CipherLab 9500CE Reference Manual

CipherLab 9500CE Reference Manual

Mobile computer series
Hide thumbs Also See for 9500CE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Reference Manual
9500CE Mobile
Computer Series
Version 1.08
Printed on 26 February, 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9500CE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CipherLab 9500CE

Summary of Contents for CipherLab 9500CE

  • Page 1 Reference Manual 9500CE Mobile Computer Series Version 1.08 Printed on 26 February, 2007...

  • Page 2: Copyright Notice

    Copyright © 2007 CIPHERLAB CO., LTD. All rights reserved The software contains proprietary information of CIPHERLAB CO., LTD.; it is provided under a license agreement containing restrictions on use and disclosure and is also protected by copyright law. Reverse engineering of the software is prohibited.

  • Page 3: Fcc Regulations

    The use of any batteries or charging devices, which are not originally sold or manufactured by CipherLab, will void your warranty and may cause damage to human body or the product itself. The charging and communication cradle uses an AC power adaptor. A socket outlet shall be installed near the equipment and shall be easily accessible.
  • Page 4 Care & Maintenance This terminal is intended for industrial use. The terminal is rated IP 64, however, it may do damage to the terminal when being exposed to extreme temperatures or soaked wet. When the body of the terminal gets dirty, use a clean and wet cloth to wipe off the dust. DO NOT use/mix any bleach or cleaner.

  • Page 5: Power Management

    Power Management For any portable device, power management is a critical issue especially when you are on the road. Below are some tips to help you save battery power. To speed up charging the terminal, turn off the terminal and seat it in the cradle. Bring a second battery pack on the road.

  • Page 7: Table Of Contents

    Revision History ............................1 CHAPTER 1 - Introduction 1.1 Unpacking the package...........................3 1.2 Options..............................3 1.3 Product Highlights ..........................4 1.4 Nomenclature............................5 1.4.1 9500CE .............................5 1.4.2 Accessories & Peripherals ......................6 1.4.3 Dimensions ..........................7 1.5 Features..............................8 1.5.1 Battery ............................8 1.5.2 CPU ............................11 1.5.3 Memory & Calendar.......................11 1.5.4 Keypad............................13...
  • Page 8 Contents CHAPTER 2 - Installation 2.1 Main & Backup Batteries ........................24 2.2 Hand Strap ............................26 2.3 Pistol Grip.............................27 2.4 CF / SD Card ............................28 2.5 Cradle..............................29 2.5.1 Status Indicators ........................29 2.5.2 Communication Ports ......................30 CHAPTER 3 - Windows CE Basics 3.1 General..............................32 3.1.1 Device Configuration ......................33 3.1.2 Turn On/Off..........................34...
  • Page 9 Contents 5.2.4 Connect...........................77 5.2.5 Stop Bluetooth Services......................82 5.3 ReaderConfig............................83 5.3.1 Configure Reader Settings......................84 5.3.2 1D Reader - CCD / Laser......................85 5.3.3 1D Reader - (Extra) Long Range Laser ..................94 5.3.4 2D Reader..........................101 5.3.5 RFID Reader.........................111 5.4 Inbox..............................112 5.4.1 Create an E-mail Box ......................112 5.4.2 Synchronize Inbox........................115 Specifications APPENDIX I - Comparison of Scan Modes...
  • Page 10 Contents Table of Figures Figure 1: Nomenclature (front & back) ..................5 Figure 2: Nomenclature of accessories ..................6 Figure 3: Dimensions ........................7 Figure 4: 27-key layout ......................13 Figure 5: DIP switch for backup battery pack ................24 Figure 6: Installing battery pack ....................25 Figure 7: Installing hand strap ....................26 Figure 8: Installing pistol grip ....................27 Figure 9: Inserting CF/SD card ....................28...

  • Page 11: Preface

    Delivered in the same form factor of the 9500PPC Series running Windows Mobile 2003SE, the 9500CE Series is the newest member to the Mobile Computer family. As suggested by its model designation, it is designed to run Windows CE 5.0, and therefore, allows more flexibility in customization of applications.
  • Page 12 9500CE Reference Manual Modified: section 3.4 – USB driver will be installed automatically 1.02 Oct. 16, 2006 1.01 Sep. 27, 2006 Official release...

  • Page 13: Chapter 1 - Introduction

    H A P T E R Introduction This chapter explains the hardware parts and features of the 9500CE terminal. 1.1 Unpacking the package The following items are included in the package. Save the box and packaging material for future use in case you need to store or ship the terminal.

  • Page 14: Product Highlights

    9500CE Reference Manual 1.3 Product Highlights Microsoft Windows CE 5.0 software for operating system 520 MHz Intel PXA270 processor A color transflective TFT display delivers excellent visibility in all lighting conditions 128 MB non-volatile NAND flash memory to store OS and software programs...

