Summary of Contents for Heatmiser PRT-R2
- Page 1 PRT-R2 Manual REVISION 1.qxd 18/11/2005 12:27 Page 1 Operating Instructions PRT-R2 REV: 1 Heatmiser UK Ltd Tel: +44(0)1254 776343 Primrose House www.heatmiser.co.uk Primrose Street Darwen Lancashire BB3 2DE...
- Page 2 PRT-R2 Manual REVISION 1.qxd 18/11/2005 12:27 Page 3 Button Layout Contents Contents Button Layout LCD Symbols Installation Initial Setup 7-11 Temporary Temperature Adjust Turning the Heating Off Setting the comfort levels 13-14 InfraRed Wiring Power Receiver PRT-R2 Wiring Diagrams On/Off “Up”...
- Page 3 PRT-R2 Manual REVISION 1.qxd 18/11/2005 12:27 Page 5 LCD Symbols 1.Installation 1. The thermostat is flush mount, a back box of 35mm Clock Indicator should have been sunk in the wall prior to installation. Heat Active Indicator 2. The thermostat should be mounted at around 6ft or Frost Mode On eye level.
- Page 4 PRT-R2 Manual REVISION 1.qxd 18/11/2005 12:27 Page 7 Step 3 Step 2 Re-connect the thermostat ribbon cable and clip the Carefully unplug the ribbon connector which is plugged in to the front half of the thermostat. two halves together. Place the thermostat front half somewhere safe.
- Page 5 Page 9 3. Initial Setup C) Calibrating the PRT-R2 The PRT-R2 has a room (built in to the thermostat) A) Frost Protection (Thermostat Off) and remote floor sensor. The room sensor must be You now need to decide if you wish the thermostat to calibrated when it is first installed.
- Page 6 If the remote sensor probe has been enabled, the PRT-R2 will detect if the sensor is faulty / The clock is now set. The PRT-R2 has a battery which disconnected. In such a case, the heating will turn off maintains the clock on a power failure. All program so that there is no risk of the floor surface overheating.
- Page 7 PRT-R2 Manual REVISION 1.qxd 18/11/2005 12:27 Page 13 Temperature Override F) Setting the floor limit temperature If you have enabled the floor sensor probe, you need Using the Up/Down arrow keys you can adjust the to set the floor limit temperature. Should the floor current set temperature.
- Page 8 Setting the Comfort Levels • To begin programming the comfort levels, press The PRT-R2 has 4 comfort levels for the weekday and once. You will see Mo - Fr displayed. 4 for the weekend. This method of control is not to have on/off times but to allow the occupant to set •...
- Page 9 PRT-R2 Manual REVISION 1.qxd 18/11/2005 12:27 Page 17 Heatmiser PRT-R2 Keylock Function Enable/Disable This function allows you to lock the keypad. To use this function, you first need to enable it. • Turn the thermostat off • Press the A and Up arrow key for 10 seconds •...
