CAUTION - FOR YOUR SAFETY
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
This is a gas-fire appliance. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air For Combustion and
Ventilation of page 7 of this manual.
This appliance is convertible for use with propane/LP gas by using the MANUAL ON/OFF
VALVE/SAFETY PILOT KIT (see ACCESSORIES on page 18).
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-877-447-4768, 8:30 a.m. – 4:30 p.m., CST, Monday – Friday or
email us at customerservice@ghpgroupinc.com.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
VL-WO18D / VL-WO24D / VL-WO30D
VL-AA18D / VL-AA24D / VL-AA30D
VL-NO18D / VL-NO24D / VL-NO30D
VL-SA18D / VL-SA24D / VL-SA30D
VL-CA18D / VL-CA24D / VL-CA30D
0418GL012S
1
VENTED NATURAL
GAS LOGS
MODELS
Complies with ANSI Z21.84-
2012, Standard for Manually
lighted, Natural Gas Decorative
Gas Appliances for Installation in
Solid-Fuel Burning Fireplaces.
Complies with ANSI Z21.60-
2012, Standard for Decorative
Gas Appliances for Installation
in Solid-Fuel Burning Fireplaces
when the LP Conversion Kit
(SPK100) is installed by a
qualified technician.
80-10-232 - 2018-08-21
Advertisement
Related Manuals for pleasant hearth VL-WO18D
Summary of Contents for pleasant hearth VL-WO18D
- Page 1 VENTED NATURAL GAS LOGS MODELS VL-WO18D / VL-WO24D / VL-WO30D VL-AA18D / VL-AA24D / VL-AA30D VL-NO18D / VL-NO24D / VL-NO30D VL-SA18D / VL-SA24D / VL-SA30D VL-CA18D / VL-CA24D / VL-CA30D Complies with ANSI Z21.84- 2012, Standard for Manually lighted, Natural Gas Decorative Gas Appliances for Installation in Solid-Fuel Burning Fireplaces.
- Page 3 The charts indicate technical information regarding the installation of your gas log set. Please make sure that all of the specifications shown are applicable before installation is attempted. The fireplace must include a working flue and venting system with the minimum openings shown as below. VL-WO18D VL-WO24D VL-WO30D VL-AA18D...
- Page 4 SAFETY INFORMATION IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this log set. Improper use of this log set can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. Only a qualified installer, service agent, or local gas supplier may install and service this product.
- Page 5 SAFETY INFORMATION 1. This appliance is only for use with the type of gas indicated on the rating plate. 2. Do not place propane/LP supply tank(s) inside any structure. Locate propane/LP supply tank(s) outdoors. 3. If you smell gas • shut off gas supply •...
- Page 6 PRODUCT IDENTIFICATION Cover Plate* Log Risers Pilot Bracket Screw (4) 8X3/8PPHTS-B Burner Manifold Burner Clamp* Grate Burner Pan Burner Inlet *Uses (4) 8X3/8PPHTS-B Screws...
- Page 7 PRODUCT FEATURES The State of Massachusetts requires that the chimney flue damper, when used with decorative gas log sets, be welded open or completely removed. In the State of Massachusetts, this appliance must be installed by a licensed plumber or gasfitter. In the State of Massachusetts the gas cock must be a T-handle type.
- Page 8 ASSEMBLING LOGS VL-WO18D/VL-WO24D/VL-WO30D/VL-SA18D/VL-SA24D/VL-SA30D WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this log set may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in contact with any log.
- Page 9 ASSEMBLING LOGS VL-AA18D/VL-NO18D/VL-CA18D WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this log set may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in contact with any log.
- Page 10 ASSEMBLING LOGS VL-AA24D/VL-AA30D/VL-NO24D/VL-NO30D/VL-CA24D/VL-CA30D WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this log set may result in property damage or personal injury. CAUTION: After installation and periodically thereafter, check to ensure that no yellow flame comes in contact with any log.
