Summary of Contents for Jeep 2016 WRANGLER

  • Page 1 WRA N G LER 2016 U SE R GUI DE...
  • Page 2 If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/Uconnect Manuals or Warranty Booklet by calling 1-877-426-5337 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer. The driver’s primary the road.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION/WELCOME OFF-ROAD CAPABILITIES (4WD OPERATION) WELCOME FROM FCA US LLC ..3 FOUR–WHEEL DRIVE OPERATION CONTROLS AT A GLANCE (COMMAND-TRAC I OR ROCK-TRAC) . . 93 DRIVER COCKPIT ....6 AXLE LOCK (TRU-LOK) —...
  • Page 4 TABLE OF CONTENTS MOPAR® ACCESSORIES AND JEEP® PERFORMANCE PARTS AUTHENTIC ACCESSORIES AND JEEP PERFORMANCE PARTS BY MOPAR . . 143 FREQUENTLY ASKED QUESTIONS FREQUENTLY ASKED QUESTIONS . . . 144 INDEX ....146...
  • Page 5: Introduction/Welcome

    INTRODUCTION/WELCOME WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC (“FCA US”) vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. Your new FCA US vehicle has characteristics to enhance the driver's control under some driving conditions.
  • Page 6 INTRODUCTION/WELCOME This is a specialized utility vehicle designed for both on-road and off-road use. It can go places and perform tasks for which conventional two-wheel drive enclosed vehicles were not intended. It handles and maneuvers differently from many passenger cars both on-road and off-road, so take time to become familiar with your vehicle.
  • Page 7 If your symptoms persist, please see an authorized dealer. When it comes to service, remember that your authorized dealer knows your Jeep ® vehicle best, has factory-trained technicians and genuine MOPAR ®...
  • Page 8: Controls At A Glance

    CONTROLS AT A GLANCE DRIVER COCKPIT 1. Turn Signal/Lights Lever (behind steering wheel) pg. 29 2. Instrument Cluster pg. 8 3. Wiper/Washer Lever (behind steering wheel) pg. 31 4. Audio System pg. 54 5. Power Windows 6. Glove Compartment 7. Climate Controls pg. 36...
  • Page 9 CONTROLS AT A GLANCE 8. Switch Panel • Heated Seats pg. 28 • Hazard Warning Light • Electronic Stability Control (ESC) OFF pg. 106 9. Gear Selector 10. Speed Control pg. 33 11. Ignition Switch 12. Electronic Vehicle Information Center (EVIC) Controls pg. 88 13.
  • Page 10: Instrument Cluster

    CONTROLS AT A GLANCE INSTRUMENT CLUSTER 1. Fuel Filler Door Location 2. Fuel Gauge 3. Speedometer (See page 103 for Instrument Cluster Warning Lights.)
  • Page 11 CONTROLS AT A GLANCE 4. Tachometer 5. Engine Temperature Gauge (See page 108 for Instrument Cluster Indicator Lights.)
  • Page 12: Getting Started

    GETTING STARTED KEY FOB Locking And Unlocking The Doors/Swing Gate Push the LOCK button once to lock all the doors and swing gate. Push the UNLOCK button once to unlock the driver’s door only and twice within five seconds to unlock all the doors and swing gate.
  • Page 13: Remote Start - If Equipped

    GETTING STARTED Panic Alarm 1. Push the PANIC button once to turn the panic alarm on. 2. Wait approximately three seconds and push the PANIC button a second time to turn the panic alarm off. WARNING! • Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons.
  • Page 14: Vehicle Security Alarm

    GETTING STARTED VEHICLE SECURITY ALARM The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the ignition for unauthorized operation. While the Vehicle Security Alarm is armed, interior switches for door locks and decklid release are disabled. If something triggers the alarm, the Vehicle Security Alarm will provide the following audible and visible signals: the horn will pulse, the park lamps and/or turn signals will flash, and the Vehicle Security Light in the instrument cluster will flash.
  • Page 15: Occupant Restraint Systems

    GETTING STARTED OCCUPANT RESTRAINT SYSTEMS Some of the most important safety features in your vehicle are the restraint systems: • Seat Belt Systems • Supplemental Restraint Systems (SRS) Air Bags • Child Restraints SEAT BELT SYSTEMS Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. Be sure everyone in your vehicle is in a seat and using a seat belt properly.
  • Page 16 GETTING STARTED SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS Air Bag System Components Your vehicle may be equipped with the following air bag system components: • Occupant Restraint Controller (ORC) • Air Bag Warning Light • Steering Wheel and Column •...
  • Page 17 GETTING STARTED Refer to the “Supplemental Restraint System (SRS)” in “Things To Know Before Starting Your Vehicle” in the Owner's Manual on the DVD for further information. WARNING! • Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly.
  • Page 18 GETTING STARTED Enhanced Accident Response System In the event of an impact, if the communication network remains intact, and the power remains intact, depending on the nature of the event, the ORC will determine whether to have the Enhanced Accident Response System perform the following functions: •...
  • Page 19 GETTING STARTED Event Data Recorder (EDR) This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
  • Page 20 GETTING STARTED LATCH – Lower Anchors And Tethers For CHildren (Four Door Models) Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The rear outboard seating positions have lower anchors and top tether anchors. The rear center seating position has a top tether anchor only.
  • Page 21 GETTING STARTED Locating Tether Anchorages In addition, there are tether strap anchors located behind each rear seatback, near the floor. Two Door Vehicle Tether Locations Four Door Vehicle Tether Locations Center Seat LATCH (Two-Door Models) WARNING! This vehicle does not have a center seating position. Do not use the center lower LATCH anchorages to install a child seat in the center of the back seat.
  • Page 22 GETTING STARTED 4. Tighten all of the straps as you push the child restraint rearward and downward into the seat. Remove slack in the straps according to the child restraint manufacturer’s instructions. 5. Test that the child restraint is installed tightly by pulling back and forth on the child seat at the belt path.
  • Page 23 GETTING STARTED Tether Strap Installation 1. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. 2. If your vehicle is equipped with adjustable rear head restraints, raise the head restraint, and where possible, route the tether strap under the head restraint and between the two posts.
  • Page 24: Head Restraints

