Keyboard LED Controls for Model B Computers

Note that Model B computers feature a series of additional LEDs, some of which can be configured by the keyboard
controls and keyboard backlight application outlined on the following pages. Note the following keyboard LED features
unique to Model B computers.
Main LED Switch (Toggle all LEDs On/Off - except
Fn +
Turn Volume Bar LED On/Off
Fn +
• Use the Main LED switch to turn on/off all LEDs
• Use the Fn + key combination to turn on/off the Vol-
ume Bar LED
• Use the keyboard LED controls and backlight application
to configure colors and effects for the Touchpad, keyboard,
power button and top case logo LEDs
• Note that the Volume Bar LED will not oscillate if the vol-
ume level is set lower than 20%
12
Keyboard LED Controls for Model B Computers
the Power Button LED)
Table 5 - Keyboard LED Controls for Model B Computers
Top Case Logo LED (Rear)
Volume Bar
LED
Keyboard
LED
Touchpad LED
Rear Left &
Right LEDs
Power Button
LED
