Fig. 2 nstallation WARNING! Installation other than that described in the body of this document requires specific documentation from MartinLogan. BREAK IN Allow approximately 72 hours of break-in at 90 dB (moderate listening levels) before any critical listening. INSTALLING ON A FLAT SURFACE...
INSTALLING ON A WALL Note: This speaker is mountable in either a hori- zontal or vertical orientation. Horizontal mounting requires the use of two shoulder bolts and two wall brackets. Vertical mounting requires the use of only one shoulder bolt and mounting bracket. Note: These instructions assume the mounting surface is standard wood frame and sheet rock construction.
2 Affix the wall pads to the back of the speaker at the lower contact points (fig. 6). 3 Locate mounting location using a level and the installation template. Note:.HORIZONTAL installation requires the use of TWO wall brackets. Note:.VERTICAL installation requires the use of ONE wall bracket.
• Check speaker wires and connections. • Check all interconnecting cables. • If you are unable to resolve your problem, please contact your dealer or MartinLogan cus- tomer service (see below). ontaCting ustomer MartinLogan customer service is available Monday–Friday between the hours of 8am–5pm...
Limited 5 Year Warranty coverage. To obtain the Limited 5 Year Warranty coverage you need to complete and return the Certificate of Registration to MartinLogan within 30 days of purchase. For your convenience MartinLogan also offers online warranty registration at www.martinlogan.com.
Fig. 2 nstallation AVERTISSEMENT! Une installa- tion autre que celle décrite dans le présent document exige des docu- ments particuliers de MartinLogan. RODAGE Un rodage d’environ 72 heures à 90 dB (niveaux d’écoute moyens) est nécessaire avant toute écoute critique.
Page 17
INSTALLATION SUR UN MUR Remarque.: cette enceinte peut être montée en position horizontale ou verticale. Le montage horizontal nécessite l’utilisation de deux boulons d’épaulement et de deux supports muraux. Le mon- tage vertical nécessite un boulon d’épaulement et un support mural. Remarque.:.ces instructions supposent que la sur- face de montage est un cadre en bois standard et une construction en gyproc.
nécessite l’utilisation de DEUX boulons d’épaulement (fig. 5A). Remarque. : l’installation HORIZONTALE n é c e s s i t e l ’ u t i l i s a t i o n d ’ U N b o u l o n d’épaulement (fig.
MartinLogan (voir ci-dessous). ommuniquer veC le Le service à la clientèle de MartinLogan est dis- ponible du lundi au vendredi, de 8 h à 17 h (heure normale du Centre) en composant le (785) 749-0133 ou en envoyant un courriel à l’adresse service@martinlogan.com.
Pour obtenir la garantie limitée de cinq ans, vous devez rem- plir et retourner le certificat d’enregistrement à MartinLogan dans les 30 jours qui suivent la date d’achat. Pour plus de commodité, MartinLogan permet également l’enregistrement en ligne à la garantie à...
