- Page 1 SB8015A All-in-One Bezel Free Android POS Terminal User Manual User Manual Ver 1.0...
-
Page 2: How To Use This Manual
How to Use This Manual This manual contains information to set up and use the SB8015A. In addition, instructions are included for added hardware, software, upgrades, and optional items. Chapter 1 An introduction to what you find in the box and an overview of product specifications, appearance, and interface. -
Page 3: Federal Communications Commission (Fcc) Notice
Federal Communications Commission (FCC) Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Copyright
Copyright The information in this guide is subject to change without prior notice. The manufacturer shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material. This manual contains information protected by copyright. -
Page 5: Precautions
Precautions 1. Please read these safety instructions carefully. 2. Keep this User Manual for later reference. 3. Disconnect this equipment from the AC outlet before cleaning. Do not use liquid or spray detergent for cleaning. Use only a moistened sheet or cloth. 4. -
Page 6: Table Of Contents
Features ..........................1 Specifications ........................... 1 Package Contents ........................2 Base System ..........................3 Expandable Options ......................... 4 SB8015A Dimensions ........................ 5 Connector Panel ........................6 Chapter 2 Disassemby Guide ..................7 Detaching the LCD Panel ......................7 Opening Back Cover ......................... 8 Chapter 3 Optional Components and Peripherals ............ -
Page 7: Chapter 1 Introduction
Chapter 1 Introduction Features 15” TFT LCD with Bezel Free Resistive Touch FreeScale i.MX 6 Dual core Cortex-A9 1.0 GHz Robust plastic housing IP65 sealed front touch panel 2 x COM, 4 x USB, 1 x VGA ... -
Page 8: Package Contents
Package Contents The following items come standard with the SB8015A: POS System Power Adaptor Utility and Main Board Chipset AC Power Cord Driver CD... -
Page 9: Base System
Base System Before you begin, take a few moments to become familiar with the SB8015A. Touch Screen Base The rear of the system Right Speaker Left Speaker... -
Page 10: Expandable Options
Expandable Options Rear Mount VFD (optional) -
Page 11: Sb8015A Dimensions
SB8015A Dimensions (Unit: mm) -
Page 12: Connector Panel
Connector Panel The SB8015A primary connector panel is located at the back side of LCD. NOTE: SB8015A COM ports are referred as "ttymxc0" and "ttymxc1" respectively in Android. -
Page 13: Chapter 2 Disassemby Guide
Chapter 2 Disassemby Guide Detaching the LCD Panel Turn off the system power properly through the operating system, then turn off any external devices. Disconnect the power cord from the power outlet and disconnect any external devices. CAUTION: Regardless of the power-on state, voltage is always present on the main board as long as the system is plugged into an active AC outlet. -
Page 14: Opening Back Cover
Opening Back Cover CAUTION: To prevent loss of work and damage to the system or drive: If you are inserting or removing a drive, shut down the operating system properly, turn off the system, and unplug the power cord. Do not remove a drive while the system is on or in standby mode. - Page 15 5. Unscrew the eight screws as shown below to remove it. 6. Open the metal cover in the direction of the arrow.
-
Page 16: Chapter 3 Optional Components And Peripherals
Chapter 3 Optional Components and Peripherals MSR Module Installation 1. Turn off the system power properly through the operating system, then turn off any external devices. 2. Disconnect the power cord from the power outlet and disconnect any external devices. CAUTION: Regardless of the power-on state, voltage is always present on the main board as long as the system is plugged into an active AC outlet. -
Page 17: Rear Mount Vfd Module Installation
5. Connect the single MSR module’s signal cable connector into the socket. Next, fix MSR module with two screws. 6. Reconnect the power cord and any external devices, then turn on the system. NOTE: The MSR module interfaces to Android as HID keyboard. To allow use of the on- screen keyboard in Android, it is necessary to change the settings of "Hardware Physical Keyboard"... - Page 18 5. Reconnect the power cord and any external devices, then turn on VFD/LCD power. Finally, turn on the system power. NOTE: The rear mount VFD module is connected with serial interface to Android apps under device name "/dev/ttymxc3" and the baud rate is 9600.
-
Page 19: Chapter 4 Main Board Configuration
Chapter 4 Main Board Configuration... -
Page 20: Main Board Connector Pin Definitions
Chapter 5 Main Board Connector Pin Definitions COM1 (ttymxc0) COM Connector Pin Definition Pin # COM1_1A Pin # Pin Definition COM1_DCD# COM1_RI# COM1_SIN COM1_DTR# COM1_SOUT COM1_CTS# COM1_SOUT COM1_DTR# COM1_RTS# COM1_SIN COM1_DSR# COM1_DCD# COM1_DSR# COM1_RTS# 0.5A DSUB_9(M)Hx2 COM1_CTS# 600_100MHz COM1_RI# GND_COM COM2 (ttymxc1) COM Connector Pin Definition... - Page 21 HDMI1 HDMI Connector Pin Definition Pin # Pin # Pin Definition HDMI1 HDMI_TD2+ HDMI_TD2+ HDMI A TYPE HDMI_CLK- HDMI_TD2- HDMI_TD1+ HDMI_TD2- HDMI_CEC_A HDMI_TD1- HDMI_TD0+ HDMI_TD1+ HDMI_TD0- HDMI_CLK+ DDC_CLK_HDMI_A HDMI_CLK- HDMI_CEC_A HDMI_TD1- DDC_DATA_HDMI_A DDC_CLK_HDMI_A HDMI_TD0+ DDC_DATA_HDMI_A +5V_HDMI GND_HDMI +5V_HDMI HDMI_HP HDMI_19H HDMI_TD0- HDMI_HP HDMI_CLK+...
- Page 22 JUSB2 USB Pin for single usb port Pin Definition Pin # +V5_USBPWR7 +V5_USBPWR7 JUSB2 USB7_D- USB7_D+ USB7_D- USB7_D+ WB_4V_2.0mm LAN+USB RJ45+USB*2 Connector Pin Definition Pin # LAN+USB1A LAN_ACT R158 330 5%_1/16W MDI0+ R159 NL/0 C248 100nF 10%_16V MDI0- MDI0+ MDI1+ MDI0- 0.1uF MDI1+...
- Page 23 RTC1 RTC Connector Pin Definition Pin # RTC1 COIN_RTC COIN_RTC WB_2V_1.25mm 100nF SPEAKER1 SPEAKER Connector Pin Definition Pin # SPEAKER1 SPK_RP SPK_LP SPK_LM SPK_RM SPK_RP SPK_LM SPK_RM WB_4V_2.0mm SPK_LP COM_SEL2 COM2 VCC Select Pin Definition Pin# COM_SEL2 COM2_PWR 30_100MHz 1.1A COM2_PWR COM2_PWR +V12...
- Page 24 SB8015A Bematech 999 S. Oyster Bay Rd Building #104 Bethpage, NY 11714 Tel: +1 516 248 0400 Fax: +1 516 495 4075...