    GETTING STARTED HEAD RESTRAINTS Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear. WARNING! The head restraints for all occupants must be properly installed and adjusted prior to operating the vehicle or occupying a seat.
  • Page 25 GETTING STARTED Rear Head Restraints — 2 Door Model The rear seat head restraints are not adjustable. They can be removed to make it easier to take out the rear seat. To remove the head restraint, push the button on each of the two head restraint guides and pull upward on the head restraint.
  • Page 26: Front Seats

    GETTING STARTED FRONT SEATS Front Seat Adjustment The seat can be adjusted forward or rearward by using a bar located by the front of the seat cushion, near the floor. While sitting in the seat, lift up on the bar located under the seat cushion and move the seat forward or rearward.
  • Page 27 GETTING STARTED Manual Seat Height Adjustment — If Equipped The driver's seat height can be raised or lowered by using the ratcheting handle, located on the outboard side of the seat. Pull upward on the handle to raise the seat, push downward on the handle to lower the seat.
  • Page 28: Rear Seats

    GETTING STARTED Front Passenger Easy Entry Seat — Two-Door Models Pull upward on the recline lever (toward the rear of the vehicle) and slide the entire seat forward. To return the seat to a sitting position, rotate the seatback upright until it locks and push the seat rearward until the track locks.
  • Page 29: Tilt Steering Column

    GETTING STARTED To Raise The Rear Seat Lift up on the seatback to return it to the upright position. WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be severely injured or killed.
  • Page 30: Heated Seats

    GETTING STARTED HEATED SEATS On some models, the front driver and passenger seats may be equipped with heaters in both the seat cushions and seatbacks. There are two heated seat switches that allow the driver and passenger to operate the seats independently.
  • Page 31: Operating Your Vehicle

    OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in.
  • Page 32 OPERATING YOUR VEHICLE • Rotate the center portion of the lever upward to the next detent position to brighten the odometer and radio controls when the parking lights or headlights are on. • Rotate the center portion of the lever upward to the last detent to turn on the interior lighting.
  • Page 33: Wiper/Washer Lever

    OPERATING YOUR VEHICLE WIPER/WASHER LEVER Windshield Wiper Operation Rotate the end of the lever upward to the second detent past the intermittent set- tings for low-speed wiper operation. Ro- tate the end of the lever upward to the third detent past the intermittent set- tings for high-speed wiper operation.
  • Page 34 OPERATING YOUR VEHICLE Windshield Washers To use the washer, pull the lever toward you and hold while spray is desired. If the lever is pulled while in the delay range, the wiper will start and continue to operate for two or three wipe cycles after the lever is released, and then resume the intermittent interval previously selected.
  • Page 35: Electronic Speed Control

    OPERATING YOUR VEHICLE ELECTRONIC SPEED CONTROL When engaged, the Electronic Speed Control takes over accelerator operations at speeds greater than 25 mph (40 km/h). The Electronic Speed Control buttons are located on the right side of the steering wheel. NOTE: In order to ensure proper operation, the Electronic Speed Control System has been designed to shut down if multiple...
  • Page 36 OPERATING YOUR VEHICLE To Set A Desired Speed Turn the Electronic Speed Control ON. When the vehicle has reached the desired speed, push the SET (-) button and release. Release the accelerator and the vehicle will operate at the selected speed. NOTE: The vehicle should be traveling at a steady speed and on level ground before pushing the SET (-) button.
  • Page 37 OPERATING YOUR VEHICLE To Decrease Speed When the Electronic Speed Control is set, you can decrease speed by pushing the SET (-) button. The drivers preferred units can be selected through the instrument panel settings if equipped. Refer to “Understanding Your Instrument Panel” in the Owner’s Manual on the DVD for more information.
  • Page 38: Manual Climate Controls

    OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS Manual Climate Controls 1 — Rotate Blower Control 4 — Push A/C Button 2 — Push Air Recirculation Button 5 — Rotate Mode Control 3 — Rotate Temperature Control 6 — Push Rear Window Defroster Button Air Recirculation Use Recirculation for maximum A/C operation.
  • Page 39: Automatic Temperature Controls (Atc)

