SPECIFICATIONS (General)

Item
Engine Mfg.
Fuel Mix Ratio
Spark Plug
Fuel Capacity
Weight
Width
Height
Length
Chute Rotation
Chute Throat Diameter
Impeller Diameter
Rotor Drive Reduction

TORQUE SPECIFICATIONS

Description / Where Used
Engine Pulley
Square Head Set Screw
Allen Head Set Screw
Nut On Recoil Support
Engine Mounting Screws
Rotor Pulley Capscrew
Brake Arm Shoulder Bolt
Plastite Screws
Belt Cover Top Screw (has an O-ring on it)

LUBRICATION

Engine - "Fuel and Oil Requirements" on page 1 - 6.
Engine crankshaft pulley. Apply anti-seize compound to shaft before installation of pulley.
Apply a light coat of #2 general purpose grease to the brake arm, shoulder bolt, and washers.
Snow Commander Service Manual
Description
The Toro Company 141cc E series (R tek)
50:1
NGK
BPMR4A or equivalent
1.2 US quart (1.1 l)
113 lbs. (51.4 kg) (recoil start)
115 lbs. (52.3 kg) (electric start)
24.3" (61.7 cm)
40.4" (102.6 cm) (highest point)
51.3" (130.3 cm)
210 degrees
6.2" (15.7 cm)
10" (25.4 cm)
3.95:1
In-Lbs
120 - 150
60 - 80
90 - 120
170 - 220
100
170 - 250
Tighten securely, but do not deform the plastic
Tighten to compress O-ring to .08" - .11" (2.03 - 2.79mm) thick.
MAINTENANCE
Torque Value
N·cm
1355 - 1694
678 - 904
1016 - 1355
1920 - 2483
1125
1920 - 2824
(Must pivot freely)
7 - 11
