- Page 1 Hope Industrial Systems, Inc. User Manual 12” Panel Mount Industrial Monitor Revision C Model Numbers: HIS-ML12- _ _ _ C...
-
Page 2: Table Of Contents
Table of Contents SAFETY AND REGULATORY INFORMATION ..............3 Warning ..........................3 FCC Notice ......................... 3 CONTROL PANEL BUTTONS AND INDICATORS .............. 4 Power Indicator Light Status ....................4 OSD FUNCTIONS ......................... 5 INSTALLATION INSTRUCTIONS ..................7 Preparing for Installation ..................... 7 Installation into Panel...................... -
Page 3: Safety And Regulatory Information
Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the device. -
Page 4: Control Panel Buttons And Indicators
Control Panel Buttons and Indicators Control Panel Button Description Power On/Off Press to turn monitor power on and off. Pressing this button the first time brings up the OSD (On Screen Menu Display) menu. Once inside the OSD menu, pressing this but- ton again selects the highlighted function. -
Page 5: Osd Functions
OSD Functions Menu Description 101 scales of brightness are available to choose from (0 to 100) Brightness Contrast 256 scales of contrast are available (0 to 255) For adjustment of the display’s horizontal position. H. Position For adjustment of the display’s vertical position. V. - Page 6 USER – Three colors (Red, Green, Blue) can be adjusted from the OSD menu. Saves the values of this setting and exits the OSD menu function. Save + Exit Brightness 101 scales of brightness are available to choose from (0 to 100) 256 scales of contrast are available (0 to 255) Contrast For adjustment of the display’s horizontal position.
-
Page 7: Installation Instructions
3. Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifications of the unit. • The maximum rated temperature of the HIS-ML12 is 50°C (122°F) • Remember that heat rises – the temperature at the top of the cabinet will be much hotter than at the bottom when the air is not circulating. -
Page 8: Installation Into Panel
6. Tighten all 8 nuts to a torque of 24 inch-pounds to assure a water-tight seal be- tween the poron bezel gasket on the monitor and equipment panel. HIS will not assume liability for damage to internal electronics due to improper installation. -
Page 9: Touchscreen Driver Installation
Touchscreen Driver Installation The enclosed CD-ROM contains documentation and drivers for all major operating systems. To be sure you have the most current information, check the following Internet addresses: http://HISmonitors.com/Touchscreen_Drivers.htm... -
Page 10: Cleaning
Cleaning CAUTION! DO NOT USE ABRASIVE MATERIALS SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touch- screen. -
Page 11: Troubleshooting
Troubleshooting Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. • Press the power button and check to see if the power LED is lit. • If the LED turns green, make sure the PC is powered on. Make sure all cables are connected. -
Page 12: Drawings
Drawings Front and Side Views... -
Page 13: Rear View (Showing Cutout Dimensions)
Rear View (Showing Cutout Dimensions) -
Page 14: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 12.1” diagonal Image size 9.7” (246mm) W x 7.3” (184.5mm) H Native resolution SVGA (800 x 600) Plug and Play DDC1/2B compatible Minimum resolution 640 x 350 Pixel pitch 0.3075mm x 0.3075mm Number of colors 262,144... -
Page 15: Electrical
Electrical Power Adapter Input 100VAC – 240VAC, 50-60 Hz Power adapter output 12VDC @ 2.5 amps Monitor input 12VDC Power consumption Approximately 20 watts Power management DPMS/energy star, < 5W Environmental Temperature 0-50°C (consult factory for installation instructions when con- tinuous 24/7 operation exceeds 40°C) Humidity 20% to 90% non-condensing... -
Page 16: Physical
Physical Depth 1.6” (2.5” at connectors) behind panel maximum Bezel Stainless Steel Front bezel outside di- 13.3” W x 11.6” H x 0.236” thick (not including gasket) mensions Cutout dimensions 12.12” (308mm) W x 10.35” (263mm) H ; +/- .020” Net weight 8 lbs. -
Page 17: Factory Preset Timing
Factory Preset Timing Horizontal Vertical Pixel Clock Mode Frequency Frequency (MHz) Resolution (KHz) (Hz) 640 x 350 31.469 70.087 25.175 VGA-350 640 x 400 31.469 70.087 25.175 VGA-400-GRAPH 640 x 480 31.469 59.940 25.175 VGA-480 640 x 480 37.861 72.809 31.500 VESA-480-72Hz 640 x 480... -
Page 18: Warranty Statement
We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below. This warranty remains in force for a three-year period beginning on the date we invoice you for the product. If HIS repairs or replaces a product under war- ranty, its warranty term is not extended. - Page 19 (This page left blank.)
- Page 20 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2006 Hope Industrial Systems, Inc. Publication ML12C July, 2006...