    OPERATING YOUR VEHICLE AUTOMATIC TEMPERATURE CONTROLS (ATC) Automatic Temperature Controls 1 — Rotate Blower Control 4 — Push A/C Button 2 — Push Air Recirculation Button 5 — Rotate Mode Control 3 — Rotate Temperature Control 6 — Push Rear Window Defroster Button Automatic Operation •...
  • Page 40: Sunrider And Soft Top

    OPERATING YOUR VEHICLE SUNRIDER AND SOFT TOP Two Door Sunrider Open Follow these simple steps to open the Sunrider feature. 1. Unclip and move the sun visors to the side. 2. Release the header latches from the loops on the windshield frame. Step 2 3.
  • Page 41 OPERATING YOUR VEHICLE 4. Grasp the header and lift the top back. Make sure the material is folded back as shown. Step 4 5. Locate the straps to secure the side bows. Wrap the straps around the bows as shown. Repeat on the other side. 6.
  • Page 42 OPERATING YOUR VEHICLE Two Door Soft Top Down Follow these simple steps to lower the Two Door soft top. 1. Remove the side and back windows. Step 1 2. Fold and place the Sail Panels on top of your Wrangler. Step 2...
  • Page 43 OPERATING YOUR VEHICLE 3. Release header latches from the windshield frame. Step 3 4. Make sure the plastic sleeves are slid rearward over the Sunrider link to lock in the link (Sunrider Models only). Step 4...
  • Page 44 OPERATING YOUR VEHICLE 5. Release the Sunrider latch (both sides). Step 5 6. Open the swing gate and lower the top. NOTE: Ensure the fabric does not overhang the sides of the vehicle. • To raise the soft top, perform the above steps in the opposite order.
  • Page 45 OPERATING YOUR VEHICLE Four Door Sunrider Down Follow these simple steps to open the Sunrider feature. 1. Unclip and move the sun visors to the side. 2. Release the header latches from the loops on the windshield frame. Step 2 3.
  • Page 46 OPERATING YOUR VEHICLE 4. Fold the top so that the material forms a "W" as shown. Enter the vehicle and move the material into two folds. Step 4 5. Fold back the front section of the top and gently rest the header on top of the rear portion of the deck.
  • Page 47 OPERATING YOUR VEHICLE 6. Secure the top by using the two provided straps. Each strap will wrap around the side bow and Velcro to itself; use one strap on each side of the vehicle. NOTE: • Failure to fold the fabric rearward will allow the material to sag and may block the rearview mirror.
  • Page 48 OPERATING YOUR VEHICLE 2. Fold and place the Sail Panels on top of your Wrangler. Step 2 3. Release header latches from the windshield frame. Step 3...
  • Page 49 OPERATING YOUR VEHICLE 4. Fold header rearward, pulling the fabric to the rear. Step 4 5. Fold the top so that the material forms a "W" as shown. Enter the vehicle and move the material into two folds. Step 5...
  • Page 50 OPERATING YOUR VEHICLE 6. Release Sunrider latch (both sides). Step 6 Step 6...
  • Page 51 OPERATING YOUR VEHICLE 7. Open the swing gate and lower the top. NOTE: Ensure the fabric does not overhang the sides of the vehicle. • To raise the soft top, perform the above steps in the opposite order. Step 7 CAUTION! •...
  • Page 52: Hard Top And Freedom Top

    OPERATING YOUR VEHICLE HARD TOP AND FREEDOM TOP Freedom Top Removal Follow these simple steps to remove the front panels. 1. Fold down the sun visor, and move it to the side. 2. Turn the rear fasteners (knobs) (located on the overhead speaker bar assembly) counterclockwise until they can be removed.
  • Page 53 OPERATING YOUR VEHICLE 4. Turn the rear L-shaped lock (located above the shoulder belt anchorage). Step 4 5. Unlatch the header panel latch located at the top of the windshield. 6. Remove the left-hand panel. • To remove the right panel, follow the steps above except for Step 3.
  • Page 54 OPERATING YOUR VEHICLE Hard Top Removal Follow these simple steps to remove the hard top. 1. Remove both front panels. Refer to “Front Panel(s) Removal” above. 2. Open both doors. 3. Remove the two Torx head screws that secure the hard top at the B-pillar (near the top of the door) using a #40 Torx head driver (Four–Door Only).
  • Page 55: Dual Top - If Equipped

    OPERATING YOUR VEHICLE DUAL TOP – IF EQUIPPED • If your vehicle is equipped with a Dual Top, you must remove one of the tops from the vehicle. • Two Door - If the soft top is removed, the pivot brackets must also be removed from the sport bar.
  • Page 56: Electronics

    ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Voice Command Button pg. 85 2. Uconnect Phone Button pg. 82 3. Steering Wheel Audio Controls (Left – Behind Steering Wheel) pg. 80 4. Volume Knob/ON Button 5. Eject Button...
  • Page 57 ELECTRONICS 6. Steering Wheel Audio Controls (Right – Behind Steering Wheel) pg. 80 7. Uconnect 430/430N Radio pg. 65 8. Tune/Scroll Knob/Browse/Enter Button 9. Audio Jack pg. 81 10. USB Port (Inside Console) pg. 81...
  • Page 58: Cybersecurity

