22 M32C DIGITAL RACK MIXER User Manual
Modulation Delay
Modulation Delay combines three of the most used time modulation eff ects
into one easy-to-operate unit, featuring true-stereo delay with a lush chorus,
topped off with three reverb models to choose from.
The BALANCE knob adjusts ratio of delay to reverb. The processor chain can
operate as serial where one eff ect fl ows into the next, or parallel where
each eff ect is applied to the source signal independently. TIME, FEED (back),
LOW and HI CUT all aff ect the delay. Modulation DEPTH and RATE are adjustable.
Three types of reverb are available – ambience, club and hall – with adjustable
DECAY and HI DAMP.
Dimensional Chorus
The Dimensional Chorus off ers the most user-friendly and classic sounds,
best described as "space" and "dimensional". The 4 MODE buttons can
be engaged individually or simultaneously for light chorus or very thick,
exaggerated modulation. Adjust the 1st encoder to select mono or stereo
operation, and press the encoder to engage or bypass the eff ect.
Leisure Compressor
This model of a popular tube-based optical compressor provides natural and
eff ortlessly musical compression, inspired by the Teletronix LA-2A. Simply adjust
the input GAIN and PEAK REDUCTION knob to dial in the amount of desired
compression, then adjust the OUTPUT GAIN knob for the desired output level.
The COMP setting will give a gentle compression ratio, whereas the LIMIT setting
results in a higher ratio.
Ultimo Compressor
The Ultimo Compressor is based on the Urei 1176LN Limiting Amplifi er and
authentically captures the smooth character of the original class-A output stage
in its FET's legendary fast attack.
Start with the INPUT and OUTPUT knobs at the -24 position for unity gain and set
the ATTACK and RELEASE knobs fully counterclockwise. Select the compression
ratio, then raise the ATTACK knob to lightly compress the signal. Increase the ratio
for heavier compression and experiment with ATTACK, RELEASE and INPUT levels
to achieve your desired result. Compensate for overall level reduction with the
OUTPUT knob.
Fair Compressor
This model of a Fairchild 670 delivers some of the fi nest colorations in compressor
history. Two small trim VRs, BIAS and BALANCE, preset the control side chain
action, a 6-step knob determines the timing, and the 2 large INPUT GAIN
and THRESHOLD knobs adjust the levels. There are models available for dual,
stereo-linked, or mid/side operation.
Combinator
The Combinator emulates famous broadcasting and mastering compressors,
utilizing automatic parameter control that produces very eff ective yet
"inaudible" results.
The MIX knob allows some of the source signal to pass through unaff ected.
ATTACK and RELEASE have dedicated controls, and an Auto Release function can
be engaged. Global X-OVER, RATIO, THRESH(old) and GAIN controls are available.
Engage the Spectral Balance Control (SBC) to allow automatic gain balancing
between the audio bands and its SPEED control to determine how aggressively
the eff ect works. The meters can also display band reduction or the SBC gain
balance, and can display peak outputs. The THRESH(old) and GAIN can be
adjusted for each band independently.
XTEC EQ1
Inspired by the Pultec EQP-1a, this passive equalizer is a very powerful tool for
sound enhancement.
GAIN allows compensation for level changes resulting from frequency
adjustments. Press the 1st encoder to engage or disengage the eff ect. Select the
low frequency with the LO FREQ knob, adjust the amount of enhancement with
the LO BOOST, then adjust the attack with the LO ATT. The same adjustments are
available for the high frequencies.
XTEC EQ5
This Pultec emulation is a classic analog passive equalizer that off ers very
warm and musical frequency sculpting. Simply select the center frequency for
the 3 bands, then adjust how much low and high you want to boost and how
much midrange you want to cut.
23 M32C DIGITAL RACK MIXER User Manual
Sub Octaver
The Sub Octaver provides two channels of sub harmonics generation, one or even
two octaves below the input signal.
Adjust the DIRECT knob to blend the "dry" signal with the lower octaves. Use the
RANGE switch to optimize the tracking by selecting the frequency range of the
input signal. The OCT1 and OCT2 knobs adjust how much 1 octave down and
2 octaves down content is included.
Edison EX1
The EDISON EX1+ is a remarkably eff ective tool that allows manipulation of the
stereo fi eld. The eff ect off ers stereo and mid/side input and output and a phase
correlation meter. Exaggerate the stereo fi eld with the ST SPREAD knob and
adjust the ratio of mono to stereo content with the BALANCE knob. The CENTER
DIST knob allows the mono content to be panned. Compensate for level changes
with the OUTPUT GAIN knob.
Sound Maximizer
Inspired by the Sonic Maximizer 482i, this eff ect restores natural brilliance and
clarity to any audio signal by adjusting the phase and amplitude integrity to
reveal more of the natural texture of the sound. LO CONTOUR adjusts the level
of phase-corrected low frequencies and PROCESS adjusts the level of phase-
corrected high frequencies. GAIN compensates for level changes caused by
the eff ect.
