Kolida KTS-470 R Series User Manual

Electronic total station
Hide thumbs
Table of Contents

Advertisement

Quick Links

FOREWORD .............................................................................................................................................. 6
PRECAUTIONS ......................................................................................................................................... 7
BATTERY NOTIFICATION ..................................................................................................................... 8
SAFETY GUIDE......................................................................................................................................... 9
1. NOMENCLATURE AND FUNCTIONS ............................................................................................ 10
1.1 NOMENCLATURE ....................................................................................................................... 10
1.2 KEYPAD ....................................................................................................................................... 12
2. SYNCHRONIZATION WITH PC ...................................................................................................... 13
2.1 MICROSOFT ACTIVESYNC INSTALLATION .......................................................................... 13
2.2 CONNECTING TOTAL STATION WITH PC .............................................................................. 13
3. KNOWING ABOUT KTS470(R) ........................................................................................................ 15
3.1 OPERATING SYSTEM ................................................................................................................. 15
3.2 SETTING YOUR TOTAL STATION ............................................................................................ 15
3.2.1 Backlight ................................................................................................................................. 15
3.2.2 Touch-screen Adjustment ........................................................................................................ 16
3.3 APPROACHES TO INPUT NUMERAL AND CHARACTER ..................................................... 18
4．STAR KEY (★) MODE ..................................................................................................................... 21
5. PREPARATION FOR MEASUREMENT ......................................................................................... 24
5.1 UNPACKING AND STORE OF INSTRUMENT ......................................................................... 24
5.2 INSTRUMENT SETUP ................................................................................................................. 24
5.3 BATTERY INFORMATION ......................................................................................................... 26
5.4 REFLECTOR PRISM .................................................................................................................... 27
5.5 MOUNTING AND DISMOUNTING INSTRUMENT FROM TRIBRACH ................................ 28
5.6 EYEPIECE ADJUSTMENT AND COLLIMATING OBJECT ..................................................... 29
5.7 VERTICAL AND HORIZONTAL ANGLE TILT CORRECTION ................................................ 29
6. BASIC SURVEY ................................................................................................................................... 30
6.1 ANGLE MEASUREMENT ........................................................................................................... 31
6.1.1 Horizontal Angle (Right Angle) and Vertical Angle Measurement ......................................... 31
Contents
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KTS-470 R Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kolida KTS-470 R Series

Summary of Contents for Kolida KTS-470 R Series

  • Page 1: Table Of Contents

    Contents FOREWORD .............................. 6 PRECAUTIONS ............................7 BATTERY NOTIFICATION ........................8 SAFETY GUIDE............................9 1. NOMENCLATURE AND FUNCTIONS .................... 10 1.1 NOMENCLATURE ........................10 1.2 KEYPAD ............................12 2. SYNCHRONIZATION WITH PC ...................... 13 2.1 MICROSOFT ACTIVESYNC INSTALLATION ................13 2.2 CONNECTING TOTAL STATION WITH PC ................
  • Page 2 6.1.2 Switch Horizontal Angle Right/Left ..................32 6.1.3 Horizontal Angle Reading Setting ..................33 6.1.4 Vertical Angle Percentage (%) Mode ..................35 6.1.5 Repeat Angle Measurement ....................36 6.2 DISTANCE MEASUREMENT ..................... 38 6.2.1 Setting Atmosphere Correction ....................39 6.2.2 Atmospheric Refraction and Earth Curvature Correction ............42 6.2.3 Setting Target Type .........................
  • Page 3 9.4 PROJECT OPTION ........................82 9.5 GRID FACTOR ..........................83 10. DATA EXPORT/IMPORT ......................... 85 10.1 DATA EXPORT ........................... 85 10.2 DATA IMPORT..........................87 11. RECORD MEASUREMENT DATA ....................89 11.1 SETTING OCCUPIED POINT AND BACKSIGHT POINT ............89 11.2 BACKSIGHT OBSERVATION (BS OBS) ................100 11.3 FORESIGHT OBSERVATION (FS OBS) ..................
  • Page 4 13.2.2 Edit Alignment ........................148 13.2.3 Define Vertical Alignment ....................150 13.2.4 Edit Vertical Alignment ....................... 151 13.2.5 Alignment Setout ......................... 153 13.2.6 Slope Setout ........................156 13.2.7 Cross Section Setout ......................158 13.3 COGO ............................161 13.3.1 Intersection ......................... 161 13.3.2 4-Intersection........................
  • Page 5 【APPENDIX-A】 ..........................206 1 EXPORT DATA FROM TOTAL STATION ..................206 1.1 Raw Data Format ........................206 1.2 Coordinate Data Format ......................206 2 IMPORT DATA TO TOTAL STATION ..................207 2.1 Coordinate Data/Fixed Point Data Format ................207 2.2 Cross Section Data Format ..................... 207 2.3 Point P Coding Format ......................

  • Page 6: Foreword

    FOREWORD Thank you for purchasing Electronic Total Station KTS-470 R Series. KTS-470R is our second generation of Win-Total station, which realizes the automation and informationization. KTS-470R has smaller size, larger screen and control panel, it is a computer-like total station.

  • Page 7: Precautions

    PRECAUTIONS 1. Do not collimate the objective lens direct to sunlight without a filter. 2. Do not store the instrument in high and low temperature to avoid the sudden or great change of temperature. 3. When the instrument is not in use, place it in the case and avoid shock, dust and humidity.

  • Page 8: Battery Notification

    BATTERY NOTIFICATION 1． Battery should be recharged only with the charger SC-20 which comes with the total station. 2 .Battery Recharging Cautions： The charger has built-in circuitry for protection from overcharging. However, do not leave the charger plugged into the power outlet after recharging is completed. Be sure to recharge the battery at a temperature of 0°...

  • Page 9: Safety Guide

    SAFETY GUIDE For laser EDM (visible laser) Warning: The total station is equipped with an EDM of a laser grade---3R/Ⅲa. It is verified by the following labels. CAUTION LASER RADIATION-DO NOT STARE INTO BEAM 620-690nm CLASS Ⅲ LASER PRODUCT Over the vertical tangent screw sticks an indication label “CLASS III LASER PRODUCT”.

  • Page 10: Nomenclature And Functions

    1. NOMENCLATURE AND FUNCTIONS 1.1 NOMENCLATURE...

  • Page 12: Keypad

    1.2 KEYPAD Functions of the Keys Nomenclature Function Power Key To switch power ON/OFF. 0～9 Numeric Key To input desired numbers. A～/ Alpha Key To input alphabets. Inputting Panel To display inputting panel. Backspace To delete one character leftward when inputting numbers or alphabets.

  • Page 13: Synchronization With Pc

    2. SYNCHRONIZATION WITH PC 2.1 The Installation of Microsoft Activesync There is a CD-ROM attached with the instrument. Put it into your CD-Rom driver, and install Microsoft ActiveSync, then you can establish activeSync connection between 470R and Computer. Before Installing Microsoft ActiveSync Before installing, read the following words carefully: ●During the installation processing, reboot your computer is required.
  • Page 14 Using “Browse” Function After the synchronization, you can click “Browse” button to view the files stored in the total station. Copy, paste and deletion are synchronized on both ends. See the picture below.

  • Page 15: Knowing About Kts470(R)

    3. KNOWING ABOUT YOUR KTS-470(R) Press POWER to turn on the instrument. See the initial interface as below. 3.1 OPERATING SYSTEM 470R is based on Windows CE operating system; WINCE is quite similar to Windows system. The functions and interfaces are easy to use for the surveyor. Note: we also provide in KTS-470R two powerful Mapping softwares: WinMG and WinEG.

  • Page 16: Touch-Screen Adjustment

    OPERATIONAL STEPS DISPLAY ① Click “Control panel” Control panel On the desktop. ② Use stylus to roll the scroll Backlight bar to find “Backlight” icon. ③ The brightness of LCD screen backlight depends position of the cursor. [OK] turn on/off keyboard backlight by change the lower option.
  • Page 17 OPERATION STEPS DISPLAY control panel ① In “Control panel” find “adjust” icon. adjust adjust ② Click “adjust”‟ Calibration Calibration ③ Click “Calibration”, and then “Recalibrate”. Recalibrate ④ According to the prompt, use the stylus to click the cross center. Repeat as the cross moves around the screen.

  • Page 18: Approaches To Input Numeral And Character

    ⑤Press [ENT] to save new [ENT] setting, Press [Esc] to return to control [Esc] panel. 3.3 APPROACHES TO INPUT NUMBER AND CHARACTER For Total Station KTS-470R, two kinds of inputting approaches are available. One is using the keyboard, like the keyboard of a mobile phone, with 3 characters on one key. Press it once to display the first characters.
  • Page 19 ③ Press to open the soft keyboard ④ One can switch between capital letter [shift] lower-case though “shift” on the soft keyboard. Input “J”. ⑤ The system automatically returns to small letter inputting mode. Use the stylus to click characters key [o] and [b] to input “o”...
  • Page 20 ⑦ After inputting, press the “Shift” to close the soft keyboard. Press [ENT] to create the current working project. Press [ ] key to close soft keyboard. [Example 2：Input by physical keyboard] OPERATIONAL STEPS DISPLAY ① Click “project” choose “New project” on the pull-down menu.

