speed Control
OPERATING YOUR VEHICLE ELECTRONIC SPEED CONTROL The Electronic Speed Control switches are located on the right side of the steering wheel. Cruise ON/OFF • Push the ON/OFF button to acti- vate the Electronic Speed Control. CRUISE CONTROL READY will appear in the Electronic Vehicle Information Center (EVIC) or Driver Information Display (DID) to indicate the Electronic Speed...
Page 46: Operating Your Vehicle
OPERATING YOUR VEHICLE Metric Speed (km/h) • Pushing the SET + button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h. • If the button is continually pushed, the set speed will continue to increase until the button is released, then the new set speed will be established.
Page 47: Adaptive Cruise Control (Acc)
OPERATING YOUR VEHICLE ADAPTIVE CRUISE CONTROL (ACC) If your vehicle is equipped with Adaptive Cruise Control the controls operate ex- actly the same as the electronic speed control with only a couple of differences. With this option you can set a specified distance you would like to maintain be- tween you and the vehicle in front of you.
Page 48 OPERATING YOUR VEHICLE Metric Speed (km/h) • Pushing the SET + button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h. • If the button is continually pushed, the set speed will continue to increase in 10 km/h increments until the button is released.
Page 49 OPERATING YOUR VEHICLE Distance Setting (ACC Only) The specified following distance for ACC can be set by varying the distance setting between four bars (longest), three bars (long), two bars (medium) and one bar (short). Using this distance setting and the vehicle speed, ACC calculates and sets the distance to the vehicle ahead.
Page 50 OPERATING YOUR VEHICLE WARNING! Adaptive Cruise Control (ACC) is a convenience system. It is not a substitute for active driving involvement. It is always the driver’s responsibility to be attentive of road, traffic, and weather conditions, vehicle speed, distance to the vehicle ahead; and, most importantly, brake operation to ensure safe operation of the vehicle under all road conditions.
Page 51: Forward Collision Warning Fcw) With Mitigation
OPERATING YOUR VEHICLE FORWARD COLLISION WARNING (FCW) WITH MITIGATION The Forward Collision Warning (FCW) system with mitigation provides the driver with audible warnings, visual warnings (within the EVIC/DID), and may apply a brake jerk to warn the driver when it detects a potential frontal collision. The warnings and limited braking are intended to provide the driver with enough time to react, avoid or mitigate the potential collision.
Page 52 OPERATING YOUR VEHICLE The default status of FCW is the “Far” setting. The far setting provides warnings for potential collisions more distant in front of the vehicle, allowing the driver to have the most reaction time to avoid a collision. This setting is designed to provide early warnings per NHTSA (National Highway Traffic Safety Administration) recommendations.
Page 53: Manual Climate Controls Without Touchscreen
OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITHOUT TOUCHSCREEN Manual Climate Controls Without Touchscreen 1 — Blower Control Knob 5 — A/C Button 2 — Air Recirculation Button 6 — Mode Control Knob 3 — Temperature Control Knob 7 — Rear Defroster Button 4 —...
Page 54: Manual Climate Controls With Touchscreen
OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITH TOUCHSCREEN Uconnect 5.0 Touchscreen Manual Climate Controls 6 — Mode Control Button 1 — MAX A/C Button 7 — OFF Button 2 — A/C Button 8 — Temperature Control Button 3 — Air Recirculation Button 9 —...
Page 55 OPERATING YOUR VEHICLE Uconnect 8.4 Touchscreen Manual Climate Controls 1 — MAX A/C Button 6 — Blower Speed Up 2 — A/C Button 7 — Mode Control Buttons 3 — Air Recirculation Button 8 — Blower Speed Down 4 — Front Defroster Button 9 —...
Page 56 OPERATING YOUR VEHICLE Manual Climate Controls 1 — Temperature Down Control 5 — Front Defrost Button 2 — Blower Control Knob 6 — Off Button 3 — Temperature Up Control 7 — Air Recirculation Button 4 — Rear Defrost Button 8 —...
Page 57: Automatic Temperature Controls (Atc)
OPERATING YOUR VEHICLE AUTOMATIC TEMPERATURE CONTROLS (ATC) Uconnect 5.0 Automatic Climate Controls 1 — MAX A/C Button 7 — OFF Button 2 — A/C Button 8 — Auto Button 3 — Recirculation Button 9 — SYNC Button 4 — Front Defroster Button 10 —...
Page 58 OPERATING YOUR VEHICLE Uconnect 8.4 Automatic Climate Controls 1 — MAX A/C Button 9 — SYNC Button 2 — A/C Button 10 — Blower Speed Up 3 — Air Recirculation Button 11 — Mode Control Buttons 4 — AUTO Button 12 —...
Page 59 OPERATING YOUR VEHICLE Automatic Climate Controls 1 — Driver Temperature Control 6 — Front Defroster Button 2 — OFF Button 7 — AUTO Button 3 — Blower Control Knob 8 — Air Recirculation Button 4 — Passenger Temperature Control 9 — A/C Button 5 —...
Page 60 OPERATING YOUR VEHICLE MAX A/C • MAX A/C sets the control for maximum cooling performance. • Press and release to toggle between MAX A/C and the prior settings. The button on the touchscreen illuminates when MAX A/C is ON. • In MAX A/C, the blower level and mode position can be adjusted to desired user settings.
Page 61: Stop/Start System — If Equipped
OPERATING YOUR VEHICLE STOP/START SYSTEM — IF EQUIPPED The Stop/Start function is developed to reduce fuel consumption. The system will stop the engine automatically during a vehicle stop if the required conditions are met. Releasing the brake pedal or pressing the accelerator pedal will automatically re-start the engine.
Page 62: Electric Park Brake (Epb)
OPERATING YOUR VEHICLE To Manually Turn On The Stop/Start System Push the STOP/START Off switch (located on the switch bank). The light on the switch will turn off. For complete details on the Stop/Start System refer to the “Stop/Start System” in the “Starting And Operating”...
Page 63 OPERATING YOUR VEHICLE • SafeHold a new feature that will automatically apply the park brake under certain conditions. The EPB monitors the status of the driver’s seat belt, driver’s door and pedal positions to determine if the driver may have exited while the vehicle is still capable of moving and will then automatically apply the park brake to prevent the vehicle from rolling.