  • Page 15: Nomenclature

    Chapter 1 Introduction 1.4 Nomenclature 1.4.1 9500CE Figure 1: Nomenclature (front & back)

  • Page 16: Accessories & Peripherals

    9500CE Reference Manual 1.4.2 Accessories & Peripherals Figure 2: Nomenclature of accessories...

  • Page 17: Dimensions

    Chapter 1 Introduction 1.4.3 Dimensions Figure 3: Dimensions...

  • Page 18: Features

    9500CE Reference Manual 1.5 Features 1.5.1 Battery Main Battery This rechargeable 3.7 V/4000 mAh Li-ion battery pack serves as the main power. Normally, it takes approximately four hours to fully charge the battery. The charging time may vary by working condition.
  • Page 19 Chapter 1 Introduction Caution of Low Battery Charge The battery pack is the only power source for the terminal to work. It also charges the backup battery so that the data stored in SDRAM can be retained properly. Therefore, when the main battery charge goes low, replace the battery pack with a charged one or seat it in the cradle for charging as soon as possible.
  • Page 20 9500CE Reference Manual To conserve more power, you may go to Start > Settings > Control Panel and double-tap the Display icon to configure the backlight setting.

  • Page 21: Cpu

    Chapter 1 Introduction 1.5.2 CPU Built to run Windows CE 5.0, the 9500CE terminal is equipped with an Intel X-Scale 520 MHz RISC microprocessor. 1.5.3 Memory & Calendar The terminal is equipped with two card slots, one SD and one CompactFlash Type II. You may upgrade memory by inserting an optional SD or CF memory card.
  • Page 22 9500CE Reference Manual System Properties - Memory tab Start > Settings > Control Panel and double-tap the System icon 1. In the Memory tab, it displays the current capacity and usage of the 128 MB onboard SDRAM. (Left below) 2. You may tap, hold, and drag the slider to re-allocate the memory.

  • Page 23: Keypad

    Chapter 1 Introduction 1.5.4 Keypad The terminal is equipped with a physical keypad that consists of 27 keys. Silicon rubber has been chosen for their durability and prompt feedback. The layout of the 27-key keypad includes alphanumeric, assorted characters, etc. This keypad is set to numeric mode by default.

  • Page 24: Keypad Settings

    9500CE Reference Manual Keypad Settings first, and then The LED backlight of keypad is turned off by default. It can be toggled ON/OFF by the key combination: [Func] + [0]. Start > Settings > Control Panel and double-tap the Keyboard icon The Character Repeat functionality is enabled by default.
  • Page 25 Chapter 1 Introduction Func Key The [Func] (function) key serves as a modifier key. 1. To enable this modifier key, press on the keypad. A circular icon of the letter "F" will appear on the status bar. This modifier key is hold down as long as the icon is displayed.

  • Page 26: Lcd

    9500CE Reference Manual 1.5.5 LCD The terminal comes with a 3.5” TFT graphic LCD, 240 by 320 pixels resolutions. The LED backlight of screen, which helps ease reading under dim environments, can be controlled manually and automatically. Warning: Using backlight while on battery power will substantially reduce battery life.
  • Page 27 Chapter 1 Introduction To conserve more power, you may go to Start > Settings > Control Panel and double-tap the Power icon to configure the power-saving setting.

  • Page 28: Stylus Properties

    9500CE Reference Manual Stylus Properties This LCD is also a touch screen that can be calibrated through screen alignment. Warning: DO NOT use any pointed or sharp objects to move against the surface of the screen. Start > Settings > Control Panel and double-tap the Stylus icon 1.

  • Page 29: Status Led

    Chapter 1 Introduction 1.5.6 Status LED The tri-color LED on top of the [Scan] button is used to provide information on status of battery charging or Bluetooth connection. Tasks Green LED Red LED Green & Red Blue Terminal charging Charging done Charging error Flashing Bluetooth connection enabled...

  • Page 30: Reader

    9500CE Reference Manual 1.5.9 Reader A wide variety of scan engines is available for delivering flexibility to meet different requirements. Types of Reader Scan Engine CCD (Long Range Imager) 1D Barcode Reader Laser scan engine Long Range Laser scan engine...
  • Page 31 Chapter 1 Introduction Symbologies Enabled Depending on the scan engine integrated (check the “Active Device” setting in ReaderConfig), the terminal is capable of scanning barcodes of a number of symbologies as shown below. If you need to scan barcodes that are encoded in a different symbology, use the ReaderConfig tool to enable the symbology first.

  • Page 32: Wireless Support

    9500CE Reference Manual 1.5.10 Wireless Support The 9500CE terminal supports state-of-the-art wireless technologies, Bluetooth and 802.11b, so that it is able to send/receive data in real time in an efficient way. 1.5.11 Resistance Shock The terminal is designed for harsh industrial environments, and is proved to survive...

