- Page 1 SAFETY AND OPERATING MANUAL ORIGINAL INSTRUcTIONS WX254 WX254.1...
-
Page 2: General Power Tool Safety Warnings
GENERAL POwER TOOL SAFETY wARNINGS outlets will reduce risk of electric shock. b) Avoid body contact with grounded WARNING: Read all safety warnings and surfaces such as pipes, radiators, ranges instructions. Failure to follow the warnings and refrigerators. There is an increased risk and instructions may result in electric shock, fire of electric shock if your body is earthed or and/or serious injury. - Page 3 of drugs, alcohol or medication. A moment of dust extraction and collection facilities, ensure these are connected and properly of inattention while operating power tools may used. Use of dust collection can reduce dust- result in serious personal injury. b) Use personal protective equipment. related hazards.
- Page 4 that may affect the power tools operation. clips, coins, keys, nails, screws or other If damaged, have the power tool repaired small metal objects, that can make a before use. Many accidents are caused by connection from one terminal to another. poorly maintained power tools.
- Page 5 SYMBOL Do not stare directly into the tool holder. When changing the tool insert, it can be thrown out toward the front. Wear eye protection Wear ear protection Wear dust mask To reduce the risk of injury, user must read instruction manual Do not expose to rain or water C-tick marking...
-
Page 7: Technical Data
coveR foRWARD/ReveRSe RotAtIoN coNtRol Soft GRIP HANDle oN/off SWItcH leD lIGHt BIt HolDeR oR cHUck BIt cARtRIDGe cHARGING INDIcAtoR cHARGING Socket TEchNIcAL DATA Charger voltage 230V/240V~50Hz Rated voltage 4V Max* Rated speed 230/min Machine weight 0.5kg Charging time 3~5 hours * Voltage measured without workload. - Page 8 OPERATING INSTRUcTIONS Note: Before using the tool, read the instruction book carefully. BefoRe oPeRAtING tHIS tool A) cHARGe tHe BAtteRy The battery charger supplied is only for the Li-Ion battery installed in the machine. Do not use another battery charger. The Li-Ion battery is protected against deep discharging.
- Page 9 Charger. Disconnect the Charger from the screwdriver. The screwdriver is ready to be used. IMPoRtANt: When charging, the Charger and screwdriver may become warm to the touch; this is normal and does not indicate a problem. 2. oPeRAtING INStRUctIoNS Inspect the screwdriver before using to ensure all the parts are running smoothly and there are no abnormal sounds or sparks.
- Page 10 Move the top Cover back and forth until the desired bit is in place. If the bits in the Bit Cartridge need to be replaced, remove Bit Cartridge by pushing it up from the window underneath. Replace the bits with the desired bits. Ensure the bits are properly positioned in the Cartridge and are not protruding from the back of the Bit Cartridge.
-
Page 11: Switch Lock
3. SWItcH lock The On/off Switch (4) can be locked in the OFF position. This helps to reduce the possibility of accidental starting when the screwdriver is not in use. To lock the On/off Switch, place the Forward/Reverse Rotation Control (2) in the center position. 4. -
Page 12: Using The Led Light
5. fUlly AUtoMAtIc SPINDle lockING (AUto-lock) (See fig. f) The screwdriver Chuck (6) is locked when the On/Off Switch (4) is not pressed. This allows the driver to be used manually when needed. IMPoRtANt: When using as a manual tool, do not press the On/Off Switch (4). -
Page 13: Maintenance
MAINTENANcE Your tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. - Page 16 www.worxtools.com Copyright © 2012, Positec. All Rights Reserved. 2CSD16APK11002A0...
