Summary of Contents for HIS HIS-ML23 Series
- Page 1 23" PANEL MOUNT INDUSTRIAL MONITOR REVISION B USER MANUAL Model No. HIS-ML23- _ _ _ B...
-
Page 2: Table Of Contents
Table of Contents Safety and Regulatory Information ��������������������������������������������������������������������������������3 FCC Notice ����������������������������������������������������������������������������������������������������������������������������� 3 Hazardous Locations �������������������������������������������������������������������������������������������������������������� 4 Waste Electrical and Electronic Equipment Directive (WEEE) ����������������������������������������������� 4 Mechanical Drawings ������������������������������������������������������������������������������������������������������5 Front and Side Views �������������������������������������������������������������������������������������������������������������� 5 Bottom View ���������������������������������������������������������������������������������������������������������������������������� 5 Installation Instructions ��������������������������������������������������������������������������������������������������6 Step 1: Prepare for Installation ����������������������������������������������������������������������������������������������... -
Page 3: Safety And Regulatory Information
Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the device�... -
Page 4: Hazardous Locations
The following applies only to monitors rated for hazardous locations (model numbers HIS-ML23- _ _ HB and HIS-ML23- _ _ UB): This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D; Class II, Division 2, Groups F and G;... -
Page 5: Mechanical Drawings
Mechanical Drawings Mechanical Drawings Front and Side Views 596.9 mm (23.50") 374.7 mm 286.4 mm 316.5 mm (14.75") (11.28") (12.46") 509.2 mm 7.1 mm (20.05") (0.28") Bottom View 536.4 mm (21.12") 59.2 mm (2.33") (Design to maximum depth of 69.0 mm to ensure future compatibility with later revisions 7.1 mm and replacement units.) -
Page 6: Installation Instructions
3� Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifications of the unit. f The maximum rated temperature for the HIS-ML23 is 50°C (122°F). f Remember that heat rises – the temperature at the top of the cabinet will be much hotter than at the bottom if air inside the enclosure is not actively circulating. -
Page 7: Step 2: Bench-Test Configuration
Installation Instructions Step 2: Bench-test Configuration Make sure everything works before installing into the production environment. TIP! If using a KVM extender, please refer to the installation instructions included with the KVM extender module. It is particularly important to bench-test the full configuration prior to final installation. -
Page 8: Install Touch Screen Driver
Installation Instructions Video Connection The HIS-ML23 supports digital video through its DVI port, and analog video through its VGA port. After selecting the appropriate interface, connect one end of your video cable to the input port on the rear of the monitor and the other end to the appropriate port on your host computer or other video source�... - Page 9 Installation Instructions IMPORTANT! If you will be using a USB connection, install the touch screen driver first, and then connect the USB cable. If you will be using a Serial connection, connect the Serial cable first, and then install the touch screen driver� USB Connection 1�...
- Page 10 Installation Instructions 3� Click to "Run" the software when prompted. Follow on-screen instructions to download and execute the touch screen driver installation� Calibrate the Touch Screen Once the driver has finished installing, you are ready to calibrate the touch screen. Open the touch screen's Control Panel by clicking on the "Elo Touchscreen"...
-
Page 11: Step 3: Install Into Panel
Hope Industrial Systems will not assume liability for damage to internal electronics due to improper installation� Contact Hope Industrial Systems if you need additional assistance� 1� Refer to the drawing below for the cutout dimensions for the HIS-ML23. 566.7 mm (22.31") 342.4 mm... - Page 12 Installation Instructions 3� Cut a rectangular hole in the panel. f Cutout Dimensions (W x H) for the HIS-ML23: 566.7 mm x 342.4 mm (22.31" x 13.48"); ± 0.5 mm (0.020") 4� Clean and deburr the panel hole� 5� Separate the rear collar from the monitor by removing the 14 nuts.