    ELECTRONICS CYBERSECURITY Your vehicle may be a connected vehicle and may be equipped with both wired and wireless networks. These networks allow your vehicle to send and receive informa- tion. This information allows systems and features in your vehicle to function properly.
  • Page 59: Uconnect 130

    ELECTRONICS UCONNECT 130 Uconnect 130 1 — CD Eject Button 9 — Set Clock Button 2 — Seek Down Button 10 — Audio Settings/Rotate To Tune 3 — Seek Up Button 11 — Radio Sales Code 4 — AM/FM Button 12 —...
  • Page 60 ELECTRONICS 5. Push the TUNE/SCROLL control knob to save the changes. 6. Push any button/knob or wait five seconds to exit. Equalizer, Balance And Fade 1. Push the TUNE/SCROLL control knob and “BASS” will display. 2. Rotate the TUNE/SCROLL control knob to select the desired setting. 3.
  • Page 61: Uconnect 130 With Siriusxm Satellite Radio

    ELECTRONICS UCONNECT 130 WITH SiriusXM SATELLITE RADIO Uconnect 130 With SiriusXM Satellite Radio 1 — CD Eject Button 12 — Audio Jack 2 — Seek Down Button 13 — Set Preset/CD Random Play 3 — Seek Up Button 14 — Station Preset Buttons 4 —...
  • Page 62 ELECTRONICS Clock Setting 1. Push and hold the TIME button until the hours blink. 2. Turn the TUNE/SCROLL control knob to set the hours. 3. Push the TUNE/SCROLL control knob until the minutes begin to blink. 4. Turn the TUNE/SCROLL control knob to set the minutes. 5.
  • Page 63 ELECTRONICS SiriusXM Satellite Radio SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 to cancel.
  • Page 64: Uconnect 230

    ELECTRONICS UCONNECT 230 Uconnect 230 1 — CD Eject Button 13 — Audio Jack 2 — Seek Down Button 14 — Radio Sales Code 3 — Seek Up Button 15 — AUX Mode Button 4 — Scan Radio Stations Button 16 —...
  • Page 65 ELECTRONICS • Your radio has many features that add to the comfort and convenience of you and your passengers. Some of these radio features should not be used when driving because they take your eyes from the road or your attention from driving. Clock Setting 1.
  • Page 66 ELECTRONICS SETUP Button • Pushing the SETUP button allows you to select between items that are available in that particular mode. • Turn the TUNE/SCROLL control knob to scroll through the entries. Push the AUDIO/SELECT button to select an entry and make changes. SiriusXM Satellite Radio SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase.
  • Page 67: Uconnect 430/430N

    ELECTRONICS Audio Jack Operation The AUX/Audio Jack provides a means to connect a portable audio device, such as an MP3 player or an iPod, to the vehicle’s sound system. This requires the use of a 3.5 mm stereo audio patch cable. •...
  • Page 68 ELECTRONICS NOTE: • Your radio may not be equipped with the Uconnect Voice Command and Uconnect Phone features. To determine if your radio has these features, push the Voice Command button on the radio. You will hear a voice prompt if you have the feature, or see a message on the radio stating “Uconnect Phone not available”...
  • Page 69 ELECTRONICS Equalizer, Balance And Fade Audio Control Menu • Push the AUDIO button on the face- plate on the right side of the radio. • Use either the “arrow” buttons on the touchscreen or the sliders to adjust BASS, MID, and/or TREBLE. •...
  • Page 70 ELECTRONICS Radio Operation Radio Operation 1 — Radio Tuner Tabs 6 — Station Scan 2 — Individual Presets 7 — Seek Down 3 — Search/Browse 8 — Direct Tune 4 — Radio Station/Track Info 9 — Seek Up 5 — Sort Presets •...
  • Page 71 ELECTRONICS • Once the desired station is found, press and hold one of the “PRESETS” buttons on the touchscreen in the list to the right, until the preset key flashes and the station text on the button on the touchscreen changes. NOTE: If the Presets are not visible on the right side of the screen, press the “PRESETS”...
  • Page 72 ELECTRONICS Insert A CD/DVD Disc • To insert a disc, push the LOAD button on the faceplate. • With the printed side upwards, insert the disc into the disc slot of the radio. The radio pulls the disc in automatically and closes the flip screen. The radio selects the appropriate mode after the disc is recognized, and starts playing the first track.
  • Page 73 ELECTRONICS Copying Music From CD • Push the LOAD button on the faceplate. • Insert a disc, then push the MY FILES button on the faceplate. Select the “MY MUSIC” button on the touchscreen. • Press the “Add Music Files to HDD” button on the touchscreen, then press the “Disc”...
  • Page 74 ELECTRONICS Copying Pictures To The HDD • Insert either a CD or a USB device containing your pictures in JPEG format. • Push the MY FILES button on the faceplate. • Press the “My Pictures” button on the touchscreen to get an overview of the currently stored images, then press the “Add”...
  • Page 75 ELECTRONICS Playing Music From The HDD • Push the MEDIA button on the faceplate to display the media source tabs at the top of the screen. Press the “HDD” button on the touchscreen. Press the desired track button on the touchscreen to play or press the “SEARCH/BROWSE” button on the touchscreen to search by artist, by album, by song, by genre, from a folder, or from Favorites.
  • Page 76 ELECTRONICS Garmin Navigation • Uconnect 430N integrates Garmin’s consumer-friendly navigation into your ve- hicle. Garmin Navigation includes a database with over six million points of interest. • Press the “NAV” button in the upper right corner of the touchscreen to access the Navigation system.
  • Page 77 ELECTRONICS Finding A Place By Spelling The Name • From the Main Navigation Menu press the “Where To?” button on the touch- screen. Next, press the “Points of Interest” button on the touchscreen then press the “Spell Name” button on the touchscreen. •...
  • Page 78 ELECTRONICS Following Your Route Your route is marked with a magenta line on the map. If you depart from the original route, your route is recalculated. A speed limit icon could appear as you travel on major roadways. Following Your Route 1 —...
  • Page 79: Siriusxm Satellite Radio/Travel Link