Page 64: Parksense
OPERATING YOUR VEHICLE PARKSENSE ParkSense Front And Rear Park Assist ParkSense can be enabled and disabled by pushing the ParkSense switch located on the switch panel below the Uconnect display. The six ParkSense sensors, located in the rear fascia/bumper, monitor the area behind the vehicle that is within the sen- sors’...
Page 65 OPERATING YOUR VEHICLE ParkSense Active Park Assist The ParkSense Active Park Assist system can be enabled and disabled with the ParkSense Active Park Assist switch, located on the switch panel below the Uconnect display. The ParkSense Active Park Assist system is intended to assist the driver during parallel and perpendicular parking ma- neuvers by identifying a proper parking...
Page 66: Lanesense
OPERATING YOUR VEHICLE LANESENSE The LaneSense system can be enabled and disabled with the LaneSense button located on the switch panel below the Uconnect display. • Push the LaneSense button to turn the system ON (LED turns off). The LaneSense system is operational at speeds above 37 mph (60 km/h) and below 112 mph (180 km/h).
Page 67 OPERATING YOUR VEHICLE NOTE: The ParkView Rear Back Up Camera has programmable modes of operation that may be selected through the Uconnect System. Refer to “Uconnect Settings” in “Under- standing Your Instrument Panel” for further information. When the vehicle is shifted out of REVERSE (with camera delay turned OFF), the rear camera mode is exited and the previous screen appears again.
Page 68: Power Sunroof
OPERATING YOUR VEHICLE POWER SUNROOF The power sunroof switches are located on the overhead console. Opening Sunroof Express • Push the sunroof switch rearward and release it within one-half second and the sunroof will automatically open to the halfway position and stop auto- matically.
Page 69 OPERATING YOUR VEHICLE Venting Sunroof Push and release the button and the sunroof will open to the vent position. This is called “Express Vent” and will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof. Opening Power Shade Express Push the shade switch rearward and release it within one-half second and the shade...
Page 70 OPERATING YOUR VEHICLE Pinch Protection Feature This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract. Remove the obstruction if this occurs. Next, push the switch forward and release to Express Close.
Page 71: Wind Buffeting
OPERATING YOUR VEHICLE WIND BUFFETING Wind buffeting can be described as a helicopter-type percussion sound. If buffeting occurs with the rear windows open, adjust the front and rear windows together. If buffeting occurs with the sunroof open, adjust the sunroof opening, or adjust any window.
Page 72: Your Vehicle's Sound System
ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Phone Button pg. 131 2. Uconnect Voice Command Button pg. 112 3. Phone Hang Up Button 4. Steering Wheel Audio Controls (Left – Behind Steering Wheel) pg. 142 5. Steering Wheel Audio Controls (Right – Behind Steering Wheel) pg. 142 6.
Page 73 ELECTRONICS 8. Uconnect 8.4 Radio pg. 97 9. BACK Button 10. BROWSE/ENTER Button — TUNE/SCROLL Knob 11. USB Port pg. 104 12. SD Card Slot pg. 104 13. Audio Jack pg. 104 14. Power Outlet pg. 148...
Page 74: Identifying Your Radio
ELECTRONICS IDENTIFYING YOUR RADIO Uconnect 5.0 • 5” Touchscreen • Three buttons on each side of the display Uconnect 5.0 Uconnect 5.0 Uconnect 8.4A • 8.4” Touchscreen • SiriusXM Travel Link feature NOT listed within Apps Uconnect 8.4A Uconnect 8.4AN •...
Page 75: Uconnect Access
ELECTRONICS UCONNECT ACCESS Uconnect Access — If Equipped (Available On Uconnect 8.4A/8.4AN — U.S. Residents Only) WARNING! • ALWAYS obey traffic laws and pay attention to the road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable 1X (voice/data) or 3G (data) network connection.
Page 76 ELECTRONICS Before you drive, familiarize yourself with the easy-to-use Uconnect Access. 1. The ASSIST and 9-1-1 buttons are located on your rearview mirror. The ASSIST button is used for contacting Roadside Assistance, Vehicle Care and Uconnect Care. The 9-1-1 button connects you to emergency services. NOTE: Vehicles sold in Canada and Mexico DO NOT have 9-1-1 call system capabilities.
Page 77 ELECTRONICS Signing up is easy! Simply follow the steps above. Or, press the “Apps ” button on the touchscreen, then select the Uconnect registration app to “Register By Web” and complete the process using your device or computer. Why sign up for Uconnect Access? Here are just a few examples of things you’ll be able to do: •...
Page 78 ELECTRONICS Via Mobile Apps — If Equipped • Aha by HARMAN — Aha by HARMAN makes it easy to instantly access your favorite Web content on the go. Choose from over 40,000+ stations spanning internet radio, personalized music, news, entertainment, hotels, weather, audiobooks, Facebook, Twitter, and more.
Page 79 ELECTRONICS Getting Started With Apps Applications (Apps for short) in your Uconnect Access system are designed to deliver the features and services that you want. There are two basic categories: 1. Built-In Features — use the 1X (voice/data) or 3G (data) network on your Uconnect 8.4A or 8.4AN radio.
Page 80 ELECTRONICS App Manager Press the “App Manager” button to access the following categories: Favorite Apps — This is the default screen when you first press the “App Manager” button on the touchscreen, and is a good place to put the apps you use most frequently.
Page 81 ELECTRONICS Built-In Features WARNING! • ALWAYS obey traffic laws and pay attention to the road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable 1X (voice/data) or 3G (data) network connection. • ALWAYS drive safely with your hands on the steering wheel. You have full responsibility and assume all risks related to the use of the Uconnect features and applications in this vehicle.
Page 82 ELECTRONICS 1. Assist Call (8.4AN) — The rearview mirror contains an ASSIST push button which automatically connects the vehicle occupants to one of these predefined desti- nations for immediate support: • Roadside Assistance Call — If you get a flat tire, or need a tow, you’ll be connected to someone who can help anytime.
Page 83 ELECTRONICS and may share information obtained through such recording and monitoring in accordance with regulatory requirements. You acknowledge, agree and consent to any recording, monitoring or sharing of information obtained through any such call recordings. 4. Yelp — Customers have the ability to search for nearby destinations or a Point Of Interest (POI) either by category or custom search by using keywords (for example, “Italian restaurant”).
