INTRODUCTION/WELCOME WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC (“FCA US”) vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. Your new FCA US vehicle has characteristics to enhance the driver's control under some driving conditions.
Page 6 INTRODUCTION/WELCOME VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines). WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.
Page 7 INTRODUCTION/WELCOME Rollover Warning • Utility vehicles have a significantly higher rollover rate than other types of vehicles. This vehicle has a higher ground clearance and a higher center of gravity than many passenger cars. It is capable of performing better in a wide variety of off-road applications.
Page 8 INTRODUCTION/WELCOME WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury. • Always make sure that objects cannot fall into the driver foot well while the vehicle is moving. Objects can become trapped under the brake pedal and accelerator pedal causing a loss of vehicle control.
Page 9 If your symptoms persist, please see an authorized dealer. When it comes to service, remember that your authorized dealer knows your Jeep ® vehicle best, has factory-trained technicians and genuine MOPAR parts, and cares ®...
Page 10: Controls At A Glance
CONTROLS AT A GLANCE DRIVER COCKPIT 1. Headlight Switch pg. 45 2. Turn Signal/Wiper/Washer/High Beams Lever (Behind Steering Wheel) pg. 47 3. AutoStick pg. 61 4. Driver Information Display (DID) Controls pg. 152 5. Instrument Cluster pg. 10 6. Speed Control pg. 51 7.
Page 11 CONTROLS AT A GLANCE 9. Glove Compartment 10. Automatic Climate Controls pg. 67 11. Switch Panel 12. Gear Selector pg. 60 13. Hood Release pg. 221 14. Emergency Brake Pedal 15. Power Mirrors 16. Power Windows 17. Power Window Locks...
Page 12: Instrument Cluster
CONTROLS AT A GLANCE INSTRUMENT CLUSTER 1. Tachometer 2. Speedometer 3. Driver Information Display (DID) pg. 152 (See page 194 for Instrument Cluster Warning Lights.)
Page 13 CONTROLS AT A GLANCE 4. Engine Temperature Gauge pg. 195 5. Fuel Door Location 6. Fuel Gauge pg. 200 (See page 200 for Instrument Cluster Indicator Lights.)
Page 14: Getting Started
GETTING STARTED KEY FOB Locking And Unlocking The Doors/Liftgate Push the LOCK button once to lock all the doors and the liftgate. Push the UNLOCK button once to unlock the driver’s door only and twice within five seconds to unlock all the doors and liftgate.
Page 15: Remote Start
GETTING STARTED REMOTE START Push the REMOTE START button on the Key Fob twice within five seconds. Pushing the REMOTE START button a third time shuts the engine off. To drive the vehicle, with a valid Keyless Enter-N-Go Key Fob within 5 ft (1.5m) of the driver's side of the vehicle, grab the front driver door handle to unlock the driver's door automatically, then push the START/STOP button.
Page 16: Keyless Enter-N-Go - Passive Entry
GETTING STARTED KEYLESS ENTER-N-GO — PASSIVE ENTRY The Keyless Enter-N-Go Passive Entry system is an enhancement to the vehicle’s Remote Keyless Entry (RKE) feature. This feature allows you to lock and unlock the vehicle's door(s) and liftgate without having to push the RKE Key Fob LOCK or UNLOCK buttons, as well as starting and stopping the vehicle with the push of a button.
Page 17 GETTING STARTED • If “Unlock All Doors 1st Press” is programmed all doors and liftgate will unlock when you push the liftgate button. If “Unlock Driver Door 1st Press” is pro- grammed only the liftgate will unlock when you push the liftgate button. To select between “Unlock Driver Door 1st Press”...
Page 18: Keyless Enter-N-Go - Ignition
GETTING STARTED KEYLESS ENTER-N-GO — IGNITION Starting Perform the following starting procedure with a Remote Keyless Entry (RKE) Key Fob inside the vehicle: 1. Place the gear selector in PARK or NEUTRAL. 2. While depressing the brake pedal, push the ENGINE START/STOP but- ton once.
Page 19: Vehicle Security Alarm
GETTING STARTED 3. Push the ENGINE START/STOP button a third time to return the ignition to the OFF position. NOTE: If the ignition is left in the ACC or ON/ RUN (engine not running) position and the transmission is in PARK, the system will automatically time out after 30 min- Ignition Positions utes of inactivity, and the ignition is re-...
Page 20: Seat Belt Systems
GETTING STARTED SEAT BELT SYSTEMS Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. Be sure everyone in your vehicle is in a seat and using a seat belt properly. Position the lap belt so that it is snug and lies low across your hips, below your abdomen.
Page 21: Supplemental Restraint System (Srs) - Air Bags
GETTING STARTED SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS Air Bag System Components Your vehicle may be equipped with the following air bag system components: • Occupant Restraint Controller (ORC) • Air Bag Warning Light • Steering Wheel and Column •...
Page 22 GETTING STARTED If it is necessary to modify the air bag system for persons with disabilities, contact your authorized dealer. Refer to the Owner's Manual on the DVD for further details regarding the Supple- mental Restraint System (SRS). Supplemental Knee Air Bags This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the steering column.
Page 23 GETTING STARTED Supplemental Side Air Bags This vehicle is equipped with Supplemental Seat-Mounted Side Air Bags (SABs) located in the outboard side of the front seats. The SABs are marked with a SRS AIRBAG or AIRBAG label sewn into the outboard side of the seats. This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains (SABICs) located above the side windows.
Page 24 GETTING STARTED Enhanced Accident Response System In the event of an impact, if the communication network remains intact, and the power remains intact, depending on the nature of the event, the ORC will determine whether to have the Enhanced Accident Response System perform the following functions: •...
Page 25: Child Restraints
GETTING STARTED Event Data Recorder (EDR) This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 26 GETTING STARTED LATCH – Lower Anchors And Tethers For CHildren Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The rear outboard seating positions have lower anchors and top tether anchors. The rear center seating position has a top tether anchor only.
Page 27 GETTING STARTED Center Seat LATCH Do not install a child restraint in the center position using the LATCH system. Use the seat belt and tether anchor to install a child seat in the center seating position. Center Arm Rest Tether For rearward facing infant seats secured in the center seat position with the vehicle seat belts, the rear center seat position has an armrest tether that secures the arm rest in the upward position.
Page 28 GETTING STARTED Installing The Child Restraint Using The Vehicle Seat Belts The seat belts in the passenger seating positions are equipped with a Switchable Automatic Locking Retractor (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint. Any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary.
Page 29 GETTING STARTED Tether Strap Installation 1. To access the top tether strap anchorages behind the rear seat, pull the carpeted floor panel away from the seat back, this will expose the top tether strap anchorages. 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.
Page 30: Head Restraints
GETTING STARTED HEAD RESTRAINTS Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear. WARNING! The head restraints for all occupants must be properly installed and adjusted prior to operating the vehicle or occupying a seat.
Page 31 GETTING STARTED WARNING! • All occupants, including the driver, should not operate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a collision. •...
Page 32: Front Seats
GETTING STARTED FRONT SEATS Power Seats Some models may be equipped with eight-way power driver and front passen- ger seats. The power seat switches are located on the outboard side of the seat. There are two switches that control the movement of the seat cushion and the seatback.
Page 33 GETTING STARTED Driver Memory Seat — If Equipped This feature allows the driver to store up to two different memory profiles for easy recall through a memory switch. Each memory profile contains desired position settings for the driver seat, side mirrors, and power tilt and telescopic steering column (if equipped) and a set of desired radio station presets.
Page 34 GETTING STARTED NOTE: • Memory profiles can be set without the vehicle in PARK, but the vehicle must be in PARK to recall a memory profile. • To set a memory profile to your RKE Key Fob, refer to “Linking And Unlinking The Remote Keyless Entry Key Fob To Memory”...
Page 35 GETTING STARTED Driver Two Memory Position Recall • To recall the memory setting for driver two using the memory switch, push MEMORY button number 2 on the memory switch. • To recall the memory settings for driver two using the RKE Key Fob, push the UNLOCK button on the RKE Key Fob linked to memory position 2.
Page 36 GETTING STARTED Manual Seat Adjustment Manual Front Seats Forward/Rearward Adjustment Some models may be equipped with a manual front passenger seat. The seat can be adjusted forward or rearward by using a bar located by the front of the seat cushion, near the floor.
Page 37 GETTING STARTED Manual Front Passenger Seatback Adjustment — Recline To adjust the seatback, lift the lever lo- cated on the outboard side of the seat, lean back to the desired position and release the lever. To return the seatback, lift the lever, lean forward and release the lever.
Page 38: Rear Seats
GETTING STARTED REAR SEATS 60/40 Split Rear Seat To Lower Rear Seat Either side of the rear seat can be lowered to allow for extended cargo space and still maintain some rear seating room. NOTE: Be sure that the front seats are fully upright and positioned forward. This will allow the rear seatback to fold down easily.