    ELECTRONICS Taking A Detour To take a detour you must be navigating a route. • Press the “back arrow” icon button on the touchscreen multiple times to return to the Main Navigation menu. • Press the “Detour” button on the touchscreen. NOTE: If the route you are currently taking is the only reasonable option, the device might not calculate a detour.
  • Page 80 ELECTRONICS Search/Browse • Press the “magnifying glass” button on the touchscreen to search/browse the SiriusXM channel listing by Favorites and Categories such as Song, Artist and Channel Name. The Search/Browse also allows you to manage your Favorites. SAT Browse SiriusXM Satellite Radio Favorites (SAT Favorites) •...
  • Page 81 ELECTRONICS Display SAT Favorites List • Press the “Search/Browse” button on the touchscreen and select “Favorites” from the SAT Browse screen. • Press the desired favorites button on the touchscreen to switch the SAT tuner to the corresponding channel. You may use the “LIST” button on the touchscreen to toggle between: •...
  • Page 82: Steering Wheel Audio Controls

    ELECTRONICS Replay Option Option Description Play/Pause Press to pause content playback. Press Pause/Play again to resume playback. Rewind/RW Rewinds the channel content in steps of five seconds. Press and hold to rewind continuously, then release to begin playing content at that point.
  • Page 83: Ipod/Usb/Mp3 Control

    ELECTRONICS IPOD/USB/MP3 CONTROL There are many ways to play music from iPod/MP3 players or USB devices through your vehicle's sound system. The remote USB port, located within the center console, allows you to plug an iPod into the vehicle's sound system. •...
  • Page 84: Uconnect Phone

    ELECTRONICS UCONNECT PHONE The Uconnect Phone is a voice-activated, hands-free, in-vehicle communications system with Voice Command Capability that allows you to dial a phone number with your mobile phone using simple voice commands (see Voice Command section). • To determine if your vehicle is equipped with Uconnect Phone, push the “Uconnect Phone”...
  • Page 85 ELECTRONICS • You will then be prompted to give the phone pairing a name (each phone paired should have a unique name). • Next you will be asked to give this new pairing a priority of 1 through 7 (up to seven phones may be paired);...
  • Page 86 ELECTRONICS Making A Phone Call • Push the “Phone” button • After the BEEP, say “dial” (or “call” a name). • After the BEEP, say number (or name). Receiving A Call — Accept (And End) • When an incoming call rings/is announced on Uconnect, push the “Phone” button •...
  • Page 87: Uconnect Voice Command

    ELECTRONICS UCONNECT VOICE COMMAND Voice Command Operation The Uconnect Voice Command system allows you to control your AM, FM radio, satellite radio, disc player, HDD, Uconnect Phone, a memo recorder, and supported portable media devices. • When you push the “Voice Command” button located on the radio faceplate or steering wheel, you will hear a beep.
  • Page 88 ELECTRONICS While In: Voice Command Example: “Channel Number” (to change the channel by its spoken number) “Next Channel” (to select the next channel) “Previous Channel” (to select the previous channel) “List Channel” (to hear a list of available channels) SiriusXM Satellite Radio Mode "Channel Name"...
  • Page 89: Bluetooth Streaming Audio

    ELECTRONICS Voice Text Reply If equipped with Uconnect Voice Command, your Uconnect 430N radio may be able to play incoming Short Message Service (SMS) messages (text messages) through the vehicle's sound system. It also allows you to respond by selecting from various predefined phrases.
  • Page 90: Electronic Vehicle Information Center (Evic)

    ELECTRONICS ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) The Electronic Vehicle Information Cen- ter (EVIC) features a driver interactive display that is located in the instrument cluster. Pushing the controls on the steer- ing wheel allows the driver to select ve- hicle information and Personal Settings. For additional information, refer to “Pro- grammable Features”...
  • Page 91: Programmable Features

