14.2 ASSEMBLING AND wIRING
The KA-POT1 pack is composed of:
PCB with potentiometer
2 x screws M3X6
2 x 4-pin connector plugs
Drilling jig
Position the drilling jig on an appropriate box and make the three holes. Install your cap in a box for
switches and insert the PCB with the potentiometer coming out from the center hole. Secure with the
two included screws. Cover the potentiometer with the gray knob.
18
KA-POT1 UNPACKING
Ver. 1.2
