  • Page 1 Aruba AP-60/61 Access Point Installation Guide...
  • Page 2 VPN client devices constitutes complete acceptance of liability by that individual or corporation for this action and indemnifies, in full, Aruba Networks, Inc. from any and all legal actions that might be taken against it with respect to infringement of copyright on behalf of those vendors.

  • Page 3: Table Of Contents

    ....... . The Aruba AP Setup Process AP Deployment......... .
  • Page 4 ........Aruba AP-60 Access Point ........

  • Page 5: Introduction

    Introduction The Aruba AP-60/61 is part of a comprehensive wireless network solution. The device works in conjunction with the Aruba Mobility Controller and can act as a wireless access point or air monitor. As a wireless Access Point (AP), the Aruba AP-60/61 provides transparent, secure, high-speed data communications between wireless network devices (fixed, portable, or mobile computers with IEEE 802.11a or IEEE 802.11b/g...

  • Page 6: Front View

    Introduction Chapter 1 Front View Aruba AP-60/61 Front View IGURE Antenna fixtures for Wireless Communications Depending on the model, the AP will have one of the following: Aruba AP-60/61 0510160-03 Installation Guide April 2008...
  • Page 7 (not included). For details, see “Aruba AP-60 Detachable Antennas” page 8. (The AP-60 requires that both connectors be used in ArubaOS 2.2 releases or lower. Single antenna operation is supported with ArubaOS 2.3 or higher.) When facing the AP-60 as shown in...
  • Page 8 DC Power Socket This socket is used to connect the optional AC power adapter (not included). If POE is being used to supply power to the Aruba AP-60/61, the power adapter is not necessary. Aruba AP-60/61...

  • Page 9: Back View

    Introduction Chapter 1 Back View Aruba AP-60/61 Back View IGURE Mounting Slots The keyhole-shaped slots on the back of the chassis are used for mounting the Aruba AP-60/61. Air Vents These vents promote proper air circulation for cooling the device. Do not allow these vents to be obstructed by mounting equipment, network cables, or any other material.

  • Page 10: The Aruba Ap Setup Process

    Introduction Chapter 1 Fold-Out Stand This fold-out stand allows the Aruba AP-60/61 to be stood upright on a table or shelf. Kensington Security Slot This slot is compatible with a Kensington MicroSaver Security Cable (not included) which can be used to prevent the unauthorized removal of the Aruba AP-60/61 from its installed location.

  • Page 11: Ap Deployment

    5.150 to 5.250 MHz are blocked.) Select a location as close as possible to the center of the intended coverage area. If necessary, use the Aruba RF Plan site survey tool to determine the optimum locations for your access points and air monitors.

  • Page 12: Aruba Ap-60 Detachable Antennas

    AP Deployment Chapter 2 The Aruba AP-60/61 can be mounted on a wall or suspended from above (not shown) using one of the optional mounting kits (dimensions vary) in the following ways: Aruba AP-60/61 Mounting Options IGURE For dimensions, see Appendix 4, “Product...
  • Page 13 AP Deployment Chapter 2 FCC-Approved Detachable Antennas Table 3-1 lists the antennas that are approved for use with the Aruba AP-60. FCC-Approved Detachable Antennas ABLE Gain Aruba Part # Description Manufacturer Man. Part # MULTI-BAND ANTENNA AP-ANT-1 Tri-Band, Nearson T614AH-2.4 High-Gain, 5/5.X-S...
  • Page 14 Cylindrical (Indoor / Outdoor) with RP-SMA Connector AP-ANT-11 Down-Tilt, Cushcraft SQ5153WP3 Omni-Directional 6RSM Patch Antenna (Indoor) with RP-SMA Connector AP-ANT-12 High-Gain, Cushcraft S52514WP3 Directional Patch 6RSM Antenna (Indoor / Outdoor) with RP-SMA Connector Aruba AP-60/61 0510160-03 Installation Guide April 2008...

  • Page 15: Free-Standing Placement

    AP Deployment Chapter 2 Free-Standing Placement To place the Aruba AP-60/61 indoors on a flat table or shelf: Flip open the stand located on the back of the Aruba AP-60/61: Aruba AP-60/61Fold-Out Stand IGURE Place the device on a sturdy table or shelf.

  • Page 16: Using The Built-In Mounting Slots

    Chapter 2 Using the Built-In Mounting Slots The keyhole-shaped slots on the back of the Aruba AP-60/61 can be used to attach the device upright to an indoor wall or shelf. Do not use the mounting slots to hang the Aruba...

