Dimplex Mozart CFP3811 Service Manual

Mozart fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Service Manual
Mozart Fireplace
Model Numbers:
CFP3811
Dimplex North America Limited
1367 Industrial Road
Cambridge ON Canada N1R 7G8
1-888-346-7539
www.dimplex.com
In keeping with our policy of continuous product development, we reserve the right to make changes without notice.
REV
PCN
DATE
00
11600
Aug 31, 09
7400240000rev00

Advertisement

Table of Contents
loading

Related Manuals for Dimplex Mozart CFP3811

Summary of Contents for Dimplex Mozart CFP3811

  • Page 1 Model Numbers: CFP3811 DATE 11600 Aug 31, 09 Dimplex North America Limited 1367 Industrial Road Cambridge ON Canada N1R 7G8 1-888-346-7539 www.dimplex.com In keeping with our policy of continuous product development, we reserve the right to make changes without notice.

  • Page 2: Table Of Contents

    Table Of Contents Operation ........... . . Page 3 Exploded Parts Diagram and Parts List.

  • Page 3: Operation

    OFF and waiting five (5) minutes before switching the unit back on. Figure 1 Control Panel CAUTION: If you need to continuously reset the heater, unplug the unit and call Dimplex North America Limited at 1-888-346-7539 for technical support. Manual Control Switches A - Main On/Off Switch Controls the electricity supply to the heater and flame effect.

  • Page 4: Exploded Parts Diagram And Parts List

    Exploded Parts Diagram Replacement Parts List CFP3811 Part Number 6903640100 Replacement Part: 1. Log set 0439290100RP 8. High Heat Switch (II) 2800071000RP 2. Flicker Motor 2000210100RP 9. Terminal Block 4000080100RP 3. Reflector Assembly (Flicker Rod) 5900990100RP 10. Cord Set 4100090103RP 4.

  • Page 5: Wiring Diagram

    Wiring Diagram...

  • Page 6: Light Bulb Replacement

    Light Bulb Replacement Mirror Replacement Allow at least five (5) minutes for light bulbs to cool before If the fireplace was operating prior to servicing allow at least touching bulbs to avoid accidental burning of skin. five (5) minutes for light bulbs and heating element to cool off to avoid accidental burning of skin.
  • Page 7 iii) Carefully turn the fireplace onto its front and remove: Trim Figure 5 two (2) Phillips screws from along the top edge of the rear of the fireplace; and three (3) Phillips screws from each side edge of the rear of the fireplace (8 in total) (Figure 8).

  • Page 8: Switch Replacement

    into place. 6. Remove the three (3) sided Cover: From the bottom of the fireplace, remove the four (4) 10. Re-assemble fireplace in reverse order as above. Phillips screws as shown in Figure 6 (Page 7). NOTE: When installing the Cover back onto the chassis: ii) From the front of the fireplace, remove six (6) Phillips place the bottom flap of the Cover on the top surface of screws as shown in Figure 7 (Page 7).

  • Page 9: Flicker Motor/Flicker Rod Replacement

    Flicker Motor/Flicker Rod Replacement Figure 12 If the fireplace was operating prior to servicing allow at least five (5) minutes for light bulbs and heating element to cool off to avoid accidental burning of skin. Flicker Rod Support Disconnect power before attempting any maintenance or Bracket Assembly cleaning to reduce the risk of electric shock or damage to persons.
  • Page 10 12. Remove three (3) Phillips screws from each side of the 16. With the Flicker Motor and Terminal Block exposed, fireplace (refer to Figure 12, Page 9). This will allow the use side cutters to cut any zip ties that bind the wires Flicker Rod Support Bracket Assembly to be removed, connecting the Flicker Motor with the Terminal Block.

  • Page 11: Heater Assembly/Cutout Replacement

    Replacement Procedure NOTE: Ensure that both rubber spacers are retained (one (1) from between the Flicker Motor and bracket and 1. Pull fireplace away from the wall far enough to access one (1) from between bracket and chassis) as they will be the back of the unit.
  • Page 12 Phillips screws from the bottom panel as shown in Cutout Replacement Figure 19. Using a small flat head screwdriver, backup the screw that clamps down on the two (2) blue wires in the Terminal Block of the Bottom Panel and release them Figure 19 (Figure 19).

  • Page 13: Power Cord Replacement

    iii) Referring to Figure 21, remove the four (4) screws the back of the unit. indicated to release the Heater Assembly from the 2. Remove two (2) Phillips screws from each of the four (4) chassis. brackets which attach the fireplace to the mantel (Figure 3, Page 6).
