The stand must be secured to the wall with the bracket and fasteners provided in this kit.
The security bracket must be attached to two studs.
The ice machine must be secured to the stand top cover with the supplied bolts (4) and washers (4).
The stand top cover must be secured to the stand with the screws (2) provided.

Material List

REAR
TOP
PANEL
PANEL
LEG
SUPPORT
(4)
ANGLE
(2)

Cabinet Assembly

Step 1 - Slide side panels onto
base.
Manitowoc Ice, Inc.
th
2110 South 26
Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879
Web Site - www.manitowocice.com
K00384 Ice Machine Stand
Installation Instructions

WARNING

FRONT
BRACE
PANEL
PANEL
BASE
TOP
COVER
Step 2 - Place support angles
under the side panels.
SIDE
PANEL
(2)
(2)
BOLT (4)
WASHER (4)
Step 3 - Screw legs into the base
(through support angles & side panels).
TOP
CAP
COVER
PLUG
SCREWS
(4)
(2)
SECURITY
BRACKET
BOLT (2)
WASHER (2)
NUT (2)
000002675
Page 1 of 3
07/23/07
