- Page 1 CINO XS GRANDE PRO VHO type: compact INSTALLATION AND MAINTENANCE MANUAL Translation of the original instructions MAN2100154 rel. 00 dated 04.11.2013 __________________________________________ www.rheavendors.com...
- Page 2 Cino XS grande PRO VHO by preliminary before using the machine, carefully read this information that helps you safety behave properly and guarantee a safe use; information the following pages use the symbols listed here below, whose meaning is of attention: GENERAL;...
- Page 3 Cino XS grande PRO VHO by the symbol means that it is forbidden to dispose of the equipment as urban waste and compulsory to provide for separate collection in order to prevent any potential effect on the environment and human health;...
- Page 4 Cino XS grande PRO VHO by residual risks a residual risk is understood as a potential danger that can not be eliminated and it persists despite all precautions in use since it is related to the intrinsic features of the product and it also includes non- identifiable risks;...
- Page 5 Cino XS grande PRO VHO by general guarantee these conditions regulate Rheavendors Industries S.p.A.’s conditions obligations with reference to guarantee and repair; any other term or condition, either verbal or written, is not applicable, including those in the purchaser’s purchase orders, if not explicitly accepted and signed by Rheavendors Industries S.p.A.;...
- Page 6 Cino XS grande PRO VHO by declaration of Rheavendors Industries S.p.A. declares that this drink vending conformity machine has been designed and manufactured in compliance with the following directives and safety standards: Directives: 2004/108/EC; 2006/95/EC; 2006/42EC; 2002/95/EC (RoHS); 2002/96/EC (RAEE); 1907/2006/EC (REACH);...
- Page 7 Cino XS grande PRO VHO by table of contents legend page 08 introduction page 08 technical data page 09 configurations page 11 presentation page 12 preliminary actions page 20 connections page 22 installation and first power on page 23 programming...
- Page 8 Cino XS grande PRO VHO by legend some general information that may be of use to consult this manual; 01.01. pictograms § dispensing of drinks machines with pitch of the worm product shaker of based on instant external water screw of product...
- Page 9 Cino XS grande PRO VHO by technical data 03.01. dimensions height (including the coffee beans canister projecting by 80 mm): 670 mm height (including the grounds base): 815 mm width: 420 mm depth: 590mm depth with open door: 880 mm 03.02.
- Page 10 (see 09.06.); 03.23. notes the water and energy supply tolerance limits for a good and regular operation of the machine Cino XS grande PRO VHO are: water: - total hardness: from 10 °f to 25 °f (*) - recommended conductivity: 400 μS @ 20 °C...
- Page 11 Cino XS grande PRO VHO by configurations Cino XS grande PRO VHO's two possible configurations are represented here below: product canisters, mixers waters numbered progressively from the left to the right, as it is specified later on; this numbering is used in the chapter about drink programming (see 09.);...
- Page 12 Cino XS grande PRO VHO by presentation 05.13. door switch 05.19. coffee beans canister 05.19. instant product canisters 05.19. 05.14. baffle PROG internal button 05.19. 05.15. product slide flash key seat 05.22. 05.26. variable coffee brewer mixing bowl 05.06. 05.27.
- Page 13 Cino XS grande PRO VHO by 05.20. product sensor 05.21. 05.37. grinder motor 05.28. 05.32. product motor floater switch 05.31. 05.32. environment aspirator air break 05.35. 05.35. instant solenoid valves pressure boiler 05.30. 05.25. powder aspirator coffee brewer motor 05.34.
- Page 14 05.05. cup station the Cino XS grande PRO VHO vending machine has a fixed drink dispenser on the cup surface and a folding support for smaller cups;...
- Page 15 Cino XS grande PRO VHO by 05.14. internal button the button giving access to the machine programming mode is (PROG) arranged inside the door on the orange protection carter (PROG); 05.15. flash key seat the seat for programming flash keys is made available in the carter inside the door (see 09.06.);...
- Page 16 Cino XS grande PRO VHO by 05.23. brewer detector the coffee brewer presence is controlled by a micro switch that - in switch case of absence thereof - inhibits the selections including coffee beans; 05.24. coffee brewer besides protecting the operator against moving parts, a safety...
- Page 17 Cino XS grande PRO VHO by 05.34. pressure boiler pump a vibration pump with by pass conveys water to the pressure boiler that is connected with the block of instant solenoid valves and the three-way valve for espresso; attention these components may be very hot even if the machine is off;...