Page 84 ELECTRONICS Uconnect Access Remote Features If you own a compatible iPhone or Android powered device, the Uconnect Access App allows you to remotely lock or unlock your doors, start your engine or activate your horn and lights from virtually anywhere. Your vehicle must be equipped with remote start and your vehicle must have an operable 1X (voice/data) or 3G (data) network connection).
Page 85 ELECTRONICS To use this feature after the Uconnect Access App is downloaded, login using your user name and password. You will need your four digit Uconnect Security PIN to confirm the request. Press the “closed lock” icon on your Uconnect Access App to lock the doors, and press the “open Lock”...
Page 86 ELECTRONICS To Send A Text Message: 1. Push the Uconnect Phone Button on the steering wheel. 2. Wait for the beep. 3. Say “Text.” 4. Uconnect will prompt you “Say the phone number, or full name and phone type of the contact you want to send a message to.” 5.
Page 87: Uconnect 5.0
ELECTRONICS UCONNECT 5.0 Uconnect 5.0 Radio 1 — Radio Mode Button 4 — MORE Functions Button 2 — Compass Information Button 5 — Uconnect Phone Button 3 — Climate Functions Button 6 — Media Mode Button CAUTION! Do NOT attach any object to the touchscreen, doing so can result in damage to the screen.
Page 88 ELECTRONICS Equalizer, Balance And Fade 1. Push the MORE button on the faceplate. 2. Press the “Settings” button on the touchscreen. 3. Then scroll down and press the “Audio” button on the touchscreen to get to the Audio menu. 4. The Audio Menu shows the following options for you to customize your audio settings.
Page 89 ELECTRONICS Radio Operation Uconnect 5.0 Radio Screen 1 — Radio Station Presets 5 — Station Info 2 — Show All Presets 6 — Direct Tune 3 — Seek Up 7 — Radio Band 4 — Audio Settings 8 — Seek Down Seek Up/Down Buttons •...
Page 90 ELECTRONICS SiriusXM Premier Over 160 channels Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio, every MLB and NHL game, every NASCAR race, Martha Stewart and more.
Page 91 ELECTRONICS USB/Audio Jack (AUX)/SD CARD — If Equipped To select a specific audio source, push the MEDIA button on the faceplate. To allow music to play from your device through the vehicle’s speakers, press the “Source” button then select one of the following modes: USB/iPod Uconnect Media Hub...
Page 92 ELECTRONICS UCONNECT 5.0 VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 5.0 system. Key Features: • 5” touchscreen •...
Page 93 ELECTRONICS Get Started 1. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition. 3. Speak clearly at a normal pace and volume while facing straight ahead. The microphone is positioned on the rearview mirror and aimed at the driver.
Page 94 ELECTRONICS Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. Push the VR button . After the beep, say: • Cancel to stop a current voice session • Help to hear a list of suggested Voice Commands •...
Page 95 ELECTRONICS Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button . After the beep, say: • Tune to ninety-five-point-five FM •...
Page 96 ELECTRONICS Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If Equipped). Voice operation is only available for connected USB and iPod devices. (Remote CD player optional and not available on all vehicles.) Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
Page 97 ELECTRONICS Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions. Push the Phone button .
Page 98 ELECTRONICS Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button say Listen. (Must have compatible device paired to Uconnect system.) 1. Once an incoming text message is read to you, push the Phone button . After the beep, say: Reply.
Page 99: Uconnect 8.4A/8.4An
ELECTRONICS UCONNECT 8.4A/8.4AN Uconnect 8.4A/8.4AN AT A GLANCE Uconnect 8.4AN Radio Screen CAUTION! Do NOT attach any object to the touchscreen, doing so can result in damage to the screen. Setting The Time • Model 8.4AN synchronizes time automatically via GPS, so it should not require any time adjustment.
Page 100 ELECTRONICS Background Themes • Screen background themes are selectable from a pre-loaded list of themes. If you’d like to set a theme, follow the instructions below. • Press the “Settings” button on the touchscreen. • Press the “Display” button on the touchscreen. •...
Page 101 ELECTRONICS PERSONALIZED MENU BAR The Uconnect features and services in the main menu bar are easily changed for your convenience. Simply follow these steps: Uconnect 8.4A/8.4AN Main Menu 1. Press the “Apps ” button to open the App screen. 2. Press and hold, then drag the selected App to replace an existing shortcut in the main menu bar.
Page 102 ELECTRONICS RADIO Uconnect 8.4AN Radio 1 — Radio Station Presets 7 — Audio Settings 2 — Toggle Between Presets 8 — Seek Up 3 — Status Bar 9 — Direct Tune To A Radio Station 4 — View Small Navigation Map 10 —...
Page 103 ELECTRONICS Direct Tune • Tune directly to a radio station by pressing the “Tune” button on the screen, and entering the desired station number. Store Radio Presets Manually Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM). They are shown at the top of your radio screen.
Page 104 ELECTRONICS Direct Tune • Tune directly to a SXM channel by pressing the “Tune” button on the touchscreen on the screen, and entering the desired station number. Jump • Automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel.
Page 105 ELECTRONICS Browse Sub-Menu Sub-Menu Description Favorites Lets you manage artists and songs in the Favorites list and configure Alert Settings to let you know when favorite songs or artists are playing on other channels. Also, view a list of channels airing any of your Favorites.
Page 106 ELECTRONICS Disc Operation (If Equipped) • Your vehicle may have a remote CD player located in the lower center console storage bin, or in the lower center bench seat bin. • CD/Disc Mode is entered by either inserting a CD/Disc or by pressing the MEDIA button.
Page 107 ELECTRONICS USB Port • Connect your compatible device using a USB cable into the USB Port. USB Memory sticks with audio files can also be used. Audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.
Page 108 ELECTRONICS MEDIA CONTROLS Media Controls 1 — Repeat Music Track 5 — Show Songs Currently In Cue To 2 — Music Track And Time Be Played 3 — Shuffle Music Tracks 6 — Browse Music By 4 — Music Track Information 7 —...
Page 109 ELECTRONICS NAVIGATION • The information in the section below is only applicable if you have the 8.4AN system or the Navigation has been activated on your 8.4A system. • If you have a Uconnect 8.4A system your radio is “Navigation-Ready,” and can be equipped with Navigation at an extra cost.
