- Page 1 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS fi-71 0/fi-72 ONSUMABLE EPLACEMENT LEANING NSTRUCTIONS NSTRUCTIONS CG00002-285801 Revision A...
- Page 2 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Kit Contents Brake Roller Qty 1 Pick Rollers Qty 2 Cotton Swabs F1 Cleaner Qty 1 100/pack Low VOC Qty 1 Lint Free Cleaning Cloths Cleaning Paper Qty 1 20/pack Qty 1 10/pack...
- Page 3 The consumables must be replaced periodically. You can check the number of scanned pages for the Brake roller unit and the Pick roller unit by referring to each counter on this scanner. Description Life Fujitsu P/N Pick Roller 200,000 PA03670-0002 Brake Roller...
- Page 4 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS LEANING OF THE CANNER The Scanners Automatic Document Feeder (ADF) should be cleaned at least every 5000 pages. This is very dependant on the types of paper being scanned, when scanning documents with tonner that has not fused well or have ink, the scanner may require more frequent cleaning.
- Page 5 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Clean the Pick Rollers(5) by removing them from the scanner and cleaning with a lint free cloth moistend with F1 cleaner. Using the same lint free cloth moistend with F1 clean the Glass(4), Plastic Rollers(6) and Ultrasonic Sensor(7).
-
Page 6: Replacing Consumables
fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS If this message appears you may be able to scan a bit longer but you should replace consumables as soon as possible. EPLACING ONSUMABLES From the [start] menu, select [All Programs] [Scanner Utility for Microsoft Windows] [Software Operation Panel]. -
Page 7: Replacing The Pick Roller
Operator’s Guide. Detailed instructions can be found under the “ Replacing Consumables” section of the Operator’s Guide as well as at the begining of this section of this fi-71x0/fi-72x0 Consumable Replacement and Cleaning Instructions. EPLACING THE... - Page 8 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Open the sheet guide by lifting the tab Rotate the bushing on the shaft to release the pick shaft Lift up the shaft in direction 1 (about 5mm), and slide the shaft in direction 2 to pull out the leading end from the slot, then lift the shaft in direction 3 to remove it.
- Page 9 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Remove the two Pick Rollers from the shaft one at a time. Pull out the pick roller from the shaft as you lift the retaining clip. Pull out the other pick roller from the shaft as you lift the retaining clip.
- Page 10 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Attach the two new Pick Rollers onto the shaft one at a time. Insert the retaining clip of the pick roller into the slot Insert the retaining clip of the other pick roller into the slot. Re-install the pick shaft by inserting the left end into the slot, and gradually lower the other end.
- Page 11 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Rotate the bushing to lock the shaft in place and then close the sheet guide. Close the ADF and attach the ADF paper chute (feeder) by inserting the tabs into the slots on the back of the scanner in the direction of arrow 1, and tilt in the direction of arrow 2 until it locks into place.
- Page 12 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Replacing the Brake Roller Remove all documents from the ADF paper chute (feeder) Pull the ADF release tab towards you and then open the ADF Remove the Brake Roller Hold both ends of the cover and open it in the direction of the arrow. Lift the right side of the roller first, then pull out the shaft from the slot on the left.
- Page 13 fi-71 0/fi-72 ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Remove the Brake Roller from the shaft. Install the new Brake Roller on the shaft. Insert the protrusion on the shaft into the slot on the roller hub.