- Page 18 Cino XS grande PRO VHO by 05.37. electronics 05.37.a. CPU temperature probe connector DL5 - led pressure boiler heating element display board connector pressure boiler heating element RFID connector DL3 - led 5 V CPU IN 230 V ac MDB connector...
- Page 19 Cino XS grande PRO VHO by 05.38. software the software installed in in Cino XS grande PRO VHO can be subdivided into two different chapters called: - master: it is the software determining the machine cycles, the links between the functions, the order of execution of operations;...
- Page 20 Cino XS grande PRO VHO by preliminary actions 06.01. handling the vending machine may be transported, handled and positioned vending machine by skilled and trained personnel only; never overturn the machine while transporting it and never forget to observe the orientation arrows on the package;...
- Page 21 06.05. unpacking the 60x45x20 cardboard package includes the complete tabletop grounds base base suitable for the Cino XS grande PRO VHO vending machine; the following items are also included: 1 pc. tabletop base (b) with grounds drawer (c) 1 pc. grounds conveying slide (h) 1 pc.
- Page 22 Cino XS grande PRO VHO by connections 07.01. water make sure that the water used to supply the vending machine has all proper features for human consumption; make sure that there is no sign of impurity and check the degree of hardness;...
- Page 23 Cino XS grande PRO VHO by installation and first power-on 08.01. foreword after unpacking the vending machine, placing it firmly at the work station as well as providing for water and energy connection, carry out some actions for its functionality;...
- Page 24 Cino XS grande PRO VHO by 08.03. washing transportation, storage and installation conditions are such that the vending machine immediately used recommended to carry out a complete wash cycle before using the vending machine; press the programming button (see 05.14.) to display the following...
- Page 25 Cino XS grande PRO VHO by programming the vending machine is programmed at works with the required parameters; the variables composing the recipes are stored in the machine and they enable the user to dispense drinks without requiring the installer to provide for special programming;...
- Page 26 Cino XS grande PRO VHO by 09.01. “programming” the items are (scroll by pressing key “1”): 1=PROGRAMMING 09.01.a. button 1÷10 it contains the variables composing selection 1; PROGRAMMING … BUTTON N it contains the variables composing selection 10; 09.01.b. prices it establishes the prices of every single dispensing cycle;...
- Page 27 Cino XS grande PRO VHO by 09.01.a. button 1 ÷ 10 when the display shows “key n”, press key “2” to scroll (by PROGRAMMING pressing “4” and “5”) the variables composing the function of that BUTTON N key; - if you press “2” when “ENABLED”, the key will fulfil the function FUNCTIONING for which it is programmed (dispensing of one drink);...
- Page 28 Cino XS grande PRO VHO by the rotation time of the mixer fan may be changed by pressing MIXER N keys “4” and “5”; if time is set to zero, the mixer will not rotate; 0= inhib. 60.0 you can carry out a "time test" on the set-up value; (see 13.17.);...
- Page 29 Cino XS grande PRO VHO by 09.01.b. prices press key “2” to display: each selection may be assigned a sales price; use “4” and “5” to PRICE N vary the amount and “2” to scroll the price lines; 0.00 09.01.c. happy price press key “2”...
- Page 30 Cino XS grande PRO VHO by - fan delay: it determines how many minutes the dust extraction FAN TIME fan will remain active after the last dispensing cycle; min. - beep time: buzzer time, active at the end of each machine BEEP TIME function;...
- Page 31 Cino XS grande PRO VHO by 09.01.h. sales audit this menu is intended to gather the quantities of the selections made by the machine: names are assigned according to the EVA- DTS standard: - VA 102 TOTAL SELECTIONS quantity of total vends (parameter not resettable);...
- Page 32 09.01.i. MDB press “2” to display the variables necessary for the MDB protocol; since Cino XS grande PRO VHO is unable to accommodate changegiver payment systems, some of these variables will be of no significance, even if made available; press keys “4” and “5” to scroll the values;...
- Page 33 Cino XS grande PRO VHO by 09.01.m. out of service it displays the twenty errors last occurred and recorded for the n. N off NN machine; press key “2” to scroll records and press key “4” to reset hh:mm dd-mm-yyyy them (see 11.);...
- Page 34 Cino XS grande PRO VHO by 09.01.q. tuning motors compared to setpoint values in 09.01.a.: - the rotation time of each product motor can be varied (keys “4” TUNING MOTOR N and “5”) by +/-30%; the variation concerns all activations of the +00 % product motors for all selections;...
- Page 35 Cino XS grande PRO VHO by 09.06. data support the values of the variables composing the machine programming (configuration) can be transferred to an external support, i.e. the flash key; to transfer the machine parameters to the key: - power off the machine;...
