P/N 875,021M REV. J 01/2010
Portland
US
Ce manuel d'installation est disponible en francais, simplement
en faire la demande. Numéro de la pièce 875,021CF.
WARNING
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
WARNING: If the information in these instructions is
not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
INSTALLATEUR: Laissez cette notice avec l'appareil.
CONSOMMATEUR: Conservez cette notice pour consul-
tation ultérieure.
Order Parts at: PartsFor.com or 866-607-2787
OTL Report No. 116-F-05-5
Order Parts at: PartsFor.com or 866-607-2787
CARE AND OPERATION INSTRUCTIONS
Direct-Vent
MODELS
Millivolt Models
EDV3530CNM-B
EDV4035CNM-B
EDV4540CPM-B
AVERTISSEMENT
UNE SURFACE VITRÉE CHAUDE PEUT
LAISSER REFROIDIR LA SURFACE
NE PERMETTEZ JAMAIS À UN ENFANT
DE TOUCHER LA SURFACE VITRÉE.
AVERTISSEMENT: Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire
au minimum le risque d'incindie ou d'explosion ou
pour éviter tout dommage matériel, toute blessure
ou la mort.
- Ne pas entreposer ni utilizer d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir
des téléphones se trouvant dans le bâtiment où vous
trouvez.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du fournis-
seur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par
le fournisseur de gaz.
Electronic Models
EDV3530CPM-B
EDV3530CNE-B
EDV4035CPM-B
EDV4035CNE-B
EDV4540CPM-B
EDV4540CNE-B
CAUSER DES BRÛLURES.
VITRÉE AVANT D'Y TOUCHER.
™
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Lennox EDV4540CPM
Summary of Contents for Lennox EDV4540CPM
- Page 1 Portland EDV3530CNM-B EDV3530CPM-B EDV3530CNE-B OTL Report No. 116-F-05-5 EDV4035CNM-B EDV4035CPM-B EDV4035CNE-B EDV4540CPM-B EDV4540CPM-B EDV4540CNE-B Ce manuel d’installation est disponible en francais, simplement en faire la demande. Numéro de la pièce 875,021CF. AVERTISSEMENT WARNING UNE SURFACE VITRÉE CHAUDE PEUT HOT GLASS WILL CAUSER DES BRÛLURES.
-
Page 2: Table Of Contents
CONGRATULATIONS! GENERAL INFORMATION WARNING In selecting this Lennox Hearth Products direct-vent gas appliance you have chosen the finest and most dependable fireplace to be found anywhere. It is a beautiful, prestigious Children and adults should be alternative to a wood burning fireplace. Welcome to a family of tens of thousands of alerted to the hazards of high satisfied Lennox Hearth Products fireplace owners. - Page 3 Order Parts at: PartsFor.com or 866-607-2787 Note: Installation and repair should be Due to high temperatures the appli- WARNING ance should be located out of traffic done by a qualified service person. The and away from furniture and draperies. appliance should be inspected before use Failure to comply with the instal- Locate furniture and window coverings and at least annually by a professional...
- Page 4 Order Parts at: PartsFor.com or 866-607-2787 BTU Input Deration - At higher elevations, the amount of Manifold Gas Supply Pressure BTU fuel value delivered must be reduced by (all models) These fireplaces are designed as supplemental either using gas that has been derated by the gas Fuel # High heaters.