-
Page 13: Video Settings
Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g. 1920 x 1080) and refresh rate (or vertical frequency; e.g. 60 Hz). After setting the timing mode, use the On-Screen Display (OSD) controls to adjust the screen image. -
Page 14: Control Panel Buttons
Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. CONTROL PANEL BUTTONS 1� To display the Main Menu, press button [1]. NOTE: All OSD menus and adjustment screens disappear automatically after 15 seconds. -
Page 15: Osd And Power Lock Settings
Video Settings Button Control Functions Enter When the OSD menu IS NOT displayed: • Shortcut to toggle between analog and digital connection� When the OSD menu IS displayed: • Displays the control screen for the highlighted control. Down / When the OSD menu IS NOT displayed: Brightness •... -
Page 16: On-Screen Display (Osd) Menus
Video Settings On-Screen Display (OSD) Menus To open the OSD menu, press button [1] once. The following screen will appear: Main Menu Description Auto Image Adjust Automatically sizes, centers, and fine tunes the video signal to eliminate waviness and distortion� Contrast / Brightness Includes the Contrast and Brightness functions. -
Page 17: Auto Image Adjust Menu
Video Settings Auto Image Adjust Menu The Auto Image Adjust menu automatically sizes, centers, and fine tunes the video signal to eliminate waviness and distortion� NOTE: Auto Image Adjust works with most common video cards. If this function does not work on your display, lower the video refresh rate to 60 Hz and set the resolution to its pre-set value�... -
Page 18: Color Adjust Menu
Video Settings Color Adjust Menu The Color Adjust menu provides several color adjustment modes, including preset color temperatures and a User Color mode which allows independent adjustment of red (R), green (G), and blue (B). The factory setting for this product is Native. Color Adjust Menu Description sRGB... -
Page 19: Information Menu
Video Settings Information Menu The Information menu displays the timing mode (video signal input) coming from the graphics card in the computer. See your graphics card's user guide for instructions on changing the resolution and refresh rate (vertical frequency)� NOTE: VESA 1920 x 1080 @ 60 Hz (recommended) means that the resolution is 1920 x 1080 and the refresh rate is 60 Hz�... -
Page 20: Setup Menu
Video Settings Manual Image Adjust Description Menu Dynamic Contrast Allows the user to turn the contrast ratio enhancement On or Off. Dynamic Contrast adjusts the brightness of the backlights to improve the contrast of the screen image (darker screen images will have better black levels). Aspect Ratio Selects the image size for 4:3 or full screen. -
Page 21: Memory Recall Menu
Video Settings Setup Menu Description Language Select Allows the user to choose the language used in the menus and control screens� Resolution Notice Advises the optimal resolution to use� OSD Position Allows the user to move the OSD menus and control screens� OSD Time Out Sets the length of time the OSD screen is displayed. -
Page 22: Cleaning Instructions
Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. All displays may be cleaned using any standard glass cleaner as long as there is no abrasive or oily content. -
Page 23: Troubleshooting
Troubleshooting Troubleshooting Video Troubleshooting IMPORTANT! If using a KVM extender, first try to resolve any problems using the solutions listed below. If the problem still exists, try bypassing the KVM extender. If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem�... - Page 24 Troubleshooting Symptom Causes Solutions "Out of Range" The source signal exceeds Adjust the computer settings to the message box the maximum resolution monitor's native resolution: and no image on and/or refresh rate that the 1920 x 1080 @ 60 Hz the screen monitor can handle ( >...
-
Page 25: Touch Screen Troubleshooting
Troubleshooting Touch Screen Troubleshooting Applies to touch screen monitors only� To be sure that you have the most current driver, please check the following Internet address: http://www�HopeIndustrial�com/Touchscreen_Drivers�htm Symptom Causes Solutions No response Touch screen driver has not Download and install the latest driver from when touching been installed�... -
Page 26: Specifications
Specifications Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 23" diagonal Image Size (W x H) 509�2 mm x 286�4 mm (20�05" x 11�28") Native Resolution Full HD 1080p (1920 x 1080, 16:9 aspect ratio) Minimum Resolution VGA (640 x 480) Pixel Pitch 0�265 mm x 0�265 mm... -
Page 27: Video
Specifications Video Input Connectors • HD-15, DVI-D • Compatible inputs using optional adapter (call for details): • HDMI (via HDMI to DVI adapter) • DisplayPort (via DisplayPort to DVI adapter) • BNC (via HD-15 to 5-wire BNC adapter) Input Signal Formats •... -
Page 28: Electrical
Specifications Electrical Monitor Input • AC power models – 100 to 240 VAC, 1.5/0.75 A, 60/50 Hz • DC power models – 9.6 to 36.6 VDC, 2.5 to 0.65 A, Class 2 or SELV/LPS Power Consumption ~ 24 W Power Consumption <... -
Page 29: Compliances And Certifications
• WEEE (Registration No. WEE/DJ1859ZX for UK only) Enclosure UL 50E (File No. E318630) For monitors with model numbers HIS-ML23- _ _ HB only: Hazardous Location • UL Rated for Hazardous Locations: Industrial Control Equipment for Hazardous Location: Listed for Class I, Division 2 for Groups A, B, C, and D;... -
Page 30: Warranty Statement
Warranty Statement Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent� What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below. - Page 31 (This page intentionally left blank.) ML23B User Manual, October 2015...
- Page 32 Hope Industrial Systems, Inc. US / International 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 United States Toll Free: (877) 762-9790 International: +1 (678) 762-9790 Fax: +1 (678) 762-9789 Sales and Customer Service: sales@HopeIndustrial.com Support and Returns: support@HopeIndustrial.com Accounting Department: accounting@HopeIndustrial.com www.HopeIndustrial.com United Kingdom...