  • Page 21: 4．Star Key (★) Mode

    ④ Press [α] key to switch [α] back to number inputting mode and press [-] to input-and [1] to input the number “1”. ⑤ After inputting, press [ENT] key. [ENT] ※ press [ ] key one time to open the soft keyboard. Press again to close it. ] to select “Keyboard”...
  • Page 22 Rotate the leveling screws while observing electric circular bubble. After the bubble centered at the cross point, press [Back] to return the previous interface. 2. Set the Temperature ,Pressure, Atmospheric Correction Value （ PPM） and Prism constant value（PSM） Click [Atmos] to view the Temperature, Pressure, PPM and PSM. To modify parameters, point the cursor to the textbox by stylus, and input the new value.
  • Page 23 laser EDM. The reflector can be set as Prism, Non-prism and Reflecting Sheet. ●Refer to “technical parameters” for the parameter of different reflectors. Setting of illumination of cross hair: ●Move the stylus to adjust the brightness of crosshair. L: Indicate that the crosshair is dim. H: Indicate that the crosshair is bright Move the stylus from left to right to change the brightness of the crosshair from dim to bright.

  • Page 24: Preparation For Measurement

    5. PREPARATION FOR MEASUREMENT 5.1 UNPACKING AND STORAGE OF INSTRUMENT - Unpacking of instrument Keep the case right side up with care, and open the instrument container and take out the instrument. - Storage of instrument Cover the objective lens with the cap and place the instrument into the case. Make sure the vertical clamp screw and circular vial stay upwards (Objective lens towards tribrach), and slightly tighten the vertical clamp screw and lock the case.
  • Page 25 ③ Turn the leveling screw C to move the bubble to the center of the circular vial. 4) Precisely leveling by using the plate vial ① Rotate the instrument horizontally by loosening the Horizontal Clamp Screw and place the plate vial parallel to the line connecting leveling screw A and B, and then bring the bubble to the center of the plate vial by turning the leveling screws A and B.

  • Page 26: Battery Information

    whether the bubble is correctly centered in all directions. 2. Centering by using the optical plummet 1) Set tripod Set up tripod to suitable height, ensure equal length of three legs, spread and make tripod head parallel to the ground, and place it right above the measurement station point.

  • Page 27: Reflector Prism

    measurement mode, so the power enough for the latter is not sure applicable for the previous one. Pay particular attention to this when switching angle measurement mode to distance measurement mode, because insufficient battery power might lead to interrupted operation. ●...

  • Page 28: Mounting And Dismounting Instrument From Tribrach

    5.5 MOUNTING AND DISMOUNTING INSTRUMENT FROM TRIBRACH · Dismounting If necessary, the instrument (including reflector prisms with the same tribrach) can be dismounted from tribrach. Loosen the tribrach locking screw in the locking knob with a screwdriver. Turn the locking knob about 180° counter-clockwise to disengage anchor jaws, and take off the instrument from tribrach.

  • Page 29: Eyepiece Adjustment And Collimating Object

    5.6 EYEPIECE ADJUSTMENT AND COLLIMATING OBJECT Method of Collimating Object（for reference） ① Sight the Telescope to bright place and rotate the eyepiece tube to make the reticle clear. ② Collimate the target point with top of the triangle mark in the coarse collimator.

  • Page 30: Basic Survey

    Turn the leveling screw to make the black dot move into the small circle. When the small black dot is in the small circle, it means the instrument is within the auto tilt compensation scale ±3.5′. If it is outside the small circle, the instrument needs to be leveled manually.

  • Page 31: Angle Measurement

    Current parameters Mode key Function key Description of each function key: Function keys display at the bottom of the screen, which change with the measure mode. The following graph lists each function key in every measure mode. Mode Display Softkey Function 0 Set 0 Set horizontal angle.

  • Page 32: Switch Horizontal Angle Right/Left

    Make sure the mode is Angle measurement. OPERATION STEPS DISPLAY ① Sight target A Sight the first target A. ② Set the horizontal angle of target A as 0°00′00″. [0 Set] Click [0 SET], press [OK] in the [OK] pop-up dialog box to confirm. ③...

  • Page 33: Horizontal Angle Reading Setting

    Make sure the mode is Angle measurement. OPERATION STEPS DISPLAY ① Make sure the mode is Angle measurement. ② Click [HR/HL] key, horizontal right angle measuring mode is [HR/HL] shifted to left angle mode.※1) ※1)Every time click [HR/HL] key，HR/HL is shifted in order. 6.1.3 Horizontal Angle Reading Setting 1) Setting by holding the angle Make sure the mode is Angle measurement.
  • Page 34 ② [Hold] Click [Hold], hold the required horizontal angle. ③ ※ Collimate the target. 1） ④ Click [Unlock]]，to release the horizontal angle. The display turns [Unlock] back to normal angle measurement mode ， setting current horizontal angle as the value held just now.

  • Page 35: Vertical Angle Percentage (%) Mode

    ② [HSet] Click [HSet]，a dialog box pops Input ③ horizontal Input the required horizontal ※ ※ angle angle 1)、 For Example: 120°00′00″ ④ ※ After inputting, press [ENT] [ENT] When completed, normal measuring from required Horizontal angle is possible. ※ 1) You can press [ ] to open inputting panel, click the numbers to input,see “3.3 APPROACHES TO INPUTTING NUMBERS AND LETTERS”.

  • Page 36: Repeat Angle Measurement

    ② [V%] Click [V/%]. ※ 1) Every time Click [V/%], the display mode switches accordingly. 6.1.5 Angle Repetition Measurement This program is used to angle repetition measurement, displaying the sum and average value of all observed angles. It records the observation times at the same time. Example：...
  • Page 37 ② Sight target A Sight the first target A. ③ [0 Set] Click [0 Set], 0 Set the horizontal angle. ④ Sight B Use horizontal clamp screw and horizontal tangent to sight the second target B. ⑤ [Hold] Click [Hold].

  • Page 38: Distance Measurement

    ⑥ Sight A again Use horizontal clamp screw and horizontal tangent to sight first target A again. [Unlock] ⑦ Click [Unlock]. ⑧ Sight B again Use horizontal clamp screw and horizontal tangent to sight the second target B again. [Hold] ⑨...

  • Page 39: Setting Atmosphere Correction

    When the [DIST] is triggered, the EDM measures the object which is in the beam path at that moment. If e.g. people, cars, animals, swaying branches, etc. cross the laser beam while a measurement is being taken, a fraction of the laser beam is reflected and may lead to incorrect distance values.
  • Page 40 meter) If the pressure unit adopted is mmHg: make conversion with: 1hPa = 0.75mmHg. ●The standard atmospheric condition of KTS-470R Series (e.g. the atmospheric condition under which the atmospheric correction value of the instrument is zero ) : Pressure：1013 hPa ℃...
  • Page 41 ④ Press [OK] to save these parameters. System will get PPM value from value temperature and air pressure, The [OK] screen displays as the right graph. ※1The inputting range: Temperature:-30～+60℃(step length 0.1℃) or -22～+140℉(step length 1℉) Air pressure:420 ～ 800 ㎜ Hg(step length 1 ㎜ Hg) or 560 ～ 1066 hPa (step length 0.1hpa) 16.5 ～...

  • Page 42: Atmospheric Refraction And Earth Curvature Correction

    ③Click [Save] to save the value. [Save] ※1)The inputting scope of Atmospheric parameters ：-100 ～ +100 PPM(step length : 1PPM) Atmospheric Correction value also can be set in star key (★)mode. 6.2.2 Atmospheric Refraction and Earth Curvature Correction When calculating the horizontal distance and the height differences, the instrument will automatically correct the effect of atmosphere refraction and the earth curvature the correction.

  • Page 43: Setting Target Type

    6.2.3 Setting Target Type KTS-470(R) Series Total Stations can set options of visible Laser EDM and Invisible Laser EDM, as well as reflector with prism, non-prism, and reflective sheet. User can set them according to the requirements of the job. You can set Target Type in star key (★)model.

  • Page 44: 4Setting The Prism Constant

    6.2.4 Setting the Prism Constant Since the constants of prisms manufactured by different companies are different, the corresponding prism constant must be set. Once the prism constant is set, it would be kept even if the machine is turned off. OPERATION STEPS OPERATION DISPLAY...
  • Page 45 OPERATION STEPS DISPLAY ① Sight Sight at the center of prism. ③ Click [Dist] to enter distance measurement. The system start [Dist] measuring according to EDM mode set last time. ③Click [Mode] to enter EDM Mode setting. [Mode] Here takes Fine[r] as example. ④The measure result displays.※1)～...