Page 39: Heated/Ventilated Seats
GETTING STARTED Reclining Rear Seat To recline the seatback, lift the lever located on the outboard side of the seat, lean back and release the lever at the desired position. To return the seatback, lift the lever, lean forward and release the lever. WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 40 GETTING STARTED WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.
Page 41 GETTING STARTED FRONT VENTILATED SEATS If your vehicle is equipped with ventilated seats, the seat cushion and seat back will have fans that draw the air from the passenger compartment and move air through fine perforations in the seat cover to help keep the driver and front passenger cooler in higher ambient temperatures.
Page 42: Heated Steering Wheel
GETTING STARTED HEATED STEERING WHEEL The steering wheel contains a heating element that helps warm your hands in cold weather. The heated steering wheel has only one temperature setting. Once the heated steering wheel has been turned on it will operate for up to 80 minutes before automatically shutting off.
Page 43: Tilt/Telescoping Steering Column
GETTING STARTED TILT/TELESCOPING STEERING COLUMN Manual Tilt/Telescoping Steering Column This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping lever is located below the steering wheel at the end of the steering column. To unlock the steering column, push the lever downward (toward the floor).
Page 44 GETTING STARTED Power Tilt/Telescoping Steering Column This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The power tilt/telescoping steering column lever is located below the multifunction lever on the steering column. To tilt the steering column, move the lever up or down as desired.
Page 45: Operating Your Vehicle
OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS 3.6L Engine Break-In For vehicles equipped with the 3.6L, use the following engine break-in recommendations: A long break-in period is not required for the drivetrain (engine, transmission, clutch, and rear axle) in your new vehicle. Drive moderately during the first 300 miles (500 km).
Page 46 OPERATING YOUR VEHICLE CAUTION! Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as an indication of difficulty.
Page 47: Headlight Switch
OPERATING YOUR VEHICLE For the first 1500 miles (2414 km): • Do not participate in track events, sport driving schools, or similar activities during the first 1500 miles (2414 km). NOTE: Check engine oil with every refueling and add if necessary. Oil and fuel consumption may be higher through the first oil change interval.
Page 48 OPERATING YOUR VEHICLE Automatic Headlights — If Equipped This system automatically turns the headlights on or off according to ambient light levels. To turn the system on, rotate the headlight switch to the A (AUTO) position. When the system is on, the Headlight Delay feature is also on. This means the headlights will stay on for up to 90 seconds after you turn the ignition switch to the OFF position.
Page 49: Turn Signal/Wiper/Washer/High Beam Lever
OPERATING YOUR VEHICLE The brightness of the instrument panel lighting can be regulated by rotating the dimmer control up (brighter) or down (dimmer). When the headlights are on you can supplement the brightness of the DID, radio and overhead console by rotating the control to its farthest position up until you hear a click.
Page 50 OPERATING YOUR VEHICLE Windshield Wipers And Washers The windshield wiper/washer controls are located on the multifunction lever on the left side of the steering column. The front wipers are operated by rotating a switch, located on the end of the lever. For information on the rear wiper/washer, refer to “Rear Window Wiper/Washer”...
Page 51 OPERATING YOUR VEHICLE Mist Use the Mist feature when weather conditions make occasional usage of the wipers necessary. Rotate the end of the lever downward to the Mist position and release for a single wiping cycle. NOTE: The mist feature does not activate the washer pump; therefore, no washer fluid will be sprayed on the windshield.
Page 52 OPERATING YOUR VEHICLE The Rain Sensing system has protection features for the wiper blades and arms, and will not operate under the following conditions: • Low Ambient Temperature — When the ignition is first turned ON, the Rain Sensing system will not operate until the wiper switch is moved, vehicle speed is greater than 0 mph (0 km/h), or the outside temperature is greater than 32°F (0°C).
Page 53: Automatic Dimming Mirrors
OPERATING YOUR VEHICLE AUTOMATIC DIMMING MIRRORS The rearview and driver side exterior mirror automatically adjusts for headlight glare from vehicles behind you. ELECTRONIC SPEED CONTROL When engaged, the Electronic Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h). The Electronic Speed Control buttons are located on the right side of the steering wheel.
Page 54 OPERATING YOUR VEHICLE To Set A Desired Speed Turn the Electronic Speed Control ON. When the vehicle has reached the desired speed, push the SET (+) or SET (-) button and release. Release the accelerator and the vehicle will operate at the selected speed. Once a speed has been set a message CRUISE CONTROL SET TO MPH (km/h) will appear indicating what speed was set.
Page 55 OPERATING YOUR VEHICLE To Decrease Speed When the Electronic Speed Control is set, you can decrease speed by pushing the SET - button. The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “Understanding Your Instrument Panel” in the Owner’s Manual on the DVD for more information.
Page 56: Adaptive Cruise Control (Acc)
OPERATING YOUR VEHICLE ADAPTIVE CRUISE CONTROL (ACC) If your vehicle is equipped with Adaptive Cruise Control the controls operate ex- actly the same as the electronic speed control with only a couple of differences. With this option you can set a specified distance you would like to maintain be- tween you and the vehicle in front of you.
Page 57 OPERATING YOUR VEHICLE Metric Speed (km/h) • Pushing the SET + button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h. • If the button is continually pushed, the set speed will continue to increase in 10 km/h increments until the button is released.
Page 58 OPERATING YOUR VEHICLE Distance Setting (ACC Only) The specified following distance for ACC can be set by varying the distance setting between four bars (longest), three bars (long), two bars (medium) and one bar (short). Using this distance setting and the vehicle speed, ACC calculates and sets the distance to the vehicle ahead.
Page 59 OPERATING YOUR VEHICLE WARNING! Adaptive Cruise Control (ACC) is a convenience system. It is not a substitute for active driving involvement. It is always the driver’s responsibility to be attentive of road, traffic, and weather conditions, vehicle speed, distance to the vehicle ahead; and, most importantly, brake operation to ensure safe operation of the vehicle under all road conditions.
Page 60 OPERATING YOUR VEHICLE FORWARD COLLISION WARNING (FCW) The Forward Collision Warning (FCW) system provides the driver with audible warnings and visual warnings within the Driver Information Display (DID), to warn the driver when it detects a potential frontal collision. The warnings are intended to provide the driver with enough time to react, avoid or mitigate the potential collision.
Page 61 OPERATING YOUR VEHICLE The far setting provides warnings for potential collisions more distant in front of the vehicle, allowing the driver to have the most reaction time to avoid a collision. More cautious drivers that do not mind frequent warnings may prefer this setting. NOTE: This setting gives you the most reaction time.
Page 62: Transmission Gear Selector
OPERATING YOUR VEHICLE TRANSMISSION GEAR SELECTOR Your vehicle is equipped with a fuel efficient 8 speed transmission. The gear selector is located in the center console. The transmission gear selector has PARK, REVERSE, NEUTRAL, DRIVE, and MANUAL (AutoStick) shift positions. Manual shifts can be made using the AutoStick shift...
Page 63: Autostick
OPERATING YOUR VEHICLE AUTOSTICK AutoStick is a driver-interactive transmission feature providing manual shift control, giving you more control of the vehicle. AutoStick allows you to maximize engine braking, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can also provide you with more control during passing, city driving, cold slippery conditions, mountain driving, trailer towing, and many other situations.
Page 64: Fuel Economy (Eco) Mode
OPERATING YOUR VEHICLE • Transmission shifting will be more noticeable when AutoStick is enabled. • The system may revert to automatic shift mode if a fault or overheat condition is detected. NOTE: When Selec-Speed or Hill Descent Control is enabled, AutoStick is not active. To disengage AutoStick, return the gear selector to the DRIVE position, or press and hold the (+) shift paddle (if the gear selector is already in DRIVE) until "D"...
Page 65: Stop/Start System - If Equipped
OPERATING YOUR VEHICLE STOP/START SYSTEM — IF EQUIPPED The Stop/Start function was developed to reduce fuel consumption. The system will stop the engine automatically during a vehicle stop if the required conditions are met. Releasing the brake pedal or pressing the accelerator pedal will automatically restart the engine.
Page 66 OPERATING YOUR VEHICLE • HVAC set to MAX A/C. • Engine has not reached normal operating temperature. • The transmission is not in a forward gear. • Hood is open. • Vehicle is in 4LO transfer case mode. • Brake pedal is not pressed with sufficient pressure. Other Factors Which Can Inhibit Autostop Include: •...
Page 67 OPERATING YOUR VEHICLE To Manually Turn Off The Stop/Start System 1. Push the STOP/START OFF switch (lo- cated on the switch bank). The light on the switch will illuminate. 2. The “STOP/START OFF” message will appear in Driver Information Display (DID).
