SERVICE MANUL
PFL1165W-U
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It
dose not contain warnings and cautions to advice non-technical individuals of potential dangers in attempting to service a product.
Product powered by electricity should by serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
SERVICE MANUAL
MODEL: PFL1165W-U
WARNING
Washing Machine
All rights reserved. Unauthorized copying and distribution is a violation of law.
Order No. FL0911S002V1.1
Washing Machine
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Proline PFL1165W-U
Summary of Contents for Proline PFL1165W-U
-
Page 1: Service Manual
SERVICE MANUAL Order No. FL0911S002V1.1 Washing Machine MODEL: PFL1165W-U WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It dose not contain warnings and cautions to advice non-technical individuals of potential dangers in attempting to service a product. -
Page 2: Table Of Contents
SERVICE MANUL PFL1165W-U Contents Chapter 1 General Information ________________________________________________ 1-1. General Guidelines _____________________________________________________ 1-2. Caution and Warning symbols ____________________________________________ 1-3. Function indication symbols ______________________________________________ Chapter 2 Product Feature ___________________________________________________ 2-1. Features _____________________________________________________________ 2-2. Specification __________________________________________________________ Chapter 3 Matters needing attention ___________________________________________ 3-1. - Page 3 SERVICE MANUL PFL1165W-U 8-3. Adjusting the washing machine _________________________________________ 8-4. Joining the Inlet Hose to the Washing Machine _____________________________ 8-5. Drainage Hose ______________________________________________________ 8-6. Connecting to the Power Supply ________________________________________ Chapter 9 Wiring circuit and Self check ______________________________________ 9-1. Wiring circuit ________________________________________________________ 9-2.
-
Page 4: Chapter 1 General Information
SERVICE MANUL PFL1165W-U Chapter 1 General Information 1-1. General Guidelines When servicing,observe the original lead dress.If a short circuit is found, replace all parts which are overheated or damaged by the short circuit.After servicing ,see to it that all the protective devices such as insulation barriers ,insulation papers shields are properly installed .Confirm that the screws,parts and wiring... -
Page 5: Chapter 2 Product Feature
SERVICE MANUL PFL1165W-U Chapter 2 Product Feature 2-1. Features (1). 300mm diameter porthole, door may be open at a 180 degrees. Facilitate view of wash process, facilitate unloading and easy to use with large port. (2). Class A energy-saving Scientific design for tub can reduce the use of water heavy during washing, consequently upgrade the energy efficiency class to A,also use scientific washing (3). -
Page 6: Specification
SERVICE MANUL PFL1165W-U 2-2. Specification PFL1165W-U washing machines Product identification Description of appliance Washing machine Type of appliance(FS = standing, BI = built-in) Supplier own brand Supplier bar code Europe Commercial Brand / Model Commercial bar code Key-Features Energy efficiency class... - Page 7 SERVICE MANUL PFL1165W-U Auto water cool-down (before drain 90°C boiled water) Water overflow protection Acqua Stop kit Child protection Programs n° 1) Strong action /cotton cycles (90°C/60°C/40°C/30°C/ ) n° 2) Normal action / synthetics (90°C/60°C/40°C/30°C/ ) 3) Delicate action / wool or cashmere cycles (60°C/40°C/30°C/ ) n°...
-
Page 8: Chapter 3 Matters Needing Attention
SERVICE MANUL PFL1165W-U Chapter 3 Matters needing attention 3-1. Safety... -
Page 9: During Use
SERVICE MANUL PFL1165W-U 3-2. During Use... -
Page 10: Chapter 4 Operational Guidance
SERVICE MANUL PFL1165W-U Chapter 4 Operational Guidance PROG. Delay Spin Prewash Delicate Wash Temperature Cotton Silk Rinse Synthetic Spin Quick Wool Drain Start/Pause Delay Temperature Spin On/Off... - Page 11 SERVICE MANUL PFL1165W-U...
