PETROL
LINE TRIMMER/
BRUSH CUTTER
33.5CC 4 Stroke
INSTRUCTION MANUAL
SPECIFICATIONS
Engine:
33.5cc 4-stroke
Power Output:
1kW (1.33HP)
Fuel Tank Capacity:
0.65L
Max. Spool No Load Speed:
8500/min
Cutting Width (Line Trimmer):
460mm
Cutting Width (Brush Cutter):
255mm
Weight:
9kg
ozito.com.au
1
WHAT'S IN THE BOX
Safety Guard
Upper &
Lower Shaft
Handle
Spool
Cutting Blade
Screwdriver
Spark Plug
Wrench
Spanner
4 & 5mm Hex Key
Harness
Split Pin (2x)
Screw (2x)
Support Plate
Engine Oil
Filling Bottle
PLTBC-460
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito PLTBC-460
Summary of Contents for Ozito PLTBC-460
-
Page 1: Line Trimmer
Spark Plug Max. Spool No Load Speed: 8500/min Wrench Cutting Width (Line Trimmer): 460mm Cutting Width (Brush Cutter): 255mm Spanner Weight: ozito.com.au 4 & 5mm Hex Key Harness Split Pin (2x) Screw (2x) Support Plate Engine Oil Filling Bottle PLTBC-460... -
Page 2: Know Your Product
KNOW YOUR PRODUCT ASSEMBLY PETROL LINE TRIMMER / BRUSH CUTTER 1. ASSEMBLING THE TRIMMER 1 Choke lever 2 Recoil starter WARNING! DO NOT START THE ENGINE UNTIL 3 Air filter housing THE LINE TRIMMER/BRUSH CUTTER IS FULLY 4 Fuel pump “primer” ASSEMBLED. 5 Petrol tank 6 Support plate Fitting the... - Page 3 Pressure Plate Cover Pressure Plate Blade Carrier Plate 2. SAFETY GUARD & BLADE & LINE Carrier Plate Cover Assembling and fitting the safety guard 6. Slide the split pin through the hole in the drive shaft and bend the lugs IMPORTANT! THE SAFETY GUARD MUST BE FITTED around the shaft.
-
Page 4: Setup & Preparation
SETUP & PREPARATION 3. CUTTING HEIGHT 4. FUEL & OIL Setting the cutting height WARNING! PETROL IS VERY FLAMMABLE. AVOID 1. Fit the harness so that the shoulder pads SMOKING OR CAUSING ANY SPARKS OR FLAMES sit on the shoulders and the plate hangs NEAR FUEL. -
Page 5: Operation
As a result of this friction, the cable will become frayed and will wear away faster. Always hold the starter handle when the cable retracts. Never allow the cable to snap back when it has been pulled out. PLTBC-460... -
Page 6: Maintenance
APPLICATIONS MAINTENANCE 6. CUTTING METHODS 7. LINE REPLACEMENT Trimming/mowing WARNING! BEFORE CLEANING YOUR TRIMMER/ Swing the trimmer from side to side as CUTTER OR CARRYING OUT ANY MAINTENANCE you walk forward. Always keep the line PROCEDURE, MAKE SURE THAT THE ENGINE IS OFF spool parallel to the ground. -
Page 7: Description Of Symbols
DESCRIPTION OF SYMBOLS Cubic Centimeters 8. GENERAL MAINTENANCE No load speed /min Revolutions or reciprocation per minute Decibel level Regulator compliance mark Read the manual prior to use Extremely hot surface. IMPORTANT: REMOVE ALL GRASS AND WEED REMAINS AT REGULAR INTERVALS TO PREVENT Wear safety glasses Wear safety boots THE SHAFT TUBE OVERHEATING. -
Page 8: Safety Instructions
For further information, or any parts not listed here, visit www. Recycling packaging reduces the need for landfill and raw ozito.com.au or contact Ozito customer service materials. Reuse of recycled material decreases pollution in the Australia 1800 069 486 environment. Please recycle packaging where facilities exist. -
Page 9: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0614...