Page 68: Sport Mode - If Equipped
OPERATING YOUR VEHICLE SPORT MODE — IF EQUIPPED Your vehicle is equipped with a Sport Mode feature. This mode is a configura- tion set up for typical enthusiast driving. The engine, transmission, and steering systems are all set to their SPORT set- tings.
Page 69: Automatic Temperature Controls (Atc)
OPERATING YOUR VEHICLE AUTOMATIC TEMPERATURE CONTROLS (ATC) Uconnect 5.0 Touchscreen Automatic Climate Controls Uconnect 5.0 Automatic Climate Controls 1 — Max A/C Button 8 — Rear Climate Button 2 — A/C Button 9 — Climate Off Button 3 — Air Recirculation Button 10 —...
Page 70 OPERATING YOUR VEHICLE Uconnect 8.4 Touchscreen Automatic Climate Controls Uconnect 8.4 Automatic Climate Controls 1 — MAX A/C Button 9 — Passenger Temperature Down 2 — A/C Button 10 — SYNC Button 3 — Air Recirculation Button 11 — Blower Control Buttons 4 —...
Page 71 OPERATING YOUR VEHICLE Climate Control Knobs Automatic Climate Controls 1 — Driver Temperature Up 7 — Passenger Temperature Down 2 — OFF Button 8 — AUTO Button 3 — Blower Control Knob 9 — Driver Temperature Down 4 — Passenger Temperature Up 10 —...
Page 72 OPERATING YOUR VEHICLE Air Conditioning (A/C) • If the air conditioning button is pushed while in AUTO mode, the system will exit AUTO mode and stay in A/C. The mode and blower will be set at the closest mode and blower position that the system was operating in AUTO. MAX A/C •...
Page 73: Parksense Front And Rear Park Assist
OPERATING YOUR VEHICLE PARKSENSE FRONT AND REAR PARK ASSIST ParkSense can be enabled and disabled by pushing the ParkSense switch located below the climate controls, on the switch panel. The four ParkSense sensors, located in the rear fascia/bumper, monitor the area behind the vehicle that is within the sensors field of view.
Page 74: Parkview Rear Back-Up Camera
OPERATING YOUR VEHICLE PARKVIEW REAR BACK-UP CAMERA You can see an on-screen image of the rear of your vehicle whenever the transmission is shifted into REVERSE. The ParkView Rear Back-Up Camera image will be displayed on the radio display screen, located on the center stack of the instrument panel.
Page 75: Blind Spot Monitoring
OPERATING YOUR VEHICLE BLIND SPOT MONITORING The Blind Spot Monitoring (BSM) system uses two radar-based sensors, located inside the rear bumper fascia, to detect Highway licensable vehicles (automobiles, trucks, motorcycles etc.) that enter the blind spot zones from the rear/front/side of the vehicle.
Page 76: Power Sunroof
OPERATING YOUR VEHICLE POWER SUNROOF The power sunroof switch is located on the overhead console. Opening Sunroof Express Open Push the switch rearward and release it within one-half second. The sunroof will fully open and stop automatically. Manual Open Push and hold the switch rearward to open the sunroof.
Page 77 OPERATING YOUR VEHICLE Venting Sunroof Push and release the button and the sunroof will open to the vent position. This is called “Express Vent” and will occur regardless of sunroof position. During Express Vent operation, any movement of the switch will stop the sunroof. Closing Sunroof Express Closing Push the switch forward and release it within one-half second.
Page 78 OPERATING YOUR VEHICLE Closing Power Shade Express Push the switch forward and release it within one-half second and the shade will close automatically from any position. Manual To close the shade, push and hold the switch in the forward position. NOTE: Any release of the switch will stop the movement and the shade will remain in a partially closed condition until the switch is pushed and held forward again.
Page 79: Wind Buffeting
OPERATING YOUR VEHICLE WIND BUFFETING Wind buffeting can be described as a helicopter-type percussion sound. If buffeting occurs with the rear windows open, adjust the front and rear windows together. If buffeting occurs with the sunroof open, adjust the sunroof opening, or adjust any window.
Page 80: Electronics
ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Phone Button pg. 137 2. Uconnect Voice Command Button pg. 118 3. Phone Hang Up Button pg. 137 4. Steering Wheel Audio control (Left- Behind Steering Wheel) pg. 151 5. Steering Wheel Audio control (Right- Behind Steering Wheel) pg. 151 6.
Page 81 ELECTRONICS 8. Uconnect System pg. 103 9. Back Button 10. Tune/Scroll Knob — Browse/Enter Button 11. AUX Jack pg. 110 12. USB Port pg. 110 13. SD Card Slot pg. 110 14. Power Outlet pg. 158...
Page 82: Cybersecurity
ELECTRONICS CYBERSECURITY Your vehicle may be a connected vehicle and may be equipped with both wired and wireless networks. These networks allow your vehicle to send and receive informa- tion. This information allows systems and features in your vehicle to function properly.
Page 83: Identifying Your Radio
ELECTRONICS IDENTIFYING YOUR RADIO Uconnect 5.0 • 5” Touchscreen • Three buttons on the faceplate on ei- ther side of the display Uconnect 5.0 Uconnect 8.4A • 8.4” Touchscreen • Climate button on the touchscreen in lower menu bar Uconnect 8.4A Uconnect 8.4AN •...
Page 84: Uconnect Access
ELECTRONICS UCONNECT ACCESS Uconnect Access — If Equipped (Available On Uconnect 8.4A/8.4AN — U.S. Residents Only) WARNING! • ALWAYS obey traffic laws and pay attention to the road. Some Uconnect Access services, including 9-1-1 and Assist, will NOT work without an operable 1X (voice/data) or 3G (data) network connection.
Page 85 ELECTRONICS NOTE: Vehicles sold in Canada and Mexico DO NOT have 9-1-1 call system capabilities. 9-1-1 or other emergency line operators in Canada and Mexico may not answer or respond to 9-1-1 system calls. 2. The Uconnect “Apps ” button in the center of the menu bar of the radio touchscreen.
Page 86 ELECTRONICS Why sign up for Uconnect Access? Here are just a few examples of things you’ll be able to do: • Know that help, if you need it, is only a button press away. • Lock and unlock your vehicle doors from hundreds of miles away. •...
Page 87 ELECTRONICS Via Mobile Apps — If Equipped • Aha by HARMAN — Aha by HARMAN makes it easy to instantly access your favorite Web content on the go. Choose from over 40,000+ stations spanning internet radio, personalized music, news, entertainment, hotels, weather, audiobooks, Facebook, Twitter, and more.
Page 88 ELECTRONICS 2. Uconnect Access Via Mobile — use the Uconnect Access App and your device's data plan to access your personal Pandora, iHeartRadio, Aha and Slacker accounts from the vehicle and control them using the touchscreen. Customer's data plan charges will apply.
Page 89 ELECTRONICS Maintaining Your Uconnect Access Account Selling Your Vehicle When you sell your vehicle, we recommend that you remove your Uconnect Access Account information from the vehicle. You can do this on the Mopar Owner Connect website moparownerconnect.com. Removing your account information cancels your subscription and makes your vehicle factory-ready for a new owner/subscriber.
Page 90 ELECTRONICS 1. Assist Call (8.4AN) — The rearview mirror contains an ASSIST push button which automatically connects the vehicle occupants to one of these predefined desti- nations for immediate support: • Roadside Assistance Call — If you get a flat tire, or need a tow, you’ll be connected to someone who can help anytime.
Page 91 ELECTRONICS may share information obtained through such recording and monitoring in accordance with regulatory requirements. You acknowledge, agree and consent to any recording, monitoring or sharing of information obtained through any such call recordings. 4. Yelp — Customers have the ability to search for nearby destinations or a Point Of Interest (POI) either by category or custom search by using keywords (for example, “Italian restaurant”).
Page 92 ELECTRONICS Uconnect Access Remote Features If you own a compatible iPhone or Android powered device, the Uconnect Access App allows you to remotely lock or unlock your doors, start your engine or activate your horn and lights from virtually anywhere. Your vehicle must be equipped with remote start and your vehicle must have an operable 1X (voice/data) or 3G (data) network connection).
Page 93 ELECTRONICS To use this feature after the Uconnect Access App is downloaded, login using your user name and password. You will need your four digit Uconnect Security PIN to confirm the request. Press the “closed lock” icon on your Uconnect Access App to lock the doors, and press the “open lock”...
Page 94 ELECTRONICS To Send A Text Message: 1. Push the Uconnect Phone Button on the steering wheel. 2. Wait for the beep. 3. Say “Text.” 4. Uconnect will prompt you “Say the phone number, or full name and phone type of the contact you want to send a message to.” 5.
Page 95: Uconnect 5.0
ELECTRONICS UCONNECT 5.0 Uconnect 5.0 Radio 1 — Radio Mode Button 10 — AM/FM/SXM Button 2 — Reverse Seek Button 11 — Browse/Enter Button Tune/ 3 — Forward Seek Button Scroll Knob 4 — Compass Information Button 12 — Back Function Button 5 —...
Page 96 ELECTRONICS 4. Once the time is set press the “Done” button on the touchscreen to exit the time screen. NOTE: In the Clock Setting Menu you can also select the “Show Time Status” button on the touchscreen, then select from “On” or “Off” to display the time in the status bar. Equalizer, Balance And Fade 1.
Page 97 ELECTRONICS Radio Operation Seek Up/Seek Down • Press the up or down button to seek through radio stations in AM, FM or SXM bands. • Hold either button to bypass stations without stopping. Store Radio Presets Manually The Radio stores up to 12 presets in each of the Radio modes. There are four visible presets at the top of the radio screen.
Page 98 ELECTRONICS Disc Operation Your vehicle may have a remote CD player located in the lower center console storage bin. • CD/Disc Mode is entered by either inserting a CD/Disc or by pushing the MEDIA button on the faceplate. Once in Media Mode, select “Disc.” •...
