Summary of Contents for Heatmiser PRT-ETS WiFi
-
Page 1: Operating Instructions
Operating Instructions Model: PRT-ETS WiFi 07/12 Version 1 Ref: PRT-ETSWIFI... -
Page 3: Table Of Contents
Contents Page Setting up your WiFi Thermostat Remote Connection Setup Display Symbols Explained Installation Procedure 12-13 Setting the Clock Comfort Levels Explained Locking the Keypad Temperature Override Temperature Hold Holiday Heat On/Off Clean Screen Factory Reset Optional Feature Setup 21-26 Re-calibrating the Thermostat Wiring Diagrams 27-28... -
Page 4: Setting Up Your Wifi Thermostat
Setting up your WiFi Thermostat Step 1: Download and install the network utility from our web site: www.heatmiser.co.uk/wifi Step 2: Connect the thermostat to your pc with the USB cable provided, this will power the thermostat from the USB port & will allow you to test the Wi-Fi connection. - Page 5 Your Wi-Fi thermostat needs a fixed IP address in order for local and remote access to operate, so you will need to set this up manually. Log into your wireless router and navigate to the LAN settings page. You should see an option for DHCP setup. This should detail the IP range that can be assigned to devices connecting to the network.
- Page 6 Step 6: You need to enter the IP address of your gateway and DNS. In most cases, this is the IP address of your wireless router. Step 7: Browser Username & Password You should now create a username and password that is used when you access your thermostat from a web browser.
- Page 7 Security Types & Compatability Explained The Wi-Fi Thermostats operate on the 802.11b standard. If your router is a G model, you should ensure it is setup to work in B&G mode otherwise you will not be able to connect to your thermostat. There are currently 4 methods of securing your wireless connection in common use These are :...
-
Page 8: Remote Connection Setup
10 or 26 digit hex password and won’t accept anything else. Your thermostat utility can deal with both options. The following restrictions apply: A hex password can only be made up of the numbers 0 to 9 and the letters a to f, lower case only. Hex passwords can only be 10 characters or 26 characters in length. - Page 9 As a brief outline, you should first create a new service within your router. Within this service you need to open TCP port 8068. You now need to forward this service, using the port forwarding function to the IP of your WiFi thermostat. Remote Access via Web Browser In order to access your WiFi Thermostat remotely via a web browser, you need to open port 80 and forward this to the IP of your WiFi Thermostat.
-
Page 10: What Is A Programmable Room Thermostat
What is a programmable room thermostat? A programmable room thermostat is both a programmer and a room thermostat. A programmer allows you to set “On” and “Off” time periods to suit your own lifestyle. A room thermostat works by sensing the air temperature, switching on the heating when the air temperature falls below the thermostat setting, and switching it off once this set temperature has been reached. - Page 11 The way to set and use your programmable room thermostat is to find the lowest temperature settings that you are comfortable with at the different times you have chosen, and then leave it alone to do its job. The best way to do this is to set low temperatures first, say 18ºC, and then turn them up by one degree each day until you are comfortable with the temperatures. You won’t have to adjust the thermostat further.
- Page 12 You may be able to temporarily adjust the heating programme, for example, “Override”, “Advance” or “Boost”. These are explained in the manufacturer’s instructions. Programmable room thermostats need a free flow of air to sense the temperature, so they must not be covered by curtains or blocked by furniture. Nearby electric fires, televisions, wall or table lamps may prevent the thermostat from working properly.
-
Page 13: Display Symbols Explained
Wi-Fi Thermostat Display Guide V1.0 V1.0 Shown on the PRT-ETS WiFi Model. Displayed when the floor temperature rises above the floor limit temperature. Indicates the current room temperature. Indicates the current floor temperature (PRT-ETS WiFi Only). Indicates the thermostat is in Away Mode. -
Page 14: Installation Procedure
Installation Procedure DO’s 1. Do mount the thermostat at eye level. 2. Do read the instructions fully so that you get the best from our product. DON’Ts 1. Do not install near a direct heat source as this will affect the workings of the thermostat. 2. Do not push hard on the LCD otherwise you will damage the liquid crystal display and this is not repairable. - Page 15 Step 2 Place the thermostat front half somewhere safe. Terminate the thermostat as shown in the diagrams at the back of this booklet. Screw the thermostat back plate on to the back box. Step 3 Re-connect the two parts of the thermostat. Connecting to the Thermostat from your Web Browser To connect to your thermostat, open your preferred browser...