  • Page 46: Distance Measurement (Single/N-Time Measurement)

    6.2.6 Distance Measurement (Single/N-Time Measurement) When the number of times for measurement is preset, the instrument measures the distance according to the specified number or times. The average result will be displayed. When presetting the number of times as 1, it does not display the average distance because it is just single measurement;...

  • Page 47: Fine/Tracking Measurement Mode

    6.2.7 Fine/Tracking Measurement Mode Fine mode: This is the common distance measurement mode. Tracking mode: This mode measures quickly. Use this mode for stake-out measurement. It is very useful for tracing the moving object or carrying out stake-out job. Example： OPERATION STEPS DISPLAY ①Sight the center of prism.
  • Page 48 occupied point. Example： OPERATION STEPS DISPLAY ① [Coord] Click [Coord] to enter into coordinate measurement. ② [Occ] Click [Occ] . ③ Input coordinate of occupied point, after inputting one item, [Enter] click [Enter] to move to the next item.

  • Page 49: Setting The Backsight Point

    ④ [Enter] After all inputting, click [Enter] to return to coordinate measurement screen. 6.3.2 Setting the Backsight Point Example： OPERATION STEPS DISPLAY ① [BS] Click [BS] to enter BS Setting. ② Input coordinate of backsight point. After inputting one item, [Enter] click [Enter] to move to the next item.

  • Page 50: Setting The Instrument Height/ Prism Height

    ④ Sight at the backsight point, click [YES]. System sets the backsight azimuth and returns to Coordinate Measurement [Yes] Screen. The screen displays the backsight azimuth set just now. 6.3.3 Setting the Instrument Height/ Prism Height Measure the Coordinate by entering the instrument height / prism height, Coordinate of unknown point will be measured directly.

  • Page 51: Operation Of Coordinate Measurement

    6.3.4 Operation of Coordinate Measurement Measure the Coordinate by entering coordinate of occupied point, backsight azimuth, the instrument height and prism height, coordinate of unknown point will be measured directly. ●To set coordinate value of occupied point，see Section “6.3.1 Setting Coordinate Values of Occupied Point”.
  • Page 52 Example： OPERATION STEPS DISPLAY ①Set coordinate values of occupied point and instrument / prism height ※1) ②Set backsight azimuth。※2) ③Collimate target. ※3) ④ Click [Coord]. Measurement [Coord] ends and the result displays.※4) ※1) In case the coordinate of occupied point is not entered, then the coordinate of occupied point set last time would be used.

  • Page 53: Application Programs

    7. APPLICATION PROGRAMS 7.1 LAYOUT The difference between the measured distance and the preset distance is displayed. The displayed value = Measured distance – Standard (Preset) distance ● This function enables the stake-out of Horizontal Distance (HD), Vertical Difference (VD) or Slope Distance (SD) . Example：...

  • Page 54: Remote Elevation Measurement (Rem)

    7.2 REMOTE ELEVATION MEASUREMENT (REM) The Remote Elevation program calculates the vertical distance (height) of a remote object relatively to a prism and its height from a ground point (without a prism height). When using a prism height, the remote elevation measurement will start from the prism (reference point).
  • Page 55 Input prism ③ height Input prism height. ⑤ Sight the prism center P. ⑤ Sight the prism Click [Measure] to start measure. ⑥ [Measure] The HD between instrument and prism is displayed. ⑦ Click [Continue], the prism position is entered. [Continue] ⑧...

  • Page 56: Without Inputtingt Prism Height

    7.2.2 without Inputting Prism Height Example： OPERATION STEPS DISPLAY ① Use stylus to click “Without R. Without R.Ht Ht” ② Sight prism center P. ③ Sight prism Click [Measure] to start survey. ④ [Measure] The HD between instrument and prism is displayed. ⑤...

  • Page 57: Missing Line Measurement (Mlm)

    ⑥ [Continue] Click [Continue]. ⑦ Sight target Sight target K. The Vertical Distance (VD) is ※ displayed. ※ 1) To quit REM, click [Exit]. 7.3 MISSING LINE MEASUREMENT (MLM) The Missing Line Measurement program computes the horizontal distance (dHD), slope distance (dSD) and vertical difference (dVD). This program can accomplish this in two ways: 1．(A-B，A-C)：Measurement A-B，A-C，A-D ……...
  • Page 58 2．(A-B，B-C)：Measurement A-B，B-C，C-D …… [EXAMPLE] 1. (A-B，A-C) OPERATION STEPS DISPLAY ① In Distance Measurement, click [MLM] to enter into missing line [MLM] measurement function ② Use stylus to select A-B，A-C.
  • Page 59 ③ Sight prism A, click [Measure]. The HD between instrument and [Measure] prism A is displayed. ④ [Continue] Click [Continue]. ⑤ [Measure] Sight prism B， Click [Measure]]. ⑥ Click [Continue], The horizontal distance (dHD) height differentia [Continue] (dVD) and slope distance (dSD) between prism A and B display.

  • Page 60: Line Measurement (Line)

    ⑦ To measure distance between point A and C, sight prism C and [Measure] then click [Meas. After measuring, horizontal distance between the instrument and prism C displays. ⑧ [Continue] Click [Continue], the horizontal distance (dHD) height differentia (dVD) and slope distance (dSD) between prism A and C display.
  • Page 61 OPERATION STEPS DISPLAY ① [Line] In Distance Measurement, click [Line] to enter into line height measurement function ② Use stylus select with R.H. ③ Click [Set] to set instrument height and target height. After [Set] inputting, click [Enter]. ④ Sight prism A, click [Meas] to start measure.
  • Page 62 ⑤ [Meas] Sight prism B, click [Meas] to start distance measure. ⑥ After measuring click [Continue]. [Continue] ⑥ Sight line point L, Measured data to the line point L is displayed. VD : Vertical distance HD: Horizontal distance from the instrument to L Off : Horizontal distance from A to ⑦...

  • Page 63: Traverse Measurement (Restore Nez)

    ⑧ Sight at G Rotate the vertical tangent screw and sight at ground point G. ⑩Click [Next], line height LH (LH) and horizontal distance (Off) [Continue] are displayed ※1)～※3) ※ 1) To finish the measurement, press [ESC]. ※ ⑦ 2) To return to operation step click [VD].
  • Page 64 ●Set the coordinate value of instrument point P0 and set the direction angle from P0 toward the known point A. Example： OPERATIONAL STEPS DISPLAY ① [Store] Click [Store]. [Store] ② Use stylus select “Store” ③ Click [Set] to reset instrument height or prism height.
  • Page 65 ⑤ Click [Continue] . The coordinates of P1 displays at [Continue] the bottom of screen. ⑥ Click [Store] . Coordinate of P1 will be confirmed. [Store] The display returns to main menu. Power off and move instrument to P1 (Prism P1move to P0 ) 7.

  • Page 66: Offset Measurement (Offset)

    7.6 OFFSET MEASUREMENT (OFFSET) There are four offset measurement modes in the Offset Measurement. 1. Angle offset 2. Distance offset 3. Plane offset 4. Column offset 7.6.1 Angle Offset This mode is useful when it is difficult to set up the prism directly, for example at the centre of a tree.
  • Page 67 OPERATIONAL STEPS DISPLAY ① [Offset] Click [Offset]. ② In the prompted dialogue box click [Angle Offset] to enter into angle offset measurement. Angle ③ Use the stylus to select “Free Offset VA” (or “Fixed VA”) to start angle offset measurement. Sight prism P ④...

  • Page 68: Distance Offset

    ⑥ Click [Continue], The slope distance, horizontal distance [Continue] height differentia and coordinate from instrument to point AO will be ※ ※ shown 1)， ※ 1) To set instrument height or target height, click [Set]. ※ 2) Click [Exit] to quit. ●...
  • Page 69 OPERATIONAL STEPS DISPLAY ① [Distance In Offset dialog box, click [Distance Offset] to enter into Dist. Offset] Offset. ② Move stylus to “Input”, enter the offset distance. When each value is inputted, use stylus to move the next item. ③ After inputting “dRL”, sight the prism, click [Measure] to start [Measure]...

  • Page 70: Column Offset

    7.6.3 Column Offset If it is possible to measure circumscription point (P1) of column directly, the distance to the center of the column (P0), coordinate and direction angle can be calculated by measured circumscription points (P2) and (P3). The direction angle of the center of the column is 1/2 of total direction angle of circumscription points (P2) and (P3).

  • Page 71: Plane Offset

    ③ Collimate the point (P2) on the left side, as shown in the right [Continue] graph. Click [Continue]. ④ Collimate the right side of the column (P3) ⑤ Click [Continue], the distance between the instrument and center [Continue] of the column (P0) will ※...
  • Page 72 ●Setting the coordinate of occupied point, refer to “6.3.1 Setting Coordinate Values of Occupied Point”. Example： OPERATIONAL STEPS DISPLAY ① In Offset dialog box, click [Plane Offset] to enter into Plane Offset [Plane Offset] measurement. ② Sight prism P1, click [Measure] to start measure After measuring, [Measure] click [Continue].

