WHAT'S INSIDE
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety and Your Fireplace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
FREE Safety Guard Offer
(Protects Against Burns)
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . 4
L'information de sûreté importante
[EN FRANÇAIS]
Información importante de seguridad
[EN ESPAÑOL]
Manufacturer: Focal Point Fires plc. United Kingdom
This is an unvented gas-fired heater. It uses air
(oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventila-
tion air must be provided. Refer to Combustion
and Ventilation Air section in this manual.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not
prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appli-
ance is not convertible for use with other gases.
WARNING
• HOT GLASS WILL
CAUSE BURNS.
• DO NOT TOUCH GLASS
UNTIL COOLED.
• NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNING: If the information in these instructions is
not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neigh-
bor's phone. Follow the gas supplier's instruc-
tions.
• If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
P/N 850056M Rev. C 04/2012
. . . . . . . . . . . . . 2
. . . . . . . . . . . . 3–4
. . . . . . . . . . . . 3–4
AVERTISSEMENT
/
• UNE SURFACE VITRÉE CHAUDE PEUT
CAUSER DES BRÛLURES.
• LAISSER REFROIDIR LA SURFACE
VITRÉE AVANT D'Y TOUCHER.
• NE PERMETTEZ JAMAIS À UN ENFANT
DE TOUCHER LA SURFACE VITRÉE.
INSTALLATION AND OPERATION INSTRUCTIONS
Catalytic Vent-Free Fireplaces
Elite
®
CVF Models
MODELS
Elite CVF - NG and Elite CVF - LP
Report No. 317-F-08-5 (NG) & 317-F-09-5 (LP)
INSTALLER: Leave this manual
with the appliance.
Wait...
DON'T
THROW
IT AWAY!
This manual contains
important operating
and safety
information.
CONSOMMATEUR : Conservez cette
notice pour consultation ultérieure.
AVERTISSEMENT: Assurez-vous de bien suivre les instruc-
tions données dans cette notice pour réduire au minimum
le risque d'incindie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
- Ne pas entreposer ni utilizer d'essence ni d'autres vapeurs
ou liquides inflammables dans le voisinage de cet appareil
ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous trouvez.
• Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz, appelez
le service des incindies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
Portland
US
CONSUMER: Retain this manual
for future reference.
INSTALLATEUR : Laissez cette
notice avec l'appareil.
AVISO
/
• EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.
• USTED DEBE NUNCA
TOCAR EL VIDRIO CALIENTE.
• LOS NIÑOS DEBEN NUNCA
TOCAR EL VIDRIO.
Advertisement
Table of Contents
Related Manuals for Lennox Elite CVF - NG
Summary of Contents for Lennox Elite CVF - NG
- Page 1 WHAT'S INSIDE Elite CVF - NG and Elite CVF - LP Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety and Your Fireplace .
-
Page 2: Table Of Contents
To help us keep you up-to-date on product information and offers, please take a few moments to register your product online at www.lennox.com (> Hearth > Owner Resources) . To prevent severe burns and injuries, install a screen or physical barrier to prevent direct contact with the glass . - Page 3 Toutes les parties de votre foyer ¡Todas las partes de la chimenea Lennox Hearth Products deviennent Lennox Hearth Products se ponen EXTRÊMEMENT CHAUDES ! MUY CALIENTES! Afin d'éviter de vous brûler gravement ou de Instale una malla o barrera física para evitar vous blesser, installez une grille ou une barrière...
-
Page 4: Important Safety Information
Important Safety Information L'information de sûreté importante 1. AVERTISSEMENT. Ne pas utiliser l’appareil si le panneau frontal 1. WARNING: Do not operate appliance with the glass front en verre n’est pas en place, est craqué ou brisé. removed, cracked or broken. 2. -
Page 5: Appliance Installation, Service, And
These fireplaces are unvented gas WARNING: Improper installation, appliances. Do not burn wood or other Lennox ® vent-free appliances are adjustment, alteration, service or material in these appliances. designed for use as a supplemental maintenance can cause injury or heater. -
Page 6: General Information
General Information The appliance is designed to fit various types of situations as listed in the installation requirements . WARNING This appliance is factory set for operation on the gas type, and This appliance is equipped for (natural or propane) at the pressure stated on the appliance rating plate . -
Page 7: Packaging List
. Ignition Double Piezo spark Double Piezo spark This Lennox Hearth Products Unvented Gas Room Heater is certified by Spark Gap 1/8” - 3/16” 1/8” - 3/16” OMNI-Test Laboratories, Inc to ANSI Z21 .11 .2 standard . -
Page 8: Combustion And Ventilation Air
Example: COMBUSTION AND VENTILATION AIR Vent-free heater #1 9,000 BTU/Hr Vent-free heater #2 23,000 BTU/Hr Gas appliance #1 35,000 BTU/Hr This heater shall not be installed in a confined space or unusually tight (water heater) construction unless provisions are provided for adequate combustion and Total = 67,000 BTU/Hr ventilation air . -
