TOP VIEWS OF CABINET SHOWING TRAY SLIDE PILASTER POSITIONS
READ INSTRUCTIONS COMPLETELY BEFORE INSTALLATION
1. Remove all wire shelves from door opening. Remove existing pilasters by removing the thumbscrews at the top and
lifting up and off the mounting studs.
2. (Use steps 2 and 3, when installing on bottom half.) Use top slotted holes on tray slide pilaster, as shown in Fig. 3.
Press in and down to lock into place.
Manitowoc Ice, Inc.
2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA
Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879
Web Site -
www.manitowocice.com
K00333/K00334 TRAY SLIDE KIT 1/2/3 DOOR
Installation Instructions
1 Dr.
K00333 PARTS LIST
Item
Qty.
Part No.
1
4
3203343
2
16
6022201
3
4
6022301
K00334 PARTS LIST
Item
Qty.
Part No.
1
4
3203343
2
16
6022201
3
1
6022191
4
3
6022301
5
47"
9202503
Thumbscrew
3 Dr.
Description
Wire Shelf Pilaster
Tray Slide
Tray Slide Pilaster
Description
Wire Shelf Pilaster
Tray Slide
Tray Slide Pilaster - 2 Dr.
Tray Slide Pilaster
Tape, Extruded
2 Dr.
8010553
Sheet 1 of 2
Rev. 04/01/99
Advertisement
Table of Contents
Related Manuals for Manitowoc K00333
Summary of Contents for Manitowoc K00333
- Page 1 Manitowoc Ice, Inc. 2110 South 26 Street, P.O. Box 1720, Manitowoc, WI 54221-1720 USA Telephone 920-682-0161, Fax - Sales: 920-683-7589, Service/Parts: 920-683-7585, Other: 920-683-7879 Web Site - www.manitowocice.com K00333/K00334 TRAY SLIDE KIT 1/2/3 DOOR Installation Instructions Thumbscrew 3 Dr. K00333 PARTS LIST Item Qty.
- Page 2 3. Install your precut wire shelf pilasters to the top half of your cabinet above the tray slide pilaster. Note: when installing your wire shelf pilaster above the tray slide pilaster on the 2-door, the top of the pilaster closest to the drain tube must be cut off to an overall length of 17.625”...