-
Page 12: Chapter 5 Program Introduction
SERVICE MANUL PFL1165W-U Chapter 5 Program Introduction... -
Page 13: Chapter 6 Washing Mathods
SERVICE MANUL PFL1165W-U Chapter 6 Washing Mathods 6-1. Loading 6-2. Adding detergent 6-3. Selecting washing program... -
Page 14: Chapter 7 Appearance Brief Introduction
SERVICE MANUL PFL1165W-U Chapter 7 Appearance brief introduction 7-1. Name of parts... -
Page 15: Net Dimension
SERVICE MANUL PFL1165W-U 7-2. Net dimension Delay Spin PROG. Prewash Delicate Wash Temperature Silk Rinse Cotton Synthetic Quick Spin Wool Drain Delay Temperature Spin Start/Pause On/Off height:850mm / width:595mm / depth:535mm... -
Page 16: Chapter 8 Disassembly And Installation
SERVICE MANUL PFL1165W-U Chapter 8 Disassembly and Installation 8-1. Remove packing materials 8-2. Dismantle packing bolts 8-3. Adjusting the washing machine... -
Page 17: Joining The Inlet Hose To The Washing Machine
SERVICE MANUL PFL1165W-U 8-4. Joining the Inlet Hose to the Washing Machine 8-5. Drainage Hose 8-6. Connecting to the Power Supply... -
Page 18: Chapter 9 Wiring Circuit And Self Check
SERVICE MANUL PFL1165W-U Chapter 9 Wiring circuit and Self check 9-1. Wiring circuit PCB-Printed Circuit Board NTC-Temperature Sensor FA-Interference Suppresser MR-Door Lock Switch-Power Switch EVP,EVF-Water Inlet Magnetic Valve P- Pressure Switch B1-Drainage Pump R-Heating element M-Motor... -
Page 19: Self Check
SERVICE MANUL PFL1165W-U 9 - 2. S elf check Model selection 1.Press the temperature button and the power button at the same time for 4 seconds, and it will enter the model-selection mode. 2.The default display shows 1460. Press the speed button to choose 1460/1450/1260/1250/1060/1050/960/950/860/850/760/750 till the needed model.Then press the reservation key and the model can be stored. -
Page 20: Chapter 10 Error Display And Troubleshooting
SERVICE MANUL PFL1165W-U Chapter 10 Error Display and troubleshooting 10-1. Error Display Error message:Door is not properly shut 20s after program is started. Troubleshooting: Shut the door properly Pushing the door to Check Whether Door is properly shut or not Door lock is broken and need replacing, Cut off the power and then turn on again. -
Page 21: Troubleshooting
SERVICE MANUL PFL1165W-U Error message:Temperature sensor is not properly connected or damaged (display at the end of a program). Troubleshooting: Cut off power and measure the resistance NTC exist open circuit. Replace it of temperature sensor by multimeter , is... - Page 22 SERVICE MANUL PFL1165W-U Error message: The required water level is not reached within 8 min, or the water level exceeds the protection value Troubleshooting: Connect it well. Check if water is leaking from washer bottom. Inlet pipe. drain pipe or...
- Page 23 SERVICE MANUL PFL1165W-U Error message. Motor overheat protection or is damaged. Troubleshooting: Cut off power and check if motor wires Reconnect well are connected well P u t the motor in normal temperature about ten minutes, and then test again. If the resistance is natural, it M e as ure if the resistance of motor is caused by overheated protection.
-
Page 24: Examination & Troubleshooting
SERVICE MANUL PFL1165W-U 10-2. E x a mination & Troubleshooting 10-2-1. D i splay nothing Troubleshooting: Repair power supply M e asure the power supply ,is it ex i st s 220V-24 0 V A C volt age Press the power switch... -
Page 25: No Draining
SERVICE MANUL PFL1165W-U 10-2-3 . N o draini Troubleshooting: A d just the height of drainpipe to Is the height of drain pipe too high? 8 0 -100 cm Turn filter anticlockwise open and check if filter is jammed Clean and tighten filter clockwise. -
Page 26: Water Leaking
SERVICE MANUL PFL1165W-U 10-2-5. Water leaking Troubleshooting: Check if water is leaking from the inlet pipe Readjust it or the tap Is drain pipe broken Replace drainpipe Check if there is foreign material nipped Remove clothes between cushion of sight window and... -
Page 27: Chapter 11 Maintenance
SERVICE MANUL PFL1165W-U Chapter 11 Maintenance... - Page 28 SERVICE MANUL PFL1165W-U...
- Page 29 SERVICE MANUL PFL1165W-U Sincere Forever...