Page 110 ELECTRONICS Finding Points Of Interest • From the main Navigation menu, press the “Where To?” button on the touch- screen, then press the “Points of Interest” button on the touchscreen. • Select a Category and then a subcategory, if necessary. •...
Page 111 ELECTRONICS Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen. Uconnect 8.4AN Map 1 — Distance To Next Turn 5 —...
Page 112 ELECTRONICS Adding A Stop • To add a stop you must be navigating a route. • Press the “Menu” button on the touchscreen to return to the Main Navigation menu. • Press the “Where To?” button on the touchscreen, then search for the extra stop. When another location has been selected, you can choose to cancel your previous route, add as the first destination or add as the last destination.
Page 113 ELECTRONICS SiriusXM Travel Link (8.4AN & US Market Only) In addition to delivering over 130 channels of the best sports, entertainment, talk, and commercial-free music, SiriusXM offers premium data services that work in conjunction with compatible navigation systems. SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips.
Page 114: Uconnect 8.4A/8.4An Voice Recognition Quick Tips
ELECTRONICS UCONNECT 8.4A/8.4AN VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 8.4AN system. If you see the icon on your touchscreen, you have the Uconnect 8.4AN system.
Page 115 ELECTRONICS 4. Each time you give a Voice Command, you must first push either the VR or Phone button, wait until after the beep, then say your Voice Command. 5. You can interrupt the help message or system prompts by pushing the VR or Phone button and saying a Voice Command from current category.
Page 116 ELECTRONICS Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. Push the VR button . After the beep, say: • Cancel to stop a current voice session • Help to hear a list of suggested Voice Commands •...
Page 117 ELECTRONICS Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button . After the beep, say: • Tune to ninety-five-point-five FM •...
Page 118 ELECTRONICS Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If Equipped). Voice operation is only available for connected USB and iPod devices. (Remote CD player optional and not available on all vehicles.) Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
Page 119 ELECTRONICS Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit: • UconnectPhone.com for device compatibility and pairing instructions. Canadian residents can visit: •...
Page 120 ELECTRONICS Siri Eyes Free — If Equipped Siri lets you use your voice to send text messages, select media, place phone calls and much more. Siri uses your natural language to understand what you mean and will respond back to confirm your requests. The system is designed to keep your eyes on the road and your hands on the wheel by letting Siri help you perform useful tasks.
Page 121 ELECTRONICS Getting Started Ensure Siri is enabled on your iPhone. Enable Siri 1 — Select Settings on your iPhone 3 — Select Siri 2 — Select General 4 — Enable Siri 1. Pair your Siri enabled device to the vehicles sound system. Refer to “Uconnect Phone”...
Page 122 ELECTRONICS 2. Push and Hold, then release the Uconnect Voice Recognition (VR) button the steering wheel. After you hear the familiar Siri "double beep," say a command. NOTE: A push and release of the button will start normal embedded VR functions. The push and hold, then release of the button will start Siri functions.
Page 123 ELECTRONICS Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button say Listen. (Must have compatible device paired to Uconnect system.) 1. Once an incoming text message is read to you, push the Phone button . After the beep, say: Reply.
Page 124 ELECTRONICS Climate (8.4A/8.4AN) Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfort- able while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button . After the beep, say one of the following commands: •...
Page 125 ELECTRONICS Navigation (8.4A/8.4AN) The Uconnect navigation feature helps you save time and become more productive when you know exactly how to get to where you want to go. (Navigation is optional on the Uconnect 8.4A system. See your dealer to activate navigation at any time.) 1.
Page 126 ELECTRONICS Uconnect Access — If Equipped (8.4A/8.4AN) WARNING! ALWAYS obey traffic laws and pay attention to the road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable 1X (voice/ data) or 3G (data) network connection. NOTE: Your vehicle may be transmitting data as authorized by the subscriber.
Page 127 ELECTRONICS Register (8.4A/8.4AN) To unlock the full potential of Uconnect Access in your vehicle, you first need to register with Uconnect Access. 1. Push the ASSIST button on your rearview mirror. Uconnect 8.4 Registration 2. Press the “Uconnect Care” button on the touchscreen. 3.
Page 128 ELECTRONICS Mobile App (8.4A/8.4AN) You’re only a few steps away from using remote commands and playing your favorite music in your vehicle. To link your internet radio accounts: 1. Download the Uconnect Access App on your device. 2. Press the Via Mobile icon on the navi- gation bar at the bottom of the app.
Page 129 ELECTRONICS Voice Texting (8.4A/8.4AN) You must be registered with Uconnect Access and have a compatible MAP – enabled device to use your voice to send a personalized text message. (Not compatible with iPhone.) 1. To send a message, push the Phone button .
Page 130 ELECTRONICS Yelp (8.4A/8.4AN) Once registered with Uconnect Access, you can use your voice to search for the most popular places or things around you. 1. Push the VR button . After the beep, say: Launch YELP. 2. Once the YELP home screen appears on the touchscreen, push the VR button , then say: YELP search.
Page 131 ELECTRONICS SiriusXM Travel Link (8.4A/8.4AN — US Market Only) Need to find a gas station, view local movie listings, check a sports score or the 5- day weather forecast? SiriusXM Travel Link is a suite of services that brings a wealth of information right to your Uconnect 8.4AN system.
Page 132 ELECTRONICS Additional Information © 2015 FCA US LLC. All rights reserved. Mopar, Mopar Owner Connect and Uconnect are registered trademarks of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc. Yelp, Yelp logo, Yelp burst and related marks are registered trademarks of Yelp.
Page 133: Uconnect Phone
ELECTRONICS UCONNECT PHONE Uconnect Phone (Bluetooth Hands Free Calling) Uconnect 5.0 Phone Menu 1 — Call/Redial/Hold 7 — Uconnect Phone Settings Menu 2 — Mobile Phone Signal Strength 8 — Text Messaging 3 — Currently Paired Mobile Phone 9 — Direct Dial Pad 4 —...
Page 134 ELECTRONICS Uconnect 8.4A/8.4AN Phone Menu 1 — Favorite Contacts 12 — Browse Phone Book Entries 2 — Mobile Phone Battery Life (Contains 9-1-1) 3 — Currently Paired Mobile Phone 13 — End Call 4 — Mobile Phone Signal Strength 14 — Call/Redial/Hold 5 —...