  • Page 73: Parameters Setting

    ④ [Measure] Sight prism P3，Click [Measure] to start measure. ⑤ Click [Continue] to calculate and display coordinate and distance [Continue] value of cross point between collimation axis and of the plane . ※ ※ 1) To set instrument height or target height, click [Set]. ●In case the calculation of plane was not successful by the measured three points, error displays.
  • Page 74 Menu Selecting Item Contents 1. Coord. Ranking NEZ/ENZ Select the display format in the coordinate measurement mode for NEZ or ENZ 2.Occ Save 0 Set / Save Select whether to save coordinate of occupied point or 0 Set. 3.Angle Unit Deg/Gon/Mil Select degree (360°...

  • Page 75: Start Standard Surveying Program

    ④ [Default] default communication parameters, click [Default]. ⑤ [Other To set other parameters, click [Other Parameter]. Set as the same Parameter] method. ⑥ [OK] After setting click [OK] to quit. The display returns to basic survey main menu. 8. START STANDARD SURVEYING PROGRAM In Total station main menu, click “...
  • Page 76 ●Multiple Job Files Standard Surveying program uses different files (with Job name) for raw data, coordinates and character strings. The job is given alphanumeric names. You may have many jobs in the system. You may create a new job for storing data, or you may open an existing job for data storage.
  • Page 77 ●Upload Roads Design data from serial port Horizontal alignment data, vertical alignment data and cross section data for Alignment lay out can be uploaded from serial port. ●Point Setting-Out The standard setting out program calculates bearing and distance, displays offsets from occupied point to lay-out point after each measurement.

  • Page 78: Project

    ●Area Calculation Area calculation of a serial of points defined by point code. ●Radiation Coordinates of a point can be computed by entering bearing and distance. ●Missing Line measurement The slope distance, horizontal distance and vertical distance between two points can be computed.
  • Page 79 made up from the letters A-Z, numbers 0-9 and the minus sign (_# $ @ % + -), but the first character can not be a space. OPERATION STEPS DISPLAY ① [New] [Project] menu, click [New]. ② Enter In the prompt dialog box, enter name of project, operator, and brief information information.

  • Page 80: Open Project

    9.2 OPEN PROJECT Example： OPERATION STEPS DISPLAY ① In [Project] menu,，Click [Open] or press [▲]/[▼] to select. The [Open] screen lists all jobs in internal memory. ② Double click to open the project, or input project name in the Name field.

  • Page 81: Delete Project

    9.3 DELETE PROJECT Example OPERATIONAL STEPS DISPLAY ① In [Project] menu, ， Click [Delete] or press [▲]/[▼] to select. [Delete] The screen shows as the right graph. ② Double click the project you want to delete. Delete some files： The system defaults to delete all projects.

  • Page 82: Project Option

    9.4 PROJECT OPTION OPERATIONAL STEPS DISPLAY ① In [Project] menu, ， Click [Option] [Option] (or press [▲]/[▼] to select), the screens as the right graph. ②Click each item to set. Click [Set] [Set] to return. Options: Fixed File：Set fixed point file [On] or [Off]. 1）...

  • Page 83: Grid Factor

    9.5 GRID FACTOR Measured horizontal distance is multiplied by the scale factor in coordinate calculation. The raw data is not altered by the scale factor. Enter the scale factor and the mean elevation into screen, the downloaded raw data will contain a scale factor record. The following grid factor is used to calculate coordinates.
  • Page 84 ② Input the Scale and Elevation. ③ [Enter] The system calculates the grid factor. Click [Enter].The display returns to standard survey main menu. Note:1. Inputting range of scale:0.990000 ～ 1.010000. The default value: 1.00000 2. Inputting range of average altitude: -9999 ～ 9999 The default value: 0...

  • Page 85: Data Export/Import

    10. DATA EXPORT/IMPORT 10.1 DATA EXPORT Measuring data coordinate and data of dig/fill, cross section may be exported to specified location. OPERATIONAL STEPS DISPLAY ① [Data Export] In project menu, click [Data Export]. ② In the prompt dialog, click the data you want to export.
  • Page 86 SD CARD STORAGE: 470R allow surveyors to restore data into SD card. Export the data you need to the disk inside of the total station first. System will save the result in TXT form. Plug in the SD card, then you could find that icon of SD card in 470 system.

  • Page 87: Data Import

    10.2 DATA IMPORT Coordinate files for setout, fixed point and code library files, alignments and cross section files for setout may be uploaded from a computer to the total station, then import to the project. Example： OPERATION STEPS DISPLAY ① [Data Import] In Project menu, click [Data Import].
  • Page 88 ④ Click [OK], data is imported to appointed position and return to [OK] standard survey main menu. ※ 1)HZ Alignment：Upload a horizontal alignment for road design layout. Data format please refer to appendix A. There is only one start point can be existed in a block of horizontal alignment data; otherwise it may cause some mistakes.

  • Page 89: Record Measurement Data

    11. RECORD MEASUREMENT DATA The RECORD menu is mainly used for collecting and recording raw data. It allows setting occupied point and backsight bearing, start backsight observation, foresight observation, sideshot observation and cross section observation. In standard survey main menu, click [Record] or press [ ]/ [ ]. 11.1 SETTING OCCUPIED POINT AND BACKSIGHT POINT Example：...
  • Page 90 ② In “Occ PT” input the point A： name. Click [Info]. A：The system will start searching function. If the point name doesn‟t exist in internal memory, system will prompt to input coordinate As shown in the right graph. B： B ： If the point name exists in internal memory, system will call up the point automatically and display on the screen.
  • Page 91 ③ Input the backsight point. ④ system calculates azimuth. ⑤ Click [Set] to enter into BS Set function. Bks：Bearing calculated by system [Set] or entered manually. HR：Current horizontal azimuth.
  • Page 92 ⑥ A： A ： If click [0 Set] ， then the horizontal angle displays 0. Click [Enter] to quit and set BS azimuth as 0. B：If click [Set], the HR displays as the azimuth. B： C： If click [Check], backsight point coordinate will be checked by measuring the slope distance of backsight point.
  • Page 93 11.1.1 Resection If the coordinates of an occupied point are unknown, a resection can be performed to compute these coordinates. A resection involves the measurements from an occupied point to several other points with known coordinates. It is possible to perform a resection by measuring angles and distances or by measuring angles only.
  • Page 94 ③ Input PT, Input the number of know point which used for resection and prism prism height height. ④ [Mode] Click [Mode] to choose measure mode. ⑤ [Measure] Sight the center of target prism, click [Measure] to start measure. ⑥ After measuring, click [Record], a dialog box shows as the right [Record]...
  • Page 95 ⑦ The system returns to resection main menu. The screen displays the PT just measured If the coordinate is unknown, system will request user to input the coordinates and then return to resection main menu. ⑧ Click [Add] again, repeat steps ②...
  • Page 96 ●It is possible to select whether the level of the occupied point, a scale factor or the backsight bearing („Calculate Bkb‟) should be calculated. Furthermore it is possible to select whether the calculated scale or the measurements which have been performed („Store res meas‟) should be stored.
  • Page 97 E.g.: 1) If p1, p2, p3 and OccPt fall on the circle, the result can not be computed. 2) If the point is near the circle then the result is unstable. 3) Residuals are useful to avoid that observations of low quality will be used for the resection computation.
  • Page 98 ② Input Input known PT and Prism height, and sight the center of Target height prism. Click [Measure] to start [Measure] survey. ③ [Record] After measuring click [Record].
  • Page 99 A： ④ [OK] Click [OK]. A： If the point name doesn‟t exist in ↓ internal memory, system will prompt to input coordinate As shown in the right graph. System calculates height of occupied point automatically. ↓ B： B：If the coordinate of the point exists in the file, System calculates height occupied...

  • Page 100: Backsight Observation (Bs Obs)

    11.2 BACKSIGHT OBSERVATION (BS OBS) For record the raw data of backsight point. Back Sight Observations only can start after setting of occupied point and backsight point. Example： OPERATIONAL STEPS DISPLAY ① [BS Obs] In [Record] menu click [BS Obs] or press [▲]/[▼] to enter into BS measurement ②...

  • Page 101: Foresight Observation (Fs Obs)

    11.3 FORESIGHT OBSERVATION (FS OBS) The data of Foresight Observations mainly used for the traverse adjustment calculation. After setting Occ. point and BS point, the measuring begins. Example： OPERATIONAL STEPS DISPLAY ①In [Record] menu click [FS Obs] [FS Obs] or press [▲]/ [▼] to enter into FS measurement.
  • Page 102 ⑤To change measure mode, click [Mode]. Click“○” before the mode, [Mode] and click [Enter]. ⑥Click [Measure] to start survey. After measuring, the results display. [Measure] Click [Record], a dialog box [Record] prompts as the right graph. ⑦ Click [OK], N 、 E 、 Z [OK] coordinates display.