  • Page 33: Chapter 2 - Installation

    - Be cautious of low battery conditions. - Turn off the backlight in a bright work area to save battery power. - Always use proprietary CipherLab batteries for safety concern. Hand Strap - The hand strap is ideal for one-handed operation, which requires safe and convenient hold of the portable terminal.

  • Page 34: Main & Backup Batteries

    9500CE Reference Manual 2.1 Main & Backup Batteries When you first receive the package, the rechargeable functionality of the backup battery is turned off. It is controlled by a DIP switch inside the battery compartment as shown below. For shipping and storage purposes, save the terminal and the main battery in separate packages, and slide the DIP switch to the OFF position (to your right).

  • Page 35: Figure 6: Installing Battery Pack

    Chapter 2 Installation 2. Slide the battery pack into the battery compartment at a proper angle (30°~45°) so that the tabs on the bottom of the battery are hooked in the grooves of the compartment. Make sure that the battery is snugly fit into the compartment. 3.

  • Page 36: Hand Strap

    9500CE Reference Manual 2.2 Hand Strap When a hand strap is necessary, install it to the terminal by following the steps: 1. Place the terminal face down on a flat and clean surface. 2. Screw one end of the hand strap to the shield-like cover on the back of the terminal.

  • Page 37: Pistol Grip

    Chapter 2 Installation 2.3 Pistol Grip When a pistol grip is necessary, install it to the terminal by following the steps: 1. Place the terminal face down on a flat and clean surface. 2. Remove the shield-like cover on the back of the terminal by unscrewing. If there is a hand strap installed, remove it first.

  • Page 38: Cf / Sd Card

    9500CE Reference Manual 2.4 CF / SD Card When you need to expand memory or add a peripheral, install the CF or SD card to the terminal by following the steps: 1. Press the [Power] key to turn off the terminal.

  • Page 39: Cradle

    Chapter 2 Installation 2.5 Cradle The cradle is designed for charging and communications at the same time. 1. Place the cradle on a flat and clean surface. 2. Connect the line of the power adaptor to the power jack on the back of the cradle. 3.

  • Page 40: Communication Ports

    9500CE Reference Manual Front Panel LEDs Tasks Indication of connection status Spare battery Solid red Charging charging status Solid green Charging done Flashing (red/green) Error occurs Battery not ready Link / Data: Network status Solid green Ethernet connected over Ethernet...

  • Page 41: Chapter 3 - Windows Ce Basics

    H A P T E R Windows CE Basics This chapter mainly describes the basic skills to work with the 9500CE terminal. The add-on utilities for applications regarding data collection, processing, and transmission, are introduced in the following chapters. The 9500CE terminal is specifically designed for real-time data collection in the Windows CE 5.0 environment.

  • Page 42: General

    9500CE Reference Manual 3.1 General When the 9500CE terminal is fully charged, you may remove it from the cradle. Then turn on the terminal and wait for the Windows CE desktop to come up. If you are using the terminal for the first time, there are a couple of things to do after the desktop comes up.

  • Page 43: Device Configuration

    Chapter 3 Windows CE Basics 3.1.1 Device Configuration The device configuration of 9500CE is displayed in 5 digits: xxxx-x Take the screenshot of System Properties above for example. Its device configuration is “5410-0”, which means the 27-key terminal has equipped with the following parts:...

  • Page 44: Turn On/Off

    9500CE Reference Manual 3.1.2 Turn On/Off Like your PDA, Pocket PC and most handheld devices, the 9500CE terminal functions when it is turned on. This is because the Windows CE operating system eliminates the booting process and runs continuously. Turn On (= Resume from Suspend) To turn on the terminal, simply press the [Power] key.

  • Page 45: Start Menu

    Chapter 3 Windows CE Basics to the right of the taskbar, and then select Desktop. Alternatively, you may tap Note: To customize the desktop, tap on the blank area of desktop and select Properties. When you turn on the terminal and seat it in the cradle for the first time, you will find the following icons displayed on the taskbar: This icon shows that your cradle is directly connected to a computer via USB port.
  • Page 46 9500CE Reference Manual Favorites Provides access to your favorites in the directory: \Windows\Favorites Documents Provides access to recent opened documents in the directory: \Windows\Recent Settings Provides access to Control Panel Network and Dial-up Connections Taskbar and Start Menu Run… Runs a program or application.
  • Page 47 Chapter 3 Windows CE Basics Wireless It provides control of the power to the 802.11b and GPRS modules. Power Double-tap any of these icons to configure the power setting. Manager It indicates the GPRS module is enabled. See GPRS status icon below.

  • Page 48: Input Methods

    3.1.4 Input Methods Data entry can be performed by the following methods: Type with the 27-key physical keypad Scan barcode or RFID tag in applications, e.g. WordPad, CipherLab’s Application Generator, etc. Tap or write using SIP (Soft Input Panel) Soft Input Panel (SIP) Tap the SIP button on the taskbar to select a SIP mode or hide the input panel.

