Summary of Contents for Heatmiser PRT-TS WiFi
- Page 1 Model: PRT-TS WiFi Model: PRT-TS WiFi...
-
Page 2: Table Of Contents
Model: PRT-TS WiFi Table Of Contents Frost Protection Product Image Heating ON/OFF Table of Contents Comfort Levels Explained 17-18 What is a Programmable Room Thermostat? Clean Screen Installation Procedure Locking the Keypad LCD Display Temperature Control WiFi Setup 9-11 Temperature Hold... -
Page 3: What Is A Programmable Room Thermostat
The way to set and use your programmable room thermostat is to find the lowest temperature settings that you are comfortable with at the different times you have chosen, and then leave it alone to do its job. WiFi Series Model: PRT-TS WiFi... -
Page 4: Installation Procedure
Terminate the thermostat as shown in the diagrams on pages 28-30 of this booklet. Step 3 Screw the thermostat back plate securely into the back box. Step 4 Clip the front of the thermostat back onto the thermostat back plate. WiFi Series Model: PRT-TS WiFi... -
Page 5: Lcd Display
Setup/Programming Keys - Used to navigate setup options. Current Temp - Indicates the current sensor temperature. Units of Temperature - Degrees Celsius or Fahrenheit. Comfort Level Selection Keys - Used in comfort level setup (see page 17). WiFi Series Model: PRT-TS WiFi... -
Page 6: Setting Up Your Wifi Thermostat
IP address of the Multi-Link. Log into your wireless router and navigate to the LAN settings page. WiFi Series Model: PRT-TS WiFi... -
Page 7: Security Types And Compatibility
You will not be able to connect to your thermostat without changing this setting on These restrictions are common to most routers but you should refer to the router G model routers. manual for specific restrictions that apply to your model. WiFi Series Model: PRT-TS WiFi... -
Page 8: Remote Access Via Web App
You will be asked to enter a password and username. These are both set to “admin” as default. We recommend you change these settings to ensure the security of your system. For further information, click the help link within the browser. WiFi Series Model: PRT-TS WiFi... -
Page 9: Temperature Display
This is the temperature you are trying to The display and heating output will be turned off completely.* achieve in your home. To turn the thermostat back ON, press the ON key once ..........*See Feature 3 on page 23 WiFi Series Model: PRT-TS WiFi... -
Page 10: Comfort Levels Explained
21°C “Sat Sun” prompting you to program the display Tue. Leave 22:00 16°C temperature levels for the weekend. Return --,-- --°C Sleep --,-- --°C • When complete, press DONE to confirm settings and exit .... WiFi Series Model: PRT-TS WiFi... -
Page 11: Clean Screen
At this time, the thermostat will revert back to the programmed levels. • When activated, you will see the Keypad Lock symbol. • To cancel, press the bottom right corner of the display again for 10 secs. Keypad Lock Indicator Set Temperature Set Icon WiFi Series Model: PRT-TS WiFi... -
Page 12: Temperature Hold
00:00 on Monday. Holiday Icon Holiday Days Hold Temperature To cancel a Holiday setting, reduce the holiday time to 00 days. To cancel a temperature hold, follow the same steps but reduce the time to 00:00. WiFi Series Model: PRT-TS WiFi... -
Page 13: Optional Features
This limit is also applicable when the thermostat is locked and so comfort levels that can be programmed independently. allows you to give others limited control over the heating system. WiFi Series Model: PRT-TS WiFi... -
Page 14: Adjusting The Optional Settings
00 = Weekday/Weekend (Default) number (shown on page 26) and then use the Up/Down keys in the 01 = 7 Day Programming center to adjust the setting .................... • Press DONE to confirm settings and exit ..............WiFi Series Model: PRT-TS WiFi... -
Page 15: Re-Calibrating The Thermostat
Re-calibrating the Thermostat Wiring Diagram - PRT-TS WiFi Switched Live to Boiler PRT-TS WiFi Switched Live To Boiler If you need to re-calibrate the thermostat, follow these steps. Switched Live • Press and hold the OFF key to turn the thermostat OFF .......... -
Page 16: Wiring Diagrams
Wiring Diagram - PRT-TS WiFi Voltfree to Boiler Wiring Diagram - PRT-TS WiFi with Heating Valve PRT-TS WiFi With Heating Valve PRT-TS WiFi Volt Free To Boiler Volt Free To Boiler To boiler Mains Supply Heating Valve With End Switch... - Page 17 Heating Professionals: Request a copy of our product installation guide containing detailed technical specifications for our complete product range: www.heatmiser.com/guide Want More Information? Call our support team on: +44 (0)1254 669090 Or view technical specifications directly on our website: www.heatmiser.com Twitter: heatmiseruk Facebook: facebook.com/thermostats...