  • Page 103: Sideshot Observation (Ss Obs)

    11.4 SIDESHOT OBSERVATION (SS OBS) OPERATIONAL STEPS DISPLAY ① [SS Obs] In [Record] menu click [SS Obs] or press [▲]/ [▼] to enter SS Measurement. ② Input PT, R.Ht Input PT, R.Ht. Click [Measure] to start measure. [Measure] ③ [Record] After measuring, the results display.
  • Page 104 ④ Click [OK], N、 E、 Z coordinates display. [OK] If the point exists, system prompts whether to cover the point. ⑤ [Enter] Click [Enter]，the measurement results are saved. ② ⑤ ～ Repeat finish measurement. ※ 1) Click [Mode], to select measure mode among Fine[S]/Fine [N]/ Fine[R]/Track/Angle Meas. ※...

  • Page 105: Offset

    11.4.1 Offset Apply the following procedure to a point which can not be measured directly. Measured data change to raw data directly. A radial (forward) offset is along the line of sight, with positive away from the instrument, and a tangential (right) offset is perpendicular to the line of sight with positive to the right, as viewed from the instrument.
  • Page 106 Record an observation as close as possible to the required point. OPERATIONAL STEPS DISPLAY ① [Measure] In [SS] function sight the prism center. Click [Measure] to start measure. ② [Function] Keep the instrument still, click [Function]. A dialog box prompts as the right graph.
  • Page 107 ④ Input Away Input Away offset manually. Away: off set along the line of sight offset ⑤ Collimate offset target point, press [Horizon] or [Vertical] , the [Horizon] offset value will be computed and displayed on screen [Vertical] Right: The offset value for right/left direction.

  • Page 108: Plane Offset

    ⑧ [Enter] Click [Enter] to return to SS Measurement screen. 11.4.2 Plane Offset This mode is similar with【PROGRAM】→【Offset】→【Plane Offset】. Example： OPERATIONAL STEPS DISPLAY ① [Function] Measurement, click [Function]. ② Click [Plane Offset] to enter into Plane Offset Measure. [Plane Offset] Click [Define], to enter into Define Plane function.
  • Page 109 ④ [Record] After measuring click [Record]. ⑤ ③ ④ ～ Repeat steps to finish measuring other two points for entering reference plane. ⑥ After defining the Plane, the system prompts as the right graph. [On] Click [On] to open Plane Offset ※...

  • Page 110: Pt. Line Mode (For Measurement From Point To Line)

    ⑧ [Record] Click [Record] to record results of Plane Offset. ⑨ [Enter] Click [Enter] to save measuring results. ⑦ ⑧ ～ Repeat steps to finish measuring other points on the plane. ※ 1) [On]：Function key used to display “Plane Offset”. In SS Measurement screen “Plane Offset Mode”...
  • Page 111 occupied point during the process.) Example： OPERATION STEPS DISPLAY ① Measure coordinates of Point A、 B，record in the memory. In SS [Pt. Line Measurement, click [Pt. Line Mode] Mode] to enter into Point Line Mode. ② Define base line. Enter the Point number of start point and stop point If the point does not exist, it displays “Coord PT not found!”...
  • Page 112 ⑤ [Record] After measuring click [Record]. ⑥ [OK] Click[OK] to display coordinate. ⑦ [Enter] Click [Enter] to save the results.. ④ ⑥ ～ Repeat steps to finish measuring other points. ※ 1)[On]：It is used to activate Point to Line Mode. [Off]：It is used to disable the Point to Line Mode.

  • Page 113: Control Input

    11.4.4 Control Input Control Input function is used for editing the string and appended code of the point. OPERATION STEPS DISPLAY ① [CTRL Input] In SS Measurement, Click [CTRL Input] to enter into control code Input function. ② Input Control code, Code2 and String 2.
  • Page 114 Set occupied point and backsight point. OPERATIONAL STEPS DISPLAY ① In [Record] menu click[X-Sect], a dialog box prompts as the right [X-Sect] graph. Input CL Code Input CL Code and String and click and String [Enter]. ② Start cross section measurement. First measure point on center line.
  • Page 115 ④ [Record] Click [Record] to record measure results. ⑤ [OK] Click [OK] to display the coordinates of this point. Click [Enter] [Enter] to save the results. ⑥ The screen returns to standard measurement. Input code of each point on the cross section, repeat ②...

  • Page 116: Edit Data

    ⑧ When the cross section is saved; the screen will display the code of mid-line and string. Click[Enter] to receive the same code or enter new [Enter] code. Click “ ” to quit X-Sect measurement record. ⑨ ② ⑧ ～ Repeat steps to finish measuring points of cross section...
  • Page 117 To edit the raw data from the current job select Raw Data from the Edit menu.： Function keys at the bottom of the screen： [Start]：Go to the beginning of this file. [End]：Return to the end of the file [Search]：To search a specific point, code or string in the file Example OPERATION STEPS DISPLAY...
  • Page 118 B： Click [Search], in the prompt dialog box input PT, Code, String, and select between Full Name and Part Name. Click [Search] to start search. B： ③ [Edit] After finding the needed data, click [Edit],the Meas. Data Edit dialog box appears. ④...

  • Page 119: Coord. Data

    2. Coordinates that are entered or changed are rounded to 3 decimal places. 12.2 EDIT COORDINATE DATA The coordinates generated from the current job may be edited or point coordinates may be manually entered. In [Edit] menu click [Coord. Data]. 12.2.1 Edit Coord.
  • Page 120 ② A： Search the needed coord. data A：Click the slide bar to display all coord. data. Click the needed point name when it appears. You can press [▲]/[▼] to view the data. B： B： Click [Search], in the prompt dialog box input PT, Code, String, and select between Full Name and Part Name.

  • Page 121: Add Coord. Data

    ④ Input data Input new data ⑤ [Enter] Click [Enter], the screen returns to the Coord. Data Edit dialog box, the data is rectified. 12.2.2 Add Coord. Data Example： OPERATIONAL STEPS DISPLAY ① [Coord. Data] In Edit menu, click [Coord. Data], system lists...

  • Page 122: Delete Coord. Data

    Input PT ID, ③ Code, String, Input PT ID, Code, String, and N, E, Z coordinate. coordinate. ④ Click [Enter], and return to previous screen. The data will be [Enter] added on the bottom of the profiles. 12.2.3 Delete Coord. Data Example：...

  • Page 123: Fixed Point Data

    ③ [OK] Click [OK] and the data are deleted. The screen returns, and the cursor moves to next row. NOTE：1. The range of each coordinate is from -9999999.999 to 9999999.999 2. Coordinates that are entered or changed are rounded to 3 decimal places. 12.3 EDIT FIXED POINT DATA To edit the fixed point library select Fixed Data from the EDIT menu.

  • Page 124: Create New Layer

    12.4.1 Create New Layer OPERATIONAL STEPS DISPLAY ① [Code Data] In Edit Menu, click [Code Data], the system lists all code data in the job. ② [Add] Click [Add] to display a dialogue as shown on the right. Input Layer, Code Attribute dialogue.
  • Page 125 ④ A： A： New codes are added under the layer. B： B： A new code layer and code will be created.

  • Page 126: Edit Layer/Code

    12.4.2 Edit Code Layer/Code OPERATIONAL STEPS DISPLAY A：Layer ① Use the stylus to click on the layer or code to be edited. B：Code A：Edit Layer ② Click [Edit]. Input new data. [Edit] B：Edit Code...

  • Page 127: 3Delete Code

    A：Layer ③ After editing, click [Enter]. [Enter] B：Code 12.4.3Delete Code OPERATIONAL STEPS DISPLAY ① Use the stylus to click the code to be deleted. ② [Delete] Click [Delete], a notice appears as shown on the right.

  • Page 128: Fill-Cut Data

    ③ [OK] Click [OK], the screen returns, ※ and the code is deleted. ※ 1) The layer can‟t be deleted when the layer contains codes. 12.5 FILL/ CUT DATA The fill-cut data generated by the layout option can be viewed by the [EDIT]→ [Fill-Cut Data] option.

  • Page 129: Program Menu

    13. PROGRAM MENU The menu includes below functions: ⑪ Set Out ⑫ Roads ⑬ Cogo ⑭ Traverse ⑮ B.Boards ⑯ Tape Dim 13.1 SET OUT To show the SET OUT menu, from the 【Program】 menu, select 【 Set Out】 . The setting out option allows setting out by point number, strings, alignments and cross sections.
  • Page 130 OPERATION STEPS DISPLAY ① [Set Out] [Program] menu, click [Setout], in the prompt box click [Setup] [Setup] to enter into Occ. &BS Set screen. ② If alignment data exists in internal memory, you can click [Align] to set the occupied point Here the method of using alignment [Align.] to setup occupied point and azimuth...