  • Page 49: System Reset

    Chapter 3 Windows CE Basics 3.2 System Reset Reset the 9500CE terminal when it stops responding to input. Soft reset: Simply press the [Reset] button. Hard reset: Press the [Reset] button and the [Power] key at the same time. Warning: Never perform a hard reset unless a soft reset cannot solve your problems.

  • Page 50: Firmware Update

    ActiveSync operation. Then, disable the ActiveSync operation as shown below. 2. Run the installer “AP.exe” from the CD-ROM. 3. Perform a hardware reset on the 9500CE terminal. 4. For the terminal to enter the “Download” mode, press [Space] + [8] + [Power] simultaneously in three seconds.

  • Page 51: Activesync With A Computer

    2. Your computer will automatically detect the USB device. Click [OK] when the connection is established. 3. Select which partnership to set up. If you want to synchronize data between 9500CE and your computer, select Standard Partnership; otherwise, select Guest Partnership.

  • Page 52: Quick Launch A Program

    9500CE Reference Manual 3.5 Quick Launch a Program Tap the Start button to view the Start Menu. To quick launch a program, tap it from the Programs folder. Note: Alternatively, you may tap Start and select Run to run a specific program or open a document.
  • Page 53 Chapter 3 Windows CE Basics 3. Tap and hold the program, and then tap [Copy] on the pop-up menu. 4. Navigate to the Programs folder (My Device\Windows\Programs). 5. Tap and hold anywhere blank on the screen. Then tap [Paste Shortcut] on the pop-up menu.
  • Page 54 9500CE Reference Manual Using ActiveSync on PC 1. When connected, open the Microsoft ActiveSync window on your desktop computer. 2. Click the Explorer button from the toolbar. 3. Navigate through file folders to find the program you desire. 4. Right-click the program, and then select [Create Shortcut] on the pop-up menu.

  • Page 55: Add A Subfolder

    Chapter 3 Windows CE Basics 3.5.2 Add a Subfolder Using Windows Explorer 1. Go to Start > Programs, and select Windows Explorer. Alternatively, you can press the [Task] key on the keypad to launch Windows Explorer. 2. Navigate through file folders to find where you wish to create a new folder. 3.

  • Page 56: Exit A Program

    9500CE Reference Manual 3.5.3 Exit a Program In general, the system manages memory automatically, and there is no need to exit a program in order to open another or to conserve memory. However, random access memory (SDRAM) may be used up when running too many programs. As a result, it will slow down the operation or cause program errors.

  • Page 57: Install A New Program

    Chapter 3 Windows CE Basics 3.6 Install a New Program 3.6.1 Add/Remove Programs To install a program that is designed to be used on a mobile device running Windows CE, you may click [Add/Remove Programs] from the Tools Menu. 3.6.2 Copy & Paste Alternatively, you may install a new program manually.

  • Page 58: Uninstall A Program

    9500CE Reference Manual 3.7 Uninstall a Program If a user program is no longer desired, you may remove it from the system. 3.7.1 ActiveSync: Add/Remove Programs To uninstall a program that is designed to be used on a mobile device running Windows CE, you may click [Add/Remove Programs] from the Tools Menu.
  • Page 59 Chapter 3 Windows CE Basics Note: If the program does not appear in the list of installed programs, you may use Windows Explorer to locate it. Tap and hold the program, and select [Delete].

  • Page 60: Backup & Restore Programs

    9500CE Reference Manual 3.8 Backup & Restore Programs To best protect your work, you should regularly back up information on your terminal. You can perform a backup by during the ActiveSync operation. The backup file is stored on your desktop computer.

  • Page 61: Chapter 4 - Configuration

    H A P T E R Configuration In this chapter, a brief on the system settings is provided for your reference. Note: User settings are stored in SDRAM and will be overwritten by the system defaults after a hard reset. 4.1 General Settings Go to Start >...
  • Page 62 9500CE Reference Manual Items Description In the [Accessibility] dialog box, you may use these options to customize the way an external keyboard, display, or mouse functions. Many of these features are useful to people without disabilities Keyboard tab: Select StickyKeys to enable simultaneous keystrokes while pressing one key at a time;...
  • Page 63 Chapter 4 Configuration Connect an external keyboard to the cradle via the USB Host port. In the [Keyboard Properties] dialog box, you may configure settings for character repeat. Connect a mouse to the cradle via the USB Host port. In the [Mouse Properties] dialog box, you may configure and test your double-click settings.

  • Page 64: Connections

    9500CE Reference Manual In the [Stylus Properties] dialog box, Double-Tap tab: You may configure and test your double-tap settings. Calibration tab: You may need to re-calibrate the touch screen if it is not responding properly to your taps. In the [System Properties] dialog box, General tab: You may view the system information.
  • Page 65 Chapter 4 Configuration Type of Connections Description See Also This is a shortcut to USB Connection, and the Start > Settings > selected interface is USB for factory setting. Control Panel > This connection is reflected in the control panel for direct PC connection.