-
Page 5: Operation/Care Of Your Appliance
Order Parts at: PartsFor.com or 866-607-2787 OPERATION AND CARE OF YOUR APPLIANCE WARNING Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals in the house. -
Page 6: Variable Flame Adjustment
Order Parts at: PartsFor.com or 866-607-2787 Variable Flame Height Adjustment ( Millivolt Appliances only) Variable Flame Height Adjustment Inlet Pressure Port Manifold Pressure Port 1. All Millivolt appliances are equipped with a variable gas control valve. Flame height for these models may be adjusted through a range between fixed low and high settings, alternately, while the appliance is in operation. -
Page 7: Attaching Safety In Operation Warnings
3. Si no puede encontrar las etiquetas, sírvase llamar Lennox Hearth Products or your nearest Lennox ment parlée dans la résidence du propriétaire. a Lennox Hearth Products o al distribuidor de Hearth Products dealer to receive additional 3. Si vous ne trouvez pas les étiquettes, veuillez Lennox Hearth Products más cercano para recibir... -
Page 8: Maintenance
Paint is available at your local authorized burner ports are “open.” Remove any carbon periodic inspections and cleanings should be Lennox Hearth Products dealer. Never attempt deposits from the under side of the logs using performed by the homeowner. -
Page 9: Front Glass Enclosure Panel, Removal And Installation
Order Parts at: PartsFor.com or 866-607-2787 Front Glass Enclosure Panel, Removal Locate the two (2) latches at the top of the WARNING control compartment and disengage them from and Installation the door frame bottom vee-flange, pulling down Any safety screen or guard on their handles to open them. -
Page 10: Install Volcanic Stone
Order Parts at: PartsFor.com or 866-607-2787 INSTALL VOLCANIC STONE, GLOWING Glowing Embers EMBERS AND LOGS NOTE: Turn off all electricity to the appliance before you install volcanic stone, embers and logs. DO NOT attempt to install the logs until the appliance installation has been completed, the gas line connected and tested for leaks and the initial burner operation has been checked out. - Page 11 Order Parts at: PartsFor.com or 866-607-2787 EDV3530 LOG PLACEMENT Part Number Description Number Log, Rear 55M06 Log, Diagonal/Left 55M07 Log, Diagonal/Right 55M08 Log, Front/Left 55M09 Log, Top/Right 55M10 Log, Front/Center 55M11 Catalog Number for the entire log set: 55M02 Align The Hole On The Log (5) Over The Locating Pin And Postition The Notch Over The Grate As Shown Align Groove At The Bottom Locating Pins...
- Page 12 Order Parts at: PartsFor.com or 866-607-2787 EDV4035 & EDV4540 LOG PLACEMENT Part Number Description Number Log, Rear 55M12 Log, Diagonal/Left 55M13 Log, Diagonal/Right 55M14 Log, Front/Left 55M15 Log, Top/Right 55M16 Log, Front/Center 55M17 Catalog Number for the entire log set: 55M03 Align The Hole On The Log (5) Over The Locating Pin And Postition The Notch Over The Grate As Shown Align Groove At The Bottom...
-
Page 13: Burner Flame Appearance/Sooting
Order Parts at: PartsFor.com or 866-607-2787 BURNER ADJUSTMENTS (QUALIFIED TECHNICIANS ONLY) Flame Appearance and Sooting Proper flame appearance is a flame which is blue at the base and becomes yellowish-orange in the body of the flame. When the appliance is first lit, the entire flame may be blue and will gradually turn yellowish- orange during the first 15 minutes of operation. -
Page 14: Burner Flame Adjustments
Order Parts at: PartsFor.com or 866-607-2787 BURNER FLAME ADJUSTMENTS MILLIVOLT Hood Igniter Rod Burner Venturi WARNINGS Tube Thermocouple • Air shutter adjustment should Air Shutter only be performed by a quali- Opening fied professional service tech- Decrease 3/8" Min Shutter Increase nician. -
Page 15: Warranty
5. The quantity required. important information about your fireplace. 6. The installation date of the appliance. Please call Lennox Hearth Products for the REPLACEMENT PARTS phone number of your nearest Lennox Hearth If you encounter any problems or have any... -
Page 16: Accessory Components
Order Parts at: PartsFor.com or 866-607-2787 ACCESSORY COMPONENTS Product Reference Information Cat. Model Ship. Ship. Weight Volumn H2000 EDV3530NM 78 lb. 9.09 cu. ft. H2001 EDV3530PM 78 lb. 9.09 cu. ft. H2006 EDV3530NE 78 lb. 9.09 cu. ft. H2002 EDV4035NM 86 lb. - Page 17 Order Parts at: PartsFor.com or 866-607-2787 ACCESSORY COMPONENTS CONTINUED (FBK-200 Models Only) s t i Forced Air Blower Kits -Single Speed 80L84 FBK-100 -Variable Speed with wall-mountable switch 80L85 FBK-200 -Variable Speed with unit-mountable switch 80L86 FBK-250 s t i Forced Air Kit The FBK-100 blower provides constant velocity forced air circulation.
- Page 18 Order Parts at: PartsFor.com or 866-607-2787 ACCESSORY COMPONENTS CONTINUED ON/OFF Wall Switch Kit 85L87 FWSK ON/OFF Wall Switch Kit s t i The ON/OFF wall switch kit may be used to control the operation of the fireplace burner as an alternative to the modesty panel mounted ON-OFF switch.
