Summary of Contents for Marantz CDR632
- Page 1 CLASS 1 LASER PRODUCT LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT Model CDR632 User Guide CD Recorder...
-
Page 2: Warnings And Cautions
Warnings and Cautions RISK OF ELECTRIC SHOCK CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol within an equilateral tri- angle is intended to alert the user to the presence of uninsulated "dangerous sufficient magnitude to constitute a risk of electric shock to per-... -
Page 3: Important Safety Instructions
Important Safety Instructions READ BEFORE OPERATING EQUIPMENT This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of. 1. Read these instructions. 2. Keep these instructions. 3. - Page 4 — Important Safety Instructions NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV (Cable- TV) system installer's attention to Article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
-
Page 5: Table Of Contents
1 – Introduction Thank you for purchasing the CDR632. Before using the CDR632, please read this manual care- fully, and use the product as directed to insure trouble- free enjoyment. After you have read this manual, please keep it handy for future reference. -
Page 6: About Discs
1 – Introduction—About discs About discs CD-R CD-RW Handle discs carefully so as not to damage or scratch the front side. To protect the disc, avoid placing it in the following locations: • In direct sunlight or near a source of heat like a heater. -
Page 7: What Is Finalizing
What is finalizing? Even after audio data is recorded on a CD-R or CD- RW disc, it cannot be played back on a conventional CD player until the final TOC data has been recorded on the disc. The process of recording this TOC data is called “finalizing”. -
Page 8: Front And Rear Panel
2 – Front and rear panel Front panel POWER switch Turns the power on/off. Disc tray Insert a disc (CD, CD-R, CD-RW) here. (Open/Close) button Opens or closes the disc tray. The display will indicate “Open” when the tray is opened, or “Close”... -
Page 9: Rear Panel
ERASE/DEL button When using a CD-RW disc, this button lets you erase a track or the disc. When entering text, this button deletes the character at the cursor location. (stop) button Stops recording or playback. (play) button Starts recording or playback. (pause) button Pauses recording or playback. -
Page 10: Rc632Cdr (Remote Control Unit)
2 – Front and rear panel—RC632CDR (remote control unit) RC632CDR (remote control unit) OPEN/CLOSE button Performs the same function as the front panel Open/Close button ( 0–9 buttons Use these buttons to enter track numbers or to make program playback settings. CLEAR button Cancels the number entered by the 0–9 buttons. -
Page 11: Audio Signal Connections
Performs the same function as the front panel SYNC REC/< button ( REC MUTE button Records approximately four seconds of silence. After the silence is recorded, the CDR632 will enter record-ready mode (→ p.30). SEARCH buttons Search through the disc forward (... -
Page 12: Menu Mode Operations
3 – Menu mode operations This section explains the basic procedures in Menu mode, where you can make various settings for the CDR632 and perform various editing operations. Menu structure Menu mode is organized as follows. For details on each item, refer to the appropriate page. - Page 13 3 – Menu mode operations—Basic operation in Menu mode If using the remote control unit 1, 4 3, 4 Press the MENU button to enter Menu mode. You will switch from normal mode to Menu mode, and the display will show the menu items. Use the SKIP buttons to select a menu item.
-
Page 14: Playback
MP3 format audio files from media such as CD-ROM. Types of disc that can be played The CDR632 can play the following types of disc. • Commercial audio CDs recorded in CD-DA format • CD-R/CD-RW discs recorded in CD-DA format •... -
Page 15: Selecting A Song
Selecting a song Here’s how to select a song when playing a CD that contains more than one track. You can select a song either by moving to the previous or next track (Skip) or by directly specifying a track number. Skipping Here’s how to skip to the previous or next track num- ber. -
Page 16: Track Search
4 – Playback—Track search Track search During playback (or while paused), you can search to find the portion of the track you want to hear. You can search either in the normal way by fast-forwarding/ rewinding while listening to the audio, or by directly specifying a track or time and moving to that point (direct search). -
Page 17: Playback Modes
ENTER button (or the PLAY or PAUSE button). 4 – Playback—Playback modes Playback modes On the CDR632 you can use one of four different playback modes. The following playback modes are available. Continue playback (default setting) Tracks will playback consecutively as their number. -
Page 18: Program Playback
4 – Playback—Playback modes The previous display will reappear shortly after you stop operating the PLAY MODE button. With the exception of Continue playback mode, the playback mode is shown as follows in the left part of the display. Normal playback No indication Single playback [1] is lit... -
Page 19: Shuffle Playback
• If you change the playback mode while stopped, all of the program data will be erased. • If you turn off the power of the CDR632, all of the pro- gram data will be erased. Note •... -
Page 20: Repeat Playback
4 – Playback—Repeat playback Repeat playback Here’s how you can repeatedly play all tracks of the currently inserted disc, or repeatedly play a specified region within a track (A-B Repeat Playback). Normal repeat playback All tracks on the disc will play repeatedly. REPEAT button Press the REPEAT button on the front panel (or the remote control unit) to turn... -
Page 21: Pitch Control Playback
“directory mode” in which only the MP3 files in a specific directory (folder) will be available for playback. Playing back all MP3 files The CDR632 can playback an MP3 disc in the same way as a conventional disc. 1, 3 Press the (Open/Close) button to open the disc tray. - Page 22 4 – Playback—Playing MP3 files Caution MP3 files converted at a sampling rate other than 44.1 kHz cannot be played correctly. The recommended format is a 44.1 kHz sampling rate and a bit rate of 128 kbps or higher. Note •...
