CAUTION - FOR YOUR SAFETY
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
This is a gas-fire appliance. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air For Combustion and
Ventilation of page 7 of this manual.
This appliance is convertible for use with propane/LP gas by using the MANUAL ON/OFF
VALVE/SAFETY PILOT KIT (see ACCESSORIES on page 18).
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m., CST, Monday – Friday or
email us at customerservice@ghpgroupinc.com.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
VL-WO18D
VL-WO24D
VL-WO30D
1
VENTED NATURAL
GAS LOGS
MODELS
VL-AA18D
VL-NO24D
VL-AA24D
VL-NO30D
VL-AA30D
0418GL012S
Complies with ANSI Z21.84-
2012, Standard for Manually
lighted, Natural Gas Decorative
Gas Appliances for Installation in
Solid-Fuel Burning Fireplaces.
Complies with ANSI Z21.60-
2012, Standard for Decorative
Gas Appliances for Installation
in Solid-Fuel Burning Fireplaces
when the LP Conversion Kit
(SPK100) is installed by a
qualified technician.
IMVLS - 2015-07-10
Advertisement
Table of Contents
Related Manuals for pleasant hearth VL-WO18D
Summary of Contents for pleasant hearth VL-WO18D
-
Page 1: Gas Logs
VENTED NATURAL GAS LOGS MODELS VL-WO18D VL-AA18D VL-NO24D VL-AA24D VL-WO24D VL-NO30D VL-AA30D VL-WO30D 0418GL012S Complies with ANSI Z21.84- 2012, Standard for Manually lighted, Natural Gas Decorative Gas Appliances for Installation in Solid-Fuel Burning Fireplaces. Complies with ANSI Z21.60- 2012, Standard for Decorative... -
Page 3: Table Of Contents
The charts indicate technical information regarding the installation of your gas log set. Please make sure that all of the specifications shown are applicable before installation is attempted. The fireplace must include a working flue and venting system with the minimum openings shown as below. VL-WO18D VL-WO30D VL-WO18D ITEM... -
Page 4: Important Safety Information
SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this log set. Improper use of this log set can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. Only a qualified installer, service agent, or local gas supplier may install and service this product. -
Page 5: Qualified Installing Agency
SAFETY INFORMATION 1. This appliance is only for use with the type of gas indicated on the rating plate. 2. Do not place propane/LP supply tank(s) inside any structure. Locate propane/LP supply tank(s) outdoors. 3. If you smell gas • shut off gas supply •... -
Page 6: Product Identification
PRODUCT IDENTIFICATION Cover Plate* Log Risers Pilot Bracket Screw (4) 8X3/8PPHTS-B Burner Manifold Burner Clamp* Grate Burner Pan Burner Inlet *Uses (4) 8X3/8PPHTS-B Screws... -
Page 7: Product Features
PRODUCT FEATURES The State of Massachusetts requires that the chimney flue damper, when used with decorative gas log sets, be welded open or completely removed. In the State of Massachusetts, this appliance must be installed by a licensed plumber or gasfitter. In the State of Massachusetts the gas cock must be a T-handle type. -
Page 8: Preparing For Installation
PREPARING FOR INSTALLATION AIR FOR COMBUSTION AND VENTILATION WARNING: If the area in which the log set may be operated does not meet the required volume for indoor combustion air, combustion and ventilation air shall be provided by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or applicable local codes. -
Page 9: Installation
INSTALLATION Fig. 2 INSTALLATION Damper PREPARE DAMPER Damper "Opened Position" The chimney damper must be fixed open in a man- ner which will maintain the minimum permanent vent opening at all times. This may be accom- plished by installing a screw or bolt in the edge of the damper to prevent the damper from closing, by drilling a hole or holes in the damper blade or by Damper Clamp... - Page 10 INSTALLATION In compliance with ANSI Z21.60•CGA2.26 and Nation- Fig. 5 al Fuel Gas Code, Section 6. BEFORE INSTALLING THE APPLIANCE Step 4: NG 3/8" Orifice Fitting - Turn off gas supply to fireplace or firebox. - Clean fireplace floor and chimney before installing log set.
- Page 11 INSTALLATION CHECKING GAS CONNECTIONS WARNING: Test all gas piping and connections for leaks after installing or servicing. Correct all leaks immediately. WARNING: Never use an open flame to check for a leak. Apply a mixture of liquid soap and water to all joints.