- Page 36 Cino XS grande PRO VHO by 09.07. programming diagram PROGRAMMING BUTTON N FUNCTIONING PROGR. TOTAL C OFFE WATER C OFFE SEQUENC E INHIBITED PROGR. PARTIAL STEP DOWN BREWER PRODUC T N PRICES PRIC E N START DELAY PRODUC T N...
- Page 37 Cino XS grande PRO VHO by 09.07. programming diagram PROGRAMMING BUTTON N FUNCTIONING EJEC TION TUBES BUTTON N ESC ROW ENABLE C REDIT MAX REST MAX SELL TYPE TOKEN VALUE C OIN REST N BILL VALIDATOR MDB TUBES VALUE CLOCK...
- Page 38 Cino XS grande PRO VHO software; if not otherwise stated, the numeric time values of devices are expressed in tenths of a second (e.g. 27 corresponds to 2 seconds and 7 tenths);...
- Page 39 Cino XS grande PRO VHO by 10.02. LM selection Cino XS grande PRO VHO can produce a drink called Latte Macchiato, composed by milk and coffee and served in the cup in differently coloured bands, typically milk, coffee and milk;...
- Page 40 Cino XS grande PRO VHO by 10.03. limits the table is intended to list the minimum and maximum values you may assign to programmable variables; u.m. from exp coffee water 0 = no espresso; grinder time sec. product sec. 0 = no product;...
- Page 41 Cino XS grande PRO VHO by solution of problems any event that may occur during the operation of a machine may totally or partially compromise its functionality; to help the operator restore the normal functionality of the vending machine, the display shows an error code as an abbreviation that identifies the malfunction and helps the operator find the faulty device;...
- Page 42 Cino XS grande PRO VHO by OFF 2 payment system protocol OFF 2 E executive no communication between the payment system and the vending machine OFF 2 M CPU; it might be caused by improper power supply, false programming or...
- Page 43 Cino XS grande PRO VHO by OFF 10 EAROM stored data are not consistent (reading or writing error) and the overall operation of the vending machine may be otherwise than expected; OFF 14 water inlet OFF 14 B pressure boiler if water is not reloaded after six dispensing cycles, error 14 is triggered;...
- Page 44 Cino XS grande PRO VHO by maintenance the Cino XS grande PRO VHO vending machine requires no special maintenance procedure to do its job; however, if you provide for careful and frequent cleaning, this may help the machine keep its performance constant, prevent failures and ensure the high quality of dispensed drinks;...
- Page 45 Cino XS grande PRO VHO by 12.01. weekly power off the machine; disconnect the supply cable and carefully make sure that there is no sign of wear; check the stability and efficiency of internal connections of the mains supply carefully;...
- Page 46 Cino XS grande PRO VHO by 12.02. monthly besides fulfilling the tasks already specified by chapter 12.01. weekly, it is also recommended to act in the following districts: dispensing system disassemble all components of the dispensing system: - extraction drawer (f)
- Page 47 Cino XS grande PRO VHO by 12.03. yearly dispensing system replace the gasket at the base of the mixing bowl of the mixer; remove the mixer motor fan by pulling it; replace the gasket of the mixer motor shaft ;...
- Page 48 Cino XS grande PRO VHO by how to do to: 13.01. get an espresso the parameters that determine the quality and quantity of an selection espresso selection in a cup are: - the temperature and quantity of percolation water; - the coffee grinding degree;...
- Page 49 Cino XS grande PRO VHO by 13.04. empty the when the machine is off, open the grounds drawer; remove the bag grounds container from the hook ring; insert a new bag onto the ring and secure it in position by means of the two side tongues;...
- Page 50 Cino XS grande PRO VHO by 13.15. regulate the speed the rotation speed of the motors of product mixers can be adjusted of mixers between 15,000 r.p.m. and 5,000 r.p.m.; the drink quality of instant products depends a lot upon the action of the fans of...
Need help?
Do you have a question about the Cino XS Grande Pro VHO and is the answer not in the manual?
Questions and answers
I think I have a blockage in the brewer. How can I remove it to check? Thank you.
To remove a blockage in the brewer of a Rheavendors Group Cino XS Grande Pro VHO:
1. Open the machine.
2. Press on each side of the protection brewer carter (a) and remove it by letting the espresso nozzle pass through the groove.
3. Remove the espresso nozzle from the nozzle holder (b).
4. Check for blockages and clean the brewer as needed.
5. Reassemble the components in reverse order.
Ensure proper cleaning procedures are followed to prevent future blockages.