Page 99 ELECTRONICS UCONNECT 5.0 VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 5.0 system. Key Features: • 5” touchscreen •...
Page 100 ELECTRONICS Get Started 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition. 3. Speak clearly at a normal pace and volume while facing straight ahead. The microphone is positioned on the rearview mirror and aimed at the driver.
Page 101 ELECTRONICS Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. Push the VR button . After the beep, say: • Cancel to stop a current voice session • Help to hear a list of suggested Voice Commands •...
Page 102 ELECTRONICS Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button . After the beep, say: • Tune to ninety-five-point-five FM •...
Page 103 ELECTRONICS Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If Equipped). Voice operation is only available for connected USB and iPod devices. (Remote CD player optional and not available on all vehicles.) Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
Page 104 ELECTRONICS Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check device and feature compat- ibility and to find device pairing instructions. Push the Phone button .
Page 105: Uconnect 8.4A/8.4An
ELECTRONICS Additional Information © 2016 FCA US LLC. All rights reserved. Mopar, Mopar Owner Connect and Uconnect are registered trademarks of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc. Yelp, Yelp logo, Yelp burst and related marks are registered trademarks of Yelp.
Page 106 ELECTRONICS CAUTION! Do NOT attach any object to the touchscreen, doing so can result in damage to the screen. Setting The Time • Model 8.4AN synchronizes time automatically via GPS, so it should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A.
Page 107 ELECTRONICS Speed Adjusted Volume • Press the “Speed Adjusted Volume” button on the touchscreen to activate the Speed Adjusted Volume screen. The Speed Adjusted Volume is adjusted by pressing the volume level indicator. This alters the automatic adjustment of the audio volume with variation to vehicle speed.
Page 108 ELECTRONICS Radio Uconnect 8.4AN Radio 1 — Radio Station Presets 7 — Audio Settings 2 — Toggle Between Presets 8 — Seek Up 3 — Status Bar 9 — Direct Tune To A Radio Station 4 — View Small Navigation Map 10 —...
Page 109 ELECTRONICS Selecting Radio Stations • Press the desired radio band (AM, FM or SXM) button on the touchscreen. Seek Up/Seek Down • Press the Seek up or down arrow buttons on the touchscreen for less than two seconds to seek through radio stations. •...
Page 110 ELECTRONICS The following describes features that are available when in SiriusXM Satellite Radio mode: Seek Up/Seek Down • Press the Seek arrow buttons on the touchscreen for less than two seconds to seek through channels in SXM mode. • Press and hold either arrow button on the touchscreen for more than two seconds to bypass channels without stopping.
Page 111 ELECTRONICS Browse Lets you browse the SiriusXM channel listing or Genre listing. Favorites, Game Zone, Weather and Jump settings also provide a way to browse the SiriusXM channel list. Browse Sub-Menu Description Sub-Menu Shows the channel listing. Genre Provides a list of all genres, and lets you jump to a channel within the selected genre.
Page 112 ELECTRONICS Our Sirius satellite service is also available in PR (with coverage limitations). Our Internet radio service is available throughout our satellite service area and in AK and HI. ©2015 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.
Page 113 ELECTRONICS USB Port • Connect your compatible device using a USB cable into the USB Port. USB Memory sticks with audio files can also be used. Audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.
Page 114 ELECTRONICS MEDIA CONTROLS Media Controls 1 — Repeat Music Track 5 — Show Songs Currently In Cue To 2 — Music Track And Time Be Played 3 — Shuffle Music Tracks 6 — Browse Music By 4 — Music Track Information 7 —...
Page 115 ELECTRONICS Changing The Navigation Voice Prompt Volume 1. Press the “View Map” button on the touchscreen from the Nav Main Menu. 2. With the map displayed, press the “Settings” button on the touchscreen in the lower right area of the screen. 3.
Page 116 ELECTRONICS Finding A Place By Spelling The Name • From the Main Navigation Menu press the “Where to?” button on the touchscreen, press the “Points of Interest” button on the touchscreen, then press the “Spell Name” button on the touchscreen. •...
Page 117 ELECTRONICS Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen. Uconnect 8.4AN Map 1 — Distance To Next Turn 5 —...
Page 118 ELECTRONICS Adding A Stop • To add a stop you must be navigating a route. • Press the “Menu” button on the touchscreen to return to the Main Navigation menu. • Press the “Where To?” button on the touchscreen, then search for the extra stop. When another location has been selected, you can choose to cancel your previous route, add as the first destination or add as the last destination.
Page 119 ELECTRONICS SiriusXM Travel Link (8.4AN & US Market Only) In addition to delivering over 130 channels of the best sports, entertainment, talk, and commercial-free music, SiriusXM offers premium data services that work in conjunction with compatible navigation systems. SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips.
Page 120: Uconnect 8.4A/8.4An Voice Recognition Quick Tips
ELECTRONICS UCONNECT 8.4A/8.4AN VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 8.4AN system. If you see the icon on your touchscreen, you have the Uconnect 8.4AN system.
Page 121 ELECTRONICS Get Started 1. Visit UconnectPhone.com to check device and feature compatibility and to find device pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition. 3. Speak clearly at a normal pace and volume while facing straight ahead. The microphone is positioned on the rearview mirror and aimed at the driver.
Page 122 ELECTRONICS b. Long Press: Push and hold continuously for a few milliseconds, then release the VR button for Siri functions. After you hear the familiar Siri "double beep," say a command. 3. Phone Hang Up Button. Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system.
Page 123 ELECTRONICS Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button . After the beep, say: • Tune to ninety-five-point-five FM •...
Page 124 ELECTRONICS Siri Eyes Free — If Equipped Siri lets you use your voice to send text messages, select media, place phone calls and much more. Siri uses your natural language to understand what you mean and will respond back to confirm your requests. The system is designed to keep your eyes on the road and your hands on the wheel by letting Siri help you perform useful tasks.
Page 125 ELECTRONICS Getting Started Ensure Siri is enabled on your iPhone. Enable Siri 1 — Select Settings on your iPhone 3 — Select Siri 2 — Select General 4 — Enable Siri...
Page 126 ELECTRONICS 1. Pair your Siri enabled device to the vehicles sound system. Refer to “Uconnect Phone” in “Electronics” for a detailed pairing procedure. Pair Your iPhone 2. Push and Hold, then release the Uconnect Voice Recognition (VR) but- on the steering wheel. After you hear the familiar Siri "double beep,"...
Page 127 ELECTRONICS 3. After the double beep, begin speaking to Siri. Examples of Siri commands and questions: • "Play Rolling Stones" • "Send text message to John" • "Read text message from Sarah" • "Take me to the nearest coffee shop" NOTE: •...
Page 128 ELECTRONICS Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If Equipped). Voice operation is only available for connected USB and iPod devices. (Remote CD player optional and not available on all vehicles.) Push the VR button . After the beep, say one of the following commands and follow the prompts to switch your media source or choose an artist.
Page 129 ELECTRONICS Phone Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit: • UconnectPhone.com for device compatibility and pairing instructions. Canadian residents can visit: •...
Page 130 ELECTRONICS Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button say Listen. (Must have compatible device paired to Uconnect system.) 1. Once an incoming text message is read to you, push the Phone button . After the beep, say: Reply.
Page 131 ELECTRONICS Climate (8.4A/8.4AN) Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button . After the beep, say one of the following commands: •...
Page 132 ELECTRONICS Navigation (8.4A/8.4AN) The Uconnect navigation feature helps you save time and become more productive when you know exactly how to get to where you want to go. (Navigation is optional on the Uconnect 8.4A system. See your dealer to activate navigation at any time.) 1.
Page 133 ELECTRONICS NOTE: Your vehicle may be transmitting data as authorized by the subscriber. An included trial and/or subscription is required to take advantage of the Uconnect Access services in the next section of this guide. To register with Uconnect Access, press the “Apps”...
Page 134 ELECTRONICS Register (8.4A/8.4AN) To unlock the full potential of Uconnect Access in your vehicle, you first need to register with Uconnect Access. 1. Push the ASSIST button on your rearview mirror. Uconnect 8.4 Registration 2. Press the “Uconnect Care” button on the touchscreen. 3.
Page 135 ELECTRONICS Mobile App (8.4A/8.4AN) You’re only a few steps away from using remote commands and playing your favorite music in your vehicle. To link your internet radio accounts: 1. Download the Uconnect Access App on your device. 2. Press the Via Mobile icon on the navi- gation bar at the bottom of the app.