  • Page 66: Usb Connection

    9500CE Reference Manual 4.2.1 USB Connection Tap and hold on “USB Connection”. Most options can be found in the Connection menu on the toolbar as well. When you select [Set as Default], the USB Connection will become the default connection used for browsing the Internet.

  • Page 67: Gprs

    Chapter 4 Configuration 4.2.2 GPRS Tap and hold on “GPRS”. Most options can be found in the Connection menu on the toolbar as well. When you select [Set as Default], the GPRS connection will become the default connection used for browsing the Internet. Connect / Disconnect 1.
  • Page 68 9500CE Reference Manual Note: The PIN verification on the terminal only allows two attempts because the system will always process the default number first (“1234” for factory setting). Unless it matches the PIN code of your SIM card, you will have to manually input the correct PIN code.
  • Page 69 Chapter 4 Configuration Alternatively, you may go to Start > Settings > Control Panel and select Dialing. 5. After you tap the [Connect] button, the GPRS status will go through opening port, user authenticated, device connected until it is connected finally. The status icon will appear on the taskbar to indicate the GPRS connection is established successfully.
  • Page 70 9500CE Reference Manual Properties Go to Start > Settings > Network and Dial-up Connections. Tap and hold on “GPRS”, and select [Properties]. In the dialog box, you can configure the GPRS properties. Once the SIM card is inserted, the default GPRS modem will appear as shown below (right).

  • Page 71: Ax88772 (Ethernet)

    Chapter 4 Configuration 4.2.3 AX88772 (Ethernet) Tap and hold on “AX887721”. Enable / Disable Icons Description By default, the Ethernet module is enabled. When a Cat. 5 cable is connected, the status icon will become Tap and hold on “AX887721”, and select [Disable]. The status icon will disappear.

  • Page 72: Wlan

    9500CE Reference Manual 4.2.4 WLAN Tap and hold on “WLAN1”. Connect / Disconnect 1. Turn on the power to the 802.11b module through the Wireless Power Manager. Its associated icon on the taskbar will become The WLAN1 dialog box appears for establishing a connection.
  • Page 73 Chapter 4 Configuration 2. Select an access point or Wi-Fi enabled device, and tap the [Connect] button. For initial connection, the Wireless Properties dialog box will appear first. Tap [OK] after configuration.
  • Page 74 9500CE Reference Manual 3. Wait a few seconds for the terminal to connect to the selected network. 4. If you need to change the network settings, double-tap the selected network. The Wireless Properties dialog box appears as shown in step 2. Tap [OK] after configuration.
  • Page 75 Chapter 4 Configuration Icons Description By default, the 802.11b module is disabled. No status icon. Enable the 802.11b module through the Wireless Power Manager. The icon on the taskbar will become , and the status icon will appear. When successfully connecting to an access point or other Wi-Fi enabled device, the status icon will become Properties...

  • Page 76: Btpan

    9500CE Reference Manual 4.2.5 BTPAN Tap and hold on “BTPAN1”. Enable / Disable Icons Description By default, the Ethernet module is enabled. When the Bluetooth PAN service is connected through the Bluetooth Manager, the status icon will become Tap and hold on “BTPAN1”, and select [Disable]. The status icon will disappear.

  • Page 77: Chapter 5 - Applications

    H A P T E R Applications The 9500CE terminal provides several utilities and key applications which are made accessible from the desktop or the taskbar. Wireless Power Manager lets you determine whether the power is supplied to the GPRS or WLAN module, along with its associated driver installed.

  • Page 78: Wireless Power Manager

    9500CE Reference Manual 5.1 Wireless Power Manager Wireless Power Manager is a control panel applet, which allows you to choose and enable 802.11b, GPRS or other CF card. Note: Meanwhile, you may enable Bluetooth connectivity through the Bluetooth Manager. on the taskbar to run Wireless Power Manager.

  • Page 79: Bluetooth Manager

    Chapter 5 Applications 5.2 Bluetooth Manager Bluetooth Manager is a utility that helps you access and manage the available Bluetooth services efficiently. The supported Bluetooth profiles are: Serial Port Profile (SPP) Object Push Profile (OPP) File Transfer Profile (FTP) Dial-Up Networking Profile (DUN) Synchronization Profile (SP)
  • Page 80 9500CE Reference Manual Note: To start Bluetooth PAN service, go to Start > Settings > Network and Dial-up Connections. Toolbar Buttons Description See Also Tap this button to view shortcuts to preferred Bluetooth services, which may be provided on different Bluetooth devices. Then tap a desired Bluetooth service to establish a quick link.
  • Page 81 Chapter 5 Applications File You can change the FTP folder. Transfer By default, uploading files to the terminal is allowed. You can Properties cancel the check box to prohibit uploading. You can change the Bluetooth exchange folder. Object Push Properties Tap this button to view the Bluetooth properties.
  • Page 82 9500CE Reference Manual If you wish to change the device name of the terminal, go to Start > Settings > Control Panel and select System. Security tab Authentication Setting: It is disabled by default. When enabled, PIN code is required.
  • Page 83 Chapter 5 Applications remote Serial Port service will be assigned automatically. When disabled, you can select a COM port by selecting [Connect]: Auto Server COM Port: When enabled, the default COM port for local Serial Port service will be assigned automatically. Tap this button to start with ActiveSync operation via Bluetooth.

