Table Of Contents - TTI TCB-770 Service Manual

SECTION2 CIRCUIT DESCRIPTION
1 General
1-1. Receiver
1.2. Transmitter
2. Technical Description
2-1. General
2-2. Type of emission
2-3. Frequency Table
2-4. RF Power Output
2-5. DC input Voltage and Current with 13.2V DC Input to Power AMP
2-6. Receiver IF and Local Oscillator Frequencies
3. Semiconductors and Function
4. Description of Frequency Determining and Stabilizing Circuit
4-1. Introduction
4-2. Basic Synthesis Scheme
4-3. Descriptions of Each Block
4-3-1. Introduction
4-3-2. Reference Frequency
4-3-3. VCO
4-3-4. Programmable Divider and its Control
4-3-5 Phase Detector and VCO Control
4-3-6. Transmitter / Receiver Buffer AMP
4-3-7. Transmitter Doublers
4-3-8. Switching of Turning Capacitor in VCO
4-3-9. Receiver Local Oscillator Outputs
4-4. Frequency Stability
4-5. Description of other Circuits
4-5-1. Transmitter
4-5-2. Receiver
5. Test Equipment Setup and Alignment Instructions
5-1. General Section
5-2. Transmitter Section
5-3. Receiver Section