Page 136 ELECTRONICS Voice Texting (8.4A/8.4AN) You must be registered with Uconnect Access and have a compatible MAP – enabled device to use your voice to send a personalized text message. (Not compatible with iPhone.) 1. To send a message, push the Phone button .
Page 137 ELECTRONICS Yelp (8.4A/8.4AN) Once registered with Uconnect Access, you can use your voice to search for the most popular places or things around you. 1. Push the VR button . After the beep, say: Launch YELP. 2. Once the YELP home screen appears on the touchscreen, push the VR button , then say: YELP search.
Page 138 ELECTRONICS SiriusXM Travel Link (8.4A/8.4AN — US Market Only) Need to find a gas station, view local movie listings, check a sports score or the 5 - day weather forecast? SiriusXM Travel Link is a suite of services that brings a wealth of information right to your Uconnect 8.4AN system.
Page 139: Uconnect Phone
ELECTRONICS UCONNECT PHONE Uconnect Phone (Bluetooth Hands Free Calling) Uconnect 5.0 Phone Menu 1 — Call/Redial/Hold 7 — Uconnect Phone Settings Menu 2 — Mobile Phone Signal Strength 8 — Text Messaging 3 — Currently Paired Mobile Phone 9 — Direct Dial Pad 4 —...
Page 140 ELECTRONICS Uconnect 8.4A/8.4AN Phone Menu 1 — Favorite Contacts 12 — Browse Phone Book Entries 2 — Mobile Phone Battery Life (Contains 9-1-1) 3 — Currently Paired Mobile Phone 13 — End Call 4 — Mobile Phone Signal Strength 14 — Call/Redial/Hold 5 —...
Page 141 ELECTRONICS The Uconnect Phone feature enables you to place and receive hands-free mobile phone calls. Drivers can also place mobile phone calls using their voice or by using the buttons on the touchscreen (see Voice Command section). The hands-free calling feature is made possible through Bluetooth technology — the global standard that enables different electronic devices to connect to each other wirelessly.
Page 142 ELECTRONICS Start Pairing Procedure On The Radio Uconnect 5.0: 1. Place the ignition in the ACC or ON position. 2. Press the “Phone” button. 3. Select “Settings.” 4. Select “Paired Phones.” 5. Select “Add device.” • Uconnect Phone will display an “In progress”...
Page 143 ELECTRONICS Complete The iPhone Pairing Procedure: 1. When prompted on the mobile phone, accept the connection request from Uconnect Phone. NOTE: Some mobile phones will require you to enter the PIN number. Pairing Request Select The iPhone's Priority Level When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite mobile phone.
Page 144 ELECTRONICS Complete The Android Pairing Procedure: 1. Confirm the passkey shown on the mobile phone matches the passkey shown on the Uconnect system then accept the Bluetooth pairing request. NOTE: Some mobile phones require the PIN to be entered manually, enter the PIN num- ber shown on the Uconnect screen.
Page 145 ELECTRONICS Transfer Ongoing Call Between Handset And Vehicle • During an on-going call, press the “Transfer” button on the Phone main screen to transfer an on-going call between handset and vehicle. Phonebook The Uconnect system will automatically sync your phonebook from your paired phone, if this feature is supported by your phone.
Page 146 ELECTRONICS Using Do Not Disturb With Do Not Disturb, you can disable notifications from incoming calls and texts, allowing you to keep your eyes on the road and hands on the wheel. For your convenience there is a counter display to keep track of your missed calls and text messages while you were using Do Not Disturb.
Page 147 ELECTRONICS To enable incoming text messaging: iPhone 1. Press the settings button on the mobile phone. 2. Select Bluetooth. • Ensure Bluetooth is enabled, and the mobile phone is paired to the Uconnect system. 3. Select located under DEVICES next to Uconnect. 4.
Page 148 ELECTRONICS Android Devices 1. Push the Menu button on the mobile phone. 2. Select Settings. 3. Select Connections. 4. Turn “Show Notifications” to On. • A pop up will appear asking you to accept a request for permission to connect to your messages.
Page 149 ELECTRONICS Here’s How: 1. Push the Uconnect Phone button and wait for the beep, then say “reply.” Uconnect will give the following prompt: “Please say the message you would like to send.” 2. Wait for the beep and say one of the pre-defined messages. (If you are not sure, you can say “help”).
Page 150 ELECTRONICS Mobile Phone won’t pair to system: • Perform a hard reset in the mobile phone by removing the battery (if removable — see your mobile phone’s owner manual). • Delete pairing history in mobile phone and Uconnect system; usually found in phone’s Bluetooth connection settings.
Page 151: Video Entertainment System (Ves)
ELECTRONICS VIDEO ENTERTAINMENT SYSTEM (VES) System Operation • Cycle the ignition to the ON or ACC position. • The LCD screens are located in the rear of the front seats. To open the LCD screen, lift the cover. • The system may be controlled by the front seat occupants using the touch- screen radio, or by the rear seat occu- pants using the remote control.
Page 152 ELECTRONICS Play A Blu-ray Disc The Blu-ray Disc player is located in the center console. To view a Blu-ray insert the disc into the Blu-ray Disc Player. Playback will begin automatically after the Blu-ray Disc is recognized by the disc drive. If playback does not begin automatically after the disc is inserted into Blu-ray Disc Player follow these steps:...
Page 153: Steering Wheel Audio Controls
ELECTRONICS Auxiliary Audio/Video Input Jacks Audio/Video RCA/HDMI Jacks (AUX/ HDMI Jacks) on the side of each front seat enable the LCD monitor to display video directly from a video camera, con- nect video games for display on the screen, or play music directly from an MP3 player.
Page 154: Driver Information Display (Did)
ELECTRONICS DRIVER INFORMATION DISPLAY (DID) The DID features a driver interactive display that is located in the instrument cluster. Pushing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings. For additional information, refer to “Programmable Features”...
Page 155: Programmable Features
ELECTRONICS PROGRAMMABLE FEATURES DID Main Menu Selectable Items The DID can be used to view the following main menu items: NOTE: Depending on the vehicles options, feature settings may vary. • Speedometer • Trip • MPH to km/h • Audio •...
Page 156 ELECTRONICS DID Screen Setup The following settings allow you to change what information is displayed in the instrument cluster as well as the location that information is displayed: • None • Average MPH (L/100km) • Compass • Current MPH (L/100km) •...
Page 157: Universal Garage Door Opener (Homelink)
ELECTRONICS UNIVERSAL GARAGE DOOR OPENER (HomeLink) • HomeLink replaces up to three hand- held transmitters that operate devices such as garage door openers, motor- ized gates, lighting or home security systems. The HomeLink unit is pow- ered by your vehicles 12 Volt battery. •...
Page 158 ELECTRONICS 3. Push and hold the HomeLink button you want to program while you push and hold the hand-held transmitter button. 4. Continue to hold both buttons and observe the indicator light. The HomeLink indicator will flash slowly and then rapidly after HomeLink has received the frequency signal from the hand-held transmitter.
Page 159: Power Inverter
ELECTRONICS Using HomeLink To operate, push and release the programmed HomeLink button. Activation will now occur for the programmed device (i.e., garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.,). The hand-held transmitter of the device may also be used at any time. WARNING! •...
Page 160: Power Outlets
ELECTRONICS WARNING! To Avoid Serious Injury or Death DO NOT: • insert any objects into the receptacles • touch with wet hands Close the lid when not in use. If this outlet is mishandled, it may cause an electric shock and failure. POWER OUTLETS There are three 12 Volt electrical power outlets on this vehicle.
Page 161 ELECTRONICS The rear power outlet is located in the right rear cargo area. The power outlets are labeled with either a “key” or a “battery” symbol to indicate how the outlet is powered. Power outlets labeled with a “key” are powered when the ignition switch is in the ON/RUN or ACC position, while the outlets labeled with a “battery”...
Page 162: Off-Road Capabilities (4Wd Operation)
OFF-ROAD CAPABILITIES (4WD OPERATION) QUADRA-TRAC I FOUR-WHEEL DRIVE Quadra-Trac I Operating Instructions/Precautions — 3.6L Only The Quadra-Trac I is a single-speed (HI range only) transfer case, which provides convenient full-time four-wheel drive. No driver interaction is required. The Brake Traction Control (BTC) System, which combines standard ABS and Traction Control, provides resistance to any wheel that is slipping to allow additional torque transfer to wheels with traction.
Page 163 OFF-ROAD CAPABILITIES (4WD OPERATION) Shifting Procedures 4WD HI To 4WD LOW With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h), the ignition switch in the ON/RUN position or the engine running, shift the transmission into NEUTRAL and press the “4WD LOW”...
Page 164: Selec-Terrain
OFF-ROAD CAPABILITIES (4WD OPERATION) behind the N symbol will blink, indicating shift in progress. The light will stop blinking (stay on solid) when the shift to NEUTRAL (N) is complete. A “FOUR WHEEL DRIVE SYSTEM IN NEUTRAL” message will display on the Driver Information Display (DID).
Page 165: Quadra-Lift
OFF-ROAD CAPABILITIES (4WD OPERATION) Mud – Off road calibration for use on low traction surfaces such as mud. Driveline is maximized for traction. Some binding may be felt on less forgiving surfaces. The electronic brake controls are set to limit traction control management of throttle and wheel spin.
Page 166 OFF-ROAD CAPABILITIES (4WD OPERATION) Operation • Pushing the “Up” or “Down” button once will move the suspension one position higher or lower from the current position, assuming all conditions are met (i.e., engine running and all doors and liftgate closed). •...
