IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to service this
fireplace. For your safety, always comply with all warnings and safety instructions contained in this
manual to prevent personal injury or property damage.
Dimplex North America Limited
1367 Industrial Road Cambridge ON Canada N1R 7G8
1-888-346-7539 www.dimplex.com
In keeping with our policy of continuous product development, we reserve the right to make changes without notice.
© 2012 Dimplex North America Limited
Service Manual
Mini Brockton
Model Number:
CFP4949BW
UL Part Number
6903570300
REV
PCN
DATE
00
-
20-JAN-12
7400550000R00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFP4949BW and is the answer not in the manual?

Questions and answers

Summary of Contents for Dimplex CFP4949BW

  • Page 1 Dimplex North America Limited 20-JAN-12 1367 Industrial Road Cambridge ON Canada N1R 7G8 1-888-346-7539 www.dimplex.com In keeping with our policy of continuous product development, we reserve the right to make changes without notice. © 2012 Dimplex North America Limited 7400550000R00...
  • Page 2: Table Of Contents

    NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNINg: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com...
  • Page 3: Operation

    Close the battery cover CAUTION: If you need to continuously reset the heater, disconnect power and call Dimplex customer service at Battery must be recycled or disposed of properly. Check with your Local Authority or Retailer for 1-888-DIMPLEX (1-888-346-7539).
  • Page 4: Maintenance

    To remove any accumulation of dust or fluff, the soft brush attachment of a vacuum cleaner should occasionally be used to clean the outlet grill of the fan heater. Screws to remove: 3 per side and 3 along top edge www.dimplex.com...
  • Page 5: Exploded Parts Diagram

    EXPLODED PARTS DIAgRAM Replacement Parts List POWER CORD ....4100090104RP HEATER ASSEMBLY ....2200491200RP FLICKER MOTOR .
  • Page 6: Wiring Diagram

    WIRINg DIAgRAM www.dimplex.com...
  • Page 7: Flicker Rod/Motor Replacement

    FLICKER ROD/MOTOR REPLACEMENT NOTE: When removing the Flicker Rod, damage may occur if bent excessively or handled improperly. Ensure that Tools Required: Phillips head Screwdriver the Flicker Rod is straight and not crushed before reinstall- WARNINg: If the fireplace was operating prior to ing.
  • Page 8: Heater Assembly Replacement

    Depress the retainer clips on the rear of the switch and push the switch out of the heater housing. Properly orient the new switch and reconnect all of the wiring clips and connections. Reassemble in the reverse order as above www.dimplex.com...
  • Page 9: Power Cord Replacement

    REMOTE CONTROL RECEIVER bly to the housing. This will allow you to remove the heater assembly out of the housing so that you can REPLACEMENT access the switches inside. (Figure 6) Tools Required: Phillips head Screwdriver Disconnect wiring connections and connect to replace- Slip Joint Pliers ment heater assembly noting their original locations.
  • Page 10: Troubleshooting Guide

    Flame not bright or flame not Burnt light bulbs Replace light bulbs visible Loose wiring Check wiring connections Defective light harness Replace light harness Log set dim, not glowing Burnt light bulbs Replace light bulbs Flame Shutter Defective flicker motor Replace flicker motor www.dimplex.com...
  • Page 11 Light leaking around the log set Log set not positioned properly Check log set for proper fit PROBLEM CAUSE SOLUTION Heater Heater is not turning off Improper operation Refer to Operation Section Defective Heater Switch Replace Heater Switch Defective Remote Control Receiver Replace Remote Control Receiver Defective Heater Assembly Replace Heater Assembly...