  • Page 84: Inquiry

    9500CE Reference Manual 5.2.2 Inquiry 1. Tap to discover nearby Bluetooth devices. 2. It will list the discovered devices.

  • Page 85: Pair

    Chapter 5 Applications 5.2.3 Pair When authentication is enabled on the target device, you will have to pair with it before starting a connection. 1. From the device list, tap and hold on the desired device and tap [Pair]. 2. Enter the PIN code that is specified on the remote device.
  • Page 86 9500CE Reference Manual 3. Once paired successfully, the paired device will be displayed along with a lock icon “ ”.

  • Page 87: Connect

    Chapter 5 Applications 5.2.4 Connect 1. From the device list above, double-tap a device to find out the available Bluetooth services. 2. Tap and hold a desired Bluetooth service, e.g. Serial Port Service, to establish a connection. The connected service will be displayed along with a plug icon “ ”.
  • Page 88 9500CE Reference Manual 3. If you wish to add a service to the Q_Link list for establishing a quick connection in the future, tap and hold it, and then select [Create Shortcut]. 4. For ActiveSync via Bluetooth, make sure that you use COM8 to connect to your computer.
  • Page 89 Chapter 5 Applications Steps to access the Object Push service: 1. Tap and hold the Object Push service. 2. Select [Push file] to send a file or PIM item, e.g. a business card. 3. Choose the file you wish to send. 4.
  • Page 90 9500CE Reference Manual Steps to access the File Transfer service: 1. Tap and hold the File Transfer service. 2. Select [Connect] (and assign COM port if necessary). 3. Tap and hold on anywhere blank. Then, select [Add file]. 4. Choose the file you wish to upload to the remote device.
  • Page 91 Chapter 5 Applications 6. To download a file from the remote device, tap and hold on a desired file. Then, select [Get file].

  • Page 92: Stop Bluetooth Services

    9500CE Reference Manual 5.2.5 Stop Bluetooth Services on the toolbar of the Bluetooth window to stop all Bluetooth connections. When the Bluetooth window is minimized, tap and hold on the taskbar, and then select [Exit]. Note: You may need to stop using the Bluetooth services, in order to conserve battery power, or in situations where the use of radio is prohibited, such as on airplanes, in hospitals, etc.

  • Page 93: Readerconfig

    Chapter 5 Applications 5.3 ReaderConfig ReaderConfig is the control applet and tool to manage the barcode and RFID readers integrated on the terminal. 1. Double-tap the ReaderConfig shortcut on the desktop. The associated icon will appear on the taskbar. 2. Tap and hold on the icon to access the menu that allows you to choose and enable one or both of the readers.

  • Page 94: Configure Reader Settings

    9500CE Reference Manual 5.3.1 Configure Reader Settings Tap and hold on , and then select BC Reader or RFID Reader. If it is ticked, the reader is enabled. Otherwise, it is disabled. The default reader is BC Reader for reading barcodes. If the RFID Reader is installed, the option will be available.