  • Page 131: Point Set Out

    ⑤ System calculates azimuth, click [Set]. In the display shown as right [Setup] the Backsight azimuth is set. ⑥ occupied point backsight azimuth is saved, and then the alignment setout data screen displays. ●If you already have entered the occupied point and backsight point details from either RECORD or SETOUT menus, you can skip these routines and go directly to the set out POINTS,STRINGS,ALIGN or X-SECTS.
  • Page 132 ② A： In the prompt dialog box input the PT and Prism Height. A： If the coordinates of the point number exists in memory, system will call up the point automatically. B： B： If the coordinate data of the point is not stored in memory, system will recommends that to input setout point.
  • Page 133 ④ Rotate the telescope, making “Turn” item and “→” item display as 0, and ask the rodman to move the prism. ⑤ Sight the prism center, and click [Measure] to start measure. Ask the rod man to move prism [Measure] frontward and backward.
  • Page 134 Explanation： The ANGLE screen displays the required horizontal angle (Req), the horizontal angle from the current to the setout point (Turn), the distance from the prism to the setout point (Away) and the difference in elevation (Cut). The OFFSET display shows the distance from the measured point to the required setout point in the form of offsets.

  • Page 135: String Setout

    13.1.3 String Setout After setting occupied point and backsight point, you can start string setting out Example： OPERATIONAL STEPS DISPLAY ① In [Program] menu, click [Set [Set Out] Out], in the prompt menu click [Strings] [Strings] ②Input Chainage and String of the point to be set out, and click [Set Out].
  • Page 136 13.1.4 Reference line This program facilitates stake-out or checking lines for buildings, sections of road, simple excavations, etc. What Reference Line is: A reference line can be defined as a known base line. The reference line can be offset longitudinally, in parallel or vertically to the base line, or be rotated around the first base point as required.
  • Page 137 Offset: Parallel offset of the reference line to the right, referred to the direction of the base line. Line: Longitudinal offset of the start point (=reference point) of the reference line in the direction of base point. HZ: Height offset; the reference line is higher than the selected reference height. Rotate: Rotation of the reference line clockwise around the reference point.
  • Page 138 Always computes the height difference with the height of the first reference point (△ OPERATIONAL STEPS OPERATION DISPLAY ① In Programs menu, press [Set Click Out] to enter “Reference line”. “Reference line”...
  • Page 139 ② Set the station and orientation, (As the method of setting job, station and orientation have been introduced previously; it will not be repeated here.) ③There are three methods to define the baseline points, measure directly Input Pt and call the point from List, and input the coordinates directly.
  • Page 140 ○ 6 Enter the PtID and R.HT Input the PtID and R.HT Click Meas then get the dLOff, dToff, dVOff. Orthogonal Stake-Out User can enter longitudinal, transverse and height offsets for the target points to be set-out related to the reference line. The program calculates the difference between a measured point and the calculated point.
  • Page 141 OPERATIONAL STEPS OPERATION DISPLAY ① Define the baseline as previous, Click “STAKE” the third function STAKE to enter Orthogonal Stake-Out. ② Input the PtID, R.HT and offset Input offset, and line , H/Z values. line, H/Z , click OK.

  • Page 142: Road Design And Layout

    ③ Show layout interface, the method have been introduced previously; it Click will not be repeated here. Measure 13.2 ROAD DESIGN AND LAYOUT 13.2.1 Define Horizontal Alignment In [Roads] menu select [Define HZ AL]. To know how to calculate an alignment, see appendix B.
  • Page 143 ② A： First, input the details of start point and end point: Chainage, N, and Z. A：They can be input manually. B： B：For N, E, click [Load] to load data from the project. ③ After inputting information of start point, click [Save] to save. [Save] Then enter into the screen of alignment input process.
  • Page 144 be minus. Example： OPERATIONAL STEPS DISPLAY ① [Straight] On the screen of input process, click [Straight], the screen will display factors of straight line to be defined. ② Input bearing Input the bearing and length of the straight line. and distance. ③...
  • Page 145 consists of Arc length and Radius. The rule of radius value: along the forward direction of the curve. When the curve rotates to right, the radius value is positive. When the curve rotates to left, the radius value is minus. The arc length can not be minus. Example：...
  • Page 146 Transition curve Press [TRNS] key in the “Define HZ AL”, the transition curve can be defined. Transition curve consists of the minimum radius and arc length. The rule of radius value: along the forward direction of the curve. When the curve rotates to right, the radius value is positive.
  • Page 147 ③ [Save] After inputting, click [Save] to save the data of this alignment. PT (Point) In “Define HZ AL” menu Click [PT], the point can be defined. A point element consists of coordinates, radius and transition curve parameter A1 and A2. Radius, A1 and A2 can not be minus.

  • Page 148: Edit Alignment

    ② Input Input N, E, radius and A1, A2. You can also click [Load] to load coordinate, coordinate data from the project. radius, and arc factors. ③ [Save] After inputting, click [Save] to save the data of this alignment. [NOTE]：When you want to enter A1, A2 from transition curve length L1, L2, the following equations are used: Any changes to the alignment must be done using the edit alignment option.
  • Page 149 ② A： The screen display the last alignment data. Search for the data ※ to be edited. A：Click Prev. /Next to find the alignment data to be edited. B： B ： Click [Search], a dialog as shown on the right pops up. Input the chainage and click [Search].

  • Page 150: Define Vertical Alignment

    ※ 1) Start：Press this key to go to the start of the file. End：Press this key to go to the end of the file. Prev. ：Press this key to display the previous point data. Next ：Press this key to display the previous point data. Search：Press this key to search for data, after pressing this key, enter the required chainage and press [ENTER], the data for the chainage will be displayed.

  • Page 151: Edit Vertical Alignment

    OPERATIONAL STEPS DISPLAY ①In [Roads] menu click［Define [Define VT AL ］ to enter into defining vertical alignment function. ② Input chainage, elevation and Input Curve Length. After inputting, chainage, click [Save]. elevation and The curve length of start and end Curve Length point must be 0.
  • Page 152 ② The screen displays the first A： alignment data, search the data needs to be edited. ※1) A：Click Prev. /Next to find the alignment data needed to be edited. B： B：Click [Search]，a dialog box pops up as right graph B. Input chainage and click [Search].

  • Page 153: Alignment Setout

    13.2.5 Alignment Setout After setting road data, you can start setting out For an alignment setout a horizontal alignment must have been uploaded from computer by using [Set Out]→[Alignment]. ● the vertical alignment is optional, but is required to compute cut and fill. The defining method is same as defining horizontal alignment.
  • Page 154 ②After inputting, the center line setting out data of the start chainage displays on the lower screen. ③Here stipulate: first set out point on center line, and then set out points on left/right chainage.※1) Input prism height, and click [Set Out] to set out.
  • Page 155 ⑥ Sight the prism center, click [Measure] to start measure. Ask the rodman to move prism making “Away” and “↑” display as 0. ⑥ When four items are 0, the point to be set out is found. “Cut” item indicates dig/fill value.

  • Page 156: Slope Setout

    LOFS： The key is use in setting out the left side stake. Press it to display the offset and the height difference of the left side stake. ROFS：The key is use in setting out the right side stake. Press it to display the offset and the height difference of the right side stake.
  • Page 157 Example： OPERATIONAL STEPS DISPLAY ① Enter select) the side chainage needs to precede the slope layout. ② Click [Slope] to start slope layout. [Slope] After inputting ratio of dig (or fill) of Left and Right slope After inputting, select left or right slope to layout.

  • Page 158: Cross Section Setout

    ③ Enter into slope layout menu. Input the prism pole and sight a point near where it is estimated the slope will intercept and press [Measure] to take the first trial shot. The appropriate slope is selected from the data entered in the preceding step.
  • Page 159 X-Sects layout main menu The screen displays cross section data imported to total station. About the method please refer to “10.2 DATA IMPORT”. Example： OPERATIONAL STEPS DISPLAY ① In the menu of Set Out, click [X-Sect]. ② Data will be displayed on the screen as shown on the right.
  • Page 160 ③ Click [+CHG]/[-CHG] to search data forward backward; click [LOFS]/[ROFS] display neighboring offset and elevation on the cross section. ④ Select the chainage to be set out, and input the prism height of the target. Then click [Set Out] to start setting out.

  • Page 161: Cogo

    13.3 COGO The COGO menu contains a number of coordinate geometry functions. (Fixed point data can not be used in these functions.) (1.) Intersection (2.) 4-points intersections (3.) Inverse (4.) Area (5.) Radiation (6.) Missing line Measurement 13.3.1 Intersection The coordinate for a point can be computed by the intersection of two known bearings.

  • Page 162: 4-Intersection

    ③ After inputting, click [Calc.], the system calculate the coordinate of the intersection. [Calc.] If there‟s no intersection, it displays “No intersection error”. Input the point ID, and click [Enter]. ④ Data is saved. The display returns to standard survey main menu.
  • Page 163 OPERATIONAL STEPS DISPLAY ① In COGO menu click [4-Intersection] [4-Intersection]. ②In the popped up dialog box enter the points used for 4-Intersection. If the entered PT doesn‟t exist in project, program will request you to enter coordinates. ※1) ③After inputting, click [Calc.], to calculate the coordinates of [Calc.] intersection point.

