- Page 1 INSTRUCTION MANUAL BUILT-IN FRIDGE FREEZER CIFF7012...
-
Page 2: Table Of Contents
Contents Safety Warnings ............................. 3 Unpacking ..............................5 Location......................................6 Reversing the Door Swing ................................. 7 Installing the Unit into Cabinetry ............................9 Mounting the Cabinet Door ..............................10 Securing the Unit ..................................11 Cleaning Before Use ...................................12 Before Using Your Unit ................................12 Product Overview ............................ -
Page 3: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. - Page 4 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 5: Unpacking
Thank you for purchasing your new Currys Fridge Freezer. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues. -
Page 6: Location
INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 38°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. -
Page 7: Reversing The Door Swing
INSTALLATION Reversing the Door Swing Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner • Ensure the unit is unplugged and empty. • To take the door off it is necessary to tilt the unit backwards. You should rest the unit on something solid, e.g. - Page 8 INSTALLATION 4. Re-fit the middle hinge on the left side. Then clip on the bracket cover (to the right hand side) and test that the cover does not interfere with the opening and closing of the door. Ensure the freezer door is aligned horizontally and vertically, so that the seals are closed on all sides before finally tightening the middle hinge.
-
Page 9: Installing The Unit Into Cabinetry
INSTALLATION Installing the Unit into Cabinetry 1. Ensure the size of the cabinetry chosen is adequate for the unit. ≥38mm 560mm ≥550mm 50mm 540mm 540mm 30mm 1045mm min. 200cm 14mm 628mm 55mm 2. Slowly and carefully push the unit into the cabinetry. -
Page 10: Mounting The Cabinet Door
INSTALLATION Mounting the Cabinet Door 1. Fit the door guides to the unit doors. Insert the sliders into the guides, then fully open the unit’s upper door. Guide 2. Position the slider 20mm from the aesthetic door’s edge. Mark the screw holes. -
Page 11: Securing The Unit
INSTALLATION 7. Secure the door guides to the unit door. Then fit the door guide covers on to the door guides. 8. Repeat Steps (6) to (7) for the unit’s lower door. Slider After fitting the aesthetic doors to the unit doors, ensure the doors open and Screws close without obstruction. -
Page 12: Cleaning Before Use
INSTALLATION Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the shelves, drawers and salad bin. Clean the exterior of the unit with a damp cloth. If you require more information refer to the Cleaning section. -
Page 13: Product Overview
Product Overview Thermostat and Bulb Fridge Glass Shelves Fridge Door Shelves Salad Bin Cover Shelf Salad Bin Freezer Drawers... -
Page 14: Operation
Operation Switching On Your Unit 1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are seven settings, of which position 7 is the coldest and position 0 turns the unit off. -
Page 15: Tips For Keeping Food In The Unit
Tips for Keeping Food in the Unit • Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid bacterial transfer. Keep raw meats/fishes in a container which is large enough to collect juices and cover it properly. Place the container on the lowest shelf. •... -
Page 16: Defrosting Frozen Food
Defrosting Frozen Food 1. Take the frozen food out from the freezer compartment and uncover the frozen food. Let it defrost at room temperature. Don’t forget that defrosting in a warm area encourages the growth of bacteria and low temperature cooking may not destroy dangerous bacteria. 2. -
Page 17: Cleaning
Cleaning Defrosting Frost may build up in the freezer compartment after the unit has been used for a period of time. Scrape away the frost using a plastic scraper (not included). Do not use a metal or sharp instrument to scrape away the frost, nor should you use any electrical appliances to aid defrosting. -
Page 18: Maintenance
Maintenance Changing the Internal Light The internal light is an LED panel that cannot be changed by the user. Please contact a qualified service agent. Servicing The unit should be serviced by an authorised engineer and only genuine spare parts should be used. -
Page 19: Specifications
Specifications Model CIFF7012 Appliance Category Category 7 (Refrigerator – Freezer) Overall Dimension (W x D x H) 540 x 540 x 1772 mm Fresh Food Storage Compartment 188L Volume Frozen Food Storage Volume Defrosting Type Manual Defrost Climate Class This appliance is intended to be used at an ambient temperature between 16°C and 38°C. - Page 20 For more information about where you can drop off your waste for recycling, please contact your local authority, or where you purchased your product. DSG Retail Ltd. (co. no. 504877) Maylands Avenue, Hemel Hempstead, Herts., HP2 7TG, UK. IB-CIFF7012-140429V2...
