MODELS: ZSI-E30AS, ZSI-E36AS
ZSI-E30AS-ES, ZSI-E36AS-ES
PARTS SUPPLIED
1 - Hood with internal blower
2 - Baffle filters
1 - Duct cover assembly (top and bottom)
1 - Duct cover wall bracket
2 - 50W Halogen light bulbs (ZSI-E30AS & ZSI-E36AS)
2 - Fluorescent light bulbs (ZSI-E30AS-ES & ZSI-E36AS-ES)
1 - 8" round backdraft damper
1 - Hardware package
HARDWARE PACKAGE CONTENTS
(6) M4 x 1-1/2"
(1) Light Bulb Removal
Suction Cup
ZSI-E30AS & ZSI-E36AS ONLY
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
- Duct cover extension accessory
- Recirculating kit accessory (ZSI-E30AS & ZSI-E36AS)
(2) M4 x 8
(4) M4 x 8
4