- Page 19 Order Parts at: PartsFor.com or 866-607-2787 ACCESSORY COMPONENTS CONTINUED Style View Doors - Style View Doors come in 4 beautiful styles. They are easy to install and will not require hardware to attach them to the standard glass door frame. The door includes heavy duty magnet door latches and functional twin-pane doors. Arch Design Square Design Arch Pane Design...
- Page 20 Order Parts at: PartsFor.com or 866-607-2787 ACCESSORY COMPONENTS CONTINUED Style View Doors Continued - Style View Doors also come in a Tall Arch Pane Design. Two distinctive grille kits, the “Crescents” and “Sunrise” design, are also offered seperately. They are easy to install and will not require hardware to attach them to the standard glass door frame. The door includes heavy duty magnet door latches and functional twin-pane doors.
-
Page 21: Maintenance Schedule
Order Parts at: PartsFor.com or 866-607-2787 Maintenance Schedule Annually (Before the onset of the Burning Season) Maintenance Task Accomplishing Person Procedure Inspecting/Cleaning Burner, Logs Qualified Service Technician Inspect valve and ensure it is properly op- and Controls erating. Check piping for leaks. Vacuum the control compartment, fireplace logs and burner area. -
Page 22: Lighting Instructions - Millivolt
Order Parts at: PartsFor.com or 866-607-2787 LIGHTING INSTRUCTIONS – MILLIVOLT GAS VALVE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. - Page 23 Order Parts at: PartsFor.com or 866-607-2787 INSTRUCTIONS D’ALLUMAGE – VANNE GAZ MILLIVOLT POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT : SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. •...
-
Page 24: Lighting Instructions - Electronic
Order Parts at: PartsFor.com or 866-607-2787 LIGHTING INSTRUCTIONS — ELECTRONIC FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A. - Page 25 Order Parts at: PartsFor.com or 866-607-2787 INSTRUCTIONS D’ALLUMAGE — ELECTRONIC POUR VOTRE SÉCURITÉ, LISEZ CES INSTRUCTIONS AVANT L’ALLUMAGE AVERTISSEMENT: SI VOUS NE SUIVEZ PAS CES INSTRUCTIONS À LA LETTRE, IL POURRAIT S’EN SUIVRE UN INCENDIE OU UNE EXPLOSION CAUSANT DES DOMMAGES MATÉRIELS, DES BLESSURES CORPORELLES OU MÊME DES PERTES DE VIE. A.
-
Page 26: Troubleshooting Guide - Millivolt
Order Parts at: PartsFor.com or 866-607-2787 TROUBLESHOOTING THE MILLIVOLT GAS CONTROL SYSTEM Note: Before troubleshooting the gas control system, be sure external gas shut off valve (located at gas supply inlet) is in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION... -
Page 27: Troubleshooting Guide - Electronic
Order Parts at: PartsFor.com or 866-607-2787 TROUBLESHOOTING THE ELECTRONIC IGNITION SYSTEM ote: Before troubleshooting, be sure that the appliance main line gas shut-off valve, the gas control valve and the wall switch are in the “ON” position. Important: Valve system troubleshooting should only be accomplished by a qualified service technician. SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION... -
Page 28: Replacement Parts List
Description Natural Gas Propane Gas Part No. Qty. Part No. Qty. Contact an Authorized Lennox Hearth Products dealer to obtain any of Gas Valve, SIT 43K07 88J53 these parts. Never use substitute materials. Use of non-approved parts Piezo Igniter 10K86 10K86 can result in poor performance and safety hazards. - Page 29 Order Parts at: PartsFor.com or 866-607-2787 REPLACEMENT PARTS EDV3530 EDV4035 & EDV4540 NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. Order Parts at: PartsFor.com or 866-607-2787...
- Page 30 Order Parts at: PartsFor.com or 866-607-2787 NOTE: THIS PAGE INTENTIONALLY LEFT BLANK NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. Order Parts at: PartsFor.com or 866-607-2787...
- Page 31 Order Parts at: PartsFor.com or 866-607-2787 NOTE: THIS PAGE INTENTIONALLY LEFT BLANK NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. Order Parts at: PartsFor.com or 866-607-2787...
- Page 32 Order Parts at: PartsFor.com or 866-607-2787 Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