  • Page 164: Inverse

    13.3.3 Inverse OPERATIONAL STEPS DISPLAY ①In COGO menu click [Inverse]. [Inverse] ②Enter From PT and To PT. If the entered PT doesn‟t exist in project, program will request you to enter coordinates. ※1)、※2) ③After inputting, click [Calc.], to [Calc.] calculate the coordinates ※3) ④Press[ESC] to returns to standard [ESC] survey main menu.

  • Page 165: Area

    VD：Height difference between two points. Positive sign means start point is higher than end point while minus means lower. 13.3.4 Area The points used to calculate area can be gained in two ways: use specified points or points with a common coding. 13.3.4.1 Area Using Specified Points An area can be calculated by marking at least 3 points.
  • Page 166 A： ③ A：Click [Mark] to mark pts used for area calc. ※2) B： B：You can click [Search] to search PT in project. ④ Click [Calc.] to calculate the area. The number used to calculate [Calc.] and area will be shown. ※3)、※4) ⑤Click [Enter] to quit and return to [Enter]...
  • Page 167 13.3.4.2 Area Calculation by Using Code The area of a figure enclosed by points with a common coding can be computed. When recording points observe them in the correct sequence and give each point the same point code. Example： OPERATIONAL STEPS DISPLAY ①In Area Option, click “One kind of Pt to calc”, and click [Enter].

  • Page 168: Missing Line Measurement

    the closed area is 43560ft.sq or more. [NOTE]： (1.) Area is not calculated correctly if enclosed lines cross each other. (2.) If less than 3 points are found which have been marked the software will show the message “3 PTS required”. (3.) The data in fixed points file can not be used in this program.
  • Page 169 ② Input the Pt used for MLM measurement.※1) Set Occ.& BS point: (If occupied point and Backsight azimuth has not been defined, the dialog box as right will pops up.) Pt does not exist in project: If the entered point doesn‟t exist in project, program will request you to measure this point.
  • Page 170 dHd is defined as the length of the projected missing line in the horizontal plane. dSd and dHd are always positive. 13.3.6 Radiate The coordinate for a point can be computed by entering the Azimuth and Distance. Example： OPERATIONAL STEPS DISPLAY ①In COGO menu click [Radiate].

  • Page 171: Traverse Adjustment

    ② Input From PT, Bearing and Distance, and click [Calc.]. ※1) If the entered PT doesn‟t exist in project, program will request you to enter coordinates. After inputting, click [Enter] to calculate. ③the new point coordinate will be calculated and be displayed. ※2) ※1) To call coordinate data from project, Click [Load].
  • Page 172 different from the known point too. Start Pt: 111 BKS Pt: 110 End Pt: 116 Close Pt: 117 Known Pt: 110 111 Example： 1. Measurement OPERATIONAL STEPS DISPLAY ①Select a known point and set up the instrument on the point. (For example Pt 111) Set pt 110 as back sight point.
  • Page 173 [Record] ③In [Record] menu click [FS Obs]. [FS Obs] ④Sight the traverse point 112, use [Record] to record the measured coordinates. ④ Move the instrument to PT112. Turn on the machine and select [Record], re-measure occupied point (PT112), backsight point (PT111), sight traverse point (PT113).Click record.
  • Page 174 ⑥Repeat ①～④ to measure and record coordinates of each traverse point. (The number of traverse point is entered according to length and requested accuracy). ⑦When the instrument is moved to PT115, measure a known point (916), record as PT116. ⑧To calculate traverse, you should set station on PT116, and sight another known point (such as 917), measure and record as...
  • Page 175 ② Enter Start Point, and click Enter start [Enter]. Point [Enter] ③When the entered start Point is same as the start Point in internal memory, the screen will display a dialog box to enter end point. Enter the End Point, (Measured Point) and known Point, these two Point must be different.
  • Page 176 ⑥The screen pops up” Elevation Adjust?” Here, click [OK] to adjust. Not to change and data, please click ⑦The display returns to standard survey main menu. If the closure point is measured: (The step 1, 2 are same as above). OPERATIONAL STEPS DISPLAY ③After entering Start Pt, system...
  • Page 177 ⑤ close difference calculated and displayed. Click [Enter]. ⑥The azimuth results display. If the angle is in the allowed range of close difference, click [Enter]. ⑦ Click [Enter], system calculates angle adjustment and displays the result. Click [Enter]. ⑧Here the screen pops up “Coord Adjust”...

  • Page 178: Batter Boards

    ⑨The screen pops up “Elevation Adjust” again. Click [OK] to adjust. Not to change any data, click“ ”. ⑩The display returns to standard survey main menu. 13.5 BATTER BOARDS When setting out points, particularly for building plots, it is usually necessary to mark a point with an offset so that the point can be re-established after work has been carried out in the work area.
  • Page 179 Example： OPERATIONAL STEPS DISPLAY ① In [Program] menu, click [B.Boards]. ② A： A： Input Setout P1 and click [Enter]. B： B： If the Point is unknown, a dialog box will pops up to request you to enter coordinates. After inputting, click [Enter].
  • Page 180 ③Enter Setout P2 and click [Enter]. ④ A： Now define the batter board, enter Board 1 and click [Enter]. B： If the point is unknown, SS Measurement dialog box will pop up. After measuring, the data is record to the project. ⑤Enter Board 2.

  • Page 181: Method 2: Batterboards Using One Side

    ⑥A dialog box shows the distances from intersection to PT1 and PT 2. ※1) ⑦Click “OK”, the intersection is set out. ※1) Click“ ” to quit batter board program. ※The setout of this intersection point is identical to Point Setout, which is discussed in paragraph 13.1.3, except for two differences.

  • Page 182: Operating Procedure

    Procedure Operating procedure ： (A) Two setout points (S1 and S2) are selected and one side of the batterboard is measured (BB 1). An approximate distance D1 is shown. (B) The position of the pole is changed according to the value of D1 and a measurement is performed.

  • Page 183: Tape Dimensions

    the line connecting the two setout points. The distance D1 is calculated using this assumption. Next a second point on the batter board is measured. From now on the distance D1 will be calculated using the correct orientation of the batterboard.D1 will now be more precise.
  • Page 184 ②Enter PT A (Start PT) and PT B A： (End PT) on Re. line and click [Enter]. If the point exists in project, then the Re. Line is defined. B： If the point doesn‟t exist in project, the SS Measurement dialog box pops up.
  • Page 185 ④ The reference line is defined, A：Left now use a tape to measure the line which perpendicular reference line, and start from End PT of reference line. First select direction in which the straight line proceeds and enter Dist, PT and Code, and click [Enter].
  • Page 186 ※1) stipulation of Left, Right: Along with extending direction of straight line, turn left is Left. ※2)Inputting range of Dist: 0.001～1000 There are two ways to return to the main menu ： 1) Press [ESC] key in case you have measured an open polygon. All points defined are automatically stored.

  • Page 187: System Settings

    14. SYSTEM SETTINGS 1, UNIT SETTING OPTIONS Contents Menu Selecting Item 1. Ang. Unit deg/gon/mil Select degree (360° ) , gon (400 G) or mil (6400 M) for the measuring angle unit to be shown on the display 2. Dist.Unit Meter/Int.Feet/U.S Select the distance measuring unit Meter, Int.
  • Page 188 K=0.14 ……………………Atmosphere Refraction Modulus In formula: Re=6370 km ………………The Earth Curvature Radius α (or β) ……………... The Vertical Angle Calculated From Horizontal Plane (Vertical Angle) S……………………….Oblique Distance NOTE: The atmosphere refraction modulus of this instrument has been set as: K=0.14. The value of K can be 0.14, 0.2, or shut: (0 VALUE) Example：...
  • Page 189 ④ Click [OK], the settings are [OK] saved. ⑤To set Measurement setting, click “Measurement Setting”, repeat steps ② ～ ④ to make the measurement setting. After setting, click “ ”.

  • Page 190: Check And Adjustment

    15. CHECK AND ADJUSTMENT This instrument has undergone a strict process of checking and adjustment, which ensures that it meets quality requirement. However, after long periods of transport or under a changing environment, there may be some influences on the internal structure. Therefore, before the instrument is used for the first time, or before precise surveys, user should launch check and adjustment introduced in this chapter to ensure the precision of the job.

  • Page 191: Inclination Of Reticle

    4. Adjust three adjustment screws for several times until circular bubble is centered; 5. The force power fixing three adjustment screws must be consistent when circular level is centered at last. 15.3 INCLINATION OF RETICLE Check: 1. Sight object A through the telescope and lock the horizontal and vertical clamp screws.

  • Page 192: Perpendicularity Between Line Of Sight And Horizontal Axis (2C)

    15.4 PERPENDICULARITY BETWEEN LINE OF SIGHT AND HORIZONTAL AXIS (2C) Check 1. Set object A at about 100 meters away the same height as the instrument, and make the vertical angle with ± 3° . Then level and center the instrument and turn on the power 2.
  • Page 193 Collimate the ③In Face I precisely collimate the target target, and press [Set]. [Set] ④ Rotate telescope Sight prism in precisely sight the same target in Reverse face Reverse face. Click [Set]. [Set] ⑤After setting, the screen displays [Set] as right. Click [Set]. ⑥Click [OK] to finish adjustment [OK] of collimation.