  • Page 17: Using The Optional Mounting Kits

    14). Using the Optional Mounting Kits Use the optional mounting kit to attach the Aruba AP-60/61 to a wall, shelf, or ceiling. For installation, see the Aruba AP-60/61 Mounting Kit Installation Notes (P/N 0500037-01) provided with each kit. Aruba AP-60/61...

  • Page 18: Connecting Required Cables

    The maximum length for FE cables is 100 meters (325 feet). When the Aruba AP-60/61 is installed in an air-handling space, such as above suspended ceilings, as described in National Electrical Code (2002) Article 300.22(C), and Canadian Electrical Code, Sections 2-128, 12-010(3) and 12-100,...

  • Page 19: Connecting Cables & Power

    If local regulations and practices permit, connect the optional AC power adapter (not included) to the DC power socket on the Aruba AP-60/61 and plug it into an appropriate power outlet. To prevent personal injury or damage to equipment,...

  • Page 20: Selecting An Antenna

    For releases 2.3 and higher, you can provision the antenna selection from the Mobility Controller. Maintenance The AP-60 and AP-61 require no maintenance beyond keeping the AP clean and dust free. To clean the Aruba AP-60/61, use a static-free, dry cloth. Aruba recommends that these units be inspected annually for damage, dust buildup, and to verify that all connections are secure.

  • Page 21: Port Specifications

    Port Specifications FE Port The 10/100 Mbps Ethernet (FE) port is located on the right-hand side of the Aruba AP-60/61 and has an RJ-45 female connector. The port pin-outs are shown in Figure B-1: Aruba 60/61 RJ-45 Female 10/100 Mbps Ethernet...

  • Page 22: Serial Breakout Adapter

    Serial Breakout Adapter The optional serial breakout adapter is used to separate the serial communications lines from the Aruba AP-60/61 FE+SPOE port. This allows the administrator to connect a local serial console directly to the AP and access the apboot prompt for manual provisioning.

  • Page 23: To Ap" Specifications

    Port Specifications Chapter B “To AP” Specifications The RJ-45 connector labeled “To AP” attaches to the Aruba AP-60/61 FE port either directly (if the AP is physically available) or indirectly (if the AP is already deployed). When connecting indirectly, use a straight-through FE coupler to attach the “To AP”...
  • Page 24 Port Specifications Chapter B The Aruba AP-60/61 and serial breakout adapter are plenum rated. When is installed in an air-handling space, as described in NEC (2002) Article 300.22(C), the connecting FE cable should be suitable under NEC Article 800.50 and marked accordingly for use in plenums and air-handling spaces with regard to smoke propagation, such as CL2-P , CL3-P , MPP or CMP .

  • Page 25: Compliance

    Product Specifications Compliance United States FCC - Class B Aruba AP-60/61...

  • Page 26: Canada

    GHz. Antennas not included in this list or having a gain greater than 15.0 dBi for 2.4 GHz and 14.0 dBi for 5 GHz are strictly prohibited for use with this device. The required antenna impedance is 50 Ohms. Aruba AP-60/61...

  • Page 27: Japan

    Section 300-22(C) of the National Electrical Code, and Sections 2-128, 12-010(3) and 12-100 of the Canadian Electrical Code, Part 1, CSA C22.1. Aruba AP-60/61 Installation Guide...
  • Page 28 Consult the manufacturer or field service technician for help. Aruba Networks provides a multi-language document containing country specific restrictions, additional safety and regulatory information for the enclosed Access Point. You may find this reference on our website at: www.arubanetworks.com/safety_addendum...

  • Page 29: Certifications

    UL Listed (Canadian Electrical Code/CSA 22.2 No. 60950) EN60950 / IEC60950 National Electrical Code Section 300-22(C) Canadian Electrical Code, Part 1, CSA C22.1 Sections 2-128, 12-010(3), and 12-100 IEC 60601-1:1988 and Amendments 1 and 2 EN 60601-1-1:2001 UL 2043 Aruba AP-60/61 Installation Guide...

  • Page 30: Product Label

    Product Specifications Chapter C Product Label The product label is affixed to the chassis of the Aruba AP 60/61 The symbols on the label are explained in this chapter. Product Features Wireless dual-band transceiver Varied antenna options: The Aruba AP-60 has dual Reverse Polarity SMA (RP-SMA) antenna connectors that accept a variety of high-gain detachable antennas (not included).

