TurboChef Tornado Daily Maintenance

Daily Maintenance for the Tornado

Supplies and Equipment
TurboChef Oven Cleaner (any other cleaner can damage critical parts and void warranty), TurboChef Oven Guard, nylon scrub pad, clean towels, soft-bristle cleaning brush.
Optional - protective eyeware and dust mask.
Step 1: Prepare Oven
1a
1a. Turn off the oven by pressing the "Back" key while in
the main menu.
DO NOT
to Clean."
1b. Oven will display "Oven Off-Cooling Down."
1b
Warning
Oven operates at approximately 500ºF (260ºC). To
avoid injury, allow approximately
2 Step 2: Remove Lower Access Panel and Wipe out
Crumbs with Damp Cloth
The Lower Access Panel is attached to the oven via four
clips. To remove it, grab it on each end and GENTLY tug
one side, then the other. Repeat until panel comes off.
Step 3: Remove Rack (and Stone if Present)
3
Remove the wire rack and wash, rinse, sanitize, and air-dry.
DO NOT
DO NOT
GENTLY scrub the stone with a dry nylon scrub pad to remove
food particles (Refer to "Cook Stone Cleaning Tips" below).
4 Step 4: Lift Bottom Element
DO NOT
Wipe debris from the bottom of the oven cavity.
Step 5: Clean Oven Interior
5a
5a. Spray Oven Cleaner on clean damp towel. For stubborn stains,
saturate towel or scrub pad with cleaner, and sparingly spray
cleaner on the stain, allowing it to penetrate for five minutes.
NEVER
DO NOT
IR element/nozzles.
5b
5b. Wipe oven interior. After allowing cleaner to penetrate for five
minutes on stubborn stains, wipe the stains.
NEVER
Cleaner. If it accidentally gets saturated, ensure all water is
removed and it is dry before turning on the oven.
Warning
5c
Be careful when wiping inside of oven due to sharp edges.
5c.
will result in a non-warranty service call.
NOTE: Wave Guide Covers will not return to original color
when clean. They will retain stains.
DO:
Clean the oven during off-peak periods.
Ensure the oven is cleaned daily.
Use only TurboChef Oven Cleaner.
Use only microwave-safe TurboChef approved
cooking accessories in the oven.
Review cooking instructions to ensure oven
settings are correct for corresponding products.
Call Customer Service (800.90TURBO) or your
Authorized Distributor immediately if Wave Guide
Covers are broken.
Discard used towels once cleaning is completed.
Part Number: NGC-1226/Revision C/June 2008
begin cleaning oven until display reads "Ready
90 minutes to
wash Cook Stone (water and pressure can break it).
use Oven Cleaner or Guard to clean Cook Stone.
use Oven Cleaner on the bottom element.
use soap when cleaning the oven.
spray Oven Cleaner directly into oven or wipe on
saturate the bottom of the oven with water or Oven
DO NOT apply pressure to the Wave Guide Covers. Breaking
DO NOT:
DO NOT lift the oven by the door handle.
DO NOT slam or mishandle the oven door.
DO NOT place foil/metal objects of any kind in oven.
DO NOT operate without food in the cook chamber.
DO NOT frequently open/close door to check product.
DO NOT use unapproved cleaning agents.
DO NOT allow cleaning solution or water to remain
on the bottom of the cook chamber.
DO NOT use abrasive sponges or scrub pads to clean
or wipe inside/outside of oven.
8 0 0 . 9 0 T U R B O
+ 1 2 1 4 . 3 7 9 . 6 0 0 0
6
7
cool.
8
9a
9b
9c
10
11
PLEASE WAIT
WARMING UP
CC 74 F IR 106 F
COOK STONE CLEANING TIPS:
If your oven includes a cook stone, GENTLY scrub with a dry nylon scrub
pad to remove food particles.
Accelerating the World of Cooking TM
TM
Step 6: Clean Inside of Oven Door
Saturate clean towel with Oven Cleaner and clean the
inside of the oven door.
For stubborn stains, saturate towel or scrub pad with
cleaner, and sparingly spray cleaner on the stain,
allowing it to penetrate the stain for five minutes.
Step 7: Clean Lower Access Panel and Bottom of Oven Door
DO NOT spray chemicals in this area.
Using a damp cloth, wipe this surface area.
Step 8: Apply Oven Guard to Oven Interior
Saturate towel with Oven Guard. Wipe top, bottom, and
sides of interior and door.
DO NOT spray Oven Guard directly into oven or wipe on
IR element/nozzles.
Step 9: Clean Oven Exterior
9a. Using a clean, damp towel, wipe the oven door and any
panels, if necessary.
9b. DO NOT spray chemicals into or around any opening,
such as the louvers on the side panels, or the cooling
fan/vent tube openings on the back of the oven. Doing
so will damage critical oven components.
9c. Using a dry soft-bristle cleaning brush, clean the area
behind the cooling fan cover on the back of the oven.
DO NOT spray cleaner in this area.
Step 10: Lower Bottom Element and Reset Rack, Stone,
and Lower Access Panel
Be sure to orient the rack as shown in Figure 10.
The metal slot in the center of the rack should face the front.
Ensure all four clips on Lower Access Panel are engaged and
panel is flush with bottom of door.
Step 11: Turn on the Oven
Turn on the oven and allow approximately 20 minutes for it to
warm to temperature.
Warning
Scrubbing too vigorously can cause the cook stone to crack and break.
DO NOT immerse the cook stone in water. If it is immersed by
accident, allow it time to thoroughly air-dry before using; otherwise it
may crack.
Notes
To prolong the life of the cook stone, use the provided tray or tray
liner when cooking on the stone. Replace the stone carefully and with
shiny, smooth side facing up.