  • Page 194: Vertical Index Difference Compensation

    B. Optics Adjustment (professional maintenance man only) 1. Use the tangent screw to adjust the horizontal angle to the right reading which has been eliminated C, R+C=190°13′40″-15″=190°13′25″ 2. Take off the cover of the reticle between the eyepiece and focusing screw. Adjust the left and right adjusting screws by loosening one and tightening the other.
  • Page 195 Vertical angle value L. 2. Rotate the telescope. Sight object A in Face Ⅱ and read the Vertical angle value R. 3. If the vertical angle is 0° in zenith，i=(L+R-360° )/2 If the vertical angle is 0° in horizon. i=(L+R-180° )/2 or(L+R-540° )/2 4.

  • Page 196: Transverse Axis Error Compensation Adjustment

    ④After setting, the screen displays [Set] as right. Click [Set]. ⑤Click [OK] to finish adjustment [OK] of index error. Note: 1. Repeat the checking steps to measure the Index Error (i angle). If the Index Error cannot meet the requirement; user should check whether the three steps of the adjustment and the collimation are right.
  • Page 197 OPERATIONAL STEPS DISPLAY ① After leveling the instrument, [System Setup] click System Setup in the main menu. ②In the menu bar click Horizontal Sight the prism Axis. The screen displays as right. in front face, Sight the target precisely in front Click [Set] 10 face, Click [Set] 10 times.

  • Page 198: Optical Plummet

    ⑤Click [OK] to finish adjustment [OK] of horizontal axis. 15.8 OPTICAL PLUMMET Check 1. Set the instrument on the tripod and place a piece of white paper with two crisscross lines on it right below the instrument. 2. Adjust the focus of the optical plummet and move the paper so that the intersection point of the lines on the paper comes to the center of the field of view.

  • Page 199: Instrument Constant（K

    5. Repeat the inspection and adjusting steps to make the instrument meets the requirements. 6. Replace the protective cover. 15.9 INSTRUMENT CONSTANT（K） Instrument constant has been checked up and adjusted in the factory, K=0. It seldom changes and it is suggested to check one or two times every year. The inspection should be made on the base line, also can be made according to the following method.
  • Page 200 OPERATIONAL STEPS DISPLAY ① In [System Setup] menu, click [Instru Instrument Constant. current ment Instrument Constant and Multiple Constant Consta are displayed. ② In Input New Values field enter new Input constant. You can enter Mul. Cons. if instru needed. Click [Set]. ment consta [Set]...

  • Page 201: Parallel Between Line Of Sight And Emitting Photoelectric Axis

    15.10 PARALLELISM BETWEEN LINE OF SIGHT AND EMITTING AXIS Check: 1. Set the reflector 50m away from the instrument. 2. Collimate the center of the reflector prism with telescope reticle. 3. Switch on the instrument, and enter into Distance Measurement Mode. Press [DIST] (or [All]) to measure.
  • Page 202 Leg “f” to make Point C and D on the central line of reticle. Through the adjustment of the instrument on Point A and B, prism pole has been perpendicular. If the bubble offsets from the center, adjust the three screws under circular vial to make the bubble centered.

  • Page 203: Technical Specification

    16. Technical Specification KTS-472R KTS-475R Distance Measurement Max distance Single 5.0Km 5.0Km (Good prism weather) None 300m 300m prism Display Max：99999999.9999 Min:0.1mm With prism:± （2+2× 10 ）mm（Ⅱ） Precision Without prism：± (5+3× 10 )mm（Ⅲ） Measure time Quick measure 1.0s、Track 0.5s Atmospheric correction Auto correction Reflection prism Auto correction...
  • Page 204 Work range ± 3' Compensation error 6" Vial Plate vial 30"/2mm Circular vial 8'/2mm Optical Plummet Image Erect Magnification 0.5m~∞ Focusing range Field of view 5° Display LCD 3.2inch WindowsCE.NET English operaion system Type On-board Battery Power supply Rechargeable Ni-H battery Voltage 7.2V Continuous operation...

  • Page 205: Accessories

    17. ACCESSORIES １pc Carrying Case １pc Main Body Battery 2 pcs １pc Charger １pc Plummet Correction Pin 2 pcs １pc Fur Brush １pc Screwdriver Allen key 2 pcs １pc Cloth １pc Dryer １pc Operation Manual １pc Certificate Stylus pen 2 pc USB data cable 1 pc...

  • Page 206: Export Data From Total Station

    【APPENDIX-A】 1. EXPORT DATA FROM TOTAL STATION After saving the data collected by total station by “Data Export” to appointed route, use U disk or synchronizing software (use Microsoft ActiveSync to synchronize total station and PC.) to copy to your computer, then you can view the data. 1.1 Raw Data Format WinCE (Identifier)

  • Page 207: Import Data To Total Station

    115,1.059,1.059,1.297,, Additionally, the coordinate format of point to line program is: PT, E, N, Height, code, string, start reference PT, end reference PT 3,29.145,31.367,100.632,PT,1,2 4,128.365,56.367,115.732,PT,1,2 110,29.364,31.526,100.904,PT,101,103 111,49.892,3.958,112.834,PT,101,103 2. IMPORT DATA TO TOTAL STATION Data can be imported includes coordinate data, fixed point data, code data, horizontal alignment data, vertical alignment data and cross section data.

  • Page 208: Point P Coding Format

    12.669,-4.501,18.029 12.669,-3.500,18.059 12.669,-0.000,18.164,CL01 12.669,3.500,18.059 12.669,5.501,17.999 2.3 Point P Coding Format The code files enclosed in code library, should assure that every line has a code, which includes entity number and layer name, etc. Every entity is ended by carriage return. The edited coding format is as follows: Code[，Entity[，Layer]] TREE,1,VEG...
  • Page 209 START POINT stake number, E, N STRAIGHT azimuth, distance radius, arc length SPIRAL radius, length E，N[，A1，A2] (A1, A2: LENGTH) Example 1： START 1000.000,01050.000,1100.000 STRAIGHT 25.0000,48.420 SPIRAL 20.000,20.000 ARC 20.000,23.141 SPIRAL 20.000,20.000 STRAIGHT 148.300,54.679 Example 2： START 1000.000,1050.000,1100.000 PT 1750.000,1300.000,100.000,80.800 PT 1400.000,1750.000,200 PT 1800.000,2000.000 2.5 Vertical Curve Input vertical curve data from computer through typical point and stake number,...

  • Page 210: Appendix-B】 Calculate Road Alignment

    【APPENDIX-B】 CALCULATE ROAD ALIGNMENT The road alignment stake-out program can stake out the alignment elements including straight, arc and transition curve. NOTE: ●Road alignment data can be uploaded from computer or can be entered manually. Transect data can only be uploaded from computer. ●Road alignment and transect data is managed by chainage.

  • Page 211: Calculation Road Alignment Elements

    North East Radius Transition curve A1 Transition curve A2 1100.000 1050.000 IP1 1300.000 1750.000 100.000 80.000 80.000 IP2 1750.000 1400.000 200.000 0.000 0.000 2000.000 1800.000 Example: To enter the following data select DEF AL of ROADS in PROG menu: 1100.000 1050.000 Press [ENT] and then click (PT) on the screen, Enter the following data: 1300.000...
  • Page 212 ⑪ Calculation of the length of transition curve : Length of clothoid : Parameter of clothoid R : Radius =64 m =64 m ⑫ Calculation of Deflection Angle  =18°20′06″    = 0.32 rad 0.32  2  ...
  • Page 213  1.700    Symmetry spiral transition ⑮ Calculation of Spiral Transition coordinate    =63.348-100sin18°20′06″=31.891 s i n  Symmetry spiral transition ⑯ Calculation of Tangent Distance       tan( cot( 111°55′47″，  ...
  • Page 214    Bearing from IP1 to IP2 322° 07′30.1″ 1300 –(-182.468) * cos 322°07′30.1″= 1444.032 m  KA 2 1750 –(-182.468) * sin 322°07′30.1″= 1637.976 m  KA 2 ⑳ Calculation of coordinates BC，EC which is ARC (IP1,IP2,EP)  ...
  • Page 215 The coordinates and the distance are calculated as below ： Compute the length of straight line Straight line     BP· KA1= 1249 1100 1574 1050      straight line KA2· BC 1575 1444 1536 1637 straight line ...
  • Page 216 -100 m (“-” sign is turn left curve toward the end point) Radius Length 64 m Straight line (between KA2 and BC) Bearing 322°07′30.1″ Distance 166.004 m Arc (between BC and EC) Radius 200 (without sign is turn right curve toward the end point) Length 334.648 m Straight line (between EC and EP)
