- Page 1 SF 10W-A18 Operating instructions Mode d’emploi Manual de instrucciones Manual de instruções Printed: 15.04.2015 | Doc-Nr: PUB / 5161674 / 000 / 04...
- Page 2 This Product is Certified Ce produit est homologué Producto homologado por Este produto está registrado C US Printed: 15.04.2015 | Doc-Nr: PUB / 5161674 / 000 / 04...
- Page 3 Printed: 15.04.2015 | Doc-Nr: PUB / 5161674 / 000 / 04...
- Page 4 Printed: 15.04.2015 | Doc-Nr: PUB / 5161674 / 000 / 04...
-
Page 5: Table Of Contents
These numbers refer to the illustrations. You can find the illustrations at the beginning of the operating instructions. In these operating instructions, the designation “power tool” always refers to the SF 10W-A18 drill / driver with battery fitted. Parts, operating controls and indicators Side handle... -
Page 6: General Information
Light § Battery Charge status and fault display (Li-ion battery) Release buttons with additional function (charge status display acti- · vation) 1 General information 1.1 Safety notices and their meaning DANGER Draws attention to imminent danger that will lead to serious bodily injury or fatality. -
Page 7: Safety Instructions
Make a note of this data in your operating instructions and always refer to it when making an enquiry to your Hilti representative or service department. Type: Generation: 01 Serial no.:... - Page 8 b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
- Page 9 d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 10 2.1.5 Battery tool use and care a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. b) Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire.
- Page 11 2.4 Additional safety rules 2.4.1 Personal safety a) Modification of the machine or tampering with its parts is not permissible. b) Always hold the power tool securely with both hands on the grips provided. Keep the grips dry, clean and free from oil and grease. c) Improve the blood circulation in your fingers by relaxing your hands and exercising your fingers during breaks between working.
- Page 12 If the battery is too hot to touch it may be defective. Place the tool in a location where it can be kept under observation, well away from flammable materials, and allow it to cool down. Contact Hilti Service after the battery has cooled down.
-
Page 13: Description
3 Description 3.1 Use of the product as directed The SF 10W-A18 is a hand-held, cordless drill / driver for driving and removing screws and for drilling in steel, wood and plastic. Do not use the battery as a power source for other unspecified appliances. -
Page 14: Technical Data
LED 1, 2, 3, 4 Power tool over- loaded or over- heated 4 Technical data Right of technical changes reserved. Power tool SF 10W-A18 Rated voltage (DC voltage) 21.6 V Weight 2.7 kg (5.95 lb) Speed in 1st gear 0…310/min Speed in 2nd gear 0…530/min... -
Page 15: Before Use
Before fitting the battery, check that the power tool is switched off and that the safety lock is engaged (forward/reverse switch in the middle position). Use only the Hilti batteries approved for use with this power tool. 1. Push the battery into the tool from the rear as far as it will go and until it is heard to engage with a double click. -
Page 16: Operation
3. Slide the side handle clamping band over the chuck and onto the clamping section at the front end of the power tool. 4. Pivot the side handle into the desired position. 5. Secure the side handle by turning the handle clockwise. 6. - Page 17 6.2 Adjusting the side handle 1. Release the side handle clamping band by turning the handle counter- clockwise. 2. Pivot the side handle into the desired position. 3. Tighten the side handle by turning the handle clockwise. 4. Check that the side handle holds securely. 6.3 Speed selection using the four-speed gear selector NOTE The mechanical four-speed gear selector can be used to select the speed...
-
Page 18: Care And Maintenance
6.8 Screwdriving 6.8.1 Fitting the bit holder / bit 1. Set the forward / reverse switch to the middle position or remove the battery from the power tool. 2. Open the keyless chuck. 3. Insert the bit adapter in the keyless chuck and then turn the chuck firmly by hand until tight. -
Page 19: Troubleshooting
NOTE – If use continues, further battery discharge will be stopped automatically before the battery cells suffer damage. – Charge the batteries using the specified and approved Hilti battery chargers for Liion batteries. 8 Troubleshooting Fault Possible cause Remedy... -
Page 20: Disposal
Contact Hilti Service if the prob- lem persists. The power tool or the Electrical fault. Switch the tool off im- battery gets very hot. -
Page 21: Manufacturer's Warranty - Tools
Batteries that have reached the end of their life must be disposed of in accordance with national regulations or returned to Hilti. Most of the materials from which Hilti power tools or appliances are manufactured can be recycled. The materials must be correctly separated before they can be recycled. - Page 22 Hilti Corporation LI-9494 Schaan Tel.: +423 / 234 21 11 Fax: +423 / 234 29 65 www.hilti.com Hilti = registered trademark of Hilti Corp., Schaan Pos. 3 | 20150407 Printed: 15.04.2015 | Doc-Nr: PUB / 5161674 / 000 / 04...