- Page 23 Directory playback settings Here’s how to turn directory mode on/off and perform operations in directory mode. Note In the explanation below, we use menu mode to switch directory mode on/off, but you can also do this by press- ing the DIR button on the remote control unit. As described in “Basic operation in Menu mode”...
-
Page 24: Recording
The display will briefly indicate “Coaxial”. Using the sample rate converter The CDR632 always records at 44.1 kHz (the CD sampling rate). If you wish to digitally record a signal of a different sampling rate from a DIGITAL IN jack (OPTICAL/COAXIAL), you must turn on the sample rate converter (SRC) as follows. -
Page 25: Basic Recording Operations
If the recording source is analog ([ANALOG] lit), use the INPUT controls to adjust the level received from the connected playback unit. Set the level as high as possible without allowing the meters shown in the upper part of the display to reach the clipping point. -
Page 26: Switching The Time Display
• Never subject the CDR632 to severe vibration or turn off the power while the “PMA Writing” indication is shown. The recorded content will not be written cor- rectly if you do so. -
Page 27: Fade-In/Out
“Sync 1” (sync-record only once) → “Sync OFF” (sync-record is off). If “Sync ALL” is selected, the [SYNC] indicator in the display will light, and the CDR632 will be ready to sync-record. If “Sync 1” is selected, the [SYNC] indicator in the display will blink, and the CDR632 will be ready to sync-record. - Page 28 2. However, after Sync1 or Sync ALL is selected, and if the signal below the adjusted sync level is not detected over one sec- ond, the CDR632 will not begin recording auto- matically even it detects the audio signal. level...
-
Page 29: Auto Track Recording
Auto track recording Auto track recording is a function that automatically updates the track number when the specified condi- tion occurs. Select the auto track mode as follows. As described in “Basic operation in Menu mode” (→ p.12), access the “AUTO_TRK?” menu item and press the ENTER button. -
Page 30: Manually Updating The Track Number
5 – Recording—Manually updating the track number Manually updating the track number If you want to update the track number manually, pro- ceed as follows. Take the following steps to enable manual track number updating. As described in “Basic operation in Menu mode”... -
Page 31: Cd-R/Cd-Rw Disc Operations
A disc recorded on the CDR632 cannot be played back on a conventional CD player until the final TOC has been written to the disc. (The CDR632 itself will be able to play the disc even before it has been final- ized.) -
Page 32: Refreshing
6 – CD-R/CD-RW disc operations—Refreshing Refreshing In some cases, the CDR632 may be unable to recog- nize a disc, perhaps because finalization was aborted by a power failure or other reason, or because the disc has been used by a computer. In such cases, refresh- ing the disc as described below may enable the CDR632 to detect it. -
Page 33: Erasing A Track
Erasing a track This operation erases the specified track and all sub- sequent tracks from a recorded CD-RW disc. Caution The contents of the erased track(s) will be lost forever. Use this operation with great caution so that you don’t erase important tracks by mistake. -
Page 34: Entering Names
7 – Entering names Caution If you turn off the power without finalizing after entering a name, the TOC will not be written, and the name you entered will be discarded. You must execute the finalize operation to write the TOC. You can use the “TEXT EDIT?”... -
Page 35: Naming A Track
Naming a track Here’s how to assign a name to a track recorded on a CD-R/CD-RW disc. While stopped, access the “TEXT EDIT?” menu item and press the ENTER button. The display will indicate “Text> XXX” (you can choose Disc or a track number 01–99). Press the ENTER button, and use the MULTI JOG dial (or the SKIP buttons on the remote control unit) to select a track number 01–99. -
Page 36: Messages
8 – Messages Error messages If one of the following messages should appear, press (stop) button and then deal with the cause of the error. If you are still unable to resolve the prob- lem, please contact service center nearby. •... -
Page 37: Troubleshooting
• You can’t record on a playback-only CD. Please use a recordable CD. • A setting you changed is not memorized. The CDR632 saves backup copies of your set- tings whenever you change mode settings, how- ever, the backup may fail if you turn off the power immediately. -
Page 38: Specifications
10 –Specifications Recordable discs CD-R, CD-R-DA, CD-RW, CD-RW-DA (High Speed CD-RW is supported) Quantization bit depth 16-bit linear Sampling frequency 44.1 kHz Frequency response 20Hz–20KHz ±0.8 dB (playback) ±1.0 dB (recording) 95 dB or better (playback) 90 dB or better (recording) Dynamic range 95 dB or better (playback) 90 dB or better (recording) -
Page 39: Limited Warranty
Your Marantz Professional product is warranted against manufacturer defects in material and work- manship for a period of one year parts and labor. Marantz will pay for labor and material expenses for items covered by this limited warranty. Except as specified below, this warranty covers defects in material and workmanship. - Page 40 M Holdings Inc. & PROFESSIONAL BUSINESS COMPANY Printed in China 10/2005 D00884100A ecm-f...