Page 135 ELECTRONICS If the Uconnect Phone Button exists on your steering wheel, you then have the Uconnect Phone features. Refer to the Understand The Features Of Your Vehicle section of your vehicle's Owner's Manual on the DVD for further details. NOTE: •...
Page 136 ELECTRONICS Uconnect 8.4A, 8.4AN: 1. Place the ignition in the ACC or ON position. 2. Press the “Phone” button in the Menu Bar on the touchscreen. 3. Select “Settings.” 4. Select “Paired Phones.” 5. Select “Add device.” • Uconnect Phone will display an “In progress”...
Page 137 ELECTRONICS Select The iPhone's Priority Level When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite mobile phone. Selecting “Yes” will make this mobile phone the highest priority. This mobile phone will take precedence over other paired mobile phones within range and will connect to the Uconnect system automatically when entering the vehicle.
Page 138 ELECTRONICS Select The Android Mobile Phone's Priority Level When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite mobile phone. Selecting “Yes” will make this mobile phone the highest priority. This mobile phone will take precedence over other paired mobile phones within range and will connect to the Uconnect system automatically when entering the vehicle.
Page 139 ELECTRONICS Voice Command Tips • Speaking complete names (i.e; Call John Doe vs. Call John) will result in greater system accuracy. • You can “link” commands together for faster results. Say “Call John Doe, mobile,” for example. • If you are listening to available voice command options, you do not have to listen to the entire list.
Page 140 ELECTRONICS Incoming Text Messages After pairing your Uconnect system with a Bluetooth enabled mobile device with the Message Access Profile (MAP), the Uconnect system can announce a new incoming text message and read it to you over the vehicle’s audio system. NOTE: Only incoming text messages received during the current ignition cycle can be viewed/read.
Page 141 ELECTRONICS Android Devices 1. Push the Menu button on the mobile phone. 2. Select Settings. 3. Select Connections. 4. Turn “Show Notifications” to On. • A pop up will appear asking you to accept a request for permission to connect to your messages.
Page 142 ELECTRONICS Here’s How: 1. Push the Uconnect Phone button and wait for the beep, then say “reply.” Uconnect will give the following prompt: “Please say the message you would like to send.” 2. Wait for the beep and say one of the pre-defined messages. (If you are not sure, you can say “help”).
Page 143 ELECTRONICS Mobile Phone won’t pair to system: • Perform a hard reset in the mobile phone by removing the battery (if removable — see your mobile phone’s owner manual). • Delete pairing history in mobile phone and Uconnect system; usually found in phone’s Bluetooth connection settings.
Page 144: Steering Wheel Audio Controls
ELECTRONICS STEERING WHEEL AUDIO CONTROLS The steering wheel audio controls are located on the rear surface of the steering wheel. Right Switch • Push the switch up or down to increase or decrease the volume. • Push the button in the center to change modes AM/FM/CD/SXM.
Page 145: Programmable Features
ELECTRONICS • Push the RIGHT arrow button to access the information screens or submenu screens of a main menu item. • Push the LEFT arrow button to access the information screens or submenu screens of a main menu item. • Push the OK button to access/select the information screens or submenu screens of a main menu item.
Page 146: Universal Garage Door Opener (Homelink)
ELECTRONICS UNIVERSAL GARAGE DOOR OPENER (HomeLink) • HomeLink replaces up to three hand-held transmitters that operate devices such as garage door openers, motorized gates, lighting or home se- curity systems. The HomeLink unit is powered by your vehicles 12 Volt bat- tery.
Page 147 ELECTRONICS Programming A Rolling Code NOTE: For programming Garage Door Openers that were manufactured after 1995. These Garage Door Openers can be identified by the “LEARN” or “TRAIN” button located where the hanging antenna is attached to the Garage Door Opener. It is NOT the button that is normally used to open and close the door.
Page 148 ELECTRONICS Programming A Non-Rolling Code NOTE: For programming Garage Door Openers manufactured before 1995. 1. Turn the ignition switch to the ON/RUN position. 2. Place the hand-held transmitter 1 to 3 inches (3 to 8 cm) away from the HomeLink button you wish to program while keeping the HomeLink indicator light in view.
Page 149: Power Inverter
ELECTRONICS POWER INVERTER A 115 Volt, 150 Watt power inverter outlet is located on the rear of the center console. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts. The power inverter is designed with built-in overload protection.
Page 150: Power Outlet
ELECTRONICS POWER OUTLET There are three 12 Volt electrical power outlets on this vehicle. The front 12 Volt power outlet is located below the climate controls in the Center Console Media Center, and is powered when the ignition switch is in the ON/RUN position.
Page 151 ELECTRONICS There is also a 12 Volt power outlet located in the rear cargo area of the vehicle. This power outlet has power available directly from the battery (power available at all times). Items plugged into this outlet also may discharge the battery and/or prevent the engine from starting.
Page 152: Wireless Charging Pad
ELECTRONICS WIRELESS CHARGING PAD Wireless Charging Pad — If Equipped Your vehicle may be equipped with a wireless charging pad located inside the upper portion of the center console. This charging pad is designed to wirelessly charge your Qi enabled mobile phone. Qi is a standard that uses magnetic induction to transfer power to your mobile device.
Page 153 ELECTRONICS Wireless Charging Pad Operation To use the wireless charging pad, the coil in your mobile phone needs to align with the coil in the charging pad, which is located directly under the Qi logo. Since each mobile phone’s coil location is different, you may need a few attempts to locate the correct spot for your mobile phone: 1.
Page 154 ELECTRONICS 4. Use the adjustable cradle to hold the mobile phone in position. The cradle moves by pushing down on the finger tabs and moving the cradle in or out. NOTE: The initial adjustment will only need to be done once as long as only one mobile phone is used.
Page 155: Four-Wheel Drive Operation
OFF-ROAD CAPABILITIES FOUR-WHEEL DRIVE OPERATION 1–SPEED FOUR-WHEEL DRIVE (4X4) This feature provides on-demand Four-Wheel Drive (4X4) with no driver inputs or additional driving skills required. Under normal driving conditions, the front wheels provide most of the traction. If the front wheels begin to lose traction, power is shifted automatically to the rear wheels.