  • Page 95: Reader - Ccd / Laser

    Chapter 5 Applications 5.3.2 1D Reader - CCD / Laser General tab Settings Default Active Device The scan engine can be identified and toggled. Only Barcode Reader one scan engine can be disabled at a time. is always enabled if exists. 1D Reader RFID Good Read Beep...
  • Page 96 9500CE Reference Manual Auto ENTER This function can spare you the trouble of pressing the Scan + ENTER [Enter] key on the terminal to confirm each scan. It will automatically add an ENTER character in front or to the end of one scan.
  • Page 97 Chapter 5 Applications Negative Barcode Normally, barcodes are printed with the color of the NO (Disabled) bars darker than that of the spaces. For negative barcodes, they are printed oppositely just like negative films. That is, the spaces of the negative barcodes are printed with the color darker than that of the bars.
  • Page 98 9500CE Reference Manual 1D tab: CCD / Laser Code 39 Supported on CCD / Laser Default Enabled or Disabled Enabled Transmit Start / Stop When enabled, the start / stop characters will be OFF (Disabled) included in the data being transmitted.
  • Page 99 Chapter 5 Applications If the checksum is incorrect, data will be rejected. Transmit Checksum The checksum character is included in the data being ON (Enabled) transmitted. Length Qualification The weak structure of some barcodes may cause a Max / Min “short scan”...
  • Page 100 9500CE Reference Manual Interleaved 25 Matrix 25 Verify Checksum When enabled, the checksum verification will be OFF (Disabled) performed in decoding. If the checksum is incorrect, data will be rejected. Transmit Checksum The checksum character is included in the data being ON (Enabled) transmitted.
  • Page 101 Chapter 5 Applications Max / Min Length Maximum Length 0~127 characters Minimum Length 0~127 characters Plessey Supported on CCD / Laser Default Enabled or Disabled Disabled Convert to UK When enabled, each occurrence of the character “A” OFF (Disabled) Plessey will be converted to “X”.
  • Page 102 9500CE Reference Manual Convert to ISBN When enabled, the EAN-13 reading that starts with 978 OFF (Disabled) and 979 will be converted to ISBN. Convert to ISSN When enabled, the EAN-13 reading that starts with 977 OFF (Disabled) will be converted to ISSN.
  • Page 103 Chapter 5 Applications RSS Limited Supported on CCD / Laser Default Enabled or Disabled Disabled Transmit Checksum The checksum character is included in the data being ON (Enabled) transmitted. Transmit Application The Application ID is included in the data being ON (Enabled) transmitted.

  • Page 104: Reader - (Extra) Long Range Laser

    9500CE Reference Manual 5.3.3 1D Reader - (Extra) Long Range Laser General tab Settings Default Active Device The scan engine can be identified and toggled. Only Barcode Reader one scan engine can be disabled at a time. is always enabled if exists.
  • Page 105 Chapter 5 Applications Auto ENTER This function can spare you the trouble of pressing the Scan + ENTER [Enter] key on the terminal to confirm each scan. It will automatically add an ENTER character in front or to the end of one scan. Scan + ENTER (time-saving) ENTER + Scan (efficient for continuous scanning) Auto ENTER...
  • Page 106 9500CE Reference Manual 1D tab: (Extra) Long Range Laser UPC / EAN Supported on (Extra) Long Range Laser Default Enable UPC-A YES or NO YES (Enabled) Enable UPC-E0 YES or NO YES (Enabled) Enable UPC-E1 YES or NO NO (Disabled)
  • Page 107 Chapter 5 Applications UPC-A into UPC-A. It will then be processed according to the settings of UPC-A. Convert UPC-E1 to When enabled, the UPC-E1 reading will be expanded NO (Disabled) UPC-A into UPC-A. It will then be processed according to the settings of UPC-A.
  • Page 108 9500CE Reference Manual Length within Range For example, if “Length within Range” is selected, the terminal will only accepts those barcodes with lengths that fall between the maximum and minimum lengths; otherwise, data will be rejected. *If “Code 39 Full ASCII” is enabled, “Length within Range”...
  • Page 109 Chapter 5 Applications that fall between the maximum and minimum lengths; otherwise, data will be rejected. Verify Check Digit When enabled, the checksum verification will be Disable performed in decoding, based on the selected algorithm. If the checksum is incorrect, data will be rejected. Disable USS Check Digit (USS = Uniform Symbology Specification)
  • Page 110 9500CE Reference Manual Supported on (Extra) Long Range Laser Default Enable MSI YES or NO NO (Disabled) Select Discrete Refer to Interleaved 25 above. Any Length Length Check Digit Select check digit(s) to transmit and verify: One MSI Check Digit...