    ELECTRONICS Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic, and the EVIC will display “CAL” until the compass is calibrated. You may also calibrate the compass by completing one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL”...
  • Page 92: Power Inverter

    ELECTRONICS Flashing Lamps With Lock The turn signal lights flashing, when the doors are locked or unlocked, feature can be turned on or off. To turn this feature on or off: 1. Push and hold the UNLOCK button for at least 4 seconds, but no longer than 10 seconds.
  • Page 93: Power Outlets

    ELECTRONICS POWER OUTLETS There are three possible 12 Volt Power Outlets in this vehicle. • The front 12 Volt power outlet is located below the climate controls in the Center Console, and is powered when the ignition switch is in the ON/RUN position. The outlet can operate a conventional cigar lighter unit or power accessories designed for use with a standard power outlet adapter.
  • Page 94 ELECTRONICS • On vehicles equipped with a rear subwoofer, there is also a 12 Volt power outlet located in the rear cargo area of the vehicle. This power outlet has power available directly from the battery (power available at all times). Items plugged into this outlet also may discharge the battery and/or prevent the engine from starting.
  • Page 95: Off-Road Capabilities (4Wd Operation)

    OFF-ROAD CAPABILITIES (4WD OPERATION) FOUR–WHEEL DRIVE OPERATION (COMMAND-TRAC I OR ROCK-TRAC) WARNING! Failure to engage a transfer case position completely can cause transfer case damage or loss of power and vehicle control. You could have a collision. Do not drive the vehicle unless the transfer case is fully engaged. Operating Instructions/Precautions The transfer case provides four mode positions: •...
  • Page 96 OFF-ROAD CAPABILITIES (4WD OPERATION) When operating your vehicle in 4L, the engine speed will be approximately three times (four times for Rubicon models) that of the 2H or 4H positions at a given road speed. Take care not to overspeed the engine. Proper operation of four-wheel drive vehicles depends on tires of equal size, type, and circumference on each wheel.
  • Page 97 OFF-ROAD CAPABILITIES (4WD OPERATION) 4L Position This range locks the front and rear driveshafts together, forcing the front and rear wheels to rotate at the same speed. This range (4L) provides additional traction and maximum pulling power for loose, slippery road surfaces only. Do not exceed 25 mph (40 km/h).
  • Page 98: Axle Lock (Tru-Lok) - Rubicon Only

    OFF-ROAD CAPABILITIES (4WD OPERATION) AXLE LOCK (TRU-LOK) — RUBICON ONLY The AXLE LOCK switch is located on the instrument panel (to the left of the steering column). This feature will only activate when the following conditions are met: • Key in Run Position, vehicle in 4L (Low) range. •...
  • Page 99: Utility

    UTILITY...
  • Page 100 UTILITY...
  • Page 101: Recreational Towing (Behind Motorhome, Etc.)

    UTILITY NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo (ie. the GVWR), and the GVWR should never exceed the weight referenced on the Tire and Loading Information placard. Refer to “Tire Safety Information”...
  • Page 102 UTILITY Recreational Towing — Four-Wheel Drive Models NOTE: The transfer case must be shifted into NEUTRAL (N), automatic transmission must be shifted into PARK, and manual transmission must be placed in gear (NOT in NEUTRAL) for recreational towing. CAUTION! • DO NOT dolly tow any 4WD vehicle. Towing with only one set of wheels on the ground (front or rear) will cause severe transmission and/or transfer case damage.
  • Page 103 UTILITY CAUTION! It is necessary to follow these steps to be certain that the transfer case is fully in NEUTRAL (N) before recreational towing to prevent damage to internal parts. 1. Bring the vehicle to a complete stop. 2. Press and hold the brake pedal. 3.
  • Page 104 UTILITY Shifting Out of NEUTRAL (N) Use the following procedure to prepare your vehicle for normal usage. 1. Bring the vehicle to a complete stop, leaving it connected to the tow vehicle. 2. Firmly apply the parking brake. 3. Turn the ignition switch to the LOCK position. 4.
  • Page 105: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
  • Page 106 WHAT TO DO IN EMERGENCIES – Tire Pressure Monitoring System (TPMS) Light Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires).
  • Page 107 WHAT TO DO IN EMERGENCIES NOTE: Tire pressures change by approximately 1 psi (7 kPa) per 12° F (7° C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in the Winter. Example: If garage temperature is 68°F (20°C), and the outside temperature is 32°F (0°C), then the cold tire inflation pressure should be increased by 3 psi (21 kPa), which equals 1 psi (7 kPa) for every 12°F (7°C) for this outside temperature condition.
  • Page 108 WHAT TO DO IN EMERGENCIES The dual brake system provides a reserve braking capacity in the event of a failure to a portion of the hydraulic system. A leak in either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder has dropped below a specified level.
  • Page 109 WHAT TO DO IN EMERGENCIES – Battery Charge Warning Light This light illuminates when the battery is not charging properly. If the battery charge warning light remains on, it means that the vehicle is experiencing a problem with the charging system. We recommend you do not continue driving if the battery charge warning light is on.
  • Page 110 WHAT TO DO IN EMERGENCIES Oil Change Indicator Message If an “oil change” message (shown as “Change Oil Soon” and “Oil Change Needed”) appears and a single chime sounds, it is time for your next required oil change. Resetting The Light After Servicing 1.
  • Page 111: If Your Engine Overheats