Page 156 OFF-ROAD CAPABILITIES The NEUTRAL position allows vehicles with 2-speed Four-Wheel Drive to be flat towed (with all wheels on the ground) without damaging the drivetrain. Refer to “Recreational Towing” for instructions on shifting into and out of NEUTRAL. NOTE: In 4X4 LOW the engine speed is approximately three times that of the normal driving mode at a given road speed.
Page 157 OFF-ROAD CAPABILITIES REAR ELECTRONIC LOCKER (E-LOCKER) SYSTEM The Rear E-Locker System features a mechanical locking rear differential to provide better traction in the 4WD LOW position. The “REAR LOCK” button is on the Selec-Terrain Knob. Activating The Rear E-Locker To activate the Rear E-Locker System, the following conditions must be met: •...
Page 158: Selec-Terrain
OFF-ROAD CAPABILITIES SELEC-TERRAIN Selec-Terrain combines the capabilities of the vehicle control systems, along with driver input, to provide the best performance for all terrains. Rotate the mode control knob to select the following Selec-Terrain positions: • Auto — Fully automatic full time four- wheel drive operation can be used on and off road.
Page 159: Cargo Area Features
UTILITY CARGO AREA FEATURES Cargo Load Floor The cargo load floor system has a load capacity of 400 lbs (181 kg). To provide additional storage area, each rear seat can be folded flat. This allows for extended cargo space and still maintains some rear seating room. Refer to “Rear Seats”...
Page 160: Trailer Towing
UTILITY TRAILER TOWING Trailer Towing Weights (Maximum Trailer Weight Ratings) Maximum Engine/ Maximum GTW Model Frontal Area Tongue Wt. Transmission (Gross Trailer Wt.) (See Note) 2.4L/Automatic with or without 32 sq ft 2,000 lbs 200 lbs FWD or 4WD Trailer Tow (2.97 sq m) (907 kg) (91 kg)
Page 161 UTILITY Recreational Towing — Front-Wheel Drive (FWD) Models DO NOT flat tow this vehicle. Damage to the drivetrain will result. Recreational towing (for front-wheel drive models) is allowed ONLY if the front wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow this procedure: 1.
Page 162 UTILITY Recreational Towing — 4X4 Models With 2-Speed Power Transfer Unit The power transfer unit must be shifted into NEUTRAL (N) and the transmission must be in PARK for recreational towing. The NEUTRAL (N) selection button is adjacent to the 4WD selector switch. Shifts into and out of NEUTRAL (N) can take place with the selector switch in any mode position.
Page 163 UTILITY 1. Bring the vehicle to a complete stop and shift the transmission to PARK. 2. Turn the engine OFF. 3. Turn the ignition switch to the ON/RUN position, but do not start the engine. 4. Press and hold the brake pedal. 5.
Page 164 UTILITY Shifting Out Of NEUTRAL (N) Use the following procedure to prepare your vehicle for normal usage. 1. Bring the vehicle to a complete stop, leaving it connected to the tow vehicle. 2. Apply the parking brake. 3. Turn the ignition switch to the ON/RUN position, but do not start the engine. 4.
Page 165: Roadside Assistance
WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
Page 166: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes. If the ABS light does not turn on when the ignition switch is turned to the ON/RUN position, have the light inspected by an authorized dealer.
Page 167 WHAT TO DO IN EMERGENCIES IF THE LIGHT STARTS FLASHING INDICATING A LOW TIRE PRESSURE, ADJUST THE AIR PRESSURE IN THE LOW TIRE TO THE AIR PRESSURE SHOWN ON THE VEHICLE PLACARD OR TIRE INFLATION PRESSURE LABEL LOCATED ON THE DRIVER'S DOOR. NOTE: After inflation, the vehicle may need to be driven for 20 minutes before the flashing light will turn off.
Page 168 WHAT TO DO IN EMERGENCIES - Engine Temperature Warning Light • This light warns of an overheated engine condition. • If the light turns on and a warning chime sounds while driving, safely pull over and stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the vehicle.
Page 169 WHAT TO DO IN EMERGENCIES – Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the brake system master cylinder reservoir.
Page 170 WHAT TO DO IN EMERGENCIES - Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD II that monitors engine and automatic transmission control systems. The light will illuminate when the key is in the ON/RUN position before engine start. If the bulb does not come on when turning the key from OFF to ON/RUN, have the condition checked promptly.
Page 171 WHAT TO DO IN EMERGENCIES Oil Life Reset • Your vehicle is equipped with an engine oil change indicator system. The “Oil Change Due” message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next scheduled oil change interval.
Page 172: Instrument Cluster Indicator Lights
WHAT TO DO IN EMERGENCIES INSTRUMENT CLUSTER INDICATOR LIGHTS - Stop/Start Indicator — If Equipped This icon indicates that the Stop/Start System is active. Whenever the system is active, the telltale will illuminate in the instrument cluster. Refer to “Stop Start System”...
Page 173 WHAT TO DO IN EMERGENCIES - Adaptive Cruise Control (ACC) ON Indicator • If your vehicle is equipped with adaptive cruise control, the controls operate exactly the same as the normal (fixed speed) cruise control with one difference. You can set a specified distance you would like to maintain between you and the vehicle in front of you.
Page 174 WHAT TO DO IN EMERGENCIES – Hill Descent Control Indicator — If Equipped This indicator will illuminate when Hill Descent Control (HDC) has been selected using the Hill Descent Control Switch. – Park/Headlight ON Indicator This indicator will illuminate when the park lights or headlights are turned on. –...
Page 175: If Your Engine Overheats
WHAT TO DO IN EMERGENCIES IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating your engine by taking the appropriate action. • On the highways — slow down. • In city traffic — while stopped, put transmission in NEUTRAL, but do not increase engine idle speed.
Page 176: Tire Service Kit
WHAT TO DO IN EMERGENCIES TIRE SERVICE KIT Your vehicle may be equipped with a Tire Service Kit. Small punctures up to 1/4” (6 mm) in the tire tread can be sealed with the Tire Service Kit. Foreign objects (e.g., screws or nails) should not be removed from the tire.
Page 177 WHAT TO DO IN EMERGENCIES Tire Service Kit Usage Precautions • Replace the Tire Service Kit Sealant Bottle (1) and Sealant Hose (6) prior to the expiration date (printed on the bottle label) to assure optimum operation of the system. Refer to “Sealing A Tire With Tire Service Kit” section (F) “Sealant Bottle and Hose Replacement.”...