-
Page 16: Temperature Display
Temperature Display Room Temp = This is the current room temperature. Floor Temp = This is the current floor temperature. SET = This is the temperature you are trying to achieve in your home. Setting The Clock To set the clock, follow these steps: • Press Prog • Press Clock • Enter the Time (In 24hr Format) • Press Clock • Enter the day and month... -
Page 17: Comfort Levels Explained
Comfort Levels Explained Comfort levels allow you to set different temperatures throughout the day. For example, you may want the home warm in the morning when you are getting ready for work, cooler during the day when the house is unoccupied and then warmer in the evening when you are home relaxing. The thermostat offers 5/2 Day Programming (4 levels for the weekday, 4 for the weekend) and 7 day Programming (4 levels for each day). - Page 18 Weekend Level Time Temp Wake 09.00 21°C Leave 22.00 16°C Return --.-- --°C Sleep --.-- --°C Changing the Comfort Levels • Press PROG and select Wake. • Use to set the time for the 1st Comfort level. • Use to set the temperature in °C. • You should now repeat for the Leave, Return & Sleep levels. • Press Day to select the next day. In 5/2 day mode the thermostat will highlight “Sat Sun” prompting you to program the temperature levels for the weekend. In 7 day mode, the thermostat will highlight Tuesday.
-
Page 19: Locking The Keypad
Locking the Keypad The thermostat has a keylock facility. To enable this press the bottom right corner of the display and hold for 10 seconds. When activated, you will see To cancel, repeat the steps above. Temperature Override Using the keys allows you to adjust the set temperature. -
Page 20: Temperature Hold
Temperature Hold The Temperature Hold function is ideal for parties or when you will be going out for a number of hours. It allows you to hold a temperature for a desired period. • Press HOLD. • Set the desired Hold time and temperature. • Press Done. • To cancel a Hold time, reduce the time to 00.00. Holiday The Holiday function reduces the set temperature in your home to the frost temperature setting. -
Page 21: Heat On/Off
Heat On / Off Frost Protect Mode: Pressing the Off button once will place the thermostat in frost protect mode. In this mode, the thermostat will display the frost icon and will only turn the heating on should the room temperature drop below the set frost temperature (see page 21). Should the heating be turned on whilst in frost mode, the flame symbol will be displayed. -
Page 22: Factory Reset
Factory Reset The thermostat has a factory reset function. This will reset all settings back to their factory default. To perform a factory reset, follow these steps: Turn off the thermostat by pressing and holding the off button. Press and hold the bottom left corner of the LCD for 10 seconds. -
Page 23: Optional Feature Setup
THE FOLLOWING SETTINGS ARE OPTIONAL AND IN MOST CASES NEED NOT BE ADJUSTED Optional Features Explained Feature 01 – Temperature Format: This function allows you to select between °C or °F. Feature 02 - Switching Differential: This function allows you to increase the switching differential of the thermostat. The default is 1°C which means the thermostat will switch the heating on 1°C below the set temperature and will turn it off when the set temperature is achieved. With a 2°C... - Page 24 Feature 05 – Output Delay: To prevent rapid switching, an output delay can be entered. This can be set from 00-15 minutes. The default is 00 which means there is no delay. Feature 06 – Not used on this model. Feature 07 –...
- Page 25 03 = Floor sensor and built in air sensor. In this mode, the thermostat will maintain the set temperature by monitoring the built in air sensor and will also ensure the floor surface doesn’t overheat by monitoring the remote floor sensor. 04 = Floor sensor and remote air sensor.
-
Page 26: Adjusting The Optional Settings
Feature 11 – Rate Of Change: This is the number of minutes the thermostat has calculated it takes to raise your building 1°C. The thermostat will continue to learn the heat up time of your home and will adjust this setting to suit. - Page 27 Feature Table Feature Description Setting Temperature Format 00=°C 01=°F Switching 0.5=0.5°C - 3.0=3°C Differential 1.0°C = Default Frost Protect 00 = Disabled 01=Enabled (01=Default) Frost Temp 07-17°C (12=Default) Output Delay Enter value 00-15 minutes (00=Default) Comms Number Not available on this model Temp Limit 00 –...
-
Page 28: Re-Calibrating The Thermostat
Feature Table (continued) Feature Description Setting Floor Limit 20-45°C Optimum Start 00 = Disabled (Default) (Preheat) 01=1 hour, 02=2 hours, 03=3 hours Rate Of Change For information only Program Mode 00 = 5/2 Day (Default) 01 = 7 Day Re-calibrating the thermostat If you need to re-calibrate the thermostat follow these instructions: 1. Press and hold the OFF button to turn the thermostat off. -
Page 29: Wiring Diagrams
Heatmiser PRT-ETS WiFi Model... - Page 30 Heatmiser PRT-ETS WiFi Model...
