Aruba AP-65-MNT Installation Notes

AP 65 Mounting Kit
Installation Notes
These Installation Notes provide instructions for mounting the AP 65 Wireless
Access Point using the AP 65 mounting kit (part number AP-65-MNT).
The AP 65 mounting kit can be used to securely attach the AP 65 Wireless
Access Point to a wall, ceiling, office cubicle, or most flat surfaces, as well as
provide additional anti-theft security protection.
Additionally, the AP 65 may also be mounted directly (without the use of this kit)
to a ceiling tile / rail system using the snap-in 15/16" ceiling tile rail guide slots
integrated on the rear of the AP 65 enclosure.
Before installing the AP 65, please read the AP 65 Wireless Access Point Quick
Installation Guide as well as these Installation Notes to determine what tools and
accessories (if any) are required and are not included in the AP-65-MNT kit.

Package Contents

The following components are included in your AP-65-MNT kit:
Wall mounting cradle
Security T-bar
Cradle mounting screws (6-32 x 1" Phillips Flat Head) (2)
Security T-bar mounting screw (6-32 x 1" Torx Head) (1)
Inform your supplier if there are any incorrect, missing or damaged parts. If
possible, retain the original packing materials and use them to repack the product
in case there is a need to return it.
AP-65-MNT
Installation Notes
1