Page 167 OFF-ROAD CAPABILITIES (4WD OPERATION) • Aero Mode (Lowers the vehicle approximately 0.6 in (15 mm) – This position provides improved aerodynamics by lowering the vehicle. The vehicle will auto- matically enter Aero Mode when the vehicle speed remains between 52 mph (83 km/h) and 56 mph (90 km/h) for greater than 20 seconds or if the vehicle speed exceeds 56 mph (90 km/h).
Page 168: Hill Start Assist/Hill Descent Control/Selec Speed Control - If Equipped
OFF-ROAD CAPABILITIES (4WD OPERATION) HILL START ASSIST/HILL DESCENT CONTROL/SELEC SPEED CONTROL — IF EQUIPPED • The Hill Start Assist system assists the driver when starting a vehicle from a stop on a hill. • The Hill Descent Control system maintains vehicle speed while descending hills during off-road driving situations and is available in 4WD LOW range.
Page 169: Utility
UTILITY TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) Engine/ Model Cooling Frontal Area Max. GTW (Gross Max. Trailer Tongue Wt. Model Trailer Wt.) (See Note) 3.0L- Die- HD Cool- 55 sq ft 7,400 lbs 740 lbs sel Engine (5.11 sq m) (3,357 kg) (336 kg) 3.0L- Die-...
Page 170 UTILITY Trailer Hitch Receiver Cover Removal (Summit Models) — If Equipped Your vehicle may be equipped with a trailer hitch receiver cover, this must be removed to access the trailer hitch receiver (if equipped). This hitch receiver cover is located at the bottom center of the rear fascia. 1.
Page 171 UTILITY To reinstall the hitch receiver cover after towing repeat the procedure in reverse order. NOTE: Be sure to engage all tabs of the hitch receiver cover in the bumper fascia prior to installation. Hitch Receiver Cover 1 — Hitch Receiver Cover Tab Loca- tions 2 —...
Page 172 UTILITY Trailer Hitch Receiver Cover Removal (SRT Models) — If Equipped Your vehicle may be equipped with a trailer hitch receiver cover, this must be removed to access the trailer hitch receiver (if equipped). This hitch receiver cover is located at the bottom center of the rear fascia. 1.
Page 173 UTILITY 2. Pull the bottom of the cover outward (towards you). Hitch Receiver Cover 3. Lower back down to disengage the tabs located at the top of the hitch receiver cover and then pull outwards to remove. To reinstall the hitch receiver cover after towing repeat the procedure in reverse order.
Page 174: Recreational Towing (Behind Motorhome, Etc.)
UTILITY RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Four-Wheel Four-Wheel Towing Condi- Wheel OFF the Two-Wheel Drive Models Drive Models tion Ground Drive Models Without 4–LOW With 4–LOW Range Range See Instructions • Transmis- sion in PARK •...
Page 175 UTILITY 6. Install a suitable clamping device, designed for towing, to secure the front wheels in the straight position. CAUTION! Towing with the rear wheels on the ground will cause severe transmission damage. Damage from improper towing is not covered under the New Vehicle Limited Warranty.
Page 176 UTILITY Shifting Into NEUTRAL (N) WARNING! You or others could be injured or killed if you leave the vehicle unattended with the transfer case in the NEUTRAL (N) position without first fully engaging the parking brake. The transfer case NEUTRAL (N) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move, even if the transmission is in PARK.
Page 177 UTILITY 10. Firmly apply the parking brake. 11. With the transmission and transfer case in NEUTRAL, push and hold the ENGINE START/STOP button until the engine turns off. 12. Move the transmission gear selector to PARK. Release the brake pedal. 13.
Page 178 UTILITY Shifting Out Of NEUTRAL (N) Use the following procedure to prepare your vehicle for normal usage: 1. Bring the vehicle to a complete stop, leaving it connected to the tow vehicle. 2. Firmly apply the parking brake. 3. Start the engine. 4.
Page 179: Srt
FUEL ECONOMY (ECO) MODE The Fuel Economy (ECO) mode can improve the vehicle's overall fuel economy during normal driving conditions. Push the “ECO” switch in the center stack of the instrument panel to activate or disable ECO mode. An amber light indicates when ECO mode is engaged.
Page 180: Selec-Track
SELEC-TRACK Selec-Track combines the capabilities of the vehicle control systems, along with driver input, to provide the best perfor- mance for all terrains. Rotate the mode control knob to select the following Selec-Track positions: Selec-Track switch • Sport - Dry weather, on-road calibra- tion.
Page 181 compensate for lack of driver experience or familiarity with the race track. Use of this feature in low traction (cold, wet, gravel, etc.) conditions may results in excess wheel slip outside this systems control resulting in an aborted launch. Preconditions: •...
Page 182: Srt Performance Features
4. When the above conditions have been met, the DID will read “Release Brake”. 5. Keep the vehicle pointed straight. Launch control will be active until the vehicle reaches 62 mph (100 km/h), at which point the Electronic Stability Control (ESC) system will return to its current ESC mode.
Page 183 0-60 MPH (0-100 km/h) When selected, this screen displays the time it takes for the vehicle to go from 0 to 60 MPH (0 to 100 km/h). 0-100 MPH (0-161 km/h) When selected, this screen displays the time it takes for the vehicle to go from 0 to 100 MPH (0 to 161 km/h).
Page 184 Home When Home is selected, the following options will be available: • A series of six images which can be selected by the user. • A left and right arrow to allow the user to scroll through vehicle images. • A short-cut to the Drive Modes feature. Timers When the Timers Page is selected you will be able to select from following “Tickets”: Recent...
Page 185 NOTE: The distance measurement will be aborted if the brake pedal is released before the vehicle comes to a complete stop. Brake Speed • Displays the speed the vehicle is traveling when the brake pedal is depressed. NOTE: Brake Distance and Speed timers will only display "ready" when vehicle is traveling at greater than 30 MPH (48 km/h).
Page 186: Summer/Three-Season Tires
Vehicle Speed • Vehicle Speed measures the current speed of the vehicle in either mph or km/h, starting at 0 with no maximum value. Steering Wheel Angle • Steering Wheel Angle utilizes the steering angle sensor to measure the degree of the steering wheel relative to zero.
Page 187: Diesel
DIESEL DIESEL ENGINE BREAK-IN RECOMMENDATIONS The diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommendations are followed: • Warm up the engine before placing it under load. • Do not operate the engine at idle for prolonged periods. •...
Page 188 DIESEL CAUTION! If the “Water in Fuel Indicator Light” remains on, DO NOT START the engine before you drain the water from the fuel filters to avoid engine damage. Refer to “Maintenance Procedures/Draining Fuel/Water Separator Filter” in “Maintaining Your Vehicle” in your Diesel Supplement on the DVD for further information. Extreme Cold Weather The engine block heater is a resistance heater installed in the water jacket of the engine.
Page 189: Diesel Fuel Filters/Water Separator
DIESEL DIESEL FUEL FILTERS/WATER SEPARATOR Draining Fuel/Water Separator If the “Water in Fuel” indicator light is illuminated and an audible chime is heard five times, you should stop the engine and drain the water from the sepa- rator. The best access to this water drain valve is from under the vehicle.
Page 190: Exhaust Regeneration
DIESEL CAUTION! • Diesel fuel will damage blacktop paving surfaces. Drain the filter into an appropriate container. • Do not prefill the fuel filter when installing a new fuel filter. There is a possibility debris could be introduced into the fuel filter during this action. It is best to install the filter dry and allow the in-tank lift pump to prime the fuel system.
Page 191: Diesel Exhaust Fluid
DIESEL Exhaust Service Required — See Dealer Now This message indicates regeneration has been disabled due to a system malfunction. The Powertrain control Module (PCM) will register a fault code and the instrument panel will display the Malfunction Indicator Light (MIL). CAUTION! See your authorized dealer, as damage to the exhaust system could occur soon with continued operation.
Page 192 DIESEL nitrogen oxides (NOx) into harmless nitrogen (N2) and water vapor (H2O), two natural components of the air we breathe. You can operate with the comfort that your vehicle is contributing to a cleaner, healthier world environment for this and generations to come.
Page 193 DIESEL • The DEF gauge may also not immediately update after a refill if the temperature of the DEF fluid is below 12F (-11C). The DEF line heater will possibly warm up the DEF fluid and allow the gauge to update after a period of run time. Under very cold conditions, it is possible that the gauge may not reflect the new fill level for several drives.
Page 194 DIESEL • Engine Will Not Restart Refill DEF — This message will display when the DEF driving range is less than 1 mile, DEF fluid top off is required or the engine will not restart. The message will be displayed in the DID during vehicle start up, and it will be accompanied by a single chime.
Page 195 DIESEL • Engine Will Not Start Service DEF System See Dealer — This message will display when the fault detected is not serviced after the Engine will not restart Service DEF System See Dealer message is displayed on the next subsequent restart. Your engine will not start unless you vehicle is serviced by your authorized dealer.
Page 196: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
Page 197 WHAT TO DO IN EMERGENCIES – Engine Temperature Warning Light This light warns of an overheated engine condition. If the light turns on and a warning chime sounds while driving, safely pull over and stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the vehicle.