- Page 12 INSTALLATION ADDING PAN MATERIAL WARNING: Apply loose material (embers and lava rock [cinders]) per instruction manual. DO NOT apply extra material not supplied with this appliance. All previously applied loose material (embers) must be removed prior to reapplication. 1. Open bags of ash bed material (vermiculite), and spread evenly across burner pan to the top. It is ok to cover the connecting hardware and the burner pan, but DO NOT cover the gas valve.
-
Page 13: Assembling Logs
ASSEMBLING LOGS VL-WO18D/VL-WO24D/VL-WO30D WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this log set may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in contact with any log. - Page 14 ASSEMBLING LOGS VL-AA18D WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this log set may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in contact with any log.
- Page 15 ASSEMBLING LOGS VL-AA24D/VL-AA30D/VL-NO24D/VL-NO30D WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this log set may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in contact with any log.
-
Page 16: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance requires ignition by match lighting. When lighting the appliance, follow these in- structions exactly. - Page 17 OPERATION LIGHTING INSTRUCTIONS - MATCH LIGHT UNITS 1. STOP! Read the safety information as noted above. WARNING: BE SURE THAT THE CHIMNEY DAMPER IS FULLY OPEN. 2. Read all warnings and safety information in this manual. 3. Turn keyed shutoff valve to the "OFF" position (see Figure 30). 4.
-
Page 18: Care And Maintenance
CARE AND MAINTENANCE BURNER FLAME PATTERN Figure 31 shows a correct burner flame pattern. Figure 32 shows an incorrect burner flame pattern. The incorrect burner flame pattern shows sporadic, irregular flame tipping. The flame should not be dark or have an orange/reddish tinge. Note: When using the log set the first time, the flame will be orange for approximately one hour until the log cures. -
Page 19: Accessories
CARE AND MAINTENANCE • Keep the area around the log set clean and clear of debris. • Once every year a qualified agency or certified chimney sweep should examine and clean the venting system of the fireplace. At the beginning of each season, the system should be checked as follows: 1. -
Page 20: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •... - Page 21 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Metal expanding while Log set produces a 1. This is common with most log sets. If heating or contracting while clicking/ticking noise noise is excessive, contact qualified cooling. just after burner is lit service person.
-
Page 22: Replacement Parts
REPLACEMENT PARTS For replacement parts, call our Technical Service Department at 1-814-643-1775, 8:30 a.m. –4:30 p.m., CST, Monday – Friday. VL-WO18D / VL-WO24D / VL-WO30D ITEM PART NO. DESCRIPTION VL-WO18D VL-WO24D VL-WO30D Log Set (Complete) 80-06-27 80-06-28 80-06-29 Log 1... - Page 23 REPLACEMENT PARTS For replacement parts, call our Technical Service Department at 1-814-643-1775, 8:30 a.m. –4:30 p.m., CST, Monday – Friday. VL-AA24D / VL-AA30D VL-AA18D VL-NO24D / VL-NO30D PART NO. ITEM DESCRIPTION VL-AA24D VL-AA30D VL-AA18D VL-NO24D VL-NO30D Log Set (Complete) 80-06-047 80-06-048 80-06-049 Log 1...
-
Page 24: Warranty
This limited warranty is extended to the original retail purchaser of this heater and warrants against any years years... - Page 25 GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302 Tel: (877) 447-4768 www.ghpgroupinc.com GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302...
Need help?
Do you have a question about the VL-WO18D and is the answer not in the manual?
Questions and answers
I have a masonry fireplace and chimney. I would like to convert to natural gas log kit. I would like to know if I can install horizontal vent through the back of the chimney. (see diagram) The existing chimney is very tall and the top section is in need of repair/replacement. I would like to remove the damaged portion and cap the top as it will no longer burn wood the height should no longer be needed to extend above the highest point of the roof. I just do not know if venting as desired can be done without the aid of a blower assist. Your assistance is appreciated. unfortunately for some reason I cannot attach my sketch. If you provide an email I can send it.
No, the Pleasant Hearth VL-WO18D natural gas log kit must be installed in a solid-fuel burning fireplace with a working flue and constructed of noncombustible material. It requires a vertical venting system with a minimum height as specified in the manual. Therefore, it cannot be installed with a horizontal vent through the back of a masonry chimney.