  • Page 111: Reader

    Chapter 5 Applications 5.3.4 2D Reader General tab Settings Default Active Device The scan engine can be identified and toggled. Only Barcode Reader one scan engine can be disabled at a time. is always enabled if exists. 2D Reader RFID Good Read Beep Mute, or Sound 1~9 Sound 2...
  • Page 112 9500CE Reference Manual Auto ENTER This function can spare you the trouble of pressing the Scan + ENTER [Enter] key on the terminal to confirm each scan. It will automatically add an ENTER character in front or to the end of one scan.
  • Page 113 Chapter 5 Applications 2D tab UPC / EAN Supported on 2D Reader Default Enable UPC-A YES or NO YES (Enabled) Enable UPC-E0 YES or NO YES (Enabled) Enable UPC-E1 YES or NO NO (Disabled) Enable EAN-8 YES or NO YES (Enabled) Enable EAN-13 YES or NO YES (Enabled)
  • Page 114 9500CE Reference Manual Convert UPC-E0 to When enabled, the UPC-E0 reading will be expanded NO (Disabled) UPC-A into UPC-A. It will then be processed according to the settings of UPC-A. Convert UPC-E1 to When enabled, the UPC-E1 reading will be expanded...
  • Page 115 Chapter 5 Applications *“Convert Code 39 to Code 32” must be enabled! Select Discrete The length of a barcode refers to the number of Any Length Length characters (i.e. human readable characters), including check digit(s) it contains. Any Length One Discrete Length Two Discrete Lengths Length within Range For example, if “Length within Range”...
  • Page 116 9500CE Reference Manual If the checksum is incorrect, data will be rejected. Disable One Check Digit Two Check Digits Transmit Check Digit When enabled, the check digit will be included in the NO (Disabled) data being transmitted. *By default, this feature (Not Transmit Check Digit) only works when “Verify Check Digit”...
  • Page 117 Chapter 5 Applications **“Verify Check Digit” must be disabled! Industrial 25 Supported on 2D Reader Default Enable Industrial 25 YES or NO NO (Disabled) Select Discrete Refer to Interleaved 25 above. Any Length Length Codabar Supported on 2D Reader Default Enable Codabar YES or NO NO (Disabled)
  • Page 118 9500CE Reference Manual Postal Codes Supported on 2D Reader Default Enable US Postnet YES or NO YES (Enabled) Enable US Planet YES or NO YES (Enabled) Transmit US Check YES or NO YES (Enabled) Digit Enable UK Postal YES or NO...
  • Page 119 Chapter 5 Applications Enable UPC UPC barcodes can be “linked” with a 2D barcode UPC Always Composite Mode during transmission as if they were one barcode. There Linked are three options for these composite barcodes: UPC Never Linked (to transmit UPC barcodes only, regardless of whether a 2D barcode is detected) UPC Always Linked (to transmit UPC barcodes and the 2D portion;...
  • Page 120 9500CE Reference Manual Buffer All Symbols / Transmit Macro PDF When Complete (to transmit all decoded data from an entire Macro PDF sequence only when the entire sequence is scanned and decoded; if the decoded data exceeds the limit of 50 symbols, no transmission because...

  • Page 121: Rfid Reader

    Chapter 5 Applications 5.3.5 RFID Reader If you have RFID reader installed, click the General tab and its settings are available at the bottom of the list. General tab Settings Default Read UID of RFID tag YES or NO YES (Enabled) Read data of RFID YES or NO NO (Disabled)

  • Page 122: Inbox

    9500CE Reference Manual 5.4 Inbox You can send and receive e-mail by connecting to a POP3 or IMAP4 server. Inbox provides an e-mail service for each method you use. In addition, you can synchronize the e-mail messages in Inbox with either Microsoft Outlook or Microsoft Exchange Server on your computer through the default ActiveSync mail service.
  • Page 123 Chapter 5 Applications 3. Tap and drag the dialog box to show the right edge. Tap [Add] to create an e-mail service. 4. In the Service Name dialog box, select POP3 Mail or IMAP4 Mail for the service type. Change the name of e-mail service if necessary. Tap [OK]. 5.
  • Page 124 9500CE Reference Manual Connection Description GPRS Send and Receive e-mail through GPRS connection. Network Connection Send and Receive e-mail through Ethernet, 802.11b or Bluetooth PAN connection. USB Connection Send and Receive e-mail through USB connection via the cradle. 6. After you successfully create an e-mail service, you may start using it now.

  • Page 125: Synchronize Inbox

    Chapter 5 Applications Connect or disconnect Services > Connect When connected, it will send and receive mail automatically. 5.4.2 Synchronize Inbox When you seat the terminal in the cradle and connect it to your computer for the first time, ActiveSync 3.7.1 will guide you through setting up a partnership between the terminal and your computer.
  • Page 126 9500CE Reference Manual...

  • Page 127: Specifications

    Operating System Windows CE 5.0 Visual Studio 2005 Programming eMbedded Visual C++ 4.0 SP4 and 9500CE SDK System API (static and DLL) for system configuration ReaderDLL for reader configuration Wireless Application Generator (AG) or RF Workshop Refer to 9500 Programming Guide and RF Workshop User Guide.
  • Page 128 9500CE Reference Manual Speaker: Low power transducer type, 1 KHz to 4 KHz Vibrator: 9000 ± 2000 RPM, Max. 50 dB Communications Peer-to-Peer connection via cradle (ActiveSync) Client: USB Host: For peripherals, such as a keyboard, mouse, storage card, etc.
  • Page 129 P P E N D I X Comparison of Scan Modes For the following 1D scan engine, you can select a desired scan mode. CCD scan engine Laser scan engine Scan Mode Always Press Hold Press Release Press Barcode Time- trigger trigger trigger...
  • Page 130 9500CE Reference Manual Continuous Mode The reader is always scanning, but only one decoding is allowed for the same barcode. That is, to read (i.e. scan and decode) the same barcode multiple times, the barcode has to be taken away and replaced for new scanning.
  • Page 131 Appendix I Comparison of Scan Modes Laser Mode This mode is most often used on laser scanners. Hold down the scan trigger to start scanning. The scanning continues until one of the events happens: (1) A barcode is read. (2) The preset timeout expires. (3) The trigger is released.
