- Page 1 OPTI TRI WHITE II™ user manual ...
- Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.
-
Page 3: Table Of Contents
C O N T E N T S General Information Warranty Safety Instructions General Guidelines Fixture Overview Fixture Installation Understanding DMX Fixture Menu DMX Channel Functions And Values Cleaning and Maintenance Technical Specifications Optional Accessories OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 4: General Information
G E N E R A L I N F O R M A T I O N INTRODUCTION Congratulations, you have just purchased one of the most innovative and reliable lighting fixtures on the market today! The OPTI TRI WHITE II ™ has been designed to perform reliably for years when the guidelines in this booklet are followed. - Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...
-
Page 6: Warranty
No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss and/or or damage to any such accessories, nor for the safe return thereof. -
Page 7: Safety Instructions
Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If the power cord is damaged, replace it immediately with a new one of similar power rating. OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 8: General Guidelines
Use the original packaging and materials to transport the fixture in for service. DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power and allow approximately 15 minutes for the fixture to cool down before replacing or serving. OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 9: Fixture Overview
F I X T U R E O V E R V I E W FUSE 3pin DMX OUT powerCON OUT powerCON IN 3pin DMX IN Safety Cable Attachment Point 5pin DMX IN DOWN Button UP Button MODE Button LCD Menu Display 5pin DMX OUT OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 10: Fixture Installation
M10 screw fitted through the center hole of the Dual Yoke / Floor Stand. SECURING Regardless of the rigging option you choose for your OPTI TRI WHITE II ™ always be sure to secure your fixture with a safety cable. - Page 11 S A F E T Y C A B L E Always use a Safety Cable whenever installing this fixture in a suspended environment to ensure the fixture will not drop if the clamp fails. OPTI TRI WHITE II™ User Manual Ver. 1...
-
Page 12: Understanding Dmx
1 to that fixture no matter where it is located in the DMX chain. The OPTI TRI WHITE II™ can be controlled via DMX-512 protocol and the DMX address is set via the control menu. - Page 13 Connect the provided XLR cable to the female XLR output of your controller and the other side to the male XLR input of the OPTI TRI WHITE II™ The diagram below illustrates a typical DMX-512 connection when the fixture is in the 8 Channel Mode.
- Page 14 5pin XLR connectors in to a 3pin line a cable adaptor must be used, these adaptors are readily available at most electric stores. The following chart details a proper cable conversion. OPTI TRI WHITE II™ User Manual Ver. 1...
- Page 15 In the case of the OPTI TRI WHITE II™, when in the 8 Channel Mode you should set the starting DMX address of the first unit to 1, the second unit to 9 (1 + 8), the third unit to 17 (9 + 8), and so on.
-
Page 16: Fixture Menu
F I X T U R E M E N U ON-BOARD SYSTEM MENU The OPTI TRI WHITE II™ comes with an easy to navigate system menu. The next sections will cover how to access each menu function. LCD CONTROL PANEL DISPLAY... - Page 17 Speed = 1 (Slowest) - 16 (Fastest) Set FADE speed manually ColRandm Speed = 1 (Slowest) - 20 (Fastest) Set RANDOM STROBE speed manually ColPulse Speed = 1 (Slowest) - 20 (Fastest) Set PULSE SROBE speed manually OPTI TRI WHITE II™ User Manual Ver. 1...
- Page 18 . e l a t i o n l i g h t i n g . c o m DIMMING CURVES The DimCurve menu allows you to select one of the following preset dimming curves: Standard, Stage, TV, Architec, or Theatre. (See diagram below for more details) Dimmer OPTI TRI WHITE II™ User Manual Ver. 1...
-
Page 19: Dmx Channel Functions And Values
160-191 Random STROBE 192-223 224-255 Random PULSE STROBE DIMMER INTENSITY 0-255 Intensity 0 to 100% DIMMING CURVE MODES 0-19 STANDARD 20-39 STAGE 40-59 60-79 ARCHITECTURAL 80-99 THEATRE 100-255 Default to Unit Setting OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 20: Cleaning And Maintenance
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer. -
Page 21: Technical Specifications
Multiple Unit Power Linking: 5 units @120V / 10 units @230V APPROVALS / RATINGS CE | cETLus | IP20 Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 22: Photometric Data
. e l a t i o n l i g h t i n g . c o m PHOTOMETRIC DATA DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. OPTI TRI WHITE II™ User Manual Ver. 1... -
Page 23: Optional Accessories
Wireless DMX Transmitter EWDMXR Wireless DMX Receiver PLC3 3' (1m) powerCON PRO Link Cable AC3PDMX5PRO 5 ft. (1.5m) 3pin PRO DMX Cable AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable Additional Cable Lengths Available OPTI TRI WHITE II™ User Manual Ver. 1...