Page 178 WHAT TO DO IN EMERGENCIES 4. Remove the cap from the valve stem and then screw the fitting at the end of the Sealant Hose (6) onto the valve stem. 5. Uncoil the Power Plug (8) and insert the plug into the vehicle’s 12 Volt power outlet. 6.
Page 179 WHAT TO DO IN EMERGENCIES If the tire does not inflate to at least 26 psi (1.8 Bar) pressure within 15 minutes: The tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance. NOTE: If the tire becomes over-inflated, push the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing.
Page 180 WHAT TO DO IN EMERGENCIES If the tire pressure is 19 psi (1.3 Bar) or higher: 1. Push the Power Button (4) to turn on Tire Service Kit and inflate the tire to the pressure indicated on the tire and loading information label on the driver-side door opening.
Page 181 WHAT TO DO IN EMERGENCIES NOTE: • The metal end fitting from Power Plug (8) may get hot after use, so it should be handled carefully. • Failure to reinstall the cap on the fitting at the end of the Sealant Hose (6) can result in sealant contacting your skin, clothing, and the vehicle’s interior.
Page 182: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 183 WHAT TO DO IN EMERGENCIES WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided. Have the deflated (flat) tire repaired or replaced immediately. Preparations For Jacking 1.
Page 184 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.
Page 185 WHAT TO DO IN EMERGENCIES 1. Remove the spare tire, jack, and wheel bolt wrench. 2. If equipped with aluminum wheels where the center cap covers the wheel bolts, use the wheel bolt wrench to pry the center cap off carefully before raising the vehicle.
Page 186 WHAT TO DO IN EMERGENCIES 5. Raise the vehicle just enough to remove the flat tire. Rear Jack Location Engaged Front Jack Location Engaged WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire.
Page 187 WHAT TO DO IN EMERGENCIES 8. Mount the spare tire. CAUTION! Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the spare tire is mounted incorrectly. NOTE: • For vehicles so equipped, do not attempt to install a center cap or wheel cover on the compact spare.
Page 188: Jump-Starting Procedures
WHAT TO DO IN EMERGENCIES Road Tire Installation 1. Mount the road tire on the axle. 2. Install the remaining wheel bolts with the threaded end of the wheel bolt toward the wheel. Lightly tighten the wheel bolts. WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered.
Page 189 WHAT TO DO IN EMERGENCIES Preparations For Jump-Start The battery in your vehicle is located in the front of the engine compartment, behind the left headlight assembly. NOTE: The positive battery post is covered with a protective cap. Lift up on the cap to gain access to the positive battery post.
Page 190 WHAT TO DO IN EMERGENCIES Connecting The Jumper Cables 1. Connect the positive (+) end of the jumper cable to the positive (+) post of the discharged vehicle. 2. Connect the opposite end of the positive (+) jumper cable to the positive (+) post of the booster battery.
Page 191: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion. Turn the steering wheel right and left to clear the area around the front wheels.
Page 192: Recovery Strap — If Equipped
WHAT TO DO IN EMERGENCIES RECOVERY STRAP — IF EQUIPPED Your vehicle may be included with a recovery strap. Recovery straps do not act like traditional tow straps, chains, or winch cables. WARNING! Recovery straps should only be used in emergencies to rescue stranded vehicles. Only use Recovery straps on vehicles that fit within the recommended GVW of your recovery strap.
Page 193: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES 5. Insert a small screwdriver or similar tool down into the shift lever override access hole (at the right front corner of the shift lever assembly), and push and hold the override release lever down. 6.
Page 194: Enhanced Accident Response System (Ears)
WHAT TO DO IN EMERGENCIES ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) This vehicle is equipped with an Enhanced Accident Response System. Please refer to “Supplemental Restraint System (SRS) — Air Bags” in “Getting Started” in this guide for further information on the Enhanced Accident Response System (EARS) function.
Page 195: To Open And Close The Hood
MAINTAINING YOUR VEHICLE TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. 1. Pull the hood release lever located under the drivers side of the instrument panel. 2. Move to the outside of the vehicle and pull the safety latch release lever forward (toward you).
Page 196: Engine Compartment — 2.4L
MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.4L 1. Engine Coolant Reservoir 2. Engine Oil Fill 3. Brake Fluid Reservoir 4. Battery Terminals (Jump Starting) 5. Battery...
Page 197: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE 6. Power Distribution Center (Fuses) 7. Washer Fluid Reservoir 8. Engine Oil Dipstick 9. Air Cleaner Filter...
Page 198: Engine Compartment — 3.2L
MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.2L 1. Engine Coolant Reservoir 2. Engine Oil Fill 3. Brake Fluid Reservoir 4. Battery Terminals (Jump Starting) 5. Battery...
Page 199 MAINTAINING YOUR VEHICLE 6. Power Distribution Center (Fuses) 7. Washer Fluid Reservoir 8. Engine Oil Dipstick 9. Air Cleaner Filter...
Page 200: Fluid Capacities
MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 2.4L and 3.2L Engines 15.8 Gallons 60 Liters Engine Oil With Filter 2.4 Liter Engine 5.5 Quarts 5.2 Liters (SAE 0W-20, API Certified) 3.2 Liter Engine 6 Quarts 5.6 Liters (SAE 5W-20, API Certified) Cooling System* 2.4 Liter Engine (MOPAR Antifreeze/Engine Coolant...
Page 201 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Fuel Selection – 2.4L Flex Fuel 87 Octane, Up To 85% Ethanol. (E-85) Engines Fuel Selection – 2.4L and 3.2L 87 Octane, 0-15% Ethanol. Engines CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.
Page 202: Flexible Fuel (2.4L Engine Only If Equipped
MAINTAINING YOUR VEHICLE FLEXIBLE FUEL (2.4L ENGINE ONLY) — IF EQUIPPED E-85 General Information The information in this section is unique for Flexible Fuel vehicles only. These vehicles can be identified by a unique fuel filler door label that states Ethanol (E-85) or Unleaded Gasoline Only and a yellow fuel cap.
