USE ONLY 13W, GU24 FLUORESCENT LIGHT BULBS. MODEL SPS T3 13GUS.
ZSI-E30AS-ES
ZSI-E36AS-ES
CIRCUIT DIAGRAM
MAX.
USE ONLY TYPE MR16, GU10, 50 W.
ZSI-E30AS, ZSI-E36AS
CIRCUIT DIAGRAM
REMARKS: CONDENSER 11+11uF 250V AC FIT AC120V 60Hz
VOLTS
HZ
MAX AMPS
120
60
1.2
HALOGEN LIGHT BULBS.
VOLTS
HZ
MAX AMPS
120
60
5
16
www.zephyronline.com
Power consumption shown for default
ACT 390 CFM - Fan Max. 393W @ 3.3A
ACT 290 CFM - Fan Max. 365W @ 3.0A
Power consumption shown for default
ACT 290 CFM - Fan Max. 82W @ 0.74A