Page 198 WHAT TO DO IN EMERGENCIES – Air Bag Warning Light This light will turn on for four to eight seconds as a bulb check when the ignition switch is first turned to the ON/RUN position. If the light is either not on during starting, stays on, or turns on while driving, have the system inspected at an authorized dealer as soon as possible.
Page 199 WHAT TO DO IN EMERGENCIES Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low EVIC or DID display. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
Page 200 WHAT TO DO IN EMERGENCIES – Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the brake system master cylinder reservoir.
Page 201 WHAT TO DO IN EMERGENCIES – Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD II that monitors engine and automatic transmission control systems. The light will illuminate when the key is in the ON/RUN position before engine start. If the bulb does not come on when turning the key from OFF to ON/RUN, have the condition checked promptly.
Page 202 WHAT TO DO IN EMERGENCIES – Electronic Stability Control (ESC) Activation/Malfunction Indicator Light The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on when the ignition switch is turned to the ON/RUN position. It should go out with the engine running. If the “ESC Activation/Malfunction Indicator Light” comes on continuously with the engine running, a malfunction has been detected in the ESC system.
Page 203 WHAT TO DO IN EMERGENCIES – Vehicle Security Light This light will flash rapidly for approximately 15 seconds when the vehicle security alarm is arming. The light will flash at a slower speed continuously after the alarm is set. The security light will also come on for about three seconds when the ignition is first turned on.
Page 204: If Your Engine Overheats
WHAT TO DO IN EMERGENCIES Vehicles Equipped With Keyless Enter-N-Go 1. Without pushing the brake pedal, push the ENGINE START/STOP button and place the ignition to the ON/RUN position (do not start the engine.) 2. Fully depress the accelerator pedal, slowly, three times within 10 seconds. 3.
Page 205: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 206 WHAT TO DO IN EMERGENCIES Jack Location The scissor-type jack and tire changing tools are located in rear cargo area, below the load floor. Spare Tire Stowage The spare tire is stowed under the load floor in the rear cargo area and is secured to the body with a special wing nut.
Page 207 WHAT TO DO IN EMERGENCIES 6. Block both the front and rear of the wheel diagonally opposite of the jacking position. For example, if changing the right front tire, block the left rear wheel. NOTE: Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 208 WHAT TO DO IN EMERGENCIES CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. 1. Remove the spare tire, jack, and tools from storage. 2. Loosen (but do not remove) the wheel lug nuts by turning them to the left, one turn, while the wheel is still on the ground.
Page 209 WHAT TO DO IN EMERGENCIES 4. For the front axle, place the jack on the body flange just behind the front tire as indicated by the triangular lift point symbol on the sill molding. Do not raise the vehicle until you are sure the jack is fully engaged. Front Jacking Location 5.
Page 210 WHAT TO DO IN EMERGENCIES 7. Remove the lug nuts and wheel. 8. Position the spare wheel/tire on the vehicle and install the lug nuts with the cone-shaped end toward the wheel. Lightly tighten the nuts. CAUTION! Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the spare tire is mounted incorrectly.
Page 211 WHAT TO DO IN EMERGENCIES 12. Remove the small center cap and securely store the road wheel in the cargo area. 13. Have the aluminum road wheel and tire repaired as soon as possible, properly secure the spare tire with the special wing nut torqued to 3.7 ft-lbs (5 N·m), reinstall the jack and tool kit foam tray, and latch the...
Page 212: Jump-Starting
WHAT TO DO IN EMERGENCIES JUMP-STARTING If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump-starting can be dangerous if done improperly so please follow the procedures in this section carefully.
Page 213 WHAT TO DO IN EMERGENCIES Preparations For Jump-Start The battery in your vehicle is located under the passenger's front seat. There are remote locations located under the hood to assist in jump-starting. Remote Battery Posts 1 — Remote Positive (+) Post 2 —...
Page 214 WHAT TO DO IN EMERGENCIES WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result. Jump-Starting Procedure WARNING! Failure to follow this jump-starting procedure could result in personal injury or property damage due to battery explosion.
Page 215: Emergency Tow Hooks - If Equipped
WHAT TO DO IN EMERGENCIES CAUTION! Do not run the booster vehicle engine above 2000 rpm since it provides no charging benefit, wastes fuel and can damage booster vehicle engine. 6. Once the engine is started, remove the jumper cables in the reverse sequence: Disconnecting The Jumper Cables 1.
Page 216: Manual Park Release
WHAT TO DO IN EMERGENCIES CAUTION! Tow hooks are for emergency use only, to rescue a vehicle stranded off road. Do not use tow hooks for tow truck hookup or highway towing. You could damage your vehicle. MANUAL PARK RELEASE WARNING! Always secure your vehicle by fully applying the parking brake, before activating the Manual Park Release.
Page 217 WHAT TO DO IN EMERGENCIES 4. While the metal latch is in the open position, simultaneously pull upwards on the tether strap until the lever clicks and latches in the released position. The transmission is now out of PARK and the vehicle can be moved. Released Position CAUTION! Closing the armrest while the Manual Park Release is activated may damage the...
Page 218: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing” in the “Starting and Operating”...
Page 219 WHAT TO DO IN EMERGENCIES Proper towing or lifting equipment is required to prevent damage to your vehicle. Use only tow bars and other equipment designed for this purpose, following equipment manufacturer’s instructions. Use of safety chains is mandatory. Attach a tow bar or other towing device to main structural members of the vehicle, not to bumpers or associated brackets.
Page 220: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES Four-Wheel Drive Models The manufacturer recommends towing with all wheels OFF the ground. Acceptable methods are to tow the vehicle on a flatbed or with one end of vehicle raised and the opposite end on a towing dolly. If flatbed equipment is not available, and the transfer case is operable, vehicles with a two-speed transfer case may be towed (in the forward direction, with ALL wheels on the ground), IF the transfer case is in NEUTRAL (N) and the transmission is in PARK.
Page 221 WHAT TO DO IN EMERGENCIES CAUTION! • Racing the engine or spinning the wheels may lead to transmission overheating and failure. Allow the engine to idle with the transmission in NEUTRAL for at least one minute after every five rocking-motion cycles. This will minimize overheating and reduce the risk of transmission failure during prolonged efforts to free a stuck vehicle.
Page 222: Cap-Less Fuel Fill Funnel
WHAT TO DO IN EMERGENCIES CAP-LESS FUEL FILL FUNNEL The funnel for the Cap-Less Fuel System is located on top of the spare tire or in the storage tub if not equipped with a spare tire. If your vehicle is out of fuel and an auxiliary fuel can is needed, insert the funnel into the filler neck and proceed to fill the vehicle.
Page 223: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE OPENING THE HOOD 1. Pull the hood release lever located below the steering wheel at the base of the instrument panel. 2. Reach into the opening beneath the center of the hood and move the safety latch lever while lifting the hood at the same time.
Page 224: Engine Compartment
MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT ENGINE COMPARTMENT — 3.6L 1. Remote Jump Start Positive Terminal 2. Engine Oil Dipstick 3. Power Distribution Center (Fuses) 4. Engine Coolant Reservoir Pressure Cap 5. Remote Jump Start Negative Terminal...
Page 225 MAINTAINING YOUR VEHICLE 6. Engine Oil Fill 7. Brake Fluid Reservoir 8. Air Cleaner Filter 9. Washer Fluid Reservoir...
Page 226 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 5.7L 1. Remote Jump Start Positive Terminal 2. Engine Oil Dipstick 3. Power Distribution Center (Fuses) 4. Engine Coolant Reservoir Pressure Cap 5. Remote Jump Start Negative Terminal...
Page 227 MAINTAINING YOUR VEHICLE 6. Engine Coolant Reservoir 7. Engine Oil Fill 8. Brake Fluid Reservoir 9. Air Cleaner Filter 10. Washer Fluid Reservoir...
Page 228 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.0L DIESEL 1. Remote Jump Start Positive Terminal 2. Engine Oil Dipstick 3. Power Distribution Center (Fuses) 4. Engine Coolant Reservoir Pressure Cap 5. Remote Jump Start Negative Terminal...
Page 229 MAINTAINING YOUR VEHICLE 6. Engine Oil Fill 7. Brake Fluid Reservoir 8. Air Cleaner Filter 9. Washer Fluid Reservoir...
Page 230 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 6.4L 1. Remote Jump Start Positive Terminal 2. Engine Oil Dipstick 3. Power Distribution Center (Fuses) 4. Engine Coolant Reservoir Pressure Cap 5. Engine Coolant Reservoir...
Page 231 MAINTAINING YOUR VEHICLE 6. Remote Jump Start Negative Terminal 7. Engine Oil Fill 8. Brake Fluid Reservoir 9. Air Cleaner Filter 10. Washer Fluid Reservoir...
Page 232: Non-Srt Fluid Capacities
MAINTAINING YOUR VEHICLE NON-SRT FLUID CAPACITIES U.S. Metric Fuel (Approximate) 3.6L and 5.7L Engines 25 Gallons 94.0 Liters Engine Oil With Filter 3.6L Engine (SAE 0W-20, API Certified) 6 Quarts 5.6 Liters 5.7L Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System* 3.6L Engine (MOPAR Antifreeze/Engine Coolant...
Page 233 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible”...
Page 234: Srt Fluid Capacities
MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Use only Mopar ZF 8&9 Speed ATF Auto- matic Transmission Fluid or equivalent. Failure to use the correct fluid may affect the function or performance of your trans- mission.
Page 235: Srt Fluids, Lubricants, And Genuine Parts
MAINTAINING YOUR VEHICLE SRT FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant or Genuine Part Engine Coolant We recommend you use MOPAR Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) that meets the requirements of FCA Material Standard MS.90032. Engine Oil For best performance and maximum protection under all types of operating conditions, the manufacturer only rec-...
Page 236: Diesel Fluid Capacities
MAINTAINING YOUR VEHICLE DIESEL FLUID CAPACITIES U.S. Metric Fuel (Approximate) 3.0L Diesel Engine 24.6 Gallons 93.1 Liters Diesel Exhaust Fluid Tank 8 Gallons 30.3 Liters Engine Oil With Filter 3.0 Liter Diesel Engine (SAE 5W-30 Synthetic, 8 Quarts 7.7 Liters ACEA C3 Certified Low Ash) Cooling System...
Page 237 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Fuel Filters We recommend you use MOPAR Fuel Fil- ter. Must meet 3 micron rating. Using a fuel filter that does not meet the manufacturers filtration and water separating requirements can severely impact fuel system life and reli- ability.
Page 238: Maintenance Procedures
MAINTAINING YOUR VEHICLE Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Use only Mopar ZF 8&9 Speed ATF Auto- matic Transmission Fluid, or equivalent. Failure to use the correct fluid may affect the function or performance of your trans- mission.
Page 239 MAINTAINING YOUR VEHICLE Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. NOTE: Under no circumstances should oil change intervals exceed 10,000 miles (16,000 km), twelve months or 350 hours of engine run time, whichever comes first. The 350 hours of engine run or idle time is generally only a concern for fleet customers.
Page 240 MAINTAINING YOUR VEHICLE...
Page 241 MAINTAINING YOUR VEHICLE...
Page 242 MAINTAINING YOUR VEHICLE...
Page 243 MAINTAINING YOUR VEHICLE SRT MAINTENANCE SCHEDULE The Scheduled Maintenance services listed in this manual must be done at the times or mileages specified to protect your vehicle warranty and ensure the best vehicle performance and reliability. More frequent maintenance may be needed for vehicles in severe operating conditions, such as dusty areas and very short trip driving.
Page 244 MAINTAINING YOUR VEHICLE At Each Stop For Fuel • Check the engine oil level. Refer to “Maintenance Procedures/Engine Oil” in “Maintaining Your Vehicle” for further information. • Check the windshield washer solvent and add if required. Once A Month • Check tire pressure and look for unusual wear or damage. •...
Page 245 MAINTAINING YOUR VEHICLE...
Page 246 MAINTAINING YOUR VEHICLE...
Page 247 MAINTAINING YOUR VEHICLE...
Page 248 MAINTAINING YOUR VEHICLE...
Page 249 MAINTAINING YOUR VEHICLE...
Page 250: Maintenance Schedule - Diesel Engine
MAINTAINING YOUR VEHICLE MAINTENANCE SCHEDULE — DIESEL ENGINE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Based on engine operation conditions, the oil change indicator message will illuminate.
Page 251 MAINTAINING YOUR VEHICLE Maintenance Chart — Diesel Fuel Up To B5 Biodiesel Required Maintenance Refer to the Maintenance Schedules on the following pages for required mainte- nance. At Every Oil Change Interval As Indicated By Oil Change Indicator System: • Change oil and filter. •...
Page 252 MAINTAINING YOUR VEHICLE...
Page 253 MAINTAINING YOUR VEHICLE...
Page 254 MAINTAINING YOUR VEHICLE...
Page 255 MAINTAINING YOUR VEHICLE...
Page 256: Fuses
MAINTAINING YOUR VEHICLE FUSES Power Distribution Center The Power Distribution Center is located in the engine compartment near the battery. This center contains cartridge fuses, micro fuses, relays, and circuit breakers. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
Page 257 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink – Drive Train Control Module 30 Amp Pink – Slip Differential Control 30 Amp Pink – Sunroof - If Equipped 30 Amp Pink – Rear Defroster 25 Amp Clear –...
Page 258 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description – 30 Amp Green Audio Amplifier – 10 Amp Red PCM (If Equipped) – 15 Amp Blue HID Headlamp RH - If Equipped – 10 Amp Red Dual Batt Control (If Equipped) –...
Page 259: Adding Fuel
MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Micro Fuse Description F103 – 10 Amp Red Cabin Heater (Diesel Engine Only)/Rear HVAC F104 – 20 Amp Yellow Power Outlets (Instrument Panel/Center Console) CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is properly positioned and fully latched.
Page 260 MAINTAINING YOUR VEHICLE 2. Open the fuel filler door. NOTE: In certain cold conditions, ice may pre- vent the fuel door from opening. If this occurs, lightly push on the fuel door to break the ice buildup and re-release the fuel door using the inside release button.
Page 261: Tires - General Information
MAINTAINING YOUR VEHICLE TIRES — GENERAL INFORMATION Tire Pressures Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...
Page 262 MAINTAINING YOUR VEHICLE Spare Tires — If Equipped NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to the “Tire Service Kit” section located in your Owner’s Information kit for further information. CAUTION! Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with a compact or limited-use temporary spare installed.
Page 263 MAINTAINING YOUR VEHICLE Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not. This spare tire may have limited tread life.
Page 264 MAINTAINING YOUR VEHICLE CAUTION! Avoid products or automatic car washes that use acidic solutions or strong alkaline additives or harsh brushes. These products and automatic car washes may damage the wheel's protective finish. Such damage is not covered by the New Vehicle Limited Warranty.
Page 265: Replacement Bulbs
MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Interior Bulbs Bulb Number Glove Compartment Lamp Grab Handle Lamp L002825W5W Overhead Console Reading Lamps VT4976 Rear Cargo Lamp 214–2 Visor Vanity Lamp V26377 Underpanel Courtesy Lamps Instrument Cluster (General Illumination) Telltale/Hazard Lamp Exterior Bulbs Bulb Number Headlamps (Low Beam) - If Equipped Premium Headlamps (Low/High Beam)
Page 266: Consumer Assistance
CONSUMER ASSISTANCE FCA US LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1-877-426-5337 FCA CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1-800-465-2001 (English) Phone: 1-800-387-9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf) equipment at its customer center.
Page 267: Publications Ordering
Owner's Manual, Navigation/Uconnect Manu- als or Warranty Booklet. United States customers may visit the Jeep Contact Us page at www.jeep.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Compartment Material” from the left menu.
Page 268: Reporting Safety Defects In The United States
CONSUMER ASSISTANCE REPORTING SAFETY DEFECTS IN THE UNITED STATES If you believe that your vehicle has a defect that could cause a collision or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the manufacturer. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 269: Mopar® Accessories
• Roof Mount Cargo Basket board Carrier Carrier and Cargo Net For the full line of Authentic Jeep Accessories by Mopar, visit your local dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents. NOTE: All parts are subject to availability.
Page 270: Faq's
FAQ’s FREQUENTLY ASKED QUESTIONS GETTING STARTED How do I install my LATCH Equipped Child Seat? pg. 24 How do I program my Front Seat Memory? pg. 31 ELECTRONICS Which radio is in my vehicle? • Uconnect 5.0 pg. 81 • Uconnect 8.4A/8.4AN pg. 81 How do I activate the Audio Jack? •...
Page 271: Index
INDEX Access Assistance Towing ..194 Uconnect ..82, 83, 87 Audio Jack....110 Accessories .
Page 272 INDEX Child Seat Installation ..25 Diesel Exhaust Fluid (DEF) ..189 Diesel Fuel Water Separator ..187 Install A LATCH-Compatible Child Disabled Vehicle Towing ..194, 216 Restraint .
Page 273 INDEX Enhanced Accident Response Glass Cleaning ... .236 Feature ....220 Ethanol....231 Hands-Free Phone (Uconnect) .
Page 274 INDEX Remote Start ... .13 Malfunction Indicator Light (Check Unlock The Doors ..12 Engine) ....199 Unlock The Liftgate .
Page 275 INDEX Glass Sunroof ...74 Reporting Safety Defects..266 Inverter ....157 Restraint, Head ... . .28 Lift Gate .
Page 276 INDEX ....52 Towing Vehicle Behind A Speed Control (Cruise Control) ..51 Motorhome ... . .172 Trailer Towing Home .
Page 277 NOTES USB Port....110 Washer Adding Fluid ...236 Using Access Washers, Windshield ..48 Uconnect .
Page 278 NOTES...
Page 279 NOTES...
Page 280 NOTES...
Page 281 NOTES...
Page 282 NOTES...
Page 283 This guide has been prepared to help you get quickly acquainted with your new Jeep Brand Vehicle and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions,...
Page 284 DOWNLOAD A FREE ELECTRONIC COPY of the Owner’s Manual and Warranty Booklet by visiting: www.jeep.com/en/owners/manuals or www.jeep.com/en/warranty (U.S.); www.owners.mopar.ca/en (Canada). © 2016 FCA US LLC. All Rights Reserved. Jeep is a registered trademark of FCA US LLC. 16WK741-926-AC Grand Cherokee Third Edition User Guide...

This manual is also suitable for:

Grand cherokee srt 2016

Jeep GRAND CHEROKEE 2016 User Manual

Introduction/Welcome

Controls at a Glance

Getting Started

Operating Your Vehicle

Electronics

Off-Road Capabilities (4Wd Operation)

Utility

Srt

Diesel

What to Do in Emergencies

Maintaining Your Vehicle

Consumer Assistance

Mopar® Accessories

Faq's

Index

Quick Links

Related Manuals for Jeep GRAND CHEROKEE 2016

Summary of Contents for Jeep GRAND CHEROKEE 2016

This manual is also suitable for:

Table of Contents