  • Page 31: Power Over Ethernet

    Power Over Ethernet The Aruba AP-60/61 supports the IEEE 802.3af standard for Power Over Ethernet (POE). With this feature, the Aruba AP-60/61 can accept electrical power from a compatible POE-capable device (such as the Aruba 5000 (with Line Card LC-5000-24FE-2GE-SPOE), Aruba 2400, or Aruba 800) directly over the FE cable.

  • Page 32: Aruba Ap-60 Access Point

    Serial breakout adapter for direct access to the AP console Mounting kit (modular cradle for walls and suspended ceilings) Check with your Aruba sales representative for the availability of optional items. The following specifications apply to the Aruba AP-60 and Aruba AP-61 Access Points. Aruba AP-60 Access Point...
  • Page 33 Product Specifications Chapter C AP-60 802.11 Specifications ABLE Description 802.11a 802.11b 802.11g Antenna Dual, diversity supporting Reverse Polarity-SMA (RP-SMA) detachable antenna interfaces suitable for acceptance of single-band or tri-band 802.11a/b/g detachable antennas of various pattern types and gain. For information on...
  • Page 34 Product Specifications Chapter C AP-60 802.11 Specifications (Continued) ABLE Description 802.11a 802.11b 802.11g Operating US & Can- US & Canada: US & Canada: ada: 8 Channels ETSI: 13 ETSI: 13 ETSI: 13 Japan: 5 Japan: 13 Japan: 13 Complete Complete country...
  • Page 35 48 VDC / 200 mA Power Over Ethernet (802.3af compliant) Auto-sensing externally supplied AC power or Power Over Ethernet Output Power 100 mW maximum (or lower as configured on the Aruba Mobility Controller to comply with local regulatory requirements) Power 10 W maximum Consumption Operating 0 ºC to 50 ºC (32 ºF to 122 ºF) AP...
  • Page 36 Product Specifications Chapter C AP-60 Characteristics (Continued) ABLE Description Humidity 5 to 95%, non-condensing AP 15 to 85% RH AC Mains Power Adapter Kit 5 to 90% RH Storage Humidity AC Mains Power Adapter Kit Altitude 3,048 m (10,000 feet) maximum Standards Ethernet IEEE 802.3 / IEEE 802.3u...

  • Page 37: Aruba Ap-61 Access Point

    Product Specifications Chapter C Aruba AP-61 Access Point AP-61 IGURE Aruba AP-60/61 Installation Guide...
  • Page 38 16-QAM, QPSK QPSK, 16-QAM, 64-QAM 64-QAM Transmit Configurable by Configurable by Configurable by Power system system system administrator/ administrator/pro administrator professional fessional installer installer Media Access CSMA/CA with CSMA/CA with CSMA/CA with Control Aruba AP-60/61 0510160-03 Installation Guide April 2008...
  • Page 39 Network Wide AP Management via: WEB GUI SNMPv3 Access Point Profiles, Management by: Geographical Location BSSID Radio Type Encryption 40bit / 64bit / 128bit / 152bit WEP , TKIP , AES Support (AP and Mobility Controller) Aruba AP-60/61 Installation Guide...
  • Page 40 48 VDC / 200 mA Power Over Ethernet (802.3af compliant) Auto-sensing externally supplied AC power or Power Over Ethernet Output Power 100 mW maximum (or lower as configured on the Aruba Mobility Controller to comply with local regulatory requirements) Power 10W maximum Consumption Aruba AP-60/61...

  • Page 41: Related Documents

    (such as detachable antennas, mounting kits, and cables), which may vary Related Documents The following items are part of the complete documentation for the Aruba system: Aruba Quick Start Guide Aruba AP 60/61 Wireless Access Point Installation Guide (this document)

  • Page 42: Contacting Aruba Networks

    Wireless Security Incident http://www.arubanetworks.com/support Response Team (WSIRT) /wsirt Support Email support@arubanetworks.com WSIRT Email wsirt@arubanetworks.com Please email details of any security problem found in an Aruba product. Telephone Numbers Aruba Corporate +1 (408) 227-4500 +1 (408) 227-4550 Support United States 800-WI-FI-LAN (800-943-4526) France...

  • Page 43: China Rohs

    WEEE Directive (2002/96/EC). For more information on WEEE, refer to: http://www.dti.gov.uk/sustainability/weee/ China RoHS Aruba products also comply with China environmental declaration requirements and are labeled with the “EFUP 50” label shown at the left. Hazardous Materials Declaration Hazardous Substances) Chromium VI...
  • Page 44 Product Specifications Chapter C Aruba AP-60/61 0510160-03 Installation Guide April 2008...
