Summary of Contents for Clarion EA-2182E
- Page 1 Owner s manual & Installation manual Mode d emploi et manuel d installation Manual de instrucciones y manual de instalación Manuale dell utente e manuale di installazione Bedienungsanleitung und Installationshandbuch Bruksanvisning och installationsmanual EA-2182E EA-2182E...
-
Page 2: Table Of Contents
CONTENTS １． SAFETY INSTRUCTIONS ....................... 4 ２． BEFORE USE ............................. 6 ３． FEATURES ............................7 ４． CONTENTS ............................7 ５． FUNCTION OF EACH PART ....................8 ６． FUNCTION ........................... 10 [1] Power On/Stand-by ......................10 [2] Volume control ........................10 [3] Switch input video ..................... -
Page 3: １． Safety Instructions
SAFETY INSTRUCTIONS Please read the Safety Rules carefully before using this product. Following the safety rules pre- vents users from damages related with the misuse of the product. It is very important to follow these safety rules. We state Caution and Warning to clarify any potential risk of damage as- sociated with the misuse of the product. - Page 4 CAUTION ● Disconnect battery before installation. Re-connect once installation is complete. Prevents electric shock or short circuit. ● Do not use for long periods without engine running. It may cause battery to go fl at. ● The rear-view monitor image has the same right-left inversion as your vehicle s rearview mirrors.
-
Page 5: ２. Before Use
２. BEFORE USE Precautions (when you use the monitor) ● Use the product at the temperature range of -10° C 60° C. ● Screen may be a little dark when the product is operated in low temperature areas. Screen will show normal luminosity after a few minutes. -
Page 6: ３. Features
３. FEATURES ◆ DC 12V/24V ◆ 7 language display Selection ◆ Camera input (4 systems), camera linkage 1 - 4 ◆ User can choose split screen ( 2/3/4 Split screen) ◆ Camera input screen inversion (Normal / Mirror mode) ◆ A/V input (Video / Mono Audio) ◆... -
Page 7: ５. Function Of Each Part
５. FUNCTION OF EACH PART [Connection terminal] ③ ⑤ ① ② ④ ⑥ ① External remote control input Operations can be carried out remotely by connecting an external terminal remote control receiver sold separately. ② Camera input terminal Camera 1 - 4 input terminals ③... - Page 8 [Remote Controller(Separately sold products)] ② ① ⑤ ③ ⑥ ④ ⑧ ⑦ ⑨ ⑩ ⑫ ⑪ ① POWER POWER ON/STAND-BY ② AV Switch AUX ③ OK／ Confi rm button ▶ ④ Return button ◀ ⑤ Switch camera inputs / Set SUB-MENU ▲▼...
-
Page 9: ６. Function
６. FUNCTION Power On/Stand-by ① Press POWER 「 」 button on monitor then the picture of the camera will be shown on the monitor. ※ 「 」 Lamp is used when connected to the CJ-7600 monitor. CJ-7600 connection Volume control (CJ-7600 connection) ①... - Page 10 2) Sprit screen switching ① Press the ENT(VOL) button (OK or ▶ button on the remote control) to switch between full screen, 2-split, 3-split or 4-split screen display. ※ User can choose split screen directly with split button on remote control. CJ-7600 connection 2Split screen 3Split screen...
-
Page 11: ７ ． Settings
７ . SETTINGS ※ When CJ-7600 is connected, changes in the settings can be made on the monitor side. ※ When an external monitor is connected, connect an external remote control receiver (sold separately) to enable changes to be made to the settings with the remote control (sold separately). Common buttons when changing settings ①... - Page 12 General 1) Volume control (Applicable only when CJ-7600 is connected) ① Select Volume in the General menu and press the ENT(VOL) button (OK or ▶ button on the remote control). ② Press the ▲／▼ buttons to adjust the volume. ※ The volume can be adjusted between 0 and 15. The initial setting is 5. General General Volume...
- Page 13 4) Video signal when split screen Full screen(AV1/AV2): Automatically selected NTSC or PAL. Split screen: Select manually. ① Select Video signal in the General menu with the ▲／▼ buttons and press the ENT(VOL) button (OK or ▶ button on the remote control). ②...
- Page 14 Color tone (Display only when CJ-7600 is connected) ① Select Brightness , Tone , Vividness and Dimmer in the Color tone menu with the ▲／▼ buttons and press the ENT(VOL) button (OK or ▶ button on the remote control). Press the ▲／▼ buttons to adjust the Brightness , Tone and Vividness .
- Page 15 In such cases, the display location should be set at the closest marker No. - Distance markers cannot be set if non Clarion cameras are used. Caution - The markers may not indicate the exact position of the bumper, the vehicle s width or the distance to the rear.
- Page 16 3) Marker type (set the marker pattern) ① Select Marker type in the Marker menu and press the ENT(VOL) button(OK or ▶ button on the remote control). ② Select Type 1 to Type 7 with the ▲／▼ buttons and press the ENT(VOL) button(OK or ▶ button on the remote control).
- Page 17 4) Up/down, Left/Right adjustment (adjust the bumper position of the car) ① Select Up/down in the Marker menu and press the ENT(VOL) button (OK or ▶ button on the remote control). ② Adjust the V (vertical movement) value with the ▲／▼ buttons (▲: Up, ▼: Down) and press the ENT(VOL) button (OK or ▶...
- Page 18 Split type ① Select the 2 - 4 Screen in the Split type menu with the ▲／▼ buttons and press the ENT(VOL) button (OK or ▶ button on the remote control). ② Select the image layout with the ▲／▼ buttons, and press the ENT(VOL) button (OK or ▶ button on the remote control) to set the screen display when split.
- Page 19 Sound The audio output in the 2 - 4 split screen display can be specified. (when a camera with a built-in micro- phone is connected, and when AV2 audio input is selected) 1) When an CJ-7600 monitor is connected Select the audio of the Camera 1 - 4 that you wish to output in the split screen or AV2 with the ▲／▼ buttons in the Sound menu and press the ENT(VOL) button (OK or ▶...
- Page 20 Camera linkage 1) The camera image to be displayed can be set in the Link (TRIGGER terminal) 1 - 4. ① Select Link 1 - 4 or Link 2+3 with the ▲／▼ buttons in the Camera linkage menu, and press the ENT(VOL) button (OK or ▶...
- Page 21 ③ When there is an input signal from more than 2 TRIGGER(Links), the camera image corresponding to this is displayed.If the signal is terminated, the display returns to the previous screen. Signal priority order ： TRIGGER(Link) 1 > TRIGGER(Link) 2 > TRIGGER(Link) 3 > TRIGGER(Link) 4 >...
-
Page 22: ８. Connections
Blue (TRIGGER 2): Camera4 Connect to the + terminal of the winker lamp ※１ Use Clarion Cameras only. White (TRIGGER 3): ※２ A camera connecting cable, sold Connect to the + terminal of the winker lamp separately, is required for connecting Gray (TRIGGER 4): Connect to the + terminal of the the camera. -
Page 23: ９. Troubleshooting
９. TROUBLESHOOTING Problem Cause Measure No image is displayed. Is camera connected Check the wiring to the camera and the camera properly? connection. Power does not turn on. Is power cable connected Check the wiring. properly? Is a fuse blown out? Replace with a fuse of the same amperage (5A) Color is washed-out. - Page 24 Clarion Co., Ltd. All Rights Reserved. Copyright © 2014: Clarion Co., Ltd. Printed in Korea / Gedruckt in Korea / Stampato nella Corea del Sud / Imprimé en Corée / Impreso en Corea / Tryckt i Korea 2014/11 EA-2182E...
