Switch Settings, Adjustments and Indicators
10
Tally Lights
Power
Brightness, Color,
and Contrast controls
RATIO: Each push of the button switches
between 4:3 and 16:9 modes
MARK (16:9 mode only):
Each push of the button switches
between 16:9 standard, 4:3 marker
(shaded), and 4:3 marker (cropped)
Standard
Warranty
11
V-R1041DP-TE / V-R1042DP-TE
Marshall Electronics warranties to the first consumer, that this
be free from defects in workmanship and materials, when received in its original container, for a period of one year from the purchase date.
This warranty is extended to the first consumer only and proof of purchase is necessary to honor the warranty. If there is no proof of pur-
chase provided with a warranty claim, Marshall Electronics reserves the right, not to honor the warranty set forth above. Therefore, labor and
parts may be charged to you.
This warranty does not apply to product exterior and cosmetics. Misuse, abnormal service or handling, improper alterations or modifications
in design or construction, voids this warranty. No sales personnel of the seller, nor any other person is authorized to make any warranties
other than those described above, or to extend the duration of any warranties on behalf of Marshall Electronics, beyond the time period
described above.
Due to constant effort to improve products and product features, specifications may change without notice.
RATIO Settings
4:3 Mode
16:9 Mode
MARK Settings (16:9 Mode Only)
4:3 Marker (Shaded)
4:3 Marker (Cropped)