Page 9: Site Requirements
CLEARANCES TO COMBUSTIBLE MATERIALS SITE REQUIREMENTS Combustible materials are defined as wood, fabrics, or other materials likely to combust if exposed to flame . Generally, any material, which is This appliance is designed to be wall-hung . Do not recess any part of likely to discolor, melt or misshape when exposed to moderate heat, the appliance into the wall . -
Page 10: Preparing The Appliance
To ensure customer safety, be sure to design the installation so that the PREPARING THE APPLIANCE strength of both the wall and any wall fixings used are sufficient . Lennox Hearth Products assumes no responsibility for injuries and damages that IMPORTANT NOTE: All gas piping must be done by a licensed plumber may occur due to improper installation or handling . -
Page 11: Checking The Burner
MOUNTING THE APPLIANCE - continued CONNECTING A GAS LINE NOTE: See Page 21 for gas line entry point dimensions. Before tightening the wall-mounting screws fully, at this stage it is recommended to check the horizontal alignment of the appliance with WARNING a spirit level, as small adjust ments can still be made if necessary . -
Page 12: Checking The Gas Connections
Connect the pressure gauge . CHECKING THE GAS CONNECTIONS Turn on the gas supply and light the heater . Turn the control to the high flame setting and check the pressure . WARNING Never use an open flame to check for leaks. Turn on gas supply and test for gas leaks using a gas leak test solution (also referred to as bubble leak solution) . -
Page 13: Spark Gap
SPARK GAP Front Clamping Disc The gap between the spark electrode and the pilot should be 1/8” to 3/16” to produce a good spark . There should be no need to adjust this (DO NOT ATTEMPT TO ADJUST THE GAP) . If under any circumstances the piezo electric spark fails, the pilot cannot be lit manually . -
Page 14: Servicing
First, remove the front section of the frame (see Fitting The Glass Facia SERVICING section), the glass panel . Detach the burner front cover plate by removal of the four retaining screws . Disconnect the gas connection inside appli- ance . The gas connections to the gas valve can now be released . Undo WARNING the four screws retaining the burner brackets to the base and rear of the firebox . -
Page 15: Catalysts
CATALYSTS TESTING FOR FIREBOX LEAKAGE Appliances that are several years old or have been extensively disman tled WARNING should be checked for soundness . It is important that all the prod ucts of combustion pass through the catalytic convertors at the top of the Do not block the catalysts or the appliance outlet grill. -
Page 16: Lighting Instructions And
LIGHTING INSTRUCTIONS & TURNING OFF APPLIANCE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. • Immediately call your gas supplier from a neighbor’s phone. This appliance has a pilot which must be lit with a piezo Follow the gas supplier’s instructions. -
Page 17: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM CORRECTIVE ACTION Igniter sparks but pilot does not light • No gas to Pilot, check the gas line connections . • Air not fully purged . Purge supply or wait longer . • Spark grounding to metal work, reset gap correctly . •... -
Page 18: Replacement Parts List
FocalPointFires Single 24/07/08 DO 005860/0 Iss-B Lennox P23 Elite CVF fitting template Artwork Size: W605 x H960 REPLACEMENT PARTS - Elite® CVF - NG AND ELITE CVF - LP POSITION SPIRIT LEVEL ALONG THIS EDGE TO LEVEL TEMPLATE BEFORE MARKING OUT WALL COLOQUE EL NIVEL SOBRE ESTE BORDE PARA NIVELAR LA PLANTILLA ANTES DE MARCAR LA PARED 9-3/16”... -
Page 19: Positioning Of Field
POSITIONING OF FIELD REMOVABLE PARTS Outlet Grill Glass Door Removal: Remove the four (4) screws indicated, then lift door off. Main Firebox Assembly Valve Cover Plate Control Knob Spindle Burner Assembly Control Knob Burner Cover Plate As our policy is one of continuous improvement and development, we hope Glass Door Assembly therefore you will understand we must retain the right to amend details and/or specifications without prior notice . -
Page 20: Specifications
SPECIFICATIONS - Elite® CVF Product Reference Information Cat. No. Model Ship. Wt. Ship. Volume H6072 Elite CVF - NG 50 lb. 4.3 cu. ft. H6073 Elite CVF - LP 50 lb. 4.3 cu. ft. 6-1/4” Top View 23-7/8” 9-3/16” 27-3/16”... -
Page 21: Gas Entry Point Dimensions
GAS ENTRY POINT DIMENSIONS TOP VIEW Finished Wall Fireplace Regulator Gas Entry Point REGULATOR GAS ENTRY POINT Model 3/8” 1-3/8” 3-3/8” Elite® CVF (10mm) (35mm) (85mm) Note: The actual dimensions are shown in millimeters. The fractional dimensions are converted from millimeters and are rounded to the nearest 1/16”. -
Page 22: Product Reference Information
Fuel Type c Natural Gas c Propane Gas Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products . Consult your local distributor for fireplace code information .
