6.6.1

Name Favourites page

Enter the maximum 16 character name of your
Favourites page.
6.6.2

Areas

Select the number of areas on your Favourites page.
1, 2, 3, 4 or 6 areas on the MasterView Easy are
selectable to show your monitoring items. Besides
that, 1, 2 or 3 tank levels can be displayed, see also
section 6.9.
6.6.3

Devices

Up to 63 connected MasterBus devices are
selectable to choose your monitoring items from.
6.6.4

Groups

The monitoring items are ordened in groups, for
instance figure 13 shows one group with the name
General. Choose the group, starting to count at 1.

Add

Figure 13: Configuration of Area 1
EN / MasterView Easy MkII / September 2010
6.6.5

Items

Choose the item in the monitoring group of the
device concerned. Start to count at 1. So item 1 is
the first item in that group. The item will be shown in
the area you selected.
6.6.6 Add
Add puts the item into the area you selected. This is
done by pressing the button Add.
6.6.7

Example

See figure 13. For instance you have a MasterShunt
installed and you want the Battery state of charge to
be shown in the first of the six areas on your
MasterView Easy.
Go to Configuration in the Easy menu.
Select Favourites page and name this page.
Select 6 areas and then touch Connect to fav.
Under Connect to select Area 1.
Under Device select your MasterShunt.
Select Group no. 1 and Item no. 1.
Finally press Add and confirm.
MONITORING AND CONFIGURATION
15