    WHAT TO DO IN EMERGENCIES – Vehicle Security Light This light will flash rapidly for approximately 15 seconds when the vehicle security alarm is arming. The light will flash at a slower speed continuously after the alarm is set. The security light will also come on for about three seconds when the ignition is first turned on.
  • Page 112: Jacking And Tire Changing

    WHAT TO DO IN EMERGENCIES WARNING! You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator. If you see or hear steam coming from under the hood, do not open the hood until the radiator has had time to cool. Never try to open a cooling system pressure cap when the radiator or coolant bottle is hot.
  • Page 113 WHAT TO DO IN EMERGENCIES Spare Tire Removal To remove the spare tire from the carrier, remove the tire cover, if equipped, and remove the lug nuts with the lug wrench turning them counterclockwise. NOTE: If you have added aftermarket accessories to the spare tire mounted carrier, it cannot exceed a gross weight of 85 lbs (38.5 kg) including the weight of the spare tire.
  • Page 114 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.
  • Page 115 WHAT TO DO IN EMERGENCIES 4. Operate the jack from the front or the rear of the vehicle. Place the jack under the axle tube, as shown. Do not raise the vehicle until you are sure the jack is fully engaged.
  • Page 116 WHAT TO DO IN EMERGENCIES WARNING! To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered. Failure to follow this warning may result in serious injury. 8.
  • Page 117: Jump-Starting Procedures

    WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump-starting can be dangerous if done improperly so please follow the procedures in this section carefully.
  • Page 118 WHAT TO DO IN EMERGENCIES WARNING! • Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is ON. You can be injured by moving fan blades. • Remove any metal jewelry such as rings, watch bands and bracelets that could make an inadvertent electrical contact.
  • Page 119 WHAT TO DO IN EMERGENCIES Connecting The Jumper Cables 1. Connect the positive (+) end of the jumper cable to the positive (+) post of the discharged vehicle. 2. Connect the opposite end of the positive (+) jumper cable to the positive (+) post of the booster battery.
  • Page 120: Emergency Tow Hooks - If Equipped

    WHAT TO DO IN EMERGENCIES EMERGENCY TOW HOOKS — IF EQUIPPED If your vehicle is equipped with tow hooks, they are mounted in the front and the rear. NOTE: For off-road recovery, it is recommended to use both of the front tow hooks to minimize the risk of damage to the vehicle.
  • Page 121: Towing A Disabled Vehicle

    WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing” in the “Starting And Operating”...
  • Page 122 WHAT TO DO IN EMERGENCIES Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the LOCK position. The only approved method of towing without the ignition key is with a flatbed truck. Proper towing equipment is necessary to prevent damage to the vehicle.
  • Page 123: Freeing A Stuck Vehicle

    WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion. Turn the steering wheel right and left to clear the area around the front wheels.
  • Page 124: Enhanced Accident Response System (Ears)

    WHAT TO DO IN EMERGENCIES WARNING! Fast spinning tires can be dangerous. Forces generated by excessive wheel speeds may cause damage, or even failure, of the axle and tires. A tire could explode and injure someone. Do not spin your vehicle's wheels faster than 30 mph (48 km/h) or for longer than 30 seconds continuously without stopping when you are stuck and do not let anyone near a spinning wheel, no matter what the speed.
  • Page 125: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE TO OPEN AND CLOSE THE HOOD Release both the hood latches. Raise the hood and locate the safety latch, located in the middle of the hood opening. Push the safety latch to the left side of the vehicle, to open the hood. You may have to push down slightly on the hood before pushing the safety latch.
  • Page 126: Engine Compartment - 3.6L

    MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.6L 1. Battery 2. Integrated Power Module (Fuses) 3. Engine Oil Dipstick 4. Engine Oil Fill 5. Brake Fluid Reservoir...
  • Page 127 MAINTAINING YOUR VEHICLE 6. Washer Fluid Reservoir 7. Engine Coolant Reservoir 8. Air Cleaner Filter 9. Coolant Pressure Cap 10. Power Steering Fluid Reservoir...
  • Page 128: Fluid Capacities

    MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) Two Door Models 18.6 Gallons 70 Liters Four Door Models 22.5 Gallons 85 Liters Engine Oil with Filter 3.6L Engine 6 Quarts 5.6 Liters Cooling System * 3.6L Engine (MOPAR Antifreeze/Engine Coolant 10 Year/150,000 Mile Formula 10.5 Quarts 9.9 Liters...
  • Page 129 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible”...
  • Page 130: Maintenance Procedures

    MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES For information on the maintenance procedures for your vehicle, please refer to “Maintenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual or applicable supplement on the DVD for further details. MAINTENANCE SCHEDULE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 131 MAINTAINING YOUR VEHICLE Severe Duty All Models Change Engine Oil at 4,000 miles (6,500 km) if the vehicle is operated in a dusty and off road environment or is operated predominately at idle or only very low engine RPM’s. This type of vehicle use is considered Severe Duty. Once A Month Or Before A Long Trip: •...
  • Page 132 MAINTAINING YOUR VEHICLE...
  • Page 133 MAINTAINING YOUR VEHICLE...
  • Page 134 MAINTAINING YOUR VEHICLE...
  • Page 135 MAINTAINING YOUR VEHICLE...
  • Page 136: Fuses

    MAINTAINING YOUR VEHICLE FUSES WARNING! • When replacing a blown fuse, always use an appropriate replacement fuse with the same amp rating as the original fuse. Never replace a fuse with another fuse of higher amp rating. Never replace a blown fuse with metal wires or any other material.
  • Page 137 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Mini Fuse Description 60 Amp Yellow – Radiator Fan 30 Amp Pink – Front Wiper LO/HI 20 Amp Blue – Front/Rear Washer – – Spare – 15 Amp Blue Center High-Mounted Stop Light (CHMSL)/Switch Stop Lamp Feed –...
  • Page 138 MAINTAINING YOUR VEHICLE Cavity Cartridge Fuse Mini Fuse Description – 20 Amp Yellow Fuel Pump, Diesel Lift Pump – Export Only – 10 Amp Red Power Window Switch, Driver Window Switch – 10 Amp Red Ignition Switch Feed, Wireless Module –...
  • Page 139: Tires - General Information

    MAINTAINING YOUR VEHICLE TIRES — GENERAL INFORMATION TIRE PRESSURES • Check the inflation pressure of each tire, including the spare tire, at least monthly and inflate to the recommended pressure for your vehicle. • The tire pressures recommended for your vehicle are found on the “Tire And Loading Information”...
  • Page 140 MAINTAINING YOUR VEHICLE WARNING! • Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. • Improperly inflated tires are dangerous and can cause collisions. Under- inflation is the leading cause of tire failure and may result in severe cracking, component separation, or “blow out”.
  • Page 141 MAINTAINING YOUR VEHICLE Since this tire has limited tread life, the original equipment tire should be repaired (or replaced) and reinstalled on your vehicle at the first opportunity. Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, since the wheel is designed specifically for the compact spare tire.
  • Page 142: Replacement Bulbs

    MAINTAINING YOUR VEHICLE Wheel And Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome plated wheels, should be cleaned regularly with a mild soap and water to prevent corrosion. To remove heavy soil and/or excessive brake dust, use MOPAR Wheel Cleaner or equivalent or select a non-abrasive, non-acidic cleaner.
  • Page 143: Consumer Assistance

    Warranty Booklet. United States customers may visit the Jeep Contact Us page at www.jeep.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Compartment Material” from the left menu.
  • Page 144: Reporting Safety Defects In The United States

    • A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired model year and vehicle from the drop down lists.
  • Page 145: Mopar® Accessories And Jeep® Performance Parts

    Wrangler. • For the full line of Authentic Jeep Accessories by Mopar, visit your local dealership or online at mopar.com for U.S. residents and mopar.ca for Canadian residents.
  • Page 146: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS FREQUENTLY ASKED QUESTIONS GETTING STARTED • How do I install my LATCH Equipped Child Seat? pg. 19 • How do I adjust the height of my Front Seat? pg. 24 OPERATING YOUR VEHICLE • How do I operate my Soft Top? pg. 38 •...
  • Page 147 • How do I shift into different four-wheel drive selections? pg. 93 UTILITY • How do I know how much I can tow with my Jeep Wrangler? pg. 97 WHAT TO DO IN EMERGENCIES • What do I do if my TPMS warning light is blinking? pg. 104 •...
  • Page 148: Index

    INDEX Adding Engine Coolant Warning Light ..105 (Antifreeze)... . .128 Break-In Recommendations, New Adding Washer Fluid ..128 Vehicle .
  • Page 149 INDEX Cooling System ... .128 Cooling ....128 Adding Coolant (Antifreeze) . .128 Fuel Requirements ..126 Coolant Capacity .
  • Page 150 INDEX High Beam/Low Beam Select Headlights ... . .29 Switch ....30 Headlight Switch ..29 Passing .
  • Page 151 INDEX Overheating, Engine ..109 Adjustment ... . .24 Easy Entry ... . .26 Paint Care .
  • Page 152 INDEX Compact Spare ..138 Transmission Fluid ... .127, 128 General Information ..137, 138 Maintenance ...128 Jacking .
  • Page 153 NOTES...
  • Page 154 NOTES...
  • Page 155 This guide has been prepared to help you get quickly acquainted with your new Jeep Brand Vehicle and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions,...
  • Page 156 DOWNLOAD A FREE ELECTRONIC COPY of the Owner’s Manual and Warranty Booklet by visiting: www.jeep.com/en/owners/manuals or www.jeep.com/en/warranty (U.S.); www.owners.mopar.ca/en (Canada). © 2015 FCA US LLC. All Rights Reserved. Jeep is a registered trademark of FCA US LLC. 16JK72-926-AA WRANGLER Third Edition...

Table of Contents