Page 203 MAINTAINING YOUR VEHICLE NOTE: Under no circumstances should oil change intervals exceed 10,000 miles (16,000 km), twelve months or 350 hours of engine run time, whichever comes first. The 350 hours of engine run or idle time is generally only a concern for fleet customers.
Page 204 MAINTAINING YOUR VEHICLE...
Page 205 MAINTAINING YOUR VEHICLE...
Page 206: Fuses
MAINTAINING YOUR VEHICLE FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating. Never replace a blown fuse with metal wires or any other material.
Page 207 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description – – Not Used – 40 Amp Green Starter Solenoid 10 Amp Red – A/C Compressor Clutch – – Not Used 5 Amp Tan – Radiator Fan 70 Amp Tan – Body Controller Module (BCM) - Feed 2 50 Amp Red...
Page 208 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description – 30 Amp Pink Trailer Tow Electric Brake Module - If Equipped 20 Amp Yellow – Fuel Pump Motor – 30 Amp Pink Trailer Tow / 7-Way Connector - If Equipped –...
Page 209 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description 10 Amp Red – In Vehicle Temperature Sensor / Humidity Sensor / Driver Assist System Module (DASM) / Park Assist (PAM) - If Equipped with Stop/Start option 15 Amp Blue – HVAC (ECC) / Instrument Panel Cluster (IPC) 10 Amp Red...
Page 210 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description – – Not Used – 20 Amp Blue Engine Controller Module (Gas) – 30 Amp Pink Electric Park Brake (EPB) - Left – – Not Used 20 Amp Yellow – Horns - If Equipped With Stop/Start Engine Option F87A 20 Amp Yellow...
Page 211 MAINTAINING YOUR VEHICLE Interior Fuses The interior fuse panel is located in the passenger compartment on the left side dash panel under the instrument panel. Cavity Blade Fuse Description 15 Amp Blue Low Beam Left 10 Amp Red Interior Lighting 10 Amp Red Intrusion Module/Siren –...
Page 212: Adding Fuel
MAINTAINING YOUR VEHICLE ADDING FUEL The gas cap is located behind the fuel filler door, on the passenger side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap has been designed for use with this vehicle. NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler door reinforcement.
Page 213 MAINTAINING YOUR VEHICLE CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel filler cap. A poorly fitting cap could let impurities into the fuel system. Also, a poorly fitting aftermarket cap can cause the “Malfunction Indicator Light (MIL)”...
Page 214: Tires — General Information
MAINTAINING YOUR VEHICLE TIRES — GENERAL INFORMATION TIRE PRESSURES Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...
Page 215 MAINTAINING YOUR VEHICLE SPARE TIRES — IF EQUIPPED NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to “Tire Service Kit” in “What To Do In Emergencies” on your DVD for further information. CAUTION! Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with a compact or limited-use temporary spare installed.
Page 216 MAINTAINING YOUR VEHICLE Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not. This spare tire may have limited tread life.
Page 217: Replacement Bulbs
MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Interior Bulbs Bulb Number Cargo Lamp TL212–2 Overhead Console Lamp PLW214–2A Reading Lamp WL212–2 Exterior Bulbs Bulb Number Low Beam/High Beam (Bi-Halogen) HIR2 Headlamps Low Beam/High Beam (Bi-Xenon) D3S (Serviced at an Authorized Dealer) Headlamps Front Park/Daytime Running Lamps LED (Serviced at an Authorized Dealer) Front Turn Signal Lamps...
Page 218: Fca Us Llc Customer Center
Warranty Booklet. United States customers may visit the Jeep Contact Us page at www.jeep.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Compartment Material” from the left menu.
Page 219: Reporting Safety Defects In The United States
• A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired model year and vehicle from the drop down lists.
Page 220: Authentic Accessories By Mopar
• For the full line of Authentic Jeep Accessories by Mopar, visit your local dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents.
Page 221: Frequently Asked Questions
How do I shift into different four-wheel drive selections? pg. 153 UTILITY How do I know how much I can tow with my Jeep Cherokee? pg. 158 WHAT TO DO IN EMERGENCIES What do I do if my TPMS warning light is blinking? pg. 164 How do I change a flat tire? pg.
Page 222: Index
INDEX Access Automatic High Beams ..41 Uconnect ..73, 74, 78 Automatic Temperature Adaptive Cruise Control (ACC) Control (ATC) ... .55 Off .
Page 223 INDEX Child Restraints ... .25 Defects, Reporting ..217 Lower Anchors And Tethers Defroster, Rear Window ..51, 52 For Children .
Page 224 INDEX FAQ....219 High Beam/Low Beam Select Filters (Dimmer) Switch ..40 Air Cleaner ... .200 HomeLink (Garage Door Opener) .
Page 225 INDEX Lap/Shoulder Belts ...16 Filter Disposal ..200 Latches Materials Added To ..200 Hood ....193 Recommendation .
Page 226 INDEX Rear Park Assist System ..62 Shifting Rear ParkSense System ..62 Power Transfer Unit, Shifting Rear Seat, Folding ...35 Into Power Transfer Unit Recreational Towing .
Page 227 INDEX Tie Down Hooks, Cargo ..157 Uconnect 8.4AN ..97, 124 Tilt Steering Column ..39 Uconnect Access..73, 124 Tires .
Page 228 NOTES...
Page 229 NOTES...
Page 230 NOTES...
Page 231 NOTES...
Page 232 NOTES...
Page 233 NOTES...
Page 234 NOTES...
Page 235 This guide has been prepared to help you get quickly acquainted with your new Jeep ® Brand Vehicle and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions,...
Page 236 DOWNLOAD A FREE ELECTRONIC COPY of the Owner’s Manual and Warranty Booklet by visiting: www.jeep.com/en/owners/manuals or www.jeep.com/en/warranty (U.S.); www.owners.mopar.ca/en (Canada). © 2015 FCA US LLC. All Rights Reserved. Jeep is a registered trademark of FCA US LLC. 16KL74-926-AA Cherokee Second Edition User Guide...

Jeep 2016 CHEROKEE User Manual

Introduction/Welcome

Controls at a Glance

Getting Started

Operating Your Vehicle

Electronics

Off-Road Capabilities

Utility

What to Do in Emergencies

Quick Links

Related Manuals for Jeep 2016 CHEROKEE

Summary of Contents for Jeep 2016 CHEROKEE

Table of Contents
