Introduction

The Datapath Image4 multi screen graphics accelerator is single slot PCIe card for displaying Windows
across multiple screens as one extended desktop.
The Image4 has two graphics processor units (GPU) each with 256Mbytes of DDR2 RAM. Half of this
RAM is accessible from the PCIe bus, the rest is accessible only by the GPU.
AllcardsintheImage4rangefeature:
• Analog or DVI-D outputs.
• Supports VESA modes up to 1600 x 1200 and non-VESA modes up to 2048 x 1536.
• FullhardwarecursorsupportforflickerfreeWindowscursorsinallmodes.
• Multiple card hardware support for multiple screen systems.

Specifications:

Card format
Card size
Max output resolution
Max number of cards per system
Framebuffermemory
Max current at +3.3V
Max current at +12V
Max Power
Operating temperature
Storage temperature
Relative humidity
MTBF
Warranty
4 lane PCI express
110mm x 197mm
4x1920x1200 DVI/RGB
10 (40 display channels)
2x 256MB (512MB total)
0.25A
1.7A
22 watts
0 to 35 deg C
-20 to +70 deg C
5% to 90% non-condensing
88,293hrs
3 years
